UH5M09155HRHeart Rate Chest Strap 2.4G Transmitter

National Electronics & Watch Co., Ltd
Heart Rate Chest Strap 2.4G Transmitter - FCC ID UH5M09155HR - National Electronics & Watch Co., Ltd
Click to zoom

Application Details

Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant
Sep 05, 2011
Application Purpose
Original Equipment
Date of Application
Sep 05, 2011
Equipment Note
Heart Rate Chest Strap 2.4G Transmitter
Frequency Range
2410.00000000 - 2470.00000000
Company
National Electronics & Watch Co., Ltd
Country
Hong Kong

Documents & Files

Select a file to view

Users Manual

β†—

Cover Letter(s)

β†—

External Photos

β†—

ID Label/Location Info

β†—

Internal Photos

β†—

Test Report

β†—

Test Setup Photos

β†—

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

M09-155 Pair y our Heart Rate monitor: (HRM belt is optional and is sold separately) T he HRM belt is on standby and ready to send data to your watch. Wear the belt directly on your skin just below your breastplate. It should be snug enough to stay in place during your run. 5.1) Push one tab on the strap through t he slot in the HRM transmitter. 5.2) Wet both electrodes with a damp cloth on the back of the HRM belt. This will help create a strong electrical connection between your chest and the HRM transmitter. 5.3) W rap around the chest belt around your rib cage just below the pectoral muscles and attach the other end of the strap to the HRM transmitter. The elastic strap should be adjusted so that it is snug enough so that it will not move duri ng use but not so tight as to restrict breathing. 5.4) Bring the GPS watch within range of the HRM transmitter (3 meters). Go to SET mode/ HRM LINK to start linking the HRM belt with the watch. The watch will auto detect the HR belt ID. Click Yes to accept. The watch will then automatically go to RUN mode. Your Heart rate information will now be displayed in the watch. 5.5) If the heart rat e data does not appear on the watc h, or if you have erratic data, follow the tips below. If the problem persists, you may have to pair the HR belt again. 5.5.1. Make sure the HR belt is snugly fit to your body 5.5.2. Reapply water, saliva, or electrode gel to the electrode of the HR belt 5.5.3. Clean the electrodes from possible contam ination that may interfere with heart rate signals 5.5.4. Wear a cotton shirt or if possible, wet your cotton shirt. Synt hetic fabrics that rubs with your skin may create static elec tricity and interfere with the heart rate signal 5.5.5. Move away from strong electromagnetic fields and other wireless sensors which can interfere with your heart rate sensor. Possible sources of wireless interference may include high voltage power lines, electric motors, microwave ovens, cordless phones, and wireless LAN or access points. Note : Set your Heart rate zone in SET mode. Caution: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rule s. Operation is subject to the following two conditions: (1) This device may not cause harmf ul interference, and (2) T his device must accept any interference received, including inte rference that may cause undesired operation.

Cover Letter(s)

2011-08-10

External Photos

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS EUT – Top View EUT – Bottom View EUT – Side View

ID Label/Location Info

EXHIBIT A - FCC ID LABELING AND LOCATION FCC ID Label FCC ID Label Location Label here The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

Internal Photos

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS EUT – Battery Off View EUT – Cover off View EUT – Main Board Top View EUT – Main Board Bottom View Antenna EUT – Battery View

Test Report

Note: This test report is prepared for the customer shown above and for the equipment described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (Shenzhen). This report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP*, or any agency of the Federal Government. * This report contains data that are not covered by the NVLAP accreditation and are marked with an asterisk β€œβ˜…β€ (Rev.2) FCC PART 15.249 TEST REPORT For National Electronics & Watch Co., Ltd. Shing Dao Ind. Bldg., 232 Aberdeen Main Road, Aberdeen, Hong Kong FCC ID: UH5M09155HR Report Type: Original Report Product Type: Heart Rate Chest Strap 2.4G Transmitter Test Engineer: Jimmy Xiao Report Number: RSZ10110516-00 Report Date: 2011-09-02 Reviewed By: Merry Zhao EMC Engineer Test Laboratory: Bay Area Compliance Laboratories Corp. (Shenzhen) 6/F, the 3rd Phase of WanLi Industrial Building, ShiHua Road, FuTian Free Trade Zone Shenzhen, Guangdong, China Tel: +86-755-33320018 Fax: +86-755-33320008 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.:RSZ10110516-00 FCC Part 15.249 Page 2 of 16 TABLE OF CONTENTS GENERAL INFORMATION.......................................................................................................................................3 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) .....................................................................................3 OBJECTIVE...................................................................................................................................................................3 RELATED SUBMITTAL(S)/GRANT(S).............................................................................................................................3 TEST METHODOLOGY..................................................................................................................................................3 TEST FACILITY.............................................................................................................................................................3 SYSTEM TEST CONFIGURATION ..........................................................................................................................5 JUSTIFICATION.............................................................................................................................................................5 EQUIPMENT MODIFICATIONS.......................................................................................................................................5 BLOCK DIAGRAM OF TEST SETUP................................................................................................................................5 SUMMARY OF TEST RESULTS ...............................................................................................................................6 FCC Β§15.203 - ANTENNA REQUIREMENT.............................................................................................................7 APPLICABLE STANDARD..............................................................................................................................................7 ANTENNA CONNECTOR CONSTRUCTION......................................................................................................................7 FCC Β§15.205, Β§15.209 & Β§15.249 - RADIATED EMISSIONS ..................................................................................8 APPLICABLE STANDARD..............................................................................................................................................8 MEASUREMENT UNCERTAINTY....................................................................................................................................8 TEST EQUIPMENT SETUP..............................................................................................................................................8 EUT SETUP..................................................................................................................................................................9 TEST PROCEDURE........................................................................................................................................................9 CORRECTED AMPLITUDE & MARGIN CALCULATION...................................................................................................9 TEST EQUIPMENT LIST AND DETAILS.........................................................................................................................10 TEST RESULTS SUMMARY..........................................................................................................................................10 TEST DATA................................................................................................................................................................10 FCC Β§15.215(C) – 20 DB EMISSION BANDWIDTH..............................................................................................14 APPLICABLE STANDARD............................................................................................................................................14 TEST EQUIPMENT LIST AND DETAILS.........................................................................................................................14 TEST PROCEDURE......................................................................................................................................................14 TEST DATA................................................................................................................................................................14 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.:RSZ10110516-00 FCC Part 15.249 Page 3 of 16 GENERAL INFORMATION Product Description for Equipment under Test (EUT) The…

Text truncated - open the document above for the full version.

Test Setup Photos

EXHIBIT D - TEST SETUP PHOTOGRAPHS Radiated Emissions Test View (Below 1 GHz) Radiated Emissions Test View (Above 1 GHz)

Contact Information

Applicant

Alfred Ma(General Manager)
[email protected]+852-25541151Fax: +852-28731737

Test Firm

Bay Area Compliance Laboratory Corp. (Shenzhen)John Chan
[email protected]08675533320018Fax: 08675533320008

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.41 GHz - 2.47 GHz-
