UFJ282000902Transmitter

MonoTel-915 Operating instructions Please keep these instructions in a safe place! Operating Instructions Please keep the instructions in a safe place. Notice de service Prière de conserver cette notice de service ! Manual de instrucciones ¡Por favor guarde estas instrucciones! Istruzioni per l'uso Conservare le istruzioni! Instrukcja obs∏ugi Instrukcj ́ nale ̋y zachowaç ! Nr. 18 100.5901/0606 USA GB FR ES IT PL 309408 01 el ero elero USA 10827 Alder Circle USA-Dallas Texas 75238 [email protected] elero GmbH Antriebstechnik Linsenhofer Str. 59–63 D-72660 Beuren [email protected] www.elero.com Safety instructions USA-2 Important safety instructions! Always observe the following instructions. • For use in dry rooms only. • Use unmodified elerooriginal parts only. • Keep persons away from the systems guide track. • Keep children away from controls. • Always comply with national stipulations. • Always dispose of used batteries properly. Always replace batteries with identical type (LR 03; AAA). • If the system is controlled by one or more transmitters, the system guide track must be visible during operation. • The equipment contains small parts that could be swallowed. USA Warning! Safety instructions......................................... USA- 2 Instruction to the user..................................... USA- 3 Explanation of buttons.................................... USA- 4 General information....................................... USA- 5 Designated use............................................. USA- 5 Note......................................................... USA- 6 Wall holder installation................................... USA- 6 Explanation of functions.................................. USA- 7 Transmission control light............................ USA- 7 Group control.......................................... USA- 7 Programming radio channel settings..................... USA- 8 Programming transmitter/channel................... USA- 8 Programming additional transmitters............... USA- 8 Intermediate position for roller shutter/awning/ venetian blind.............................................. USA-10 Programming intermediate position................. USA-10 Programming ventilation/reverse position.......... USA-10 Adjustment to intermediate position................ USA-11 Adjustment to ventilation/reverse position......... USA-11 Deleting intermediate position....................... USA-11 Deleting ventilation/reverse position................ USA-11 Deleting radio channel settings........................... USA-12 Deleting individual transmitters..................... USA-12 Deleting all transmitters.............................. USA-12 Technical data.............................................. USA-12 Battery replacement....................................... USA-13 Cleaning.................................................... USA-13 Troubleshooting............................................ USA-13 General declaration of conformity........................ USA-13 Contents USA-1 USA-4 USA USA-3 Explanation of buttons elero Transmission control light Programming button P vUPbutton ySTOPbutton bDOWNbutton Battery compartment Labelling field Instruction to the user This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. Operation with non-approved equipment is likely to result in interference to radio and TV reception. The user is cautioned that changes and modifications made to the equipment without the approval of manufacturer could void the user's authority to operate this equipment. USA-6 USA USA-5 Installation Note:Radio stations transmitting in the same frequency range may cause reception interference. Please note that the operating range of the radio signal is limited by legislation as well as by the product design. Wall holder installation • Before installing the wall holder, always ensure that the transmitter and receiver are in proper working order. • Mount the holder onto the wall using the two raw plugs and screws provided. General information/Designated use General information The MonoTel-915 handheld transmitter can be used to operate one or more receivers. The MonoTel-915 device is characterised by its user-friendly operation. Designated use The MonoTel-915 may be used to operate roller shutters/sun protection systems only. • Please note that radio-controlled systems may notbe used in areas with a high risk of interference (e.g. hospitals, airports). • The remote control is intended solely for use with equipment and systems in which malfunctions in the handheld transmitter or receiver would not pose any risk to persons, animals or property or which contain safety devices to eliminate such risks. • The operator is not protected from interference from other telecommunications systems and terminal equipment (e.g. even from radio-controlled systems which are properly operated in the same frequency range). • Radio receivers may only be used in combination with equipment and sys…

Text truncated - open the document above for the full version.

Mr. Fujimoto: In order for processing of this application (FCC ID: T64282000902) to continue, the following issue(s) will have to be addressed: 1) The grantee code used on the application is invalid for the applicant. 2) An invalid grantee code is used on the FCC ID. 3) The phrase “FCC ID:” and the FCC ID itself must be on the same line. 4) The signed copy of the test report needs to be submitted. 5) The modification mentioned in the report does not appear to be complete. Please list the entire modification that was performed. 6) The spurious emissions data from 6.3 GHz to 9.3 GHz was not submitted. Please submit. 7) A modification letter was not submitted. 8) FYI – It should be noted that the FCC ID is permitted to be located in the battery compartment only if the it is visible when it is initially removed from its packaging, for instance if the device is sold with the batteries and battery cover removed. The item(s) indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Please upload responses and/or exhibits to the electronic filing website. Your correspondence number is T64282000902-1.

