U43WIH400BCommercial Induction Range

Continental Conair Limited
Commercial Induction Range - FCC ID U43WIH400B - Continental Conair Limited
Click to zoom

Application Details

Equipment Class
8CC - Part 18 Consumer Device
Date of Grant
Sep 16, 2014
Application Purpose
Original Equipment
Date of Application
Sep 16, 2014
Equipment Note
Commercial Induction Range
Frequency Range
0.02800000 - 0.02800000
Company
Continental Conair Limited
Country
Hong Kong

Documents & Files

Select a file to view

Users Manual

↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Parts List/Tune Up Info

↗
↗

Schematics

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

COMMERCIAL INDUCTION RANGE WIH400B INSTRUCTION MANUAL I IMPORTANT SAFEGUARDS When using electrical appliances, basic safety precautions should always be followed including the following: Read all instructions. 1. Do not touch hot surfaces. Use handles or knobs. 2. To protect against electrical shock do not immerse cord, plugs, or appliance in water or other liquid. 3. Close supervision is necessary when the appliance is used by or near children. 4. Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts. 5. Do not operate the appliance with a damaged cord or plug or after the appliance malfunctions or has been damaged in any manner. Return appliance to the nearest authorized service facility for examination, repair, or adjustment. 6. The use of accessory attachments not recommended by the appliance manufacturer may cause injuries. 7. Do not use outdoors. 8. Do not let cord hang over edge of table or counter, or touch hot surfaces. 9. Do not place on or near a hot gas or electric burner, or in a heated oven. 10. To disconnect, turn any control to off, then remove plug from wall outlet. 11. Do not use appliance for other than intended use. 12. Do not immerse in water. 13. Do Not Cook on Broken Cook-Top -If cook-top should break, cleaning solutions and spillovers may penetrate the broken cook-top and create a risk of electric shock. 14. Clean Cook-Top with Caution - If a wet sponge or cloth is used to wipe spills on a hot cooking area, be careful to avoid steam burn, some cleaners can produce noxious fumes if applied to a hot surface. 15. Caution - To ensure continued protection against risk of electric shock, connect to properly grounded outlets only. 16. Do not heat the pot empty or overheat it. 17. Do not place metallic objects such as knives, forks, spoons, lids, cans and aluminum foils on the top plate. 18. Allow sufficient space around the cooking area. 19. Never use the unit on low-heat-resistant materials (carpet, vinyl). 20. Do not place a sheet of paper between the pot or the pan and the unit. The paper may get burnt. 21. Be aware that the unit surface will remain hot for a short period of time. 22. Items with a magnetic field, such as: radios, televisions, automatic-banking cards and cassette tapes, can affect the unit. 23. The appliance must be connected to a branch circuit with an all-poles disconnection circuit-breaker rated 20 A. 24. There are potential interference when it is working. So please keep the device at a distance with people and some items, such as radios, televisions, automatic-banking cards and cassette tapes. This device complies with Part 18 of the FCC Rules. SAVE THESE INSTRUCTIONS Power Cord:  A short power-supply cord is to be provided to reduce the risk resulting from becoming entangled in or tripping over a longer cord.  Extension cord is available and may be used if care is exercised in their use.  If an extension cords power-supply cord is used, 1) The extension cord should be a grounding-type 3-wire cord, the marked electrical rating of the extension cord should be at least as great as the electrical rating of the appliance, and 2) The cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over unintentionally. IISPECIFICATION:  Model No.: WIH400B  Power Rate: 2900/3300 W  Voltage: 208V/240V~60 Hz  Temperature:120°F-500°F III HOW TO USE 1. Before turning on the power, make sure the cookware is on the ceramic plate with ingredients inside. 2. To turn the power on, press the ON/OFF button. Heating will begin. Notice: When there is no suitable cookware or no cookware on the glass, the LCD-display will show “-----“ and “standby” will flash. 3. To select the proper heat setting, press the REDUCE or INCREASE until the correct heat setting is achieved.(defaults=1700W under 240V, defaults=1600W under 208V). LCD will show appropriate setting in watts. 4. To select temperature setting, press the” TEMP” button (defaults=180°F). LCD display will show ‘Temp’ to indicate temp mode function and ‘180°F.Press the REDUCE or INCREASE until the correct temperature setting is achieved. Notice: The TEMP unit can be changed to °C. After plugging the plug into the socket, pressing TEMP key and hold on 3 seconds, °C or °F will flash when choosing, pressing TEMP key again to lock the TEMP unit. The default of Celsius degree is 80°C. ‘Timer’ and 0:00 to be displayed in all operation modes. To set timer, pressing TIMER and adjusting by REDUCE or INCREASE key. Time 0:00 to flash as the time is being set. Turn to steady lit once countdown starts. When it reach the setting time, the display will read “O” with four beeping sounds. The unit will not stop. 5. After cooking is completed, press the ON/OFF button again to turn off the unit. 6. The timer runs for 9:59 hours per use. If the cooktop has been operating for more than an hour and you set the timer for 9:59 hours (for a total cooking time of more than 9:59 hours), the timer function will be shortened. After the cooking time reach the maximum 9:59 hours, the display will read “OFF” around 30 seconds and then the cooktop will turn itself off with a beeping sound. Notice: If using the unit in TEMP or HEAT Function, not setting the TIMER Function, when the unit is used 9:59 hours, the LCD display shows ‘’OFF’’ around 30 seconds and then the unit will stop with a beeping sound. If using the unit in TEMP or HEAT Function for an hour, and then set the TIMER, the max Timer is 9:59 hours. But the cooking time will be less than 9:59 hours. During timer operation, you can change the duration at any time with the arrow keys. NOTE: The power will completely shut off with 60 second if either (a) the wrong type of cookware is applied or (b) no cookware is placed on the unit. IV USABLE AND NON-USABLE UTENSILS:  Compatible Pans: Steel or cast iron, enameled iron, stainless steel, flat-bottom pan/pots with diamet…

