U7GGOVHFGO

2 Slot SImplex MotoTRBO Tler Il & Hytera Compatlble IP56 Water Reslstant 32 Channels 2,000 mAh Battery Motorola M1 Radlo Connector 2 Slot SImplex MotoTRBO Tler Il & Hytera Compatlble IP56 Water Reslstant 32 Channels 2,000 mAh Battery Motorola M1 Radlo Connector Business Digital & Analog 2-Way RadioBusiness Digital & Analog 2-Way Radio USER MANUAL USER MANUAL 45 GO!® Quick Start: Perform the following steps to assemble your handheld radio: Charge the battery. Install the battery. Install the antenna. Install the belt clip. Turn on the radio. Select a channel. Install your audio accessory (if needed). Adjust the volume. Charging the Battery The radio is powered by a Li-Ion battery. To protect the battery from damage and comply with the warranty conditions, you can use only the charger provided with the battery for charging. To maximize battery performance, it is recommended to charge the battery for 10 to 12 hours before the first use. Installing the Battery Align the battery with the battery slot on the rear side of the radio. Push the battery into the slot until it is fastened. Before removing the battery, turn off the radio first. Press the battery fastener, and then remove the battery. Installing the Antenna Turn off the radio, place the antenna into the installation hole, and turn the antenna clockwise. To remove the antenna, turn the antenna anticlockwise. Before removing the antenna, ensure that you have turned off the radio and removed the universal interface cover. To replace the antenna, use a specified antenna to replace the old one. Otherwise, your radio may be damaged. Installing the Belt Clip Align the screw holes on the belt clip with those on the rear side of the radio, and fasten the belt clip with screws. Turning On the radio Turn the volume/power knob clockwise until you hear a click sound. The radio gives a short beep sound, indicating that the radio is successfully turned on. Selecting a Channel Simply look at the knob with the numbers and rotate until you land onto the group channel you desire. You should also hear the Voice Enunciation through the speaker or earpiece of which channel you are on. Installing an Audio Accessory Remove the protective cover on the side of the radio and plug in your earpiece or headset. Adjusting the Volume Turn the volume knob clockwise to turn up the volume. To turn down the volume, turn the knob anticlockwise. Be careful if you are wearing an audio accessory! Programmable Buttons Your agent can set a programmable button to a shortcut button for a function or channel or call group in accordance with the duration for which the button is pressed: • Press: means pressing a button and immediately releasing the button. Note: This radio can’t press and hold the buttons to change the function. Assignable radio Functions • Emergency call: initiates or cancels an emergency alarm or call. • Monitoring: monitors any activities in a selected analog channel. • One-press call: initiates a predefined private call, group call, or short message by pressing one button. • Scanning: enables or disables scanning. • VOX: enables or disables the VOX function. • Zone: changes the current zone of the radio. This radio has 2 groups. • Power level: switches between transmitting power levels. • Kill / Stun: Remote to close and forbid the radio. • Revive: Remote to open and revive the radio. • Remote Monitor: Remote to monitor the radio • Talk around: Turn ON / OFF this function. • Radio check : Check whether the target radio is in the working state. PTT Button Each channel can be configured as a digital channel. • During a call, if you press the PTT button, the radio transmits signals to other radios in the call. Press and hold the PTT button to talk. Release the PTT button to listen to other members in the call. When you press the PTT button, the microphone is activated. • If there is no existing call, you can press the PTT button to initiate a call (for details, refer to the Initiate a Call section). If the call admission tone function is activated, wait until the short prompt tone ends. • During a call, if the "idle channel prompt" function is enabled (preprogrammed by your agent), when the target radio (that receives your call) releases the PTT button, you will hear a short prompt tone, indicating that the channel becomes idle, and you can respond. • If the existing call is interrupted (for example, when you receive an emergency call), you will hear an idle channel prompt tone. You can disable the "idle channel prompt" function by disabling the tone/prompt function (for details,refer to the Enable or Disable the Tone/Prompt Function section). • To switch between digital channels,turn the knob. Status Indicators You can learn about radio operation through the following: LED indicator. Prompt tone. LED Indicator The LED indicator indicates operation of the radio. • If the indicator is lit red, it indicates that the radio is transmitting signals, send messages, encryption calling or data. • If the indicator is lit green, it indicates that the radio is being turned on, or receiving a call, messages,encryption calling or data. • If the indicator is lit orange, it indicates the radio is scanning. You can turn ON/OFF the some LED indicator via programmed software: transmitting, receiving, scanning state, switch channel, turn on radio, carrier wave, call hang up. Prompt Tone Prompt tones can help you learn about the radio status or response to data receiving. • Digital mode private call prompt tone: Press PTT, radio gives a “di” tone. • Digital mode group call prompt tone: Press PTT, radio gives a “di” tone. • Analog mode call prompt tone: Press PTT, radio doesn’t give a “di” tone. • Call roger prompt tone: Radio gives a “du” tone. • Keypad prompt tone: Radio gives a “di” tone. • Turn on radio prompt tone: Radio gives a continues tones. • Switch channel prompt tone: Radio gives two “den” tones. • Forbid transmitting prompt tone: Radio gives “den” tones continuously, un…

