U88-SC-8930AMPIn-Building RF Repeater

SpeedCell Repeater INSTALLATION GUIDE Ver. 1.0 ntzT_`ZWhtwVkm|Tzwy SpeedCellRepeater ntzT_`ZWhtwVkm|Tzwy Installation Guide Ver. 1.0 Contents of Box ContentsPictureQuantityContentsPictureQuantity SpeedCell Repeater System PSU Unit 4.3”(W) x 16.9”(H) x 10.7”(D) , 15 lbs DFM Unit 2.8”(W) x 16.9”(H) x 10.7”(D), 9.9 lbs 800/900 AMP Unit 3.9”(W) x 16.9”(H) x 10.7”(D) , 19 lbs 1EA Ground Cable 6.6ft (2m) 1EA Power Cord 5.9ft (1.8m) 1EA Ethernet Cable 6.6ft (2m) 1EA Mounting Bracket 23.2”(W) x 18.5”(H) x 2.75”(D), 23.5 lbs 1EA Lag Screw 1/2” x 2” 4EA CD which contains - User Manual - Installation Guide 1EA Ground Sems Screw M4 x 8mm 4EA RF Cable Set Front RF Cable 2EA, Top RF Cable 4EA, Reference Cable 3EA 1EA Mounting Sems Screw M6 x 10mm 8EA 3 UL/FCC: This equipment complies with UL and FCC This publication provides instruction for installing the SpeedCell repeaters. The images for the User Interface in this publication may vary from the repeater’s depending on its S/W Version. Copyright © 2011, GS Teletech, Inc. All Rights Reserved Printed in Republic of Korea Revision History Certification DateVersionChanges 03/2011version1.0 4 WARNING! EXPOSURE TO RF Working with the repeater while in operation, may expose the technician to RF electromagnetic fields that exceed FCC rules for human exposure. Visit the FCC website at http://www.fcc.gov/oet/rfsafety to learn more about the effects of exposure to RF electromagnetic fields. Warnings and Hazards WARNING! ELECTRIC SHOCK Opening the BDA (bi-directional amplifier) could result in electric shock and may cause severe injury. WARNING! DAMAGE TO EQUIPMENT Operating the BDA with antennas in very close proximity facing each other could lead to severe damage to the repeater. RF EXPOSURE & ANTENNA PLACEMENT Actual separation distance is determined upon gain of antenna used. Please maintain a minimum safe distance of at least 8inch while operating near the donor and the server antennas. Also, the donor antenna needs to be mounted outdoors on a permanent structure. WARRANTY Opening or tampering the BDA will void all warranties. CAUTION: REPEATER SHOULD BE INSTALLED AS CLOSE AS POSSIBLE TO POWER SOURCE. CAUTION: THIS REPEATER IS FOR INDOOR USE ONLY AND SHOULD BE LOCATED INSIDE OF BUILDING. CAUTION: RISK OF EXPLOSION IF BATTERY ON CONTROLLER BOARD IS REPLACED WITH AN INCORRECT TYPE. CAUTION: DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS 5 <Picture 1> Mounting the Bracket on a Wood-Framed Wall. Mounting Repeater Wood-Framed Wall • It is recommended to first attach a sheet of plywood to the wall. The sheet of plywood should be anchored to the studs in the wall. • Using a pencil, mark the location for each of the mounting bracket's four mounting holes on the plywood. • Place the mounting bracket over the four lag screws heads. • Thread a lag screw at the positions marked in step 2. Mounting Bracket Lag Screw 1/2” x 2” Wood-Framed Wall 6 Hang and Grounding <Picture 2> Hanging the PSU Unit. • Hang the PSU unit to the mounting bracket. • Locate the two Mounting Sems Screws (M6 x10mm) underneath the PSU unit. Tighten bolts until secure. Mounting Sems Screw M6 x 10mm 7 Hang and Grounding • Hang the rest of the units in the following order: 800/900 AMP. • Locate the two Mounting Sems Screws (M6 x10mm) underneath each unit. Tighten bolts until secure. <Picture 3> Hanging the Rest of Units. CAUTION Units must be hung in the following order only: DFM -> 800/900 AMP. 8 Hang and Grounding Ground Cable • Connect ground cables of each unit to the bracket using Ground Sems Screws (M4 x 8mm) as displayed at the picture below. CAUTION Ground cables must be properly grounded to provide both EMI and voltage surge protection for the repeater. <Picture 3> Grounding of the PSU, 1900 AMP, DFM, 800/900 AMP Units. 9 Hang and Grounding <Picture 4> Grounding the Bracket. • Locate the ground lug on the underside (or side) of the bracket. • Crimp the ground cable to the ground lug. • Route the free end of the ground cable to an approved (per local code or practice) ground source. CAUTION Ground cable must be properly grounded to provide both EMI and voltage surge protection for the repeater. 10 Position Antenna • After installing 800/900MHz antennas the installer should make line of site. • Customer specifications should be followed for positioning the antennas properly. Warning: In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna should not be less than 50cm during normal operation. The gain of the antenna is 12 dBi. < Picture 5> An installer is directing Donor Antenna to nearby BTS to receive strong input signal. 11 RF Cable Connections: Top of The Repeater CAUTION Do not connect or disconnect cable from ANT port when power is ON. • Connect the 800/900 Antennas to their corresponding ports. • Plug in four N(M) to N(M) type RF cables as demonstrated in the picture below. AB CD AB C D <Picture 6> Top View of the Repeater. 12 RF Cable Connections: Front Side A B • Take out two SMA (M) to SMA (M) type RF cables. • Please, pay attention to cable‟s corresponding number and its color while connecting. • 800/900 AMP and DFM via Band 2. <Picture 7> Front View of the Repeater. 13 AB RF Cable Connections: Bottom of The Repeater • Take out three SMA (M) to SMA (M) type RF cables. • While connecting the PSU and the DFM units underneath, use referenced cable and pay attention to the labels. Plug them into their corresponding outlets. • User may choose either of the two SMA ports on the bottom of the PSU to connect to the DFM. • User may choose any two of the four SMA ports on the bottom of the PSU to connect to amplifiers. CAUTION Please, pay attention while connecting PSU and DFM, PSU and 800/900 AMP. The repeater will not work if connection is inappropriate. <Picture 8> Bottom View of the Repeater. 14 10M REF. 13 12 11 10 9 7 6 5 4 3 2 1 14151617181920 8 2122232425 1. RS485_P 2. RS485_N 3. GND 4. INSERT 5. RESET6. NC 7. ID_R…