Text truncated - open the document above for the full version.

External Photos

EXHIBIT B - EUT EXTERNAL PHOTOGRAPH EUT - Front View EUT - Rear View EUT – Top View EUT - Bottom View EUT – Left View EUT – Right View

ID Label/Location Info

EXHIBIT A - FCC ID LABEL AND LOCATION FCC ID Label FCC ID Label Location Specifications : Text is Black or white in color and is left justified. Labels are printed in indelible ink on permanent adhesive backing or silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Label Here

Internal Photos

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS EUT – Cover off View 1 EUT – Cover off View 2 EUT – Cover off View 3 EUT – Main Board off Top View EUT – Main Board off Bottom View EUT – Uncovered Main Board 2 Top View EUT – Uncovered Main Board 2 Bottom View EUT – Covered Main Board 2 Top View EUT – Covered Main Board 2 Bottom View EUT – Coil Top View EUT – Coil Bottom View EUT – Fan Top View EUT – Fan Bottom View

Parts List/Tune Up Info

Unit Bill of Material Model No.: __WIH400B__ Product Name: _Commercial Induc tion Range Rating: _208V/240V ~60Hz ~2900W/3300W ___ Version: _USA Edition: ___A_____ Revised Date: ____2014-7-29______ Page __1_ of _2__ Item No. Part Name Qty Material / Model No. / Rating Color Manufacturer Approval & File No. 1 Schott plate 1 274x274 SCHOTT NR 2 Upper enclosure 1 Stainless steel Yu An metal products Co. NR 3 Sensor 1 MJD-103-3365-5 SHANGHAI MINJIE ELECTRONICS CO LTD E313459 fuse 1 RYD226E 250V 10A 227 °C NEC SCHOTT COMPONENTS CORP NR 4 Induction winding plate 1 40*23, 40 circles, 23 conductors Yalesi Electric Co., Ltd. NR 5 Main Pcb 1 SZ-L5 Yalesi Electric Co., Ltd. NR 6 Plastic bracket 1 FR8-6 PP Polyone Suzhou China UL E219003 7 Power cord 1 SJTO , 14AWGx3C,1.2m exposed KuaI hua Electric Appliance Co., Ltd. E254458 Plug 1 Kh-9947 KuaI hua Electric Appliance Co., Ltd. E254267 Cord Bushing 1 Pvc/series Fp Foshan Fangpu pvc Dipping Co Ltd YDTU2 E185679 8 Lower enclosure 1 Aluminium plate Yu An metal products Co. NR 9 Nut 1 Stainless steel Yu An metal products Co. NR 10 Coppery screw 1 Stainless Steel Yu An metal products Co NR 11 Adjustable rubber feets 1 Rubber Zhongchao plastic NR 12 Nut 3 Stainless steel Yu An metal products Co NR 13 Spring 1 Stainless steel Yu An metal products Co NR 14 Ring 1 Stainless steel Yu An metal products Co NR 15 Rubber Feet 1 Rubber Zhongchao plastic NR 16 Crew 1 Stainless steel Yu An metal products Co NR 17 Fan 1 YHWF-110 , DC 18V 0.17A SHENZHEN TIANXING FCC RSZ04100851 BRUSHLESS MOTOR MAKING CO., LTD. FAN BLADE 1 PBT-RG301(E171666) KINGFA SCI&TECH CO LTD QMFZ2.E171666 BRACKET 1 PBT-RG301(E171666) KINGFA SCI&TECH CO LTD QMFZ2.E171666 18 Control Panel 1 PC/FR65 SABIC INNOVATIVE PLASTICS US L L C E121562 19 Transparent Plastic 1 PC/PC-1870B MIANYANG LONGHUA FILM CO LTD E254551 20 Control PCB 1 L5-L7B Yalesi Electric Co., Ltd. NR Remark: (1) Item No. & Part Name on BOM must be matc hing with Item No. & Part Name on Assy Dwg. (2) BOM should show each leadwire’s spec. and usage (connection between one end to another end). (3) Metal parts should be also shown its raw material thickness or diameter.

