UFJ283200902Transmitter

Nr. 18 100.5601/0606 AstroTec-915 309104 01 Operating instructions Please keep these instructions in a safe place. USA T imer ist preprogrammed el ero elero USA 10827 Alder Circle USA-Dallas Texas 75238 [email protected] elero GmbH Antriebstechnik Linsenhofer Str. 59–63 D-72660 Beuren [email protected] www.elero.com Contents USA-2 Contents USA-1 USA Safety instructions........................................ USA- 3 Instruction to the user.................................... USA- 4 Explanation of displays and buttons..................... USA- 5 General information....................................... USA- 6 Designated use............................................ USA- 6 Wall holder installation................................... USA- 7 Initial operation........................................... USA- 8 Factory settings ........................................... USA- 8 Light sensors ............................................... USA- 9 Explanation of functions.................................. USA- 9 Manual/Automatic sliding switch.................... USA- 9 Transmission control light, Operating mode ........ USA- 9 OK button, +/- button, MENU button, RESET button USA- 10 Time/date.............................................. USA-10 Programme ............................................ USA- 11 Astro, Astro evening, Individual ...................... USA- 12 Week, Block, Individual, Idle period .................. USA- 13 Switching time, Offset................................ USA-14 Holiday setting, End limit............................ USA- 15 Intermediate position, Ventilation/Reverse, PROG 1 + 2 ............................................. USA-16 Language selection, Astro shift, City selection, Longitude/latitude/time zone, Automatic summer/winter time changeover ....... USA- 17 Expert mode............................................ USA-18 Programming radio channel settings.................... USA-19 Programming transmitter/channel................... USA-19 Programming additional transmitters............... USA-20 Deleting individual transmitters..................... USA-20 Deleting all transmitters.............................. USA-20 Programming............................................... USA- 21 Overview of menu..................................... USA- 21 Date and time settings................................ USA- 21 Programme (Setting control commands and idle periods) PROG 1 Astro (Astro function + Idle period vb) Week/Block 1/2/Individual............................ USA-22 PROG 1 Astro evening (Astro evening function + Idle period vb) Week/Block 1/2/Individual........ USA-23 PROG 1 Individual (Individual switching times vb) Week/Block 1/2/Individual............................ USA-25 PROG 2 Individual (Individual switching times vb) Week/Block 1/2/Individual............................ USA-26 PROG 2 Offset (Evening DOWN control command for adjustment to ventilation position)................... USA-28 Setting Holiday function, Light sensor (HOLIDAY menu, Sun/twilight sensor)................................... USA-29 Intermediate position, Ventilation/reverse, PROG 1 End limit, PROG 2 End limit (time/position programming) USA-30 English GB, Astro shift (Language selection, Astro shift)............................................. USA-32 City selection, Expert mode (longitude, latitude, time zone) ............................................. USA-33 Automatic summer/winter time changeover........ USA-34 Function Roller shutter/blind selection, Running time, EXPERT mode, Initial operation....................... USA-35 Technical data.............................................. USA-36 Battery replacement...................................... USA-36 Cleaning.................................................... USA-36 Troubleshooting........................................... USA-37 General declaration of conformity....................... USA-38 Safety instructions USA-3USA-4 Instruction to the user USA Important safety instructions! Always observe the following instructions. • For use in dry rooms only. • Use unmodified elerooriginal parts only. • Keep persons away from the systems guide track. • Keep children away from controls. • Always comply with national stipulations. • Dispose of used batteries properly. Replace batteries with identical type (LR 03/AAA) only. • If the system is controlled by one or more devices, the system guide track must be visible during operation. • The equipment contains small parts that could be swallowed. Warning! This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. Operation with non-approved equipment is likely to result in interference to radio and TV reception. The user is cautioned that changes and modifications made to the equipment without the approval of manufacturer could void the user's authority to operate this equipment. USA-6USA-5 USA General information/Designated use General information The AstroTec-915, delivered from the factory with curre…

Text truncated - open the document above for the full version.