Text truncated - open the document above for the full version.

Klein Electronics, Inc. * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter July 6, 2023 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: U7GGOVHF FRN: 0016302218 Per section 2.911(d)(7) of the FCC rules, (“ Klein Electronics, Inc.”) certifies that the equipment for which authorization is sought is designated to the following U.S. Designated agent* for service of process: Company Name: Klein Electronics, Inc. Physical U.S. Company Address: 349 North Vinewood Street, Escondido, California, USA 92029 Agent name: Michael Lopez Agent Email Address: [email protected] FRN: 0016302218 The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Designated Agent Signed: (Required, if different to Applicant): Signed: Signed: Printed name: Michael Lopez Printed name: Michael Lopez Title: VP Product Management Title: VP Product Management Company Name: Klein Electronics, Inc. Company Name: Klein Electronics, Inc. Date: July 3, 2023 Date: 2023-07-03

Klein Electronics, Inc. Covered Equipment Certification Attestation Letter 7/3/2023 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: U7GGOVHF (Klein Electronics, Inc. ) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. (Klein Electronics, Inc.) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Michael Lopez Title: VP Product Management Company Name: Klein Electronics, Inc. Date: 7/3/2023

2023-07-03 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Shenzhen Huatongwei International Inspection Co., Ltd./ 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China / Hans Hu,. to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Klein Electronics, Inc. / 349 North Vinewood Street, Escondido, California, USA 92029 Agency agreement expiration date: 2024-07-03 By: Michael Lopez Signature Printed On behalf of : Klein Electronics, Inc. Telephone: 800.959.2899

2023-07-03 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: U7GGOVHF Product Name: GO! Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics  Block diagram  Operation description  These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. By: Michael Lopez Signature Printed On behalf of : Klein Electronics, Inc. Telephone: 800.959.2899

Klein Electronics, Inc. 349 North Vinewood Street, Escondido, California, USA 92029 Attestation letter FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir/Madam, We, Klein Electronics, Inc. hereby declare that our product: GO!, FCC ID: U7GGOVHF is capable of supporting a voice channel and a minimum data rate of 4800 bits per second per 6.25 kHz of channel bandwidth. DMR interphone’s bandwidth is 12.5 kHz, and it has a double time slot, one is the speech time slot, one is the data time slot, just language sequence is satisfied with 4800 bps/6.25 kHz BW. For Part 90 frequency user, the radio is disabled 25kHz channel bandwidth mode by radio firmware at factory in order to comply with FCC mandate for part 90 frequencies. Sincerely, Michael Lopez Signature: 2023-07-03

