UFJ283000902Transmitter

309103 01 MemoTec-915 Operating instructions Please keep these instructions in a safe place ! Nr. 18 100.5701/0706 USA el ero elero USA 10827 Alder Circle USA-Dallas Texas 75238 [email protected] elero GmbH Antriebstechnik Linsenhofer Str. 59–63 D-72660 Beuren [email protected] www.elero.com Safety instructions USA-2 Important safety instructions ! Always observe the following instructions. • For use in dry rooms only. • Use unmodified elerooriginal parts only. • Keep persons away from the systems guide track. • Keep children away from controls. • Always comply with national stipulations. • Always dispose of used batteries properly. Always replace batteries with identical type (LR 03; AAA). • If the system is controlled by one or more devices, the system guide track must be visible during operation. • The equipment contains small parts that could be swallowed. USA Warning! Safety instructions......................................... USA- 2 Instruction to the user..................................... USA- 3 Explanation of buttons.................................... USA- 4 General information....................................... USA- 5 Designated use............................................. USA- 5 Wall holder installation................................... USA- 6 Explanation of functions.................................. USA- 7 Manual/Automatic sliding switch/Transmission control light, Reset button............................ USA- 7 Intermediate position, ventilation/reverse position USA- 7 24-hr button, Week button............................ USA- 8 Manual operation functions.......................... USA- 8 Automatic operation functions ...................... USA- 8 Programming radio channel settings..................... USA- 9 Programming transmitter/channel................... USA- 9 Programming additional transmitters............... USA-10 Intermediate position for roller shutter/venetian blindUSA- 11 Programming intermediate position................. USA- 11 Programming ventilation/reverse position.......... USA- 11 Adjustment to intermediate position................ USA-12 Adjustment to ventilation/reverse position......... USA-12 Deleting intermediate position....................... USA-12 Deleting ventilation/reverse position................ USA-12 Deleting radio channel settings........................... USA-13 Deleting individual transmitters..................... USA-13 Deleting all transmitters.............................. USA-13 Programming daily switching times...................... USA-14 UP control command/DOWN control command/ Deleting commands................................... USA-14 Programming weekly switching times................... USA-15 UP control command/DOWN control command/ Deleting commands................................... USA-15 Technical data.............................................. USA-16 Battery replacement....................................... USA-16 Cleaning.................................................... USA-17 Troubleshooting............................................ USA-17 General declaration of conformity........................ USA-17 Contents USA-1 USA-4 USA USA-3 Explanation of buttons LR03 (AAA) -- Programming button P week MemoTec-868 24h Pos Reset Pos POS button POS button 24 hr button Week button Reset button Explanation of buttons Buttons under the cover Programming switch (located on back of device) Control light Cover Manual/Automatic sliding switch DOWN button STOP button UP button Instruction to the user This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. Operation with non-approved equipment is likely to result in interference to radio and TV reception. The user is cautioned that changes and modifications made to the equipment without the approval of manufacturer could void the user's authority to operate this equipment. USA-6 USA USA-5 Installation Wall holder installation • Before installing the wall holder, always ensure that the transmitter and receiver are in proper working order. • Mount the holder onto the wall using the two screws provided. Note:Radio base stations transmitting in the same frequency range may cause reception interference. Please note that the operating range of the radio signal is limited by legislation as well as by the product design. General information/Designated use General information The MemoTec-915 operates your drive at the programmed switching times. The MemoTec-915 device can be operated manually at all times. The MemoTec-915 device is characterised by its user-friendly operation. Designated use The MemoTec-915 may be used to operate roller shutters/venetian blinds only. USA-8 USA USA-7 24 hr button The 24-hourbutton can be used to programme one UP and one DOWN command. These commands are then automatically executed every 24 hours. Week button The weekbutton can be used to programme one UP and one DOWN control command for each week day. These switching commands are then automatically execu…

Text truncated - open the document above for the full version.

