Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 October 22, 2007 RE: ATCB005547 FCC ID: UH5M06565 I have a few comments on this application. Depending on your responses, kindly understand there may be additional comments. 1. It is required to show the frequency of oscillators at each block diagram according to FCC 2.1031(5) as follows: “FCC 2.1031 (5) A block diagram showing the frequency of all oscillators in the device. The signal path and frequency shall be indicated at each block. The tuning range(s) and intermediate frequency(ies) shall be indicated at each block.” 2. Please indicate where I may find the 15.21 and 15.105 Information to User statement in the Manual. Below please see 15.21 and 15.105 for your reference. “Section 15.21 Information to user. The users manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.” “Section 15.105 Information to the user. (b) For a Class B digital device or peripheral, the instructions furnished the user shall include the following or similar statement, placed in a prominent location in the text of the manual: NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver.” 3. Please put section 15.19 label requirement to the user manual as your mention in “Label location” PDF file.. “Section 15.19 Labelling requirements: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation” 4. It is required to use RSS-210 issue 7 and RSS-Gen issue 2 as standard for testing the device. Please correct the issue number shown at page 16 ,17 of your test report. z Page 2 October 22, 2007 ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ ~ George Chen ~ mailto:[email protected] ~ Taiwan Mobile: +886 930600123 ~ SKYPE: georgeshirley ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.
1.The revised Block diagram has been uploaded to website. 2.The client has added to last page. 3.Please vide user manual of page 18.(page 5 of PDF file) 4.I have updated test report and IC application form with correct standard version and model number.
American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 October 22, 2007 RE: ATCB005547 FCC ID: UH5M06565 I have a few comments on this application. Depending on your responses, kindly understand there may be additional comments. 1. It is required to show the frequency of oscillators at each block diagram according to FCC 2.1031(5) as follows: “FCC 2.1031 (5) A block diagram showing the frequency of all oscillators in the device. The signal path and frequency shall be indicated at each block. The tuning range(s) and intermediate frequency(ies) shall be indicated at each block.” 2. Please indicate where I may find the 15.21 and 15.105 Information to User statement in the Manual. Below please see 15.21 and 15.105 for your reference. “Section 15.21 Information to user. The users manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.” “Section 15.105 Information to the user. (b) For a Class B digital device or peripheral, the instructions furnished the user shall include the following or similar statement, placed in a prominent location in the text of the manual: NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver.” 3. Please put section 15.19 label requirement to the user manual as your mention in “Label location” PDF file.. “Section 15.19 Labelling requirements: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation” 4. It is required to use RSS-210 issue 7 and RSS-Gen issue 2 as standard for testing the device. Please correct the issue number shown at page 16 ,17 of your test report. z Page 2 October 22, 2007 ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ ~ George Chen ~ mailto:[email protected] ~ Taiwan Mobile: +886 930600123 ~ SKYPE: georgeshirley ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.
1.The revised Block diagram has been uploaded to website. 2.The client has added to last page. 3.Please vide user manual of page 18.(page 5 of PDF file) 4.I have updated test report and IC application form with correct standard version and model number.
Statement in user manual:
Report No.: GLEMR070601681RFT Page: 1 of 17 FCC ID: UH5M06565 Authorized Signature: Jerry Chen Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. This Test Report is issued by the Company subject to its General Conditions of Service printed overleaf. Attention is drawn to the limitations of liability, indemnification and jurisdictional issues defined therein. The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This Test Report cannot be reproduced, except in full, without prior written permission of the Company. Member of the SGS Group (Société Générale de Surveillance) SGS-CSTC Standards Technical Services Ltd. No.198 Kezhu Road, Science Town Economic& Technology Development District Guangzhou, China 510663Telephone: Telephone: +86 (0) 20 82155555 Fax: +86 (0) 20 82075059 Email: [email protected] FEDERAL COMMUNICATIONS COMMISSION Registration number: 282399 TEST REPORT Application No. : GLEMR070601681RF Applicant: National Electronics & Watch Co.Ltd FCC ID: UH5M06565 Frequency Band 2.410GHz and 2.463GHz Equipment Under Test (EUT): Name: Transmitter Model No.: M06565 Trade Mark: MAVIC Standards: FCC PART 15: 2007 Please refer to section 2 for further details. Date of Receipt: 14 June 2007 Date of Test: 14 to 20 June 2007 Date of Issue: 21 June 2007 Test Result : PASS * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Ltd. Report No.: GLEMR070601681RFT Page: 2 of 17 FCC ID: UH5M06565 2 Test Summary Test Test RequirementStanadard Paragraph Result Flied Strength of Fundamental FCC PART 15 :2006 Section 15.249 (a) PASS Flied Strength of Unwanted Emissions FCC PART 15 :2006 Section 15.249 (a) Section 15.249 (d) PASS Occupied Bandwidth FCC PART 15 :2006 Section 15.249 PASS Band Edges FCC PART 15 :2006 Section 15.249 (d) PASS Remark: Tx: In this whole report Tx (or tx) means Transmitter. Rx: In this whole report Rx (or rx) means Receiver. SGS-CSTC Standards Technical Services Ltd. Report No.: GLEMR070601681RFT Page: 3 of 17 FCC ID: UH5M06565 3 Contents Page 1 COVER PAGE ...........................................................................................................................................1 2 TEST SUMMARY ....................................................................................................................................... 2 3 CONTENTS ................................................................................................................................................ 3 4 GENERAL INFORMATION........................................................................................................................ 4 4.1 CLIENT INFORMATION........................................................................................................................... 4 4.2 GENERAL DESCRIPTION OF E.U.T. ........................................................................................................ 4 4.3 DESCRIPTION OF EUT OPERATION........................................................................................................ 4 4.4 STANDARDS APPLICABLE FOR TESTING................................................................................................. 4 4.5 TEST LOCATION.................................................................................................................................... 4 4.6 OTHER INFORMATION REQUESTED BY THE CUSTOMER........................................................................... 4 4.7 TEST FACILITY...................................................................................................................................... 5 5 TEST RESULTS ......................................................................................................................................... 6 5.1 TEST INSTRUMENTS.............................................................................................................................. 6 5.2 E.U.T. OPERATION...............................................................................................................................7 5.3 TEST PROCEDURE & MEASUREMENT DATA............................................................................................ 8 5.3.1 Radiated Emissions ....................................................................................................................... 8 5.3.2 Occupied Bandwidth & Band Edge ........................................................................................12-17 SGS-CSTC Standards Technical Services Ltd. Report No.: GLEMR070601681RFT Page: 4 of 17 FCC ID: UH5M06565 4 General Information 4.1 Client Information Applicant Name: National Electronics & Watch Co.Ltd Applicant Address: 15F., SHING DAO IND.BLOG., 232 ABERDEEN MAIN ROAD, ABERDEEN, HONG KONG 4.2 General Description of E.U.T. Name: Transmitter Model No.: M06565 Trade Mark: MAVIC Power Supply: 3.0V DC (1x”CR2032” cell battery) for Tx and Rx. Power Cord: N/A Emission Designation: F9D 4.3 Description of EUT operation The EUT was a set of equipment: The Tx have 2 frequencies between 2.410GHz to 2.463GHz ,A channel 2.410GHz used for broadcast connection information, another B channel between 2.410GHz and 2.463GHz used for transfer data. A channel is a fixed frequency channel. Before the receiver be found, B frequency will hop between lowest channel to highest channel in the assigned frequenc…
Text truncated - open the document above for the full version.
198 KEZHU Road, SCIENTECH Park · Guangzhou · China
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.41 GHz - 2.46 GHz | - |