Parts List/Tune Up Info

PCBA Bill of Material Model No.: __ WIH400B__ Product Name: _Commerc ial Induction Range Rating: __ 208V/240V~60Hz ~2900W/3300W ______ Version: __ USA ____ Edition: ___A___ Revised Date: _2014-7-29_ Page _1__ of _4__ Item No. Part Name Description / Model No. / Rating Des ignation Qty Manufacturer Approval & File No. 1 jumper 7.5mm J1,J3,J8,J9,J11-J18 12 Shunde weiguofa electric Co.,Ltd. 15.2mm J2 1 20mm J10 1 10mm J4-J7 4 2 resistor 1/4W 20K R16 1 Shenzhen jinghe Electronics CO.LTD 1/4W 7K5 R15 1 1/4W 3K R34 1 1/4W 2K5 R33 1 1/4W 22K Ω R19 1 1/4W 3K R32 1 1/4W 30K R25,R27 2 1/4W 120 Ω R17 1 1/4W 10K R21,R23 2 1/4W 1K R3,R4,R18 3 1/4W 4K7 R22,R30 2 1/4W 68K R31 1 1/4W 820 Ω R11 1 1/4W 47 Ω R24,R26 2 1W 22 Ω R12 1 1W 270K R7,R2 2 1W 820K R13,R14 2 1W 470K R5,R6,R9,R10 4 3 diode UF4007 D8,D4 2 Tritech semiconductor co.,ltd IN4007 D2,D3,D5,D6,D11, D12 6 BYV26C D1 1 4 diode 18V Z1 1 Tritech semiconductor co.,ltd 5 Transistor 2N3906 Q4 1 Tritech semiconductor co.,ltd SS8050 Q1,Q3,Q5,Q6,Q7 5 6 PCB CEM-1 SZ-L5(CEM-1) 267.4x152.8mm REV:12.12.13 1 Zhaoyuan Jinbao Electronics Co., Ltd QMTS2 E141940 7 ceramic capacitor 3A332J C9 1 DONGGUAN KEHONG ELECTRONICS CO.,LTD 8 ceramic capacitor 472/400VDC CY1,CY2 2 DONGGUAN KEHONG ELECTRONICS CO.,LTD relay 10A-250VAC SJ-S-118DMH RL1 1 Dongguan Sanyou. 9 Electroanalysis capacitor 1uF/50V C8 1 DONGGUAN KEHONG ELECTRONICS CO.,LTD 10uF/450V C10 1 1000uF/25V C15 1 10uF/50V C28 1 100uF/25V C14,C18,C22 3 10 X2 capacitor 10uF/275ACV C4D5 1 Foshan Shunde Chuang Ge Electronic Industrial.CO Ltd FOKY2.E318999 4uF/275ACV C4D1,C4D2,C4D3,C4D6 4 11 HV capacitor 0.43UF/120VAC C31 1 Foshan Shunde Chuang Ge Electronic Industrial Co Ltd NR 12 buzzer PT1470 BZ1 1 Changzhou tongda-wk.Electronic.,ltd 13 IC 78L05 U3,U6 5 stmicroelectronics vip22A U1 1 14 copper resistor 1.5X20mm RJ1,RJ2 2 Zhongshan dongfeng eycom electric Appliance factory 15 transformer EE10 T2 1 Details please refer to Illustration NR 16 quick connect brass tabs 6.3mm L,N,GND 3 Guangdong zhongnan