Klein Electronics, Inc. 349 North Vinewood Street, Escondido, California, USA 92029 Extended Frequencies Justification Date: 2023-07-03 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir/Madam, TheGO!, LMR with FCC ID: U7GGOVHF was designed to operate in the frequency bands 136~174MHz. To aid equipment authorization in other countries which accept the United States FCC Grant for certification, Klein Electronics, Inc. is requesting that the FCC lists the frequencies 136~174MHz, under FCC Rules Parts 90 on the FCC Grant. Klein Electronics, Inc. attests that the radio will not be marketed to USA users with the frequency band which is not allowed by the rule part 90. Per the FCC’s KDB634817 guidance, as an alternative to listing the exact frequencies, we acknowledge that it’s a violation of the FCC Rules if this device operates on unauthorized frequencies. Frequency Range （MHz） FCC Rule Part 136-150 For Federal 150-150.05 For Federal 150.05-150.8 90 150.8-162.0125 90 162.0125-173.2 90 173.2-173.4 90 173.4-174 For Federal Sincerely, Signature: Typed or Printed Name: Michael Lopez E‐mail: [email protected]

External photos

Internal photos

Page: 1 of 25 TEST REPORT Report No. ...................................... : CHTEW23050062 Report vertification: Project No. ...................................... : SHT2304092102EW FCC ID ............................................. : U7GGOVHF Applicant’s name ........................... : Klein Electronics, Inc. Address ............................................. : 349 North Vinewood Street, Escondido, California, USA 92029 Test item description .................... : GO! Trade Mark ....................................... : Model/Type reference ....................... : GO!-VHF Listed Model(s) ................................. : - Standard ......................................... : FCC 47 CFR Part2.1093 IEEE Std C95.1, 1999 Edition IEEE 1528: 2013 Date of receipt of test sample.........: May 11, 2023 Date of testing.............................: May 11, 2023- May 23, 2023 Date of issue...............................: May 24, 2023 Result .................. ........................: PASS Compiled by ( position+printed name+signature) .. : File administrators: Fanghui Zhu Supervised by ( position+printed name+signature) .. : Test Engineer: Weiyang Xiang Approved by ( position+printed name+signature) .. : Manager: Hans Hu Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................. : 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report merely correspond to the test sample. Report No.: CHTEW23050062 Page: 2 of 25 Issued: 2023-05-24 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05 (2023-03) Contents 1. Statement of Compliance 3 2. Test Standards and Report version 4 2.1. Test Standards 4 2.2. Report version 4 3. Summary 5 3.1. Client Information 5 3.2. Product Description 5 3.3. Radio Specification Description 6 3.4. Test frequency list 6 3.5. Testing Laboratory Information 7 3.6. Environmental conditions 7 4. Equipments Used during the Test 8 5. Measurement Uncertainty 9 6. SAR