VIYHRM1086Bluetooth Dual Module

Page 1 of 5 User Manual/ユーザーマニュアル HRM1086MAN001 HRM1086 Ver.0.14 Approved Product and Technology R&D Division Hosiden Corporation User Manual/ユーザーマニュアル HRM1086 Author/発行者: Tomoki Umeda/梅田 朋季 Department/発行部門: 2nd Engineering Dept./第二技術部 Approver/承認者: Yashuhiro Ohe/大江 康博 Document Number/文書番号: HRM1086MAN001 Version/バージョン: 0.14 Status/ステータス: Approved Approved 承認 Checked 確認 Written 作成 梅田 Page 2 of 5 User Manual/ユーザーマニュアル HRM1086MAN001 HRM1086 Ver.0.14 Approved Product and Technology R&D Division Hosiden Corporation 1 Product Overview/製品概要 Item 項目 Specification 仕様 Remark 備考 Model Name 製品名 HRM1086 PMN：HRM1086 Frequency Range 周波数範囲 From 2402 MHz to 2480 MHz. 2402 MHz以上2480 MHz以下 Modulation 変調 GFSK、π/4 DQPSK、8DPSK Operational Channel 作動チャンネル BR/EDR：2402 + n MHz (n = 0,1,2...78) BLE：2402 + 2n MHz (n = 0,1,2...39) Data Rate データレート 1 Mbps and 2 Mbps and 3Mbps 1 Mbps及び2 Mbps 及び3Mbps RF Output Power RF無線出力 BR：+11dBm (Max_typ) EDR：+8dBm (Max_typ) BLE1M/2M：+10dBm (Max_typ) The output power shown are for reference only. Intended End Usage 用途 Bluetooth ® Product Bluetooth ® 製品 Installation Method 組み込み方法 Surface mount and reflow 表面実装及びリフロー Operating Voltage 電圧範囲 From 2.8V to 4.6V, 3.7V typ 2.8V以上4.6V以下 3.7V typ Applicable FCC rules 適合FCC規則リスト FCC Part 15 Subpart C Bluetooth Version Bluetoothバージョン 5.3 2 Legal Statement/ 法的声明 2.1 FCC Compliance/FCC 適合 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. The regulatory label on the final system must include the statement: "Contains FCC ID: VIYHRM1086" or using electronic labelling method as documented in KDB 784748. The OEM integrators shall be responsible for testing and evaluation for any additional compliance requirements required under regulations of each region with their finished product that is installed this module. (for example:EMC, safety, etc) The OEM integrators must select either DC / DC regulator or LDO regulator from the product's internal power supply by the software. The modular transmitter is only FCC authorized for the specific rule parts (i.e., FCC part 15 Subpart C) listed on the grant, and the host product manufacturer is responsible for compliance to any other FCC rules that apply to the host not covered by the modular transmitter grant of certification. The final host product still requires Part 15 Subpart B compliance testing with the modular transmitter installed. The manual for the final product with this product should state the following: “This transmitter must not be co-located or operated in conjunction with any other antenna or Page 3 of 5 User Manual/ユーザーマニュアル HRM1086MAN001 HRM1086 Ver.0.14 Approved Product and Technology R&D Division Hosiden Corporation transmitter.” “This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines. This equipment should be installed and operated keeping the radiator at least 20cm or more away from person’s body.” The device is designed to use an integrated antenna. Do not modify the antenna or any other part of the module. Any modifications will invalidate the modular certifications and require new approvals for the host system. In case a conflict arises between Japanese and English versions, English version takes priority. この製品はFCC規則第15部に準拠しています。以下の2つの条件に従って動作します:（1）この製品 が有害な電波干渉を発生させることはない、および（2）この製品は、誤動作を発生させる可能性のある電 波干渉を含め、受信したあらゆる電波干渉を許容する必要がある。 許可を得ることなくこの製品に変更または改造を加えると製品を使用するための許諾が取り消される場合 があります。 最終システムの規制ラベルには「Contains FCC ID: VIYHRM1086」またはKDB784748に記載されてい るような電子ラベル表示方法を使用する旨を記述する必要があります。 OEMインテグレータは、このモジュールを搭載した最終製品について各地域の規制に基づいて必要とさ れる追加のコンプライアンス要件のテストと評価を行う責任があります。(例:EMC、安全性など。) OEMインテグレータは、ソフトウェアによって製品の内部電源からDC / DCレギュレータまたはLDOレギ ュレータのいずれかを選択する必要があります。 モジュールの認証でカバーされず、ホスト製品で適合されるFCC規則(例：FCC part 15 Subpart C)につ いてはホスト製造者がその適合性に対する責任を負います。最終的なホスト製品には取り付けられたモ ジュール送信機と共にPart 15 Subpart B適合性試験が必要です。 このモジュールを搭載した最終製品のマニュアルには以下を表記する必要があります。 「本製品は他のアンテナまたは送信機と同じ場所に配置したり、一緒に操作したりしないでください。」 「この製品は、管理されていない環境に対して定められたFCCの放射線被曝制限に準拠し、FCC無線周 波数 (RF) 被曝ガイドラインを満たしています。この機器は人体から20 cm以上離して設置および操作 する必要があります。」 この製品は内蔵アンテナを使用するように設計されています。 モジュールのアンテナや他の部分を変更 しないでください。 変更を加えた場合モジュール認証が無効になり、ホストシステムでの新規認証が必要 になります。 和文と英文の表記に関し疑義が生じた場合は、英文を優先します。 Page 4 of 5 User Manual/ユーザーマニュアル HRM1086MAN001 HRM1086 Ver.0.14 Approved Product and Technology R&D Division Hosiden Corporation 2.2 Industry Canada Compliance/ インダストリーカナダ適合 This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. The regulatory label on the final system must include the statement: “Contains IC: 7305A-HRM1086” The OEM integrators shall be responsible for testing and evaluation for any additional compliance requirements required under regulations of each region with their finished product that is installed this module. (for example:EMC, safety, etc) The OEM integrators must select either DC / DC regulator or LDO regulator from the product's internal power supply by the software. The manual for the final product with this product should state the following: 「This equipment complies with ISED radiation exposure limits set forth for an uncontrolled environment and meets RSS-102 of the ISED radio frequency (RF) Exposure rules. This equipment should be installed and operated keeping the radiator at least 20cm or more away from person’s body. 」 In case a conflict arises between J…