Text truncated - open the document above for the full version.

GS Instruments Co., Ltd. #1385-14, Juan-Dong, Nam-Ku, Incheon, 402-200 Korea TEL : +82 32 870 5621, FAX : +82 32 876 3495, Date : May 23, 2011 Federal Communication Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 SUBJECT : FCC Application for FCC ID : U88-SC-8930AMP To Whom It may Concern: We, GS Instruments Co., Ltd., hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class A In-Building RF Repeater of this composite filing. Sincerely yours, Yong-il You

2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 GS Instruments Co., Ltd. May 20, 2011 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, GS Instruments Co.,Ltd. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): In-Building RF Repeater, GMS-8930AMP/DFU-SPR (FCC ID: U88-SC-8930AMP) We affirm that between SIEMIC and GS Instruments Co.,Ltd. any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Applicant’s Company : GS Instruments Co.,Ltd. Address : 1385-14, Juan-Dong, Nam-Ku, Incheon,,402-200 Korea FCC ID : U88-SC-8930AMP

Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 GS Instruments Co.,Ltd.. To: Federal Communications Comm ission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID U88-SC-8930AMP Date: May 20,2011 We hereby request confidential treatment of information accompanying this application as outlined below: COMNFIDENTIAL AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Schematics 3 Operational Description 4 Part List & Tune-UP Procedure CONFIDENTIAL 5 Internal Photos 6 External Photos 7 Test-Setup Photos SHORT-TERM CONFIDENTIAL 8 User’s Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Applicant’s Company : GS Instruments Co.,Ltd. Address : 1385-14, Juan-Dong, Nam-Ku, Incheon,,402-200 Korea

FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr (Front) 1/6 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr (Back) 2/6 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr (Left) 3/6 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr (Right) 4/6 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr (Lower Side) 5/6 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr 6/6 (Upper Side)

FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1105FR11 1/2 1.1 ID Label Information Following is a copy of the label that will be placed on the rear side of the cabinet. Both the FCC ID and compliance statement are included in the product label Figure 1.1 PRODUCT LABEL Model Name : GMS-8930AMP/DFU-SPR FCC ID : U88-SC-8930AMP EUT Type : In-Building RF Repeater Serial No : This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference , and (2) this device must accept any interference received, Includin g interference that may cause undesired operation. GS Instruments Co.,Ltd. 1385-14, Juan-Dong, Nam-Ku, Incheon, 402-200 South Korea MADE IN KOREA FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr Report No. : HCTR1105FR11 2/2 1.2 Label Location Photos The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase.(Labeling requirements per 2.925) Figure 1.2 LABEL LOCATION LABEL LOCATION

FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr 10M REF TOP 1/24 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr 10M REF BOTTOM 2/24 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr 800_1900 IO BOARD_ TOP 3/24 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr 800_1900 IO BOARD_ BOTTOM 4/24 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr 800_CAVITY 5/24 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr 800_CONVERTER_DL_TOP 6/24 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr 800_CONVERTER_DL_Bottom 7/24 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr 800_CONVERTER_UL_TOP 8/24 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr 800_CONVERTER_DL_Bottom 9/24 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr SCA-802S PCB 10/24 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr 800 iDEN LED BOARD 11/24 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr AMP Controller _TOP 12/24 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr AMP Controller _BOTTOM 13/24 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr DFM_DIGITAL_TOP . 14/24 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr DFM_DIGITAL_BOTTOM 15/24 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr DFM_LED BOARD_TOP 16/24 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr DFM_LED BOARD_BOTTOM 17/24 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr DFM RF MODULE _TOP 18/24 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr DFM RF MODULE _BOTTOM 19/24 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr FEU 20/24 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr SNMP_MAIN_TOP 21/24 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr SNMP_MAIN_BOTTOM 22/24 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr SNMP_SUB_TOP 23/24 FCC ID : U88-SC-8930AMP HCT CO., LTD. 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO,KOREA TEL:+82 31 645 6467 FAX:+82 31 645 6401 www.hct.co.kr 24/24 SNMP_SUB_BOTTOM