Correspondence by Project Project Number: Correspondence Number Memo T64282200902-1 1) The grantee code used on the application is invalid for the applicant. Response: The 731 form has been revised to show correct grantee code. 2) An invalid grantee code is used on the FCC ID. Response: The correct label has been uploaded to sow the correct grantee code 3) The phrase “FCC ID:” and the FCC ID itself must be on the same line. Response: the label has been revised to show the FCC ID on the same line. 4) FYI – It should be noted that the FCC ID is permitted to be located in the battery compartment only if the FCC ID is visible when it is initially removed from its packaging. Response: Noted. Correspondence Number Memo T64282000902-1 1) The grantee code used on the application is invalid for the applicant. Response: the grantee code has been revised on the application. 2) An invalid grantee code is used on the FCC ID. Response: The FCC ID Label has been revised. 3) The phrase “FCC ID:” and the FCC ID itself must be on the same line. Response: The FCC ID Label has been revised. 4) The signed copy of the test report needs to be submitted. Response: The test report has been signed. 5) The modification mentioned in the report does not appear to be complete. Please list the entire modification that was performed. Response: The modification page has been revised to show the exact location of the modification. 6) The spurious emissions data from 6.3 GHz to 9.3 GHz was not submitted. Please submit. Response: The test report has been revised to include this data -- which was accidently omitted. 7) A modification 1034598410 letter was not submitted. Response: The modification letter has been uploaded. 8) FYI – It should be noted that the FCC ID is permitted to be located in the battery compartment only if the it is visible when it is initially removed from its packaging, for instance if the device is sold with the batteries and battery cover removed. Response: Noted

P FCC ID: UFJ282000902This device complies with Part 15 of the FCC Rules.Operation is subject to the following two conditions:(1) This device may not cause harmful interference and(2) this device must accept any interference received, including interference that may cause undesired operation. + AAA - - AAA + FCC ID: UFJ282000902 The MonoTel Transmitter is a Handheld transmitter with FSK modulation at 915.3 Mhz. It is battery powered and has a loop type antenna soldered to the printed circuit board. It is used to activate a receiver/motor control to operate a reversible motor used in window covering applications such as rolling shutters and retractable awnings. FCC ID: UFJ282000902 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation.

Report Number: B60317B1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: MonoTel-915 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 16 FCC PART 15, SUBPART B and C TEST REPORT for TRANSMITTER MODEL: MonoTel-915 Prepared for ELERO USA, INC. 10827 ALDER CIRCLE DALLAS, TEXAS 75238 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ JAMES ROSS COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: APRIL 11, 2006 REPORT APPENDICES TOTAL BODY A B C D E PAGES 16 2 2 2 12 9 43 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B60317B1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: MonoTel-915 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 16 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description Of Test Configuration - EMI 8 4.1.1 Cable Construction and Termination 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 5.2 EMI Test Equipment 11 6. TEST SITE DESCRIPTION 12 6.1 Test Facility Description 12 6.2 EUT Mounting, Bonding and Grounding 12 7. TEST PROCEDURES 13 7.1 Conducted Emissions Test 13 7.2 Radiated Emissions (Spurious and Harmonics) Test 14 7.3 Radiated Emissions (Spurious and Harmonics) Test (continued) 15 8. CONCLUSIONS 16 Report Number: B60317B1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: MonoTel-915 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 16 LIST OF APPENDICES APPENDIX TITLE A Laboratory Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams, Charts, and Photos • Test Setup Diagrams • Radiated Emissions Photos • Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Plot Map And Layout of Radiated Site Report Number: B60317B1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: MonoTel-915 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 16 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: Transmitter Model: MonoTel-915 S/N: N/A Product Description: See Expository Statement Modifications: The EUT was modified in order to meet the specifications. Please see the list located in Appendix B of this test report. Manufacturer: Elero USA, Inc. 10827 Alder Circle Dallas, Texas 75238 Test Dates: March 9 and 10, 2006 Test Specifications : EMI requirements CFR Title 47, Part 15 Subpart B; and Subpart C, Sections 15.205, 15.209 and 15.249 Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz - 30 MHz This test was not performed because the EUT is battery powered only and does not connect to the AC public mains. 2 Radiated RF Emissions, 10 kHz - 9300 MHz Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.249. Report Number: B60317B1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: MonoTel-915 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 16 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the Transmitter Model: MonoTel-915. The EMI measurements were performed according to the measurement procedure described in ANSI C63.4. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the Class B specification limits defined by CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.249. Report Number: B60317B1 FCC Part 15 Subpart B and FCC Section 15.249 Test…

Text truncated - open the document above for the full version.