Measurements System Configuration 10 6.1. SAR Measurement Set-up 10 6.2. DASY5 E-field Probe System 11 6.3. Phantoms 12 6.4. Device Holder 12 7. SAR Test Procedure 13 7.1. Scanning Procedure 13 7.2. Data Storage and Evaluation 15 8. Position of the wireless device in relation to the phantom 17 8.1. Front-of-face 17 8.2. Body Position 17 9. Dielectric Property Measurements & System Check 18 9.1. Tissue Dielectric Parameters 18 9.2. SAR System Validation 19 9.3. System Check 19 10. SAR Exposure Limits 22 11. Radiated Power Measurement Results and Tune-up 23 12. SAR Measurement Results 24 13. Test Setup Photos 25 14. External and Internal Photos of the EUT 25 Report No.: CHTEW23050062 Page: 3 of 25 Issued: 2023-05-24 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05 (2023-03) 1. Statement of Compliance Maximum Reported SAR (W/kg @1g) RF Exposure Conditions TNF Head(Dist.= 25mm) 0.012 Body-worn(Dist.= 0mm) 0.052 Note: 1. This device is in compliance with Specific Absorption Rate (SAR) for occupational/controlled exposure limits (8 W/kg) specified in FCC 47 CFR part 2 (2.1093) and ANSI/IEEE C95.1-1992. 2. This device had been tested in accordance with the measurement methods and procedures specified in IEEE 1528 and FCC KDB publications. Report No.: CHTEW23050062 Page: 4 of 25 Issued: 2023-05-24 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05 (2023-03) 2. Test Standards and Report version 2.1. Test Standards The tests were performed according to following standards: FCC 47 Part 2.1093: Radiofrequency Radiation Exposure Evaluation:Portable Devices IEEE Std C95.1, 1999 Edition: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz IEEE Std 1528™-2013: IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques. FCC published RF exposure KDB procedures: KDB 865664 D01 SAR Measurement 100 MHz to 6 GHz v01r04: SAR Measurement Requirements for 100 MHz to 6 GHz KDB 865664 D02 RF Exposure Reporting v01r02: RF Exposure Compliance Reporting and Documentation Considerations KDB 447498 D04 Interim General RF Exposure Guidance v01: Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies KDB 643646 D01:SAR Test for PTT Radios v01r03: SAR Test Reduction Considerations for Occupational PTT Radios TCB workshop: April, 2019; Page 19, Tissue Simulating Liquids (TSL) 2.2. Report version Revision No. Date of issue Description N/A 2023-05-24 Original Report No.: CHTEW23050062 Page: 5 of 25 Issued: 2023-05-24 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05 (2023-03) 3. Summary 3.1. Client Information Applicant: Klein Electronics, Inc. Address: 349 North Vinewood Street, Escondido, California, USA 92029 Manufacturer: Klein Electronics, Inc. Address: 349 North Vinewood Street, Escondido, California, USA 92029 3.2. Product Description Main unit Name of EUT: GO! Trade Mark: Model No.: GO!-VHF Listed Model(s): - Power supply: 7.5V from battery Hardware version: DM_GO_VHF V1.0 Software version: GO(136-174) V1.0.3.18 Device Dimension: Length x Width x Thickness (mm): 120 x 58 x50 Device Category: Portable Product stage: Production unit RF Exposur…