Electronics& Electric co.,ltd 17 Quick connect connectors LIN LOUT 4 feet LIN ,LOUT 2 Foshan shunde ningbang Electronic.,ltd 18 4 pin jack TJC3-4A CON3 1 Bubujing electronics co.,ltd 19 adjustable resistor 501 VR1 1 Shenzhen kailifeng hadeware&electronic.co.ltd 20 2 pin jack TJC3-2A FAN,FAN1 2 Bubujing electronics co. 21 3 pin jack TJC3-3A HITE CN1 2 22 fuse ROHS RTI-30 15A250VC(UL/JET) F1 1 Zhongshan Lanbao Electrical Appliances CO.LTD JDYX2 E213695 23 Bridge rectifier HD25SB80 BG1 1 LESHAN RADIO CO LTD QQQX2 E231047 LESHAN SHARE ELECTRONIC CO LTD QQQX2 E249161 24 inductor 铜 450uH 2 脚立式直径 1.4(脚长 4 ±0.5 脚距 16±0.5) L1 1 Zhongshan Meiya Electronic Co., Ltd 25 inductor 2mH 4 脚立式直径 1.5(短脚) L2 1 Zhongshan Meiya Electronic Co., Ltd 26 NTC resistor MJD-103-3365-5 R-NTC 1 Shanghai Minjie electronics Co.,Ltd E313459 27 IGBT H20R1353 IGBT2,IGBT3 2 Infineon technologies NR 28 CPU HT45R0MB U102 1 Holtek semiconductor Limited by Share Ltd 29 overheat protector 40%硬度±1%(线长 150mm 红 色)15.5 高朱红色硅胶头+温度保险丝(RYD227)(线长 150MM 针插蓝色) CN1 1 China's science and technology 30 PCB SZ-L5 REV:2012.06.26 1 Zhaoyuan Jinbao Electronics Co., Ltd QMTS2 E141940 LCD Control Panel 1 LCD YXM1179A LCD1 1 ShenZhen Sunfly Technology CO.,LTD 2 rear projector YXM1179A-BL LCD1 1 ShenZhen Sunfly Technology CO.,LTD 3 porcelain capacitor ROHS 104Z/50V C1 1 DONGGUAN KEHONG ELECTRONICS CO.,LTD 4 Electroanalysis capacitor 470UF/10V EC1 1 DONGGUAN KEHONG ELECTRONICS CO.,LTD 5 sensitive switch 12×12 K-K6 10 Bubujing electronics co.,ltd 6 IC HT16K23 U2 1 Holtek semiconductor Limited by Share Ltd 7 CPU L8B-F,GRD-16 U1 1 Holtek semiconductor Limited by Share Ltd 8 4 pins wiring 4P-220mm CON1 1 guangdong xinlong enterprise Co. 9 Transistor S8050 Q1 1 Tritech semiconductor co.,ltd 10 resistor 47Ω R2 2 Foshan li an electric Co.,Ltd. 4.7KΩ R8,R10,R5,R6 4 100KΩ R1,R3,R4,R7,R9,R11 6 11 PCB L5-L7B 166X55 REV:13.09.20 1 Zhaoyuan Jinbao Electronics Co., Ltd QMTS2 E141940 Remark: (1) The Designation on BOM must be matc hing with Designation on PCBA Layout.