Mr. Fujimoto: In order for processing of this application (FCC ID: T64283000902) to continue, the following issue(s) will have to be addressed: 1) The grantee code used on the application is invalid for the applicant. 2) An invalid grantee code is used on the FCC ID. 3) The testing was only done in the battery powered mode, but the user manual mentions that it can be AC powered. Please provide the additional test data to support use in the AC powered mode. 4) Please indicate compliance with the voltage variation requirements of section 15.31(e). The item(s) indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Please upload responses and/or exhibits to the electronic filing website. Your correspondence number is T64283000902-1.

Correspondence by Project Project Number: Correspondence Number Memo T64283000902-1 1) The grantee code used on the application is invalid for the applicant. Respose: the Grantee code has been revised in the application. 2) An invalid grantee code is used on the FCC ID. Response: The FCC ID Label has been revised to show the correct grantee code. 3) The testing was only done in the battery powered mode, but the user manual mentions that it can be AC powered. Please provide the additional test data to support use in the AC powered mode. Response: The unit can only operate in DC powered mode (battery) and the owner's manual has been revised to remove the reference to AC Power. 4) Please indicate compliance with the voltage variation requirements of section 15.31(e). Response: The unit can only operate on DC power (see item #3) 1584512717

FCC ID: UFJ283000902 The MemoTec Transmitter is a wall mounted transmitter with FSK modulation at 915.3 Mhz. It is battery powered and has a loop type antenna soldered to the printed circuit board. It is used to activate a receiver/motor control to operate a reversible motor used in window covering appli- cations such as rolling shutters and retractable awnings. It includes a basic timer for automatic operation. 915 MHz FCC ID:UFJ283000902

Report Number: B60310B1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: MemoTec-915 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 16 FCC PART 15, SUBPART B and C TEST REPORT for TRANSMITTER MODEL: MemoTec-915 Prepared for ELERO USA, INC. 10827 ALDER CIRCLE DALLAS, TEXAS 75238 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ JAMES ROSS COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: APRIL 11, 2006 REPORT APPENDICES TOTAL BODY A B C D E PAGES 16 2 2 2 12 5 39 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B60310B1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: MemoTec-915 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 16 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description Of Test Configuration - EMI 8 4.1.1 Cable Construction and Termination 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 5.2 EMI Test Equipment 11 6. TEST SITE DESCRIPTION 12 6.1 Test Facility Description 12 6.2 EUT Mounting, Bonding and Grounding 12 7. TEST PROCEDURES 13 7.1 Conducted Emissions Test 13 7.2 Radiated Emissions (Spurious and Harmonics) Test 14 7.3 Radiated Emissions (Spurious and Harmonics) Test (continued) 15 8. CONCLUSIONS 16 Report Number: B60310B1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: MemoTec-915 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 16 LIST OF APPENDICES APPENDIX TITLE A Laboratory Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams, Charts, and Photos • Test Setup Diagrams • Radiated Emissions Photos • Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Plot Map And Layout of Radiated Site Report Number: B60310B1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: MemoTec-915 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 16 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: Transmitter Model: MemoTec-915 S/N: N/A Product Description: See Expository Statement Modifications: The EUT was not modified in order to meet the specifications. Manufacturer: Elero USA, Inc. 10827 Alder Circle Dallas, Texas 75238 Test Date: March 17, 2006 Test Specifications : EMI requirements CFR Title 47, Part 15 Subpart B; and Subpart C, Sections 15.205, 15.209 and 15.249 Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz - 30 MHz This test was not performed because the EUT is battery powered only and does not connect to the AC public mains. 2 Radiated RF Emissions, 10 kHz - 9300 MHz Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.249. Report Number: B60310B1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: MemoTec-915 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 16 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the Transmitter Model: MemoTec-915. The EMI measurements were performed according to the measurement procedure described in ANSI C63.4. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the Class B specification limits defined by CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.249. Report Number: B60310B1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: MemoTec-915 Brea Division 114 Olinda Dr…

Text truncated - open the document above for the full version.