Text truncated - open the document above for the full version.

Page: 1 of 39 TEST REPORT Report No. ....................................... : CHTEW23050068 Report verification: Project No. ................................. : SHT2304092101EW FCC ID ............................................ : U7GGOVHF Applicant’s name ........................... : Klein Electronics, Inc. Address.............................................: 349 North Vinewood Street, Escondido, California, USA 92029 Product name ................................. : GO! Trade Mark ....................................... : Model No. ......................................... : GO!-VHF Listed Model(s) ................................. : - Standard .......................................... : FCC CFR Title 47 Part 90 Date of receipt of test sample.........: May.11, 2023 Date of testing.............................: May.11, 2023-May.29, 2023 Date of issue...............................: May.29, 2023 Result ................. ........................: PASS Compiled by (Position-Printed name-Signature) : File administrators Fanghui Zhu Supervised by (Position-Printed name-Signature) : Project Engineer Caspar Chen Approved by (Position-Printed name-Signature) : RF Manager Hans Hu Testing Laboratory Name .............. : Shenzhen Huatongwei International Inspection Co., Ltd. Address ............................................ : 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report merely correspond to the test sample. Report No.: CHTEW23050068 Page: 2 of 39 Issued: 2023-05-29 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05(2023-03) Contents 1 T E S T S T A N D A R D S A N D RE P O R T V E R S I O N 3 1.1. Test standard 3 1.2. Report revised information 3 2 T E S T D E S C R I P T I O N 4 3 S U M M A R Y 5 3.1 Client information 5 3.2 Product description 5 3.3 Radio Specification Description *1 5 3.4 Testing laboratory information 6 4 T E S T C O N F I G U R A T I O N 7 4.1 Test frequency list 7 4.2 Operation mode 7 4.3 Support unit used in test configuration and system 8 4.4 Testing environmental condition 9 4.5 Measurement uncertainty 9 4.6 Equipment used during the testing 10 5 T E S T C O N D I T I O N S A N D R E S U L T S 11 5.1 Conducted carrier output power 11 5.2 99% occupied bandwidth & 26dB bandwidth 12 5.3 Emission mask 14 5.4 Modulation limit 16 5.5 Audio frequency response 17 5.6 Frequency stability VS temperature 19 5.7 Frequency stability VS voltage 20 5.8 Transmitter frequency behavior 21 5.9 Transmit conducted spurious emission 23 5.10 Transmitter radiated spurious emission 24 6 T E S T S E T U P P H O T O S 33 7 E X T E R N A L A N D I N T E R N AL P H O T O S 34 7.1 External photos 34 7.2 Internal photos 37 8 A P P E N D I X R E P O R T 39 Report No.: CHTEW23050068 Page: 3 of 39 Issued: 2023-05-29 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05(2023-03) 1 TEST STANDARDS AND REPORT VERSION 1.1. Test standard The tests were performed according to following standards: FCC Rules Part 90: Private land mobile radio services. FCC Rules Part 2: Frequency allocations and radio treaty matters; General rules and regulations ANSI C63.26-2015: American National Standard for Compliance Testing of Transmitters Used in Licensed Radio Services ANSI/TIA-603-E-2016: Land Mobile FM or PM Communications Equipment and Performance Standards ANSI C63.4-2014: American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz 1.2. Report revised information Revised No. Date of issued Description N/A 2023-05-29 Original Report No.: CHTEW23050068 Page: 4 of 39 Issued: 2023-05-29 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05(2023-03) 2 TEST DESCRIPTION Section Test Item Section Result Test Engineer 5.1 Conducted carrier output power Part 90.205 Part 2.1046(a) Pass Chunshui Gu 5.2 99% occupied bandwidth & 26dB bandwidth Part 90.209 & 210 Part 2.1049 Pass Chunshui Gu 5.3 Emission mask Part 90.209 & 210 Part 2.1049 Pass Chunshui Gu 5.4 Modulation limit Part 2.1047(b) Pass Chunshui Gu 5.5 Audio frequency response Part 2.1047(a) Pass Chunshui Gu 5.6 Frequency stability VS temperature Part 90.213 Part 2.1055 Pass Chunshui Gu 5.7 Frequency stability VS voltage Part 90.213 Part 2.1055 Pass Chunshui Gu 5.8 Transient frequency behavior Part 90.214 Pass Chunshui Gu 5.9 Transmit conducted spurious emission Part 90.210 Part 2.1051 Pass Chunshui Gu 5.10 Transmit radiated spurious emission Part 90.210 Part 2.1053 Pass Yifan Wang Note: The measurement uncertainty is not included in the test result. Report No.: CHTEW23050068 Page: 5 of 39 Issued: 2023-05-29 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05(2023-03) 3 SUMMARY 3.1 Client information Applicant: Klein Electronics, Inc. Address: 349 North Vinewood Street, Escondido, California, USA 92029 Manufacturer: Klein Electronics, Inc. Address: 349 North Vinewood Street, Escondido, California, USA 92029 3.2 Product description Main unit information: Product name: GO! Trade mark: Model No.: GO!-VHF Listed model(s): - Power supply: DC 7.5V from battery Hardware version: DM_GO_VHF V1.0 Software version: GO(136-174) V1.0.3.18 Accessory unit information: Battery information: Model: GO!-BATT Norm: DC 7.5V 15Wh 2000mAh Charger information: Model: GO!-Charger Input: 12V 1000…

Text truncated - open the document above for the full version.