Mr. Fujimoto: In order for processing of this application (FCC ID: T64283200902) to continue, the following issue(s) will have to be addressed: 1) The grantee code used on the application is invalid for the applicant. 2) An invalid grantee code is used on the FCC ID. 3) Please clarify the operation of the device. The test report mentions it is manually activated, but the user manual mentions it can be automatically operated via sensors. 4) A photo of only one side of the EUT was submitted. Please submit additional photos. 5) The FCC ID listed on the 731 form is an invalid FCC ID. The item(s) indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Please upload responses and/or exhibits to the electronic filing website. Your correspondence number is T64283200902-1.

http://www.celectronics.com/CorrespondenceByProject.asp?ProjectNumber=1151445831&Submit=Search Correspondence by Project Project Number: Correspondence Number Memo T64283200902-1 1) The grantee code used on the application is invalid for the applicant. Response: The Grantee code has been revised. 2) An invalid grantee code is used on the FCC ID. Response: The FCC-ID label has been revised. 3) Please clarify the operation of the device. The test report mentions it is manually activated, but the user manual mentions it can be automatically operated via sensors. Resonse: The sensor operates just like a button. (i.e. the sensor receives enough light - it then causes a command telling the shutters to move -- similar to that if a person were to press and then immediately release the button that would cause the shutters to move). 4) A photo of only one side of the EUT was submitted. Please submit additional photos. Response: The external test photo exhibit has been revised to show the additonal photos. The item(s) indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Please upload responses and/or exhibits to the electronic filing website. Your correspondence number is 1151445831 http://www.celectronics.com/CorrespondenceByProject.asp?ProjectNumber=1151445831&Submit=Search T64283200902-1.

915 MHz FCC ID: UFJ283200902 FCC ID: UFJ283200902 The AstroTec Transmitter is a wall mounted transmitter with FSK modulation at 915.3 Mhz. It is battery powered and has a loop type antenna soldered to the printed circuit board. It is used to activate a receiver/motor control to operate a reversible motor used in window covering applications such as rolling shutters and retractable awnings. It includes a multifunction timer and sun sensor for automatic operation.

Report Number: B60315B1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: AstroTec-915 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 16 FCC PART 15, SUBPART B and C TEST REPORT for TRANSMITTER MODEL: AstroTec-915 Prepared for ELERO USA, INC. 10827 ALDER CIRCLE DALLAS, TEXAS 75238 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ JAMES ROSS COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: APRIL 11, 2006 REPORT APPENDICES TOTAL BODY A B C D E PAGES 16 2 2 2 12 5 39 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B60315B1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: AstroTec-915 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 16 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description Of Test Configuration - EMI 8 4.1.1 Cable Construction and Termination 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 5.2 EMI Test Equipment 11 6. TEST SITE DESCRIPTION 12 6.1 Test Facility Description 12 6.2 EUT Mounting, Bonding and Grounding 12 7. TEST PROCEDURES 13 7.1 Conducted Emissions Test 13 7.2 Radiated Emissions (Spurious and Harmonics) Test 14 7.3 Radiated Emissions (Spurious and Harmonics) Test (continued) 15 8. CONCLUSIONS 16 Report Number: B60315B1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: AstroTec-915 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 16 LIST OF APPENDICES APPENDIX TITLE A Laboratory Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams, Charts, and Photos • Test Setup Diagrams • Radiated Emissions Photos • Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Plot Map And Layout of Radiated Site Report Number: B60315B1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: AstroTec-915 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 16 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: Transmitter Model: AstroTec-915 S/N: N/A Product Description: See Expository Statement Modifications: The EUT was not modified in order to meet the specifications. Manufacturer: Elero USA, Inc. 10827 Alder Circle Dallas, Texas 75238 Test Date: March 15, 2006 Test Specifications : EMI requirements CFR Title 47, Part 15 Subpart B; and Subpart C, Sections 15.205, 15.209 and 15.249 Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz - 30 MHz This test was not performed because the EUT is battery powered only and does not connect to the AC public mains. 2 Radiated RF Emissions, 10 kHz - 9300 MHz Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.249. Report Number: B60315B1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: AstroTec-915 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 16 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the Transmitter Model: AstroTec-915. The EMI measurements were performed according to the measurement procedure described in ANSI C63.4. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the Class B specification limits defined by CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.249. Report Number: B60315B1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Transmitter Model: AstroTec-915 Brea Division 114 …

Text truncated - open the document above for the full version.
