ETS PRODUCT SERVICE AG TEST - REPORT FCC PART 15 D for Isochronous UPCS devices RSS-213 for LE-PCS devices FCC ID: UOU69135RFP32U-01 IC ID: 1884E-69135000 Test report no.: G0M20608-0762-C-1 Certificate 1983.01 ETS STORKOWER STRASSE 38C, D-15526 REICHENWALDE B. BERLIN PRODUCT SERVICE AG PHONE +49-33631-888 00 FAX +49-33631-888 66 ETS Product Service AG Registration number: G0M20608-0762-C-1 Page 1 of 54 TABLE OF CONTENTS 1 General information 1.1 Notes 1.2 Testing laboratory 1.3 Details of approval holder 1.4 Application details 1.5 Test item 1.6 Test standards 2 TECHNICAL TEST 2.1 Summary of test results 2.2 Test environment 2.3 Test equipment utilized 2.4 Examinations and Test Procedures 3 RESULTS OF EXAMINATIONS AND TESTS 3.1. Examinations and Test Procedures 3.1.1 Coordination with fixed microwave service, FCC 15.307 (b) 3.1.2 Reference to Subpart B, FCC 15.309 (b) 3.1.3 Conducted limits AC Power line, FCC 15.315, 15.207; RSS-213 4.2; 6.3 3.1.4 Antenna requirement, FCC 15.317, 15.203 3.1.5 Modulation techniques, FCC 15.319 (b); RSS-213 6.1 3.1.6 Emission bandwidth, FCC 15.323 (a); FCC 15.31 (e); RSS-213 6.4 3.1.7 Peak Transmit Power, FCC 15.319 (c); RSS-213 4.3.1, 6:5 3.1.8 Power spectral density, FCC 15.319 (d); RSS-213 4.3.1, 6:6 3.1.9 Directional gain of the antenna, FCC 15.319 (e); RSS-213 4.1 (e) 3.1.10 Automatic discontinuation of transmission, FCC 15.319 (f); RSS-213 4.3.4 (a) ETS Product Service AG Registration number: G0M20608-0762-C-1 Page 2 of 54 3.1.11 Radio frequency radiation exposure, FCC 15.319 (i); RSS-Gen 5.5 3.1.12 Monitoring threshold; Least interfered channel; FCC 15.323 (c)(2); (c)(5) (c)(9); RSS-213 4.3.4 (b)(2) 3.1.13 Monitoring of intended transmit window and maximum reaction time, FCC 15.323 (c)(1); RSS-213 4.3.4 (b)(1) 3.1.14 Monitoring bandwidth, FCC 15.323 (c)(7); RSS-213 4.3.4 (b)(7) 3.1.15 Random waiting interval, FCC 15.323 (c)(6); RSS-213 4.3.4 (b)(6) 3.1.16 Duration of transmission, FCC 15.323 (c)(3); RSS-213 4.3.4 (b)(3) 3.1.17 Connection acknowledgement, Unacknowledged transmissions, FCC 15.323 (c)(4); RSS-213 4.3.4 (b)(5) 3.1.18 Selected channel confirmation, Segment occupancy; FCC 15.323 (c)(5) 3.1.19 Monitoring antenna, FCC 15.323 (c)(8); RSS-213 4.3.4 (b)(8) 3.1.20 Duplex connections, FCC 15.323 (c)(10); RSS-213 4.3.4 (b)(10) 3.1.21 Alternative monitoring interval for co-located devices, FCC 15.323 (c)(11); RSS-213 4.3.4 (b)(11) 3.1.22 Fair access to spectrum related to (c)(10) and (c)(11), FCC 15.323 (c)(12); RSS-213 4.3.4 (b)(12) 3.1.23 Emissions inside and outside the sub-band, FCC 15.323 (d); RSS-213 6.7 3.1.24 Frame period, FCC 323 (e); RSS-213 4.3.(c). 3.1.25 Frequency stability, FCC 323 (f); RSS-213 6.8 3.1.26 Receiver spurious emissions; RSS-213 6.8 ETS Product Service AG Registration number: G0M20608-0762-C-1 Page 3 of 54 1 General Information 1.1 Notes The purpose of conformity testing is to increase the probability of adherence to the essential requirements or conformity specifications, as appropriate. The complexity of the technical specifications, however, means that full and thorough testing is impractical for both technical and economic reasons. Furthermore, there is no guarantee that a test sample which has Passed all the relevant tests conforms to a specification. Neither is there any guarantee that such a test sample will interoperate with other genuinely open systems. The existence of the tests nevertheless provides the confidence that the test sample possesses the qualities as maintained and that is performance generally conforms to representative cases of communications equipment. The test results of this test report relate exclusively to the item tested as specified in 1.5. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the ETS PRODUCT SERVICE AG. Specific Conditions: Usage of the hereunder tested device in combination with other integrated or external antennas requires at least additional output power measurements, spurious emission measurements, conducted emission measurements (AC supply lines) and radio frequency exposure evaluations for each individual configuration are performed, for certification by competent authorities FCC; IC. This report is related to FCC Part 15 D applied to UPCS devices of which technology is derived from DECT standard. Additional this report covers the requirement of RSS-213, 2 GHz Licence exempt Personal Communications Services Devices (LE-PCS) released by Industry Canada (IC). In following the term UPCS covers the term LE-PCS too. Tester: 13.12.2006 W. Treffke Date ETS-Lab. Name Signature Technical responsibility for area of testing: 13.12.2006 N. Kaspar Date ETS Name Signature ETS Product Service AG Registration number: G0M20608-0762-C-1 Page 4 of 54 1.2 Testing laboratory 1.2.1 Location ETS PRODUCT SERVICE AG Storkower Str. 38c 15526 Reichenwalde b. Berlin Germany Telephone: + 49 33631 888-00 Telefax:: + 49 33631 888-660 E-mail: [email protected] 1.2.2 Details of accreditation status A CCREDITED TESTING LABORATORY DAR-REGISTRATION NUMBER: DAT-P-201/96 A CCREDITED COMPETENT BODY REGISTRATION NUMBER: BNetzA-zS-026/96 FCC FILED TEST LABORATORY REG. NO. 96970 Bluetooth Qualification Test Facility (BQTF) Accredited by Bluetooth Qualification Review Board (BQRF) I NDUSTRY CANADA FILED TEST LABORATORY REG. NO. IC 3470 A2LA ACCREDITED Certificate Number: 1983.01 1.2.3 Test location, where different from ETS ELECTRONIC TECHNOLOGY SYSTEM DR. GENZ GMBH (ETS) Storkower Straße 38c D-15526 Reichenwalde b. Berlin Germany Telefon : +49 33631 888 00 Telefax : +49 33631 888 66 ETS Product Service AG Registration number: G0M20608-0762-C-1 Page 5 of 54 1.3 Details of approval holder Name : DeTeWe Systems GmbH Street : Zeughofstr. 1 Town : 10997 Berlin Country : Germany Telephone : 030/6104 5329 Fax : 030/6104 4521 Contact : Herr Gerhard Hofmann Telephone : 030/6104 5329 E-mail : [email protected] …