Text truncated - open the document above for the full version.

HRM1086 External Photo <TOP V iew> <B OTTOM View > < Front view> <Back View> < Left view> < Right View>

HRM1086 Internal Photo < TOP V iew without shield case> < BOTTOM View >

UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 RF Exposure / MPE Calculation No. 14500810H Customer Hosiden Corporation Description of EUT Bluetooth Dual Module Model Number of EUT HRM1086 FCC ID VIYHRM1086 Hosiden Corporation declares that Model: HRM1086 complies with FCC radiation exposure requirement specified in the FCC Rule 2.1091 (for mobile). RF Exposure Calculations: The following information provides the minimum separation distance for the highest gain antenna provided with the “HRM1086“ as calculated from (B) Limits for General Population / Uncontrolled Exposure of TABLE 1- LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) of §1.1310 Radiofrequency radiation exposure limits. [Bluetooth (Low Energy)] This calculation is based on the highest EIRP possible from the system, considering maximum power and antenna gain, and considering a 1mW/cm^2 uncontrolled exposure limit. The Friis formula used was: Where P =9.38 mW (Maximum average output power) Time average was used for the above value in consideration of 6-minutes time-ave r Burst power average was used for the above value in consideration of worst condit G =1.230 Numerical Antenna gain; equal to 0.9dBi r =20 cm (Separation distance) 0.00230 mW/cm 2 Power Density Result S = 2 4r GP S     [Bluetooth (BR / EDR)] This calculation is based on the highest EIRP possible from the system, considering maximum power and antenna gain, and considering a 1mW/cm^2 uncontrolled exposure limit. The Friis formula used was: Where P =9.48 mW (Maximum average output power) Time average was used for the above value in consideration of 6-minutes time-ave r Burst power average was used for the above value in consideration of worst condit G =1.230 Numerical Antenna gain; equal to 0.9dBi r =20 cm (Separation distance) 0.00232 mW/cm 2 Power Density Result S = 2 4r GP S    