Schematics

1 2 3 4 56 ABCD 6 5 4 3 2 1 D CBA Titl e Number Revision Size B Date: 14-Jul-2014 Sheet of 1 2 C3 1 0.24UF/2000VDC IBGT1 H2 0R1 3 53 R26 47R R2 730K R14 2.5K* 12 N L1 450uH 12 L C4D2 4uF/400DC Fus e 1 5AH/ 25 0 VAC BZ1 4K D2 1N4007 C2 7471 C2 9 104 R2 83K +5V JR1 C2 4 104 R1 4820K 1W R1 57.5K* C2 6 471 C9 332J C2 1104 VR1500R C4 D6 4uF/275AC C30 101 C24104 R1 922K +5V T RT1 123 HITE TOP AC 1 AC 2 + 3 - 4 BG1 25A/800V R7270K1W D5 1N4007 R6 470K 1W R5 470K 1W C10 10U/450V C6 223 D4 BYV26C C8 1u/50V D1UF40 0 7 C15 1000u/25V Vin 1 GND 2 Vo ut 3 U6 78L05 C22 100uF/25V C14 100u/25V Z1 20V/0.5W +18V C18 100u/25V VDD 1 32 4 T1 EE1 0 D8 UF40 0 7 R17 120R R1 2 22R R3 168K +5V PA2 PA2 1 1 2 2 3 3 4 4 5 5 6 6 7 7 8 8 U2 VIPer-2 2 A D4 1N4007 +5V R11510R D3 1N4007 IGB T R16 3K* 1234 CON3 +5V C20104 R16 20K* R13820K1W C17104 +5V SZ-L5 PC1/C1N 1 PPG 2 PA0/ PCK0 /AN4 3 PA1/ PCK1 /AN5 4 PA2/AN6 5 PA3/AN7 6 PA4/TMR0/AN8 7 PA5/ INT/AN9 8 PA6/TMR1/AN10 9 R ES/ PB 6 10 VDD 11 VSS 12 PC5/OPO 13 PC4/OPN 14 PC3/C2N 15 PC2/C1P 16 U1 * C28 10uF/50V IBGT2 H2 0R1 3 53 R24 47R R2 530K C21104 JR2 C23104 R3 04.7K +18 V Q3SS8050Q4N3 90 6 Q5SS8050 D1 11N4007 PPG PPG R224.7K C25104 R32 3K +5V 123 HITETOP IGB T FAN R10 470K 1W R9 470K 1W Φ 1.2 3.8mH L01 C4 D5 10uF/275AC C4 D3 4uF/400DC C4D1 4uF/400DC RL1 R3 1K Q6SS8050 D6 1N4007 VDD Q7SS8050 R4 1K R2 270K1W R2110K RL RL +5V 21 R18 1K Ω VDD Q1 SS8050 +5V R2310K +5V FAN1 21 C3 104 12 GND CY2 472 CY1 472 CY3 102 123 CN1 炉面温度保险丝 增加硬件保护部分 RYD22 710A250V 10A-250VAC SJ-S-118DMH 锅底线圈盘 LOUT LIN 外圈 95UH 24KHZ Model No.: WIH400B Rating: 208V/240V ~60Hz Edition: A Date: 2014-7-29 1 2 3 4 56 ABCD 6 5 4 3 2 1 D CBA Titl e Nu mber Rev i sio n Size B Date: 1-Nov-2013 Sheet of VSS 1 PA4 2 PA3 3 PA7/RET 4 PD0/T1OUT 5 PD1/BUZ 6 PD2 7 PD3 8 PA0/PWM0 13 PA5/ADC5 14 PD7/ADC4 15 PB1/ADC3 16 PA2/ADC2 17 PA1/ADC1/INT1 18 PA6/ADC0/INT0 19 VDD 20 PD4 9 PD5 10 PD6/ADC6 11 PB0/ADC7/PWM1 12 U1P20 L5-L7B SEG9 14 COM1 2 COM2 3 COM3 4 SEG0 5 SEG1 6 SEG2 7 SEG3 8 SEG4 9 SEG5 10 SEG6 11 SEG7 12 SEG8 13 COM0 1 SEG10 15 SEG14 19 SEG11 16 SEG12 17 SEG13 18 SEG15 20 - 22/3 + 22/2 LCD1 LCD-YLS +5V VSS 1 COM0 2 COM1 3 COM2 4 COM3 5 K19 6 K18 7 K17 8 K16 9 K15 10 K14 11 K13 12 K12 13 K11 14 K10 15 K9 16 K8 17 K7 18 K6 19 K5 20 K4 21 K3 22 K2 23 K1 24 SEG O /K 0 25 SCL 26 SD A 27 VDD 28 U216K23 K6 K2K1 K5 K4K3 +5V +5V C7104 +5V EC1470uF/10V 1234 J?CON2 D_ OUT-P1C_IN-P1 C_IN-P1D_ OUT-P1 SCLSDA LCD1 LCD1 R6 4.7K R168R Q1S8050 R5 3K SCL SD A +5V R6 100K R6 100K R6 100K R6 100K R6 100K R6 100K K1 3K1 2K1 1K2K1K0 Model No.: WIH400B Rating: 208V/240v ~60Hz Edition: A Date: 2014-7-29

