UP2AWA24UAWAC24U WIRELESS USB DONGLE

AWAC24U User Manual DSAWAC24U -DSSS USB Radio Dongle UMAWAC24U Rev 1v0 October 25, 2010 2.4GHz DSSS USB Radio Dongle AWAC24U User Manual Wireless USB Radio Dongle Installation 1. Plug in the Artaflex USB dongle to any USB port, you will see the following message . 2. Once asked for the drivers please select “Install from a specific location” then Browse and select the USB driver. Artaflex Inc. UMAWAC24U Rev 1v0 215 Konrad Crescent October 25, 2010 Markham, Ontario, Canada L3R8T9 Page 2 of 4 http://www.artaflexmodules.com 905-479-0148 3. When asked for device selection please select “Artaflex USB to RF dongle” from the list 2.4GHz DSSS USB Radio Dongle AWAC24U User Manual 4. Once it is successfully installed, you will find the following message. FCC Statement One of the bottlenecks that many product developers encounter in incorporating any radio communication device is facing the legal aspect of qualifying the products and going to market without encountering legal problems. The Telecommunication Certification Body (TCB) authorization process in the United States offers manufacturers more than one approval body. The TCB authorization process certifies devices in accordance with FCC rules and policies. The performance of the Artaflex AWP24U radio is measured according to the requirements of FCC rules. The major applicable FCC regulations are described in Section 15.247 (a) to (d). Artaflex Inc. UMAWAC24U Rev 1v0 215 Konrad Crescent October 25, 2010 Markham, Ontario, Canada L3R8T9 Page 3 of 4 http://www.artaflexmodules.com 905-479-0148 2.4GHz DSSS USB Radio Dongle AWAC24U User Manual Artaflex Inc. UMAWAC24U Rev 1v0 215 Konrad Crescent October 25, 2010 Markham, Ontario, Canada L3R8T9 Page 4 of 4 http://www.artaflexmodules.com 905-479-0148 This equipment has been tested and found to comply with the limits for a Class B digital device, Pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Consult the dealer or an experienced radio/TV technician for help Any changes or modification not expressly approved by the party responsible for compliance could void the user's authority to operate the device. Where shielded interface cables have been provided with the product or specified additional components or accessories elsewhere defined to be used with the installation of the product, they must be used in order to ensure compliance with FCC regulations. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

2.4GHz DSSS USB Radio with Integrated Chip Antenna AW AC24U Block Diagram Artaflex Inc. BDAWAC24U Rev 1v0 215 Konrad Crescent October 25, 2010 Markham, Ontario, Canada L3R8T9 Page 1 of 1 http://www.artaflexmodules.com (905) 479-0148 CYRF7936 Simplified Block Diagram Radio Chip Radio Frequency Table • RF Output Range: 2.402 GHz – 2.479 GHz • Crystal: 12MHz

ELECTRONICS MANUFACTURING AND DESIGN Artaflex Inc. TEL: 905.479.0148 215 Konrad Crescent FAX: 905.479.0149 FRM-00002 Rev. 1.0 Markham, ON L3R8T9Canada www.artaflex.com October 26, 2010 Federal Communications Commission Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Gentlemen: This is your letter of authorization to accept our appointment of Global EMC Inc, a consulting and testing laboratory to act as Agent for Artaflex Inc., 215 Konrad Crescent Unit #2, Markham, Ontario, L3R 8T9, to sign applications before the Commission and to make representations to you on our behalf. Global EMC Inc is to receive and exchange data between our company and the Commission. This appointment is affective until otherwise notified by Artaflex Inc. It is our intention to provide the commission with a full disclosure of our product so that its merits can be evaluated. Indeed, we are pleased to provide any further information that the commission might wish to see. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. The Applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 USC 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. Thank you for your attention. Please contact Artaflex Inc. if the Commission requires further information. Sincerely, _________________________ Wayne Embree Design Services Manager Artaflex Inc.

Artaflex Inc. 215 Konrad Crescent Markham, Ontario, Canada L3R8T9 Page 1 of 1 (905) 479-0148 http://www.artaflex.com Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: December 20, 2010 SUBJECT: FCC Application for FCCID# UP2AWA24U To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite filing. Regards, _________________________ Wayne Embree Design Services Manager Artaflex Inc.

ELECTRONICS MANUFACTURING AND DESIGN Artaflex Inc. TEL: 905.479.0148 215 Konrad Crescent FAX: 905.479.0149 FRM-00002 Rev. 1.0 Markham, ON L3R8T9Canada www.artaflex.com October 26, 2010, Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Confidentiality Request regarding application for certification of FCC ID: UP2AWA24U Dear Examiner: I am writing to avoid the possibility of an inadvertent disclosure of proprietary information. Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name PCB film layer drawings CONF UP2AWA24U – PCB.PDF Bill of Material (Parts List) CONF UP2AWA24U – Parts.PDF Schematics CONF UP2AWA24U – Schem.PDF The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to Artaflex Inc. and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application Thank you for your attention. Please contact Artaflex Inc. if the Commission requires further information. Sincerely, _________________________ Wayne Embree Design Services Manager Artaflex Inc.