Page 1 of 6 Antenna Under Test Report/アンテナ テストレポー ト HRM1086ANT001 HRM1086 Ver.1.2 Approved Product and Technology R&D Division Hosiden Corporation Antenna Under Test Report/アンテナ テストレポート HRM1086 Author/発行者: Tomoki Umeda/梅田 朋季 Department/発行部門: 2nd Engineering Dept./第二技術部 Approver/承認者: Yasuhiro Ohe / 大江 康博 Document Number/文書番号: HRM1086ANT001 Version/バージョン: 1.2 Status/ステータス: Approved Approved 承認 Checked 確認 Written 作成 梅田 Page 2 of 6 Antenna Under Test Report/アンテナテストレポー ト HRM1086ANT001 HRM1086 Ver.1.2 Approved Product and Technology R&D Division Hosiden Corporation 1 Antenna Information/アンテナ情報 Item 項目 Specification 仕様 Remark 備考 Model Name 製品名 HRM1086 Frequency Range 周波数範囲 From 2402 MHz to 2480 MHz. 2402 MHz以上2480 MHz以下 Antenna Type アンテナタイプ 1/4λ inverted F antenna 1/4λ 逆Fアンテナ Antenna Gain アンテナゲイン 0.9 dBi Page 4 of 6 Antenna Under Test Report/アンテナテストレポー ト HRM1086ANT001 HRM1086 Ver.1.2 Approved Product and Technology R&D Division Hosiden Corporation Figure 3: Antenna efficiency /アンテナ放射効率 Figure 4: Antenna Radiated pattern θ=90°/アンテナ放射パターン θ=90° -15 -10 -5 0 220023002400250026002700 Efficiency (dB) Frequency (MHz) HRM 1086_ANT_Efficiency HRM1086_ES2_No161 AVERAGE-2.379ｄB MAX-2.207ｄB MIN-2.677ｄB 2400～2480MHｚ Page 5 of 6 Antenna Under Test Report/アンテナ テストレポー ト HRM1086ANT001 HRM1086 Ver.1.2 Approved Product and Technology R&D Division Hosiden Corporation Figure 5 : Antenna Radiated pattern φ=0°/アンテナ放射パターン φ=0° Figure 6: Antenna Radiated pattern φ=90°/アンテナ放射パターン φ=90° Page 6 of 6 Antenna Under Test Report/アンテナテストレポー ト HRM1086ANT001 HRM1086 Ver.1.3 Approved Product and Technology R&D Division Hosiden Corporation Figure 7: Antenna Gain /アンテナゲイン T able1：Test Conditions/試験条件 Te s t D a te 測定日 Test equipment 測定機器 Calibration date 校正日 Tester 試験者 Test software テストソフトウェア 2022.Sep 5 Starlab SL-OS2 2021.Mar 12 Nishiyama 西山 Satenv 3.0.3.0 build 4 Change History/ 変更履歴 Version 版 Issue Date 発行日 Status 状態 Author 発行者 Purpose 発行理由 1.0 2022. Oct 25 Approved Tomoki Umeda 梅田 朋季 First draft. 初版作成。 1.1 2022. Oct 28 Approved Tomoki Umeda 梅田 朋季 Modified to separate pages after "2. Antenna Appearance" for short- term confidentiality. 短期機密保持用に2.Antenna Appearance以降のページを分かれ るように修正。 1.2 2022. Nov 2 Approved Tomoki Umeda 梅田 朋季 Corrected title to Antenna Under Test Report. Added Figures 3 to 7 and Table 1. 表題をAntenna Under Test Report に修正。Figure3～7、Table1の追 加。 1.3 2022. Nov 7 Approved Tomoki Umeda 梅田 朋季 Antenna gain unit correction. アンテナゲインの単位修正 E nd of Document

Test Report No. : 14500810H-A-R1 Page : 1 of 49 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 RADIO TEST REPORT Test Report No.: 14500810H-A-R1 Customer Hosiden Corporation Description of EUT Bluetooth Dual Module Model Number of EUT HRM1086 FCC ID VIYHRM1086 Test Regulation FCC Part 15 Subpart C Test Result Complied (Refer to SECTION 3) Issue Date November 7, 2022 Remarks Bluetooth Low Energy part Representative Test Engineer Approved By Hiroyuki Furutaka Engineer Takumi Shimada Engineer CERTIFICATE 5107.02 The testing in which "Non-accreditation" is displayed is outside the accreditation scopes in UL Japan, Inc. There is no testing item of "Non-accreditation". Report Cover Page - Form-ULID-003532 (DCS:13-EM-F0429) Issue# 21.0 Test Report No. : 14500810H-A-R1 Page : 2 of 49 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 ANNOUNCEMENT REVISION HISTORY Original Test Report No.: 14500810H-A This report is a revised version of 14500810H-A. 14500810H-A is replaced with this repor t. Revision Test Report No. Date Page Revised Contents - (Ori ginal) 14500810H-A October 26, 2022 - 1 14500810H-A-R1 November 7, 2022 Separated for configuration diagrams of Radiated emission test and Antenna Terminal Conducted tests of Clause 4.2  This test report shall not be reproduced in full or partial, without the written approval of UL Japan, Inc.  The results in this report appl y only to the sample tested. (Laboratory was not involved in sampling.)  This sample tested is in compliance with the limits of the above re gulation.  The test results in this test report are traceable to the national or international standards.  This test report must not be used by the customer to claim product certification, approval, or endorsement by the A2LA accreditation bod y.  This test report covers Radio technical requirements. It does not cover administrative issues such as Manual or non-Radio test related Requirements. (if applicable)  The all test items in this test report are conducted b y UL Japan, Inc Ise EMC Lab.  The opinions and the interpretations to the result of the description in this report are outside scopes where UL Japan, Inc. has been accredited.  The information provided from the custome r for this report is identified in Section 1.  For test report(s) referred in this report, the latest version (includin g any revisions) is always referred. Test Report No. : 14500810H-A-R1 Page : 3 of 49 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 Reference: Abbreviations (Including words undescribed in this report) A2LA The American Association for Laboratory Accreditation ICES Interference-Causing Equipment Standard AC Alternating Current IEC International Electrotechnical Commission AFH Adaptive Frequency Hopping IEEE Institute of Electrical and Electronics Engineers AM Amplitude Modulation IF Intermediate Frequency Amp, AMP Amplifier ILAC International Laboratory Accreditation Conference ANSI American National Standards Institute ISED Innovation, Science and Economic Development Canada Ant, ANT Antenna ISO International Organization for Standardization AP Access Point JAB Japan Accreditation Board ASK Amplitude Shift Keying LAN Local Area Network Atten., ATT Attenuator LIMS Laboratory Information Management System AV Average MCS Modulation and Coding Scheme BPSK Binary Phase-Shift Keying MRA Mutual Recognition Arrangement BