UH5M10-834HR2.4GHz Digital Heart Rate Belt

Model No: M10-843 Model: 2.4GHz Digital Chest Strap Features: The 2.4GHz digital chest strap is designed to pick up heart rate signal from the skin of the chest and converted into digital data. The digital data is transmitted out by 2.4GHz RF signal. Receiver with 2.4GHz receiver can pick up the digital data and displayed on the screen or display. How to Use the 2.4GHz Digital Heart Rate Belt: Wear the Heart Rate Belt on your chest with the sensor over your heart for detection of the heart rate. 1. You will notice that there are two long grooved oval patches on the inside of the heart rate belt. These are the electrode sensors for detecting your heart rate. Before you put on the heart rate belt, wet these patches lightly with water or a conductive gel using your index finger so that the sensors can better detect your heart rate. 2. Open up the belt by unbuckling one of the side clasps that connects the fabric strap to the plastic strap. 3. Wrap the heart rate chest belt across your chest. Adjust the tightness of the strap so that the strap sits snugly and comfortably just below your pectoral muscle. Close the clasp. 4. Check that the wet electrode areas are firmly pressed against your skin and that the logo is in a central upright position. 5. Turn on the Heart Rate Receiver by pushing button and entering the heart rate mode. If a heart rate is detected by the receiver unit, the heart symbol should flash on the receiver display, and your beats per minutes should be displayed on the screen. Trouble Shooting: • If you don’t get your heart rate within 15 seconds when using the Sensor Ring, moisten finger pads and try again. It helps to wear the chest strap for a little while to allow a layer of moisture to build up between the electrodes and your skin. • If you don’t get a continuous readout when using the chest strap, check that strap is properly positioned and fastened. • Body hair or a thin layer of body grease may also interfere with the signal: if you wish to remove body grease, wipe chest and back of chest strap with tissue or soft cloth. • Exercising vigorously with a lot of body movement or body motion can cause “muscle noise” that may prevent chest strap from detecting a HR signal. • In dry or hot climates, you may need to wait a few minutes for a layer of perspiration to form between your skin and your chest strap. To speed this process, moisten electrodes with water or ECG conductive gel. • If your heart rate varies, note that fluctuations are normal in a healthy heart. • If you can’t get a stable readout when using the chest strap, avoid being too close to areas with electrical field interference such as computers, motors & overhead power line • Make sure the battery of the chest strap is not exhausted. FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: · Reorient or relocate the receiving antenna. · Increase the separation between the equipment and receiver. · Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. · Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

National Electronics & Watch Co., Ltd 15/F, Shing Dao Ind. Bldg. 232 Aberdeen Main Road Hong Kong China FCC Authorization Letter Number: CF304 Version: V03 Date: 01-08-2011 We, (the approval holder) Company name National Electronics & Watch Co., Ltd Address 15/F, Shing Dao Ind. Bldg. 232 Aberdeen Main Road City Hong Kong Country China declare that the following representative (agent): Name (person) Ruby Zhang Company name Compliance Certification Services Inc. Address No.10-1 Mingkeda Logistics park, No.18 Huanguan South Road. Guan Lan Town, Baoan District, Shenzhen, China City Shenzhen, Country China is hereby authorized to apply the following equipment for certification on our behalf: Product Description 2.4GHz Digital Chest Strap Type or Model(s) M10-843 Tradename or Brand(s) N/A We also authorize Teleconformity (Mr. M. Koop, Manager Certification, Address: Rietven 31, 7534NH Enschede, the Netherlands) to apply and sign this application for certification, registration or filing on our behalf (as representative agent or certifier).

Report No.: C130118Z01-RP1 Page 1/3 Report No.: C130118Z01-RP1 Page 2/2 .

Project: Model No.: 10-330 Movement: File: Drawer: Date:2012/12/18 1:1 Scale xiao ye PANTONE 877C 100% FCC ID:UH5M10-843HR 100% FCC ID:UH5M10-843HRM10-843 M10-843

Report No.: C130118Z01-RP1 Page 1/4 Report No.: C130118Z01-RP1 Page 2/4 . Report No.: C130118Z01-RP1 Page 3/4 . Report No.: C130118Z01-RP1 Page 4/4 .