AWAC24U External Photos

Artaflex Wireless Modules Model No: AWAC24U FCC ID: UP2AWA24U IC: 6797A-AWA24U CANADA FCC Label Artwork Scale 5: 1

Top Surface Bottom Surface FCC Label Location Artaflex Wireless Modules Model No: AWP24U FCC ID: UP2AWP24U IC: 6797A-AWP24U CANADA

ELECTRONICS MANUFACTURING AND DESIGN Artaflex Inc. TEL: 905.479.0148 215 Konrad Crescent FAX: 905.479.0149 FRM-00002 Rev. 1.0 Markham, ON L3R8T9Canada www.artaflex.com AWAC24U Module photos

2.4GHz DSSS USB Radio Circuit Description AWAC24U Circuit Details Artaflex Inc. CDAWAC24U Rev 1v0 215 Konrad Crescent October 25, 2010 Markham, Ontario, Canada L3R8T9 Page 1 of 2 http://www.artaflexmodules.com (905) 479-0148 Circuit Details The AWAC24U Module provides a complete USB to RF antenna wireless MODEM. The module is designed to implement wireless device links operating in the worldwide 2.4-GHz ISM frequency band. It is intended for systems compliant with world-wide regulations covered by ETSI EN 301 489-1 V1.41, ETSI EN 300 328-1 V1.3.1 (Europe), FCC CFR 47 Part 15 (USA and Industry Canada) and TELEC ARIB(Japan). The module contains a 2.4-GHz 1-Mbps GFSK radio transceiver, packet data buffering, packet framer, DSSS baseband controller, Received Signal Strength Indication (RSSI), and SPI interface for data transfer and device configuration. The radio supports 98 discrete 1-MHz channels (regulations limit the use of some of these channels in certain jurisdictions, check datasheets or contact Artaflex for more details). In DSSS modes the baseband performs DSSS spreading/de-spreading, while in GFSK Mode (1 Mb/s - GFSK) the baseband performs Start of Frame (SOF), End of Frame (EOF) detection and CRC16 generation and checking. The baseband may also be configured to automatically transmit Acknowledge (ACK) handshake packets whenever a valid packet is received. When in receive mode, with packet framing enabled, the device is always ready to receive data transmitted at any of the supported bit rates, except SDR, enabling the implementation of mixed-rate systems in which different devices use different data rates. This also enables the implementation of dynamic data rate systems, which use high data rates at shorter distances and/or in a low-moderate interference environment, and change to lower data rates at longer distances and/or in high interference environments . Figure 1 - Module Block Diagram 2.4GHz DSSS USB Radio Circuit Description AWAC24U Circuit Details Artaflex Inc. CDAWAC24U Rev 1v0 215 Konrad Crescent October 25, 2010 Markham, Ontario, Canada L3R8T9 Page 2 of 2 http://www.artaflexmodules.com (905) 479-0148 Figure 2 - Radio Chip Simplified Block Diagram The radio network stack runs on an Encore III Microcontroller chip by cypress. Encore III support full speed USB and connect to the PC to receive data from user application. Encore III communicate with the radio using a SPI bus interface. Encore III runs on 5V, and needs no external oscillator. An onboard regulator step down the DC power to 3.3V for the Radio Chip. The unpopulated J2 header can be used to power and debug the hardware, with few software modifications. The Radio crystal runs at 12MHz to provide reference to the internal synthesizer. A tactile switch is provided to bind the radio to other hosts in the CiFy network. It can be programmed for any other operation as well.

Global EMCScott Dry Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radi a R = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal:18.8(dBm) Maximum peak output power at antenna input terminal:75.9(mW) Antenna gain(typical):2.0(dBi) Maximum antenna gain:1.6(numeric) Time Averaging (Duty Cycle):25.0(%) Prediction distance:2.0(cm) Prediction frequency:2480.0(MHz) Power output (Duty cycle corrected)19.0 (mW) Power output (Duty cycle corrected)12.8(dBm) MPE limit for uncontrolled exposure at prediction frequency:1.0(mW/cm^2) Power density at prediction frequency:0.597957(mW/cm^2) 2 4R PG S π = Margin of compliance:-2.2(dB) This equates to5.97957274W/m^2PASS For informationThis equates to47.4794579 V/m Note: This device does not exceed the 60 / f (GHz) in mW limit as per FCC KDB 447498 2(a)(i), so it is allowable to be used in portable exposure conditions with no restrictions on host platforms Although the device duty cycle measured was 1% a worst case duty cycle of 25% was applied 2 4R PG S π =

LAB REGISTRATION #6844A-1 FCC REGISTRATION #612361 Testing Laboratory Certificate #2555.01 Page 1 of 68 Report issue date: 12/20/2010 GEMC File #:GEMC-FCC-19880R2 © Global EMC Inc. This test report shall not be reproduced except in full, without written approval of Global EMC Inc. This report is based on GEMC Template “FCC 15 247 Rev2.” Global EMC Inc. Labs EMC & RF Test Report As per RSS 210 Issue 7:2007 & FCC Part 15 Subpart C:2010 Unlicensed Intentional Radiators on the Artaflex Wireless Radio Module (AWAC24U) Scott Drysdale, Narte Certified Technician EMC Lab Manager Global EMC Inc. 180 Brodie Dr, Unit 2 Richmond Hill, ON L4B 3K8 Canada Ph: (905) 883-3919 Testing produced for See Appendix A for full customer & EUT details . Client Artaflex Product AWAC24U Standard(s) RSS 210 Issue 7:2007 / FCC Part 15 Subpart C 15:2010 Page 2 of 68 Report issue date: 12/20/2010 GEMC File #: GEMC-19880R2 © Global EMC Inc. This test report shall not be reproduced except in full, without written approval of Global EMC Inc. Table of Contents Table of Contents ................................................................................................................... 2 Report Scope .......................................................................................................................... 3 Summary ................................................................................................................................ 4 Test Results Summary ....................................................................................................... 5 Justifications, Descriptions, or Deviations......................................................................... 6 Applicable Standards, Specifications and Methods ........................................................... 7 Sample calculation(s) ......................................................................................................... 8 Document Revision Status ................................................................................................. 8 Definitions and Acronyms ..................................................................................................... 9 Testing Facility .................................................................................................................... 10 Calibrations and Accreditations ....................................................................................... 10 Testing Environmental Conditions and Dates ................................................................. 11 Detailed Test Results Section .............................................................................................. 12 Power Line Conducted Emissions ................................................................................... 13 Radiated Emissions .......................................................................................................... 19 6dB Bandwidth of Digitally Modulated Systems ............................................................ 37 Maximum Peak Envelope Conducted Power .................................................................. 41 Spurious Conducted Emissions........................................................................................ 46 Power Spectral Density .................................................................................................... 54 Maximum Permissible Exposure ..................................................................................... 57 Appendix A – EUT Summary.............................................................................................. 63 Appendix B – EUT and Test Setup Photographs................................................................. 64 Client Artaflex Product AWAC24U Standard(s) RSS 210 Issue 7:2007 / FCC Part 15 Subpart C 15:2010 Page 3 of 68 Report issue date: 12/20/2010 GEMC File #: GEMC-19880R2 © Global EMC Inc. This test report shall not be reproduced except in full, without written approval of Global EMC Inc. Report Scope This report addresses the EMC verification testing and test results of the AWAC24U, herein referred to as EUT (Equipment Under Test) performed at Global EMC Labs. The EUT was tested for compliance against the following standards: RSS 210 Issue 7:2007 / FCC Part 15 Subpart C 15:2010 Test procedures, results, justifications, and engineering considerations, if any, follow later in this report. The results contained in this report relate only to the item(s) tested. This report does not imply product endorsement by A2LA or any other accreditation agency, any government, or Global EMC Inc. Opinions/interpretations expressed in this report, if any, are outside the scope of Global EMC Inc accreditation. Any opinions expressed do not necessarily reflect the opinions of Global EMC Inc, unless otherwise stated. Client Artaflex Product AWAC24U Standard(s) RSS 210 Issue 7:2007 / FCC Part 15 Subpart C 15:2010 Page 4 of 68 Report issue date: 12/20/2010 GEMC File #: GEMC-19880R2 © Global EMC Inc. This test report shall not be reproduced except in full, without written approval of Global EMC Inc. Summary The results contained in this report relate only to the item(s) tested. EUT FCC Certification #, FCC ID: UP2AWA24U EUT Industry Canada Certification #, IC: 6797A-AWA24U EUT Passed all tests performed. Yes (see test results summary) Tests conducted by Scott Drysdale Client Artaflex Product AWAC24U Standard(s) RSS 210 Issue 7:2007 / FCC Part 15 Subpart C 15:2010 Page 5 of 68 Report issue date: 12/20/2010 GEMC File #: GEMC-19880R2 © Global EMC Inc. This test report shall not be reproduced except in full, without written approval of Global EMC Inc. Test Results Summary Standard/Method Description Class/Limit Result FCC 15.203 Antenna Requirement Unique Pass See Justification FCC 15.205 RSS 210 (Table 1) Restricted Bands for intentional operation QuasiPeak Average Pass FCC 15.207 Power line conducted emissions QuasiPeak Average Pass…

Text truncated - open the document above for the full version.

Radiated Emissions Radiated Emissions Close up Radiated Emissions – 1.5 GHz to 10 GHz Power Line Conducted Emissions Antenna Conducted Emissions