Project No.:SHT2304092101EW Appendix C:Emission Mask Operation Mode Modulation Type Test Channel TEST PLOT RESULT TX-ANLFMCH L TX-ANLFMCH L TX-ANLFMCH M Appendix Page:14 of 27 Project No.:SHT2304092101EW Appendix C:Emission Mask Operation Mode Modulation Type Test Channel TEST PLOT RESULT TX-ANLFMCH M TX-ANLFMCH H TX-ANLFMCH H Appendix Page:15 of 27 Project No.:SHT2304092101EW Appendix D:Modulation Limit Operation Mode Modulation Type Test Channel Modulation Level (dB) Peak frequency deviation (kHz) Limit (kHz) Result 300Hz 1004Hz1500Hz2500 Hz TX-ANHFM CH M -200.093 0.206 0.264 0.374 2.5PASS TX-ANHFM CH M -150.152 0.310 0.433 0.623 2.5PASS TX-ANHFM CH M -100.182 0.511 0.732 1.080 2.5PASS TX-ANHFM CH M -50.295 0.877 1.277 1.701 2.5PASS TX-ANHFM CH M 00.477 1.535 1.821 1.823 2.5PASS TX-ANHFM CH M 50.823 1.980 1.948 1.920 2.5PASS TX-ANHFM CH M 101.447 2.200 1.990 1.976 2.5PASS TX-ANHFM CH M 151.764 2.234 1.980 1.991 2.5PASS TX-ANHFM CH M 201.668 2.244 1.996 1.991 2.5PASS Appendix Page:16 of 27 Project No.:SHT2304092101EW Appendix D:Modulation Limit TEST PLOT RESULT Appendix Page:17 of 27 Project No.:SHT2304092101EW Appendix E:Audio Frequency Response Operation Mode Modulation Type Test Channel Frequency (Hz) Audio Frequency Response (dB) Lower LimitUpper LimitResult TX-ANHFM CH M 100-29.00 PASS TX-ANHFM CH M 200-29.16 PASS TX-ANHFM CH M 300-10.39 -17.84 -9.42 PASS TX-ANHFM CH M 400-8.11 -12.86 -6.93 PASS TX-ANHFM CH M 500-5.86 -9.00 -5.00 PASS TX-ANHFM CH M 600-4.43 -7.42 -3.42 PASS TX-ANHFM CH M 700-3.04 -6.09 -2.09 PASS TX-ANHFM CH M 800-1.93 -4.93 -0.93 PASS TX-ANHFM CH M 900-0.95 -3.91 0.09 PASS TX-ANHFM CH M 10000.04 -3.00 1.00 PASS TX-ANHFM CH M 12001.59 -1.42 2.58 PASS TX-ANHFM CH M 14002.90 -0.09 3.91 PASS TX-ANHFM CH M 16003.99 1.07 5.07 PASS TX-ANHFM CH M 18004.82 2.09 6.09 PASS TX-ANHFM CH M 20005.52 3.00 7.00 PASS TX-ANHFM CH M 21005.82 3.42 7.42 PASS TX-ANHFM CH M 22006.10 3.83 7.83 PASS TX-ANHFM CH M 23006.34 4.21 8.21 PASS TX-ANHFM CH M 24006.50 4.58 8.58 PASS TX-ANHFM CH M 25006.77 4.93 8.93 PASS TX-ANHFM CH M 26007.04 4.59 9.27 PASS TX-ANHFM CH M 27007.29 4.27 9.60 PASS TX-ANHFM CH M 28007.49 3.95 9.91 PASS TX-ANHFM CH M 29007.42 3.65 10.22 PASS TX-ANHFM CH M 30007.01 3.35 10.51 PASS TX-ANHFM CH M 3500-21.83 PASS TX-ANHFM CH M 4000-29.16 PASS TX-ANHFM CH M 4500-29.30 PASS TX-ANHFM CH M 5000-29.13 PASS Appendix Page:18 of 27 Project No.:SHT2304092101EW Appendix E:Audio Frequency Response TEST PLOT RESULT Appendix Page:19 of 27 Project No.:SHT2304092101EW Appendix F:Frequency Stability Test & Temperature Operation Mode Modulation Type Test ConditionsFrequency error (ppm) Limit (ppm) Result VoltageTemperature CH L CH M CH H TX-DNH 4FSK VN-30-0.039 -0.045 -0.054 ±5.0PASS TX-DNH 4FSK VN-20-0.040 -0.043 -0.050 ±5.0PASS TX-DNH 4FSK VN-10-0.037 -0.045 -0.051 ±5.0PASS TX-DNH 4FSK VN0-0.038 -0.043 -0.051 ±5.0PASS TX-DNH 4FSK VN10-0.040 -0.044 -0.051 ±5.0PASS TX-DNH 4FSK VN20-0.037 -0.043 -0.049 ±5.0PASS TX-DNH 4FSK VN30-0.040 -0.046 -0.052 ±5.0PASS TX-DNH 4FSK VN40-0.037 -0.043 -0.052 ±5.0PASS TX-DNH 4FSK VN50-0.039 -0.045 -0.050 ±5.0PASS TX-DNL 4FSK VN-30-0.027 -0.038 -0.039 ±5.0PASS TX-DNL 4FSK VN-20-0.026 -0.037 -0.039 ±5.0PASS TX-DNL 4FSK VN-10-0.027 -0.037 -0.041 ±5.0PASS TX-DNL 4FSK VN0-0.026 -0.036 -0.040 ±5.0PASS TX-DNL 4FSK VN10-0.026 -0.035 -0.039 ±5.0PASS TX-DNL 4FSK VN20-0.025 -0.035 -0.038 ±5.0PASS TX-DNL 4FSK VN30-0.027 -0.038 -0.039 ±5.0PASS TX-DNL 4FSK VN40-0.027 -0.037 -0.042 ±5.0PASS TX-DNL 4FSK VN50-0.026 -0.038 -0.039 ±5.0PASS TX-ANH FM VN-300.034 0.040 0.048 ±5.0PASS TX-ANH FM VN-200.033 0.043 0.045 ±5.0PASS TX-ANH FM VN-100.035 0.040 0.049 ±5.0PASS TX-ANH FM VN00.034 0.042 0.049 ±5.0PASS TX-ANH FM VN100.032 0.041 0.049 ±5.0PASS TX-ANH FM VN200.032 0.039 0.045 ±5.0PASS TX-ANH FM VN300.032 0.041 0.047 ±5.0PASS TX-ANH FM VN400.033 0.040 0.046 ±5.0PASS TX-ANH FM VN500.032 0.040 0.047 ±5.0PASS TX-ANL FM VN-300.066 0.068 0.076 ±5.0PASS TX-ANL FM VN-200.065 0.074 0.072 ±5.0PASS TX-ANL FM VN-100.066 0.070 0.070 ±5.0PASS TX-ANL FM VN00.061 0.074 0.072 ±5.0PASS TX-ANL FM VN100.064 0.072 0.074 ±5.0PASS TX-ANL FM VN200.060 0.068 0.070 ±5.0PASS TX-ANL FM VN300.064 0.069 0.074 ±5.0PASS TX-ANL FM VN400.064 0.069 0.072 ±5.0PASS TX-ANL FM VN500.064 0.074 0.077 ±5.0PASS Appendix Page:20 of 27 Project No.:SHT2304092101EW Appendix G:Frequency Stability Test & Voltage Operation Mode Modulation Type Test ConditionsFrequency error (ppm) Limit (ppm) Result VoltageTemperature CH L CH M CH H TX-DNH4FSKVNTN-0.037 -0.043 -0.049 ±5.0PASS TX-DNH4FSKVLTN-0.037 -0.043 -0.049 ±5.0PASS TX-DNH4FSKVHTN-0.039 -0.044 -0.052 ±5.0PASS TX-DNL4FSKVNTN-0.025 -0.035 -0.038 ±5.0PASS TX-DNL4FSKVLTN-0.025 -0.035 -0.038 ±5.0PASS TX-DNL4FSKVHTN-0.026 -0.036 -0.038 ±5.0PASS TX-ANHFMVNTN0.032 0.039 0.045 ±5.0PASS TX-ANHFMVLTN0.033 0.039 0.045 ±5.0PASS TX-ANHFMVHTN0.033 0.040 0.047 ±5.0PASS TX-ANLFMVNTN0.060 0.068 0.070 ±5.0PASS TX-ANLFMVLTN0.061 0.069 0.071 ±5.0PASS TX-ANLFMVHTN0.063 0.070 0.074 ±5.0PASS Appendix Page:21 of 27 Project No.:SHT2304092101EW Appendix H:Transmitter Frequency Behavior Operation Mode Modulation Type Test Channel TEST PLOT RESULT TX-DNH4FSKCHM TX-DNH4FSKCHM TX-ANHFMCHM Appendix Page:22 of 27 Project No.:SHT2304092101EW Appendix H:Transmitter Frequency Behavior Operation Mode Modulation Type Test Channel TEST PLOT RESULT TX-ANHFMCHM Appendix Page:23 of 27 Project No.:SHT2304092101EW Appendix I:Spurious Emission On Antenna Port Operation Mode Mo…

Text truncated - open the document above for the full version.
