VIYCBC4077CRADLE ASSY, MOBILE WIRELESS CHARGER

14 May, 2024

P． 1 ／3 Hosiden Confidential FCC ID label design FCC ID: VIYCBC4077 Model: 861C0-B2010-XX (XX= A0, E0, C0.etc.) P． 2 ／3 Hosiden Confidential ⚫ 861C0-B2010-XX, Label design FCC ID : VIYCBC4077 Font height size : 1.6mm Printing method : Sticker pasting （Thermal transfer ribbon） It will not peel off during the product life. Because it is a heat-resistant label and adhesive. P． 3 ／3 Hosiden Confidential ⚫ 861C0-B2010-C0, Bottom view ⚫ Example 861C0-B2010-C0, Bottom view (Label)

Test Report No. 15204675H-D-R2 Page 1 of 39 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 MPE TEST REPORT Test Report No. 15204675H-D-R2 Customer Hosiden Corporation Description of EUT CRADLE ASSY, MOBILE WIRELESS CHARGER Model Number of EUT 861C0-B2010-C0 FCC ID VIYCBC4077 Test Regulation FCC rule §1.1310 Radiofrequency radiation exposure limits. Test Result Complied Issue Date June 7, 2024 Remarks *This test report has issued for MPE testing by wireless charger according to KDB 680106 D01 v04. Representative test engineer Approved by Ken Fujita Engineer Tsubasa Takayama Leader CERTIFICATE 5107.02 The testing in which "Non-accreditation" is displayed is outside the accreditation scopes in UL Japan, Inc. There is no testing item of "Non-accreditation". Report Cover Page - Form-ULID-003532 (DCS:13-EM-F0429) Issue# 23.0 Test Report No. 15204675H-D-R2 Page 2 of 39 UL Jap an, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 ANNOUNCEMENT REVISION HISTORY Original Test Report No.: 15204675H-D This report is a revised version of 15204675H-D-R1. 15204675H-D-R1 is replaced with this report. Revision Test Report No. Date Page Revised Contents -(Original)15204675H-D March 19, 2024 - 1 15204675H-D-R1 June 3, 2024 Deletion of "*2)" from test data (P. 13 to 32) 1 15204675H-D-R1 June 3, 2024 Correction of the Last Calibration Date in APPENDIX 2: Test Equipment list (LIMS ID: 141572 and 141360) 2 15204675H-D-R2 June 7, 2024 Remodification of the Last Calibration Date in APPENDIX 2: Test Equipment list (LIMS ID: 141572 and 141360) This test report shall not be reproduced in full or partial, without the written approval of UL Japan, Inc.  The results in this report appl y only to the sample tested. (Laboratory was not involved in sampling.)  This sample tested is in compliance with the limits of the above re gulation. The test results in this test report are traceable to the national or international standards. This test report must not be used by the customer to claim produc t certification, approval, or endo rsement b y the A2LA accreditation body.  This test report covers Radio technical requirements. It does not cover administrative issues such as Manual or non-Radio test related Requirement s. (if applicable)  The all test items in this test report are conducted b y UL Japan, Inc. Ise EMC Lab.  The opinions and the interpretations to the result of the description in this report are outside scope s whe re UL Japan, Inc. has been accredite d.  The information provided b y the customer for this report is identified in SECTION 1.  The laboratory is not responsible for information provided by the customer which can impa ct the validit y of the results. For test report (s) referred in this report, the latest version (including any revisions) is always referred. Test Report No. 15204675H-D-R2 Page 3 of 39 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 Reference: Abbreviations (Including words undescribed in this report) A2LA The American Association for Laboratory Accreditation ICES Interference-Causing Equipment Standard AC Alternating Current IEC International Electrotechnical Commission AFH Adaptive Frequency Hopping IEEE Institute of Electrical and Electronics En gineers AM Amplitude Modulation IF Intermediate Frequency Amp, AMP Amplifier ILAC International Laboratory Accreditation Conference ANSI American National Standards Institute ISED Innovation, Science and Economic Develo pment Canada Ant, ANT Antenna ISO International Organization for Standardization AP Access Point JAB Japan Accreditation Board ASK Amplitude Shift Keying LAN Local Area Network Atten., ATT Attenuator LIMS Laboratory Information Management S ystem AV Average MCS Modulation and Coding Scheme BPSK Binary Phase-Shift Keying MRA Mutual Recognition Arrangement BR Bluetooth Basic Rate N/A Not Applicable BT Bluetooth NIST National Institute of Standards and Technolo gy BT LE Bluetooth Low Energy NS No signal detect. BW BandWidth NSA Normalized Site Attenuation Cal Int Calibration Interval NVLAP National Voluntary Laboratory Accreditation Pro gram CCK Complementary Code Keying OBW Occupied Band Width Ch., CH Channel OFDM Orthogonal Frequency Division Multiplexing CISPR Comite International Special des Perturbations Radioelectri ques P/M Power meter CW Continuous Wave PCB Printed Circuit Board DBPSK Differential BPSK PER Packet Error Rate DC Direct Current PHY Physical Layer D-factor Distance factor PK Peak DFS Dynamic Frequency Selection PN Pseudo random Noise DQPSK Differential QPSK PRBS Pseudo-Random Bit Sequence DSSS Direct Sequence Spread Spectrum PSD Power Spectral Density EDR Enhanced Data Rate QAM Quadrature Amplitude Modulation EIRP, e.i.r.p. Equivalent Isotropically Radiated Power QP Quasi-Peak EMC ElectroMagnetic Compatibility QPSK Quadri-Phase Shift Keying EMI ElectroMagnetic Interference RBW Resolution Band Width EN European Norm RDS Radio Data System ERP, e.r.p. Effective Radiated Power RE Radio Equipment EU European Union RF Radio Frequency EUT Equipment Under Test RMS Root Mean Square Fac. Factor RSS Radio Standards Specifications FCC Federal Communications Commission Rx Receiving FHSS Frequency Hopping Spread Spectrum SA, S/A Spectrum Analyzer FM Frequency Modulation SG Signal Generator Freq. Frequency SVSWR Site-Voltage Standing Wave Ratio FSK Frequency Shift Keying TR Test Receiver GFSK Gaussian Frequency-Shift Keying Tx Transmitting GNSS Global Navigation Satellite System VBW Video BandWidth GPS Global Positioning System Vert. Vertical Hori. Horizontal WLAN Wireless LAN Test Report No. 15204675H-D-R2 Page 4 of 39 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 CONTENTS PAGE SECTION 1: Customer Information ....................................................................................... 5 SECTION 2: Equipment Under…