Report No: C130118Z01-RP1 FCC ID: UH5M10-843HR Page 1/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. FCC 47 CFR PART 15 SUBPART C for 2.4GHz Digital Chest Strap Model: M10-843 Brand: N/A Test Report Number: C130118Z01-RP1 Issued for National Electronics & Watch Co., Ltd 15/F, Shing Dao Ind. Bldg. 232 Aberdeen Main Road, Hong Kong Issued by: COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. No.10-1, Mingkeda Logistics Park, No.18, Huanguan South Rd., Guan Lan Town, Baoan District, Shenzhen, China TEL: 86-755-28055000 FAX: 86-755-28055221 Issued Date: February 4, 2013 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, A2LA, NVLAP, NIST or any government agencies. The test result of this report relate only to the tested sample identified in this report. Report No: C130118Z01-RP1 FCC ID: UH5M10-843HR Page 2/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Revision History Rev. Issue No. Revisions Effect Page Revised By 00 C130118Z01-RP1 Initial Issue ALL Amay Tang Report No: C130118Z01-RP1 FCC ID: UH5M10-843HR Page 3/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TABLE OF CONTENTS 1 TEST CERTIFICATION ...........................................................................................4 2 EUT DESCRIPTION ................................................................................................5 3 TEST METHODOLOGY ..........................................................................................6 3.1. DESCRIPTION OF TEST MODES.......................................................................................6 4 TEST METHODOLOGY ..........................................................................................7 4.1. EUT EXERCISE ...................................................................................................................7 4.2. FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS............................................7 5 INSTRUMENT CALIBRATION ................................................................................8 6 SETUP OF EQUIPMENT UNDER TEST .................................................................8 6.1. DESCRIPTION OF SUPPORT UNITS .................................................................................8 6.2. CONFIGURATION OF SYSTEM UNDER TEST..................................................................8 7 FACILITIES AND ACCREDITATIONS....................................................................9 7.1. FACILITIES ..........................................................................................................................9 7.2. ACCREDITATIONS ..............................................................................................................9 7.3. MEASUREMENT UNCERTAINTY .......................................................................................9 8 FCC PART 15.249 REQUIREMENTS ...................................................................10 8.1. BAND EDGES MEASUREMENT .......................................................................................10 8.2. POWER LINE CONDUCTED EMISSIONS MEASUREMENT ...........................................16 8.3. SPURIOUS EMISSIONS MEASUREMENT .......................................................................19 Report No: C130118Z01-RP1 FCC ID: UH5M10-843HR Page 4/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 1 TEST CERTIFICATION Product 2.4GHz Digital Chest Strap Model M10-843 Brand N/A Tested January 18~ February 4, 2013 Applicant National Electronics & Watch Co., Ltd 15/F, Shing Dao Ind. Bldg. 232 Aberdeen Main Road, Hong Kong Manufacturer National Electronics & Watch Co., Ltd 15/F, Shing Dao Ind. Bldg. 232 Aberdeen Main Road, Hong Kong APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted DEVIATION FROM APPLICABLE STANDARD None We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4:2009 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209, 15.249. The test results of this report relate only to the tested sample EUT identified in this report. Approved by: Reviewed by: Tom Gan Supervisor of EMC Dept. Compliance Certification Service Inc. Ruby Zhang Supervisor of Report Dept. Compliance Certification Service Inc. Report No: C130118Z01-RP1 FCC ID: UH5M10-843HR Page 5/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 2 EUT DESCRIPTION Product 2.4GHz Digital Chest Strap Model Number M10-843 Trade Name N/A Model Discrepancy N/A Identify Number C130118Z01-RP1 Power Supply DC3.0V supplied by the battery Frequency Range 2411~2469 MHz Transmit Power Peak: 86.53dBuV/m (Max.) Average: 86.32dBuV/m (Max.) Modulation Technique GFSK Number of Channels 68 Channels Antenna Specification Metal Strap Antenna with 0.04dBi gain(MAX) Temperature Range 0°C ~ +55°C Note: 1. The sample selected for test was engineering sample that approximated to production product and was provided by manufacturer. 2. This submittal(s) (test report) is intended for FCC ID: UH5M10-843HR filing to comply with Section 15.207, 15.209 and 15.249 of the FCC Part 15, S…