Report No.: HCTR1105FR11 FCC ID: U88-SC-8930AMP DATE : May 20, 2011 HCT Co., Ltd. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, Korea TEL : +82 31 645 6300 FAX : +82 31 645 6401 www.hct.co.kr - 89 /92- 10. RF EXPOSURE STATEMENT 1. LIMITS According to §1.1310 and §2.1091 RF exposure is calculated. (B) Limits for General Population/Uncontrolled Exposures Frequency range (MHz) Electric field Strength (V/m) Magnetic field Strength (A/m) Power density (mW/cm²) Averaging time (minutes) 0.3 - 1.34....................................... 1.34 - 30....................................... 30 - 300....................................... 300 - 1500.................................... 1500 - 100.000................................. 614 824/f 27.5 ............... ............... 1.63 2.19/f 0.073 ............... ............... *(100) *(180/ f²) 0.2 f/1500 1.0 30 30 30 30 30 F = frequency in MHz * = Plane-wave equivalent power density 2. MAXIMUM PERMISSIBLE EXPOSURE Prediction Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S = PG/4πR² S = Power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Report No.: HCTR1105FR11 FCC ID: U88-SC-8930AMP DATE : May 20, 2011 HCT Co., Ltd. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, Korea TEL : +82 31 645 6300 FAX : +82 31 645 6401 www.hct.co.kr - 90 /92- 2-1. iDen Downlink (800 MHz) Max Peak output Power at antenna input terminal 26.970 dBm Max Peak output Power at antenna input terminal 497.737 mW Prediction distance 50.000 cm Prediction frequency 851.0125 MHz Antenna Gain(typical) 12.000 dBi Antenna Gain(numeric) 15.849 - Power density at prediction frequency( S) 0.251 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 0.5 67 mW/cm 2 2-2. iDen Uplink (800 MHz) Max Peak output Power at antenna input terminal 27.000 dBm Max Peak output Power at antenna input terminal 501.187 mW Prediction distance 50.000 cm Prediction frequency 806.0125 MHz Antenna Gain(typical) 12.000 dBi Antenna Gain(numeric) 15.849 - Power density at prediction frequency( S) 0.253 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 0.5 37 mW/cm 2 Report No.: HCTR1105FR11 FCC ID: U88-SC-8930AMP DATE : May 20, 2011 HCT Co., Ltd. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, Korea TEL : +82 31 645 6300 FAX : +82 31 645 6401 www.hct.co.kr - 91 /92- 2-3. iDen Downlink (900 MHz) Max Peak output Power at antenna input terminal 27.020 dBm Max Peak output Power at antenna input terminal 503.501 mW Prediction distance 50.000 cm Prediction frequency 935.0125 MHz Antenna Gain(typical) 12.000 dBi Antenna Gain(numeric) 15.849 - Power density at prediction frequency( S) 0.254 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 0.6 23 mW/cm 2 2-4. iDen Uplink (900 MHz) Max Peak output Power at antenna input terminal 26.850 dBm Max Peak output Power at antenna input terminal 484.172 mW Prediction distance 50.000 cm Prediction frequency 896.0125 MHz Antenna Gain(typical) 12.000 dBi Antenna Gain(numeric) 15.849 - Power density at prediction frequency( S) 0.244 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 0.5 97 mW/cm 2 3. RESULTS The power density level at 50 cm is 0.253 mW/cm²(iDen 800 MHz UpLink), 0.251 mW/cm²(iDen 800 MHz DownLink), 0.244 mW/cm²(iDen 900 MHz UpLink), 0.254 mW/cm²(iDen 900 MHz DownLink), which is below the uncontrolled exposure limit for iDEN band. Simultaneous MPE at 25 Cm is (0.251/0.567) + (0.254/0.623) = 0.850 < 1 (DownLink), (0.2536/0.537) + (0.244/0.597) = 0.883 < 1 (UpLink), Report No.: HCTR1105FR11 FCC ID: U88-SC-8930AMP DATE : May 20, 2011 HCT Co., Ltd. 105-1, Jangam-ri, Majang-Myeon, Icheon-si, Kyunggi-Do, Korea TEL : +82 31 645 6300 FAX : +82 31 645 6401 www.hct.co.kr - 92 /92- Warning: In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, it must also have a minimum distance of 50 cm from the body during normal operation.
