UP2AWP24UUSB Dongle

AWP24U User Manual DSAWP24U -DSSS USB Radio Dongle UMAWP24U Rev 2v0 Revised Sep 6, 2007 User Manual 2.4GHz DSSS USB Radio Dongle AWP24U Artaflex Inc. UMAWP24U Rev 2v1 215 Konrad Crescent Revised October 4, 2007 Markham, Ontario, Canada L3R8T9 Page 2 of 4 http://www.artaflexmodules.com 905-479-0148 Wireless USB Radio Dongle Installation 1. Plug in the Artaflex USB dongle to any USB port, you will see the following message . 2. Once asked for the drivers please select “Install from a specific location” then Browse and select the USB driver. 3. When asked for device selection please select “Artaflex USB to RF dongle” from the list User Manual 2.4GHz DSSS USB Radio Dongle AWP24U Artaflex Inc. UMAWP24U Rev 2v1 215 Konrad Crescent Revised October 4, 2007 Markham, Ontario, Canada L3R8T9 Page 3 of 4 http://www.artaflexmodules.com 905-479-0148 4. Once it is successfully installed, you will find the following message. FCC Statement One of the bottlenecks that many product developers encounter in incorporating any radio communication device is facing the legal aspect of qualifying the products and going to market without encountering legal problems. The Telecommunication Certification Body (TCB) authorization process in the United States offers manufacturers more than one approval body. The TCB authorization process certifies devices in accordance with FCC rules and policies. The performance of the Artaflex AWP24U radio is measured according to the requirements of FCC rules. The major applicable FCC regulations are described in Section 15.247 (a) to (d). User Manual 2.4GHz DSSS USB Radio Dongle AWP24U Artaflex Inc. UMAWP24U Rev 2v1 215 Konrad Crescent Revised October 4, 2007 Markham, Ontario, Canada L3R8T9 Page 4 of 4 http://www.artaflexmodules.com 905-479-0148 This equipment has been tested and found to comply with the limits for a Class B digital device, Pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Consult the dealer or an experienced radio/TV technician for help Any changes or modification not expressly approved by the party responsible for compliance could void the user's authority to operate the device. Where shielded interface cables have been provided with the product or specified additional components or accessories elsewhere defined to be used with the installation of the product, they must be used in order to ensure compliance with FCC regulations. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

ELECTRONICS MANUFACTURING AND DESIGN Artaflex Inc. TEL: 905.479.0148 215 Konrad Crescent FAX: 905.479.0149 FRM-00002 Rev. 1.0 Markham, ON L3R8T9Canada www.artaflex.com August 31, 2007 Federal Communications Commission Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Gentlemen: This is your letter of authorization to accept our appointment of M.Flom Associates, Inc. a consulting and testing laboratory to act as Agent for Artaflex Inc., 215 Konrad Crescent Unit #2, Markham, Ontario, L3R 8T9, to sign applications before the Commission and to make representations to you on our behalf. M.Flom Associates is to receive and exchange data between our company and the Commission. This appointment is affective until otherwise notified by Artaflex Inc. It is our intention to provide the commission with a full disclosure of our product so that its merits can be evaluated. Indeed, we are pleased to provide any further information that the commission might wish to see. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. The Applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 USC 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. Thank you for your attention. Please contact Artaflex Inc. if the Commission requires further information. Sincerely, _________________________ Wayne Embree Design Services Manager Artaflex Inc.

ELECTRONICS MANUFACTURING AND DESIGN Artaflex Inc. TEL: 905.479.0148 215 Konrad Crescent FAX: 905.479.0149 FRM-00002 Rev. 1.0 Markham, ON L3R8T9Canada www.artaflex.com August 31, 2007, Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Confidentiality Request regarding application for certification of FCC ID: UP2AWP24U Dear Examiner: I am writing to avoid the possibility of an inadvertent disclosure of proprietary information. Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name PCB film layer drawings Artwork: 4-PCB Artwork AWP24U-DSSS USB Radio Dongle.pdf Bill of Material (Parts List) Partslist: 9- BOM - SCH0381B2.pdf Schematics Schematic: 10-Schematic for USB Dongle- SCH0380B2.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to Artaflex Inc. and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application Thank you for your attention. Please contact Artaflex Inc. if the Commission requires further information. Sincerely, _________________________ Wayne Embree Design Services Manager Artaflex Inc.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 October 10, 2007 RE: Artaflex Inc. FCC ID: UP2AWP24U I have a few comments on this Application. 1. Please upload Block Diagram to the Block Diagram exhibit. 2. Please remove the 20 cm statement from the user manual as the EUT is classified as portable. 3. RF Exposure MPE is not needed for this as the power is not over the 60/Frequency limit. FYI for 15.247 all MPE is done at 20 cm. Please see attachment of SAR not Required document. This should be uploaded in place of MPE calculations. The EUT fits in a laptop which if placed in a persons lap will be less that 20 cm. 4. The peak power is rated at +4 dBm which is 0.0025 Watts yet the test report shows only half of the rated power. Please explain. Thank you, Douglas E. Noble Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. z Page 2 October 10, 2007 Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender. The unit is rated at +4 dBm conducted however because the unit has an integrated antenna radiated testing was performed. The maximum radiated power detected was reported. John Subject:Artaflex RT Date:Thu, 11 Oct 2007 12:49:00 -0700 Linked to:Jamie Allan From:JOHNE (John Erhard) <GoldMine User> To:JACKIE (Jackie Pillai) <GoldMine User> Page 1 of 1 10/11/2007file://L:\Project\2007\p0790007\exhibits\answer%20to%20RT.htm

AWP24U External Photos

Artaflex Wireless Modules Model No: AWP24U FCC ID: UP2AWP24U IC: 6797A-AWP24U CANADA FCC Label Artwork Scale 5: 1 Top Surface Bottom Surface FCC Label Location Artaflex Wireless Modules Model No: AWP24U FCC ID: UP2AWP24U IC: 6797A-AWP24U CANADA

ELECTRONICS MANUFACTURING AND DESIGN Artaflex Inc. TEL: 905.479.0148 215 Konrad Crescent FAX: 905.479.0149 FRM-00002 Rev. 1.0 Markham, ON L3R8T9Canada www.artaflex.com AWP24U Module photos

2.4GHz DSSS Wireless USB Dongle AWP24U Data Sheet Artaflex Inc. DSAWP24U Rev 2v2 215 Konrad Crescent Revised October 4, 2007 Markham, Ontario, Canada L3R8T9 Page 1 of 10 http://www.artaflexmodules.com (905) 479-0148 1 Features • The AWP24U is a 2.4-GHz Direct Sequence Spread Spectrum (DSSS) transceiver USB Dongle that includes Cypress radio integrated circuit WirelessUSB™ LP CYRF6936 and CY7C64215 enCoRe III Full Speed USB Controller Chips. • Operates in the unlicensed worldwide Industrial, Scientific and Medical (ISM) band (2.400 GHz–2.483 GHz) • Full speed USB (12Mbps) • USB 2 compliant • Dedicated 256 byte buffer • 40mA operating current (Transmit @ -5 dBm) • Transmit power up to +4 dBm • Receive sensitivity up to –97 dBm • Sleep Current 4-30 μA • Operating range of up to 30m or more. • DSSS data rates up to 250 kbps, GFSK data rate of 1 Mbps • Auto Transaction Sequencer (ATS) - no micro controller intervention • Framing, Length, CRC16, and Auto ACK • Fast Startup and Fast Channel Changes • Separate 16-byte Transmit and Receive FIFOs • AutoRate™ - dynamic data rate reception • Receive Signal Strength Indication (RSSI) • No proprietary software required • Operating voltage 5 volts • Operating temperature from 0 to 70°C • Size: 59mm x 20mm x 11mm including connector • Weight: 5 gm • FCC Part 15, EN 300 328-1, EN 301 489-1, EN 301 489-17 and Industry Canada RSS-210 standards certified. 2 Functional Description The Artaflex AWP24U Wireless USB dongle offers a complete radio module solution for integration into existing or new 2.4- GHz products. The AWP24U is tested for functional operation and is FCC/ETSI (EU) certified. The module is supplied with an integrated chip antenna. The AWP24U is available in a small PCB design and can be connected using the USB Type A / B connector. The pin-out of the USB connector is shown in the USB Connector Pin Information. 3 Applications • PC Human Interface Devices (HID) • Wireless Keyboards and Mice • VoIP and Wireless Headsets • Wireless Gamepads • Remote Control • Consumer • Sports and Leisure Equipment • Remote Controls • Audio Subwoofer • Presenter Tools • Locator Alarms • Toys • Building/Home Automation • Automatic Meter Readers (AMR) • On-Site Paging Systems • Garage door opener • Alarm and Security • Lighting Control • Climate Control • Fan Control • Industrial Control • Active RFID and asset tracking systems • Inventory Management • Point-of-sale systems • Factory Automation • Data Acquisition • USB to Serial • Transportation • Remote Keyless Entry with acknowledgement (RKE) • Airline Baggage Tracking • Diagnostics 2.4GHz DSSS Wireless USB Dongle AWP24U Data Sheet Artaflex Inc. DSAWP24U Rev 2v2 215 Konrad Crescent Revised October 4, 2007 Markham, Ontario, Canada L3R8T9 Page 2 of 10 http://www.artaflexmodules.com (905) 479-0148 Figure 1 - Module Block Diagram 12 MHz Crystal Integrated Antenna BasebandModulationRF Digital Interface J2 Optional Header 3.3V Regulator 5V Switch 3.1 Reference Documentation Technical information such as register settings, timing, application interfaces, clocking, and power management for the Cypress Semiconductor CYRF6936 Wireless USB TM LP 2.4-GHz DSSS Radio System-on-Chip and the CY7C64215 enCoRe TM Full Speed USB Controller are available at www.cypress.com The datasheet for CYRF6936 is available at: http://download.cypress.com.edgesuite.net/design_resources/datasheets/contents/cyrf6936_8.pdf The datasheet for CY7C64215 is available at: http://download.cypress.com.edgesuite.net/design_resources/datasheets/contents/cy7c64215_8.pdf For any firmware or technical details, please visit http://www.artaflexmodules.com/applications.html?cat_id=4 or post your queries at http://www.artaflexmodules.com/contact.html 2.4GHz DSSS Wireless USB Dongle AWP24U Data Sheet Artaflex Inc. DSAWP24U Rev 2v2 215 Konrad Crescent Revised October 4, 2007 Markham, Ontario, Canada L3R8T9 Page 3 of 10 http://www.artaflexmodules.com (905) 479-0148 4 Functional Overview The AWP24U Module provides a complete USB to RF antenna wireless MODEM. The module is designed to implement wireless device links operating in the worldwide 2.4-GHz ISM frequency band. It is intended for systems compliant with world-wide regulations covered by ETSI EN 301 489-1 V1.41, ETSI EN 300 328-1 V1.3.1 (Europe), FCC CFR 47 Part 15 (USA and Industry Canada) and TELEC ARIB_T66_March, 2003 (Japan). The module contains a 2.4-GHz 1-Mbps GFSK radio transceiver, packet data buffering, packet framer, DSSS baseband controller, Received Signal Strength Indication (RSSI), and SPI interface for data transfer and device configuration. The radio supports 98 discrete 1-MHz channels (regulations may limit the use of some of these channels in certain jurisdictions). In DSSS modes the baseband performs DSSS spreading/de-spreading, while in GFSK Mode (1 Mb/s - GFSK) the baseband performs Start of Frame (SOF), End of Frame (EOF) detection and CRC16 generation and checking. The baseband may also be configured to automatically transmit Acknowledge (ACK) handshake packets whenever a valid packet is received. When in receive mode, with packet framing enabled, the device is always ready to receive data transmitted at any of the supported bit rates, except SDR, enabling the implementation of mixed-rate systems in which different devices use different data rates. This also enables the implementation of dynamic data rate systems, which use high data rates at shorter distances and/or in a low- moderate interference environment, and change to lower data rates at longer distances and/or in high interference environments. 4.1 Link Layer Modes The AWP24U module supports the following data packet framing features: SOP – Packets begin with a 2-symbol Start of Packet (SOP) marker. This is required in GFSK and 8DR modes, but is optional in DDR mode and is not supported in SDR mode; if framing is disabled then an SOP event is inferred whenever two successive correlations are detected. The SOP_CODE_ADR code used for…

Text truncated - open the document above for the full version.

Flom Test Labs p0790007, d0790029 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 (866) 311-3268 phone, (480) 926-3598 fax Date: September 28, 2007 Federal Communications Commission Via: Electronic Filing Attention: Authorization & Evaluation Division Applicant: Artaflex, Inc. Equipment: AWP24U FCC ID: UP2AWP24U FCC Rules: Radio Frequency Radiation Exposure Limits 47 CFR 1.1310 MPE - Mobiles X Fixed Based Station Gentlemen: On behalf of the Applicant, enclosed please find the Supplemental Test Data Report, the whole for Environmental Assessment (MPE) of the referenced equipment as shown. We trust the same is in order. Should you need any further information, kindly contact the writer who is authorized to act as agent. Sincerely yours, Hoosamuddin S. Bandukwala, Lab Director Flom Test Labs p0790007, d0790029 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 (866) 311-3268 phone, (480) 926-3598 fax Environmental Assessment for Mobiles for FCC ID: FCC ID: UP2AWP24U Model:AWP24U to Federal Communications Commission 47 CFR 1.1310 (MPE) Radio Frequency Radiation Exposure Limits Date Of Report: September 28, 2007 On the Behalf of the Applicant: Artaflex, Inc. At the Request of: Artaflex, Inc. 215 Konrad Crescent Markham, Ontario L3R8T9 Canada Attention of: Sebastian Palazzo [email protected] (905)479-0148 X292 Supervised By: Hoosamuddin S. Bandukwala, Lab Director Flom Test Labs p0790007, d0790029 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 (866) 311-3268 phone, (480) 926-3598 fax Table of Contents Rule Description Page . Test Report 1 . Identification of the Equipment Under Test 2 . Standard Test Conditions and Engineering Practices 4 1.1310 Environmental Assessment 5 Flom Test Labs p0790007, d0790029 3356 N. San Marcos Place, Suite 107 Page 1 of 5 Chandler, Arizona 85225-7176 (866) 311-3268 phone, (480) 926-3598 fax Required information per ISO 17025-2005, paragraph 5.10: a) Test Report (Supplemental) b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) Flom Test Labs 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d0790029 d) Client: Artaflex, Inc. 215 Konrad Crescent Markham, Ontario L3R8T9 Canada e) Identification: AWP24U FCC ID: UP2AWP24U Description: USB Dongle f) EUT Condition: Not required unless specified in individual tests. g) Report Date: September 28, 2007 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with MFA internal quality manual. m) Supervised by: Hoosamuddin S. Bandukwala, Lab Director n) Results: The results presented in this report relate only to the item tested. o) Reproduction: This report must not be reproduced, except in full, without written permission from this laboratory. Flom Test Labs p0790007, d0790029 3356 N. San Marcos Place, Suite 107 Page 2 of 5 Chandler, Arizona 85225-7176 (866) 311-3268 phone, (480) 926-3598 fax Identification of the Equipment Under Test (EUT) Name and Address of Applicant: Name and Address of Applicant: Artaflex, Inc. 215 Konrad Crescent Markham, Ontario L3R8T9 Canada Manufacturer: Artaflex, Inc. 215 Konrad Crescent Markham, Ontario L3R8T9 Canada FCC ID: UP2AWP24U Model Number: AWP24U Description: USB Dongle Type of Emission: Frequency Range, MHz: 2402 to 2479 Power Rating, Watts: 250 μW Switchable Variable X N/A Modulation: AMPS TDMA CDMA X OTHER Antenna: Helical Monopole Whip Integrated PCB Antenna X Other Note: For RF Safety test antenna gain taken at the upper range of expected gain (i.e. 0 dBd) and RF Power set to highest nominal power across all channels. Flom Test Labs p0790007, d0790029 3356 N. San Marcos Place, Suite 107 Page 3 of 5 Chandler, Arizona 85225-7176 (866) 311-3268 phone, (480) 926-3598 fax A2LA “A2LA has accredited Flom Test Labs, Inc. Chandler, AZ for technical competence in the field of Electrical testing. The accreditation covers the specific tests and types of tests listed on the agreed scope of accreditation. This laboratory meets the requirements of ISO 17025:2005 ‘General Requirements for the Competence of Testing and Calibration Laboratories’ and any additional program requirements in the identified field of testing.” Please refer to www.a2la.org for current scope of accreditation. Certificate number: 2152.01 Flom Test Labs p0790007, d0790029 3356 N. San Marcos Place, Suite 107 Page 4 of 5 Chandler, Arizona 85225-7176 (866) 311-3268 phone, (480) 926-3598 fax Standard Test Conditions and Engineering Practices Except as noted herein, the following conditions and procedures were observed during the testing: In accordance with ANSI C63.4-2004 and unless otherwise indicated in the specific measurement results, the ambient temperature of the actual EUT was maintained within the range of 10° to 40°C (50° to 104 °F) unless the particular equipment requirements specify testing over a different temperature range. Also, unless otherwise indicated, the humidity levels were in the range of 10% to 90% relative humidity. Prior to testing, the EUT was tuned up in accordance with the manufacturer's alignment procedures. All external gain controls were maintained at the position of maximum and/or optimum gain throughout the testing. Measurement results, unless otherwise noted, are worst-case measurements. Flom Test Labs p0790007, d0790029 3356 N. San Marcos Place, Suite 107 Page 5 of 5 Chandler, Arizona 85225-7176 (866) 311-3268 phone, (480) 926-3598 fax Name of Test: Environmental Assessment Specification: FCC: 47 CFR 1.1310 Measurement Guide: ANSI/IEEE C95.1 1992 Name of Test: R.F. Radiation Exposure FCC Rules: 1.1307, 1.1310, 1.1311, 2.1091 Description, EUT: See page 2 of Test Report 0.3-1.234 MHz: Limit [mW/cm 2 ] = 100 1.34-30 MHz: Limit [mW/cm 2 ] = (180/f 2 ) 30-300 MHz: Limit [mW/cm 2 ] = 0.2 Limits: Uncontrolled Exposure 47 CFR 1.1310 Table 1, (B) 300-1500 MHz Limit [mW/cm 2 ] = f/1500 1500-100,000 MHz: Limit [mW/cm 2 ] = 1.0 Test Frequencies, MHz = 2402 Powe…

Text truncated - open the document above for the full version.

Flom Test Labs 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 p0790007, d0790028 (866) 311-3268 phone, (480) 926-3598 fax Date: September 28, 2007 Federal Communications Commission Via: Electronic Filing Attention: Authorization & Evaluation Division Applicant: Artaflex, Inc. Equipment: AWP24U FCC ID: UP2AWP24U FCC Rules: 15.247 Gentlemen: On behalf of the Applicant, enclosed please find Application Form 731, Engineering Test Report and all pertinent documentation, the whole for approval of the referenced equipment as shown. We trust the same is in order. Should you need any further information, kindly contact the writer who is authorized to act as agent. Sincerely yours, Hoosamuddin S. Bandukwala, Lab Director Flom Test Labs 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 p0790007, d0790028 (866) 311-3268 phone, (480) 926-3598 fax List Of Exhibits (FCC Certification (Transmitters) - Revised 9/28/98) Applicant: Artaflex, Inc. FCC ID: UP2AWP24U By Applicant: 1. Letter Of Authorization 2. Identification Drawings Id Label Location Info Attestation Statement(S) Location of Compliance Statement 3. Documentation: 2.1033(B) (3) User Manual(S) (4) Operational Description (5) Block Diagram (5) Schematic Diagram (7) External Photographs Internal Photographs Parts List Active Devices By F.T.L. Inc. A. Testimonial & Statement of Certification B. Statement of Qualifications Flom Test Labs 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 p0790007, d0790028 (866) 311-3268 phone, (480) 926-3598 fax Transmitter Certification of FCC ID: UP2AWP24U Model: AWP24U to Federal Communications Commission Rule Part(s) 15.247 Date Of Report: September 28, 2007 On the Behalf of the Applicant: Artaflex, Inc. 215 Konrad Crescent Markham, Ontario L3R8T9 Canada Attention of: Sebastian Palazzo [email protected] (905)479-0148 X292 Supervised By: Hoosamuddin S. Bandukwala, Lab Director Flom Test Labs 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 p0790007, d0790028 (866) 311-3268 phone, (480) 926-3598 fax The applicant has been cautioned as to the following: 15.21 Information to User. The users manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 15.27(a) Special Accessories. Equipment marketed to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer, without additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. Flom Test Labs 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 p0790007, d0790028 (866) 311-3268 phone, (480) 926-3598 fax Testimonial And Statement Of Certification This is to certify that: 1. That the application was prepared either by, or under the direct supervision of, the undersigned. 2. That the technical data supplied with the application was taken under my direction and supervision. 3. That the data was obtained on representative units, randomly selected. 4. That, to the best of my knowledge and belief, the facts set forth in the application and accompanying technical data are true and correct. Certifying Engineer: Hoosamuddin S. Bandukwala, Lab Director Flom Test Labs 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 p0790007, d0790028 (866) 311-3268 phone, (480) 926-3598 fax Table Of Contents Rule Description Page Test Report 1 2.1033(c) General Information Required 2 . Standard Test Conditions and Engineering Practices 4 Test Results Summary 5 15.247(b). Peak Output Power 6 15.247(d), Radiated Spurious Emissions 6 15.247(d), . Emissions At Band Edges 7 15.247(a)(2). Occupied Bandwidth 13 15.247(d). Transmitter Power Spectral Density (PSD) 17 15.207. A/C Powerline Conducted Emissions 19 . Test Equipment Utilized 21 Flom Test Labs Page 1 of 21 3356 N. San Marcos Place, Suite 107 Chandler, Arizona 85225-7176 p0790007, d0790028 (866) 311-3268 phone, (480) 926-3598 fax Required information per ISO 17025-2005, paragraph 5.10.2: a) Test Report b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044A-1) Flom Test Lab, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d0790028 d) Client: Artaflex, Inc. e) Identification: AWP24U FCC ID: UP2AWP24U Description: USB Dongle f) EUT Condition: Not required unless specified in individual tests. g) Report Date: September 28, 2007 EUT Received: h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with FTL internal quality manual. m) Supervised by: Hoosamuddin S. Bandukwala, Lab Director n) Results: The results presented in this report relate only to the item tested. o) Reproduction: This report must not be reproduc…

Text truncated - open the document above for the full version.
