1WINTECH USB Ultimate 2010- User GuideThe Mavic team has put all its passion, experience and skill into the design and manufacture of your computer. It will be an important tool for you in the improvement of your performance.Thank you for putting your trust in Mavic products.INSIDE1. PRODUCT DESCRIPTIONINSTALLATION2. INSTALLING THE COMPUTER MOUNT 3. FITTING / REMOVING THE COMPUTER 4. INSTALLING THE SPEED SENSORS 4.1. E-Skewer 4.2. E-Bolt 4.3. Fork Sensor 5. INSTALLING THE WHEEL MAGNET6. INSTALLING THE BATTERIESBASIC NAVIGATION7. DESCRIPTION OF THE DISPLAY 8. FUNCTION DISPLAY DEFAULT SEQUENCE 9. DEFAULT BUTTON FUNCTION MATRIX SETTINGS10. ENTERING THE SET UP MENU 10.1. Heart rate alarm and workzone (Wintech USB HR and Wintech USB Ultimate only) 10.2. DIGITAL PAIRING 10.3. Elevation set up (Wintech USB Alti and Wintech USB Ultimate only) 10.4. Wheel circumferences and distance unit set up 10.5. Clock set up 10.6. Odometers set up USE11. SLEEP MODE12. TRIP RESET13. USE OF LAP TIME (CR)14. ELEVATION SET UP AND DATA REVIEW MENU 14.1. Entering the Elevation set up and data review menu 14.2. Recall of Home Altitude (Wintech USB Alti and Wintech USB Ultimate only) 14.3. Setting up the current elevation (Wintech USB Alti and Wintech USB Ultimate only) 14.4. Trip Altitude and Heart Rate data review (Wintech USB Alti, Wintech USB HR and Wintech USB Ultimate only) 14.5. Lap time data review 14.6. Odometers review 15. VERTICAL SPEED EXPLAINED (Wintech USB Alti and Wintech USB Ultimate only) 16. PC PLUG17. MAINTENANCE AND RECOMMENDATION OF USE18. WINTECH DEVICES TECHNICAL SPECIFICATIONS19. WARRANTY WINTECH MANAGER SOFTWARE20. ENTERING WINTECH MANAGER21. DATA TRANSFER22. TRIPS23. REPORTS24. COMPUTER SETTINGS AND USER ACCOUNT MANAGEMENT 24.1. Create a new user or edit an already existing user 24.2. Screen customization 25. BIKE SETTINGS26. LINKS27. WINTECH MANAGER TECHNICAL SPECIFICATION 2 1. PRODUCT DESCRIPTIONMain Unit Boxa. Computer b. Cardio Belt c. Wintech Manager software CD d. Memo stick Sensor BoxE-Skewere. E-Skewer sensor f. Computer mount g. 25,4mm handlebar reducer h. Wheel magnet E-Bolti. E-Bolt sensor f. Computer mount g. 25,4mm handlebar reducer h. Wheel magnet j. Adjustment magnets Fork Sensork. Fork sensor f. Computer mount g. 25,4mm handlbar reducer h. Wheel magnet l. Zip ties (x3) After installation and before you use your computer for the first time, you MUST perform the digital pairing operation described in section 10.2. of this guide. If you don’t, there will be no communication between the computer and the different sensors and your system will not work. INSTALLATION 2. INSTALLING THE COMPUTER MOUNT2.1 Install the mount on the handlebar, to the right of the stem. To fix it to an oversize, 25.4 diameter handlebar, use the 25.4 adapter. 2.2 The mount can be installed in a variety of positions: with the computer forward of, or above the handlebar stem. 2.3. When setting it, the computer support needs to turn freely on the mount arm. Loosen the screw using a cross-slot screwdriver 2.4. Once you have chosen the right position, tighten the mount screw with a cross-slot screwdriver and secure the computer support screw again. 3. FITTING/REMOVING THE COMPUTER3.1. Slide the computer onto the mount from the front until it locks into place with an audible click. 3.2. To remove the computer from its mount, press and hold the tab located under the computer mount and slide the computer toward the front of the bicycle. wintech manager b a h j k i l c d e g f (x3) 1 2 2.1 2.3 2.4 2.2 3.1 3.2 34. INSTALLING THE SPEED SENSORS4.1 E-SkewerFit the quick-release lever to the hub, with the lever to the left (to the right when using disc brakes). Position of the locking lever Adjust the tension on the adjusting nut so that sufficient force is applied when the locking lever is moved to the “CLOSE” position (consult your retailer). If the quick release lever can be moved too easily to the CLOSE position, there will be insufficient force holding the wheel. If this is the case, place the quick release lever in the OPEN position again and tighten the adjusting nut to increase the force. Then, push again the quick release lever to the CLOSE position.If too much force is needed to move the quick release lever to the CLOSE position, place the lever in the OPEN position again, and unscrew the adjustment nut to reduce the force. Then, push again the quick release lever to the CLOSE position.Once the adjustment nut has been set, the end of the quick release shaft must not be sunk more than 2 mm in from the outside edge of the adjustment nut.Make sure the wheel is securely tightened: raise the front wheel off the ground and strike the top of the wheel sharply in a downward direction. The wheel must remain firmly in place. IMPORTANT: At this point, your computer is not yet ready to work. You still need to set the necessary programs, and then perform the pairing operation of your device. 4.2. E-BoltThe speed sensor is integrated into a fixing nut compatible with all quick-releases on the market. To install it, unscrew the fixing nut on your quick-release. Insert the quick release from the left-hand side of your bike and tighten the electronic fixing nut from the right-hand side. Adjust the tightness of the nut according to the recommendation described in section 4.1 of this user guide.4.2.1 Road bikeOnce sufficiently tightened, position the sensor towards the rear before closing the quick-release.4.2.2. Mountain bike. Once sufficiently tightened, position the sensor towards the top before closing the quick-release. IMPORTANT: At this point, your computer is not yet ready to work. You still need to set the necessary programs, and then perform the pairing operation of your device. 4.3 Fork SensorTo install the Fork sensor, the wheel magnet must be installed first. Read section 5 of this user guide first.Adjust the position of the speed sensor so the center of the magnet is aligned with one of the arrows on the sensor. Th…