Test Report

Note: This test report is prepared for the customer shown above and for the equipment described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. FCC PART 18 TEST REPORT For Continental Conair Limited 35/F, Standard Chartered Tower, Millennium City 1, 388 Kwun Tong Road, Kwun Tong, Kowloon, Hong Kong. FCC ID: U43WIH400B Report Type: Original Report Product Name: Commercial Induction Range Test Engineer: Webb Liu Report Number: RSZ140708553-00 Report Date: 2014-07-17 Reviewed By: Dick Zhang EMC Leader Test Laboratory: Bay Area Compliance Laboratories Corp. (Shenzhen) 6/F, the 3rd Phase of WanLi Industrial Building, ShiHua Road, FuTian Free Trade Zone Shenzhen, Guangdong, China Tel: +86-755-33320018 Fax: +86-755-33320008 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RSZ140708553-00 FCC Part 18 Page 2 of 13 TABLE OF CONTENTS GENERAL INFORMATION ...................................................................................................................................... 3 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) .................................................................................... 3 OBJECTIVE................................................................................................................................................................... 3 RELATED SUBMITTAL(S)/GRANT(S) ............................................................................................................................ 3 TEST METHODOLOGY .................................................................................................................................................. 3 TEST FACILITY ............................................................................................................................................................ 3 SYSTEM TEST CONFIGURATION ......................................................................................................................... 4 JUSTIFICATION ............................................................................................................................................................. 4 EUT EXERCISE SOFTWARE.......................................................................................................................................... 4 SPECIAL ACCESSORIES ................................................................................................................................................ 4 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 4 SUPPORT EQUIPMENT LIST AND DETAILS .................................................................................................................... 4 EXTERNAL CABLE ....................................................................................................................................................... 4 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 5 SUMMARY OF TEST RESULT ................................................................................................................................. 6 FCC §18.307 - AC LINE CONDUCTED EMISSIONS ............................................................................................. 7 APPLICABLE STANDARD .............................................................................................................................................. 7 EUT SETUP ................................................................................................................................................................. 7 EMI TEST RECEIVER SETUP ........................................................................................................................................ 8 TEST PROCEDURE ........................................................................................................................................................ 8 TEST EQUIPMENT LIST AND DETAILS .......................................................................................................................... 8 TEST RESULTS SUMMARY ........................................................................................................................................... 8 TEST DATA .................................................................................................................................................................. 9 FCC §18.305 – FIELD STRENGTH ......................................................................................................................... 11 APPLICABLE STANDARD ............................................................................................................................................ 11 EUT SETUP ............................................................................................................................................................... 11 EMI TEST RECEIVER SETUP AND SPECTRUM ANALYZER SETUP ............................................................................... 11 TEST PROCEDURE ...................................................................................................................................................... 12 CORRECTED AMPLITUDE CALCULATION ................................................................................................................... 12 TEST EQUIPMENT LIST AND DETAILS ........................................................................................................................ 12 TEST DATA ................................................................................................................................................................ 12 Bay Area Compliance Laboratories Corp. (Shenzhen) Report N…

Text truncated - open the document above for the full version.

Test Setup Photos

EXHIBIT D - TEST SETUP PHOTOGRAPHS AC Line Conducted Emissions – Front View AC Line Conducted Emissions – Side View Field Strength – Front View Field Strength – Rear View

Contact Information

Applicant

Wesley Chiu(Engineering Director)
[email protected]852-27514688Fax: 852-27518920

Test Firm

Bay Area Compliance Laboratory Corp. (Shenzhen)John Chan
[email protected]08675533320018Fax: 08675533320008

Technical Specifications

#Rule PartsFrequency RangePower Output
1180.028 MHz - 0.028 MHz-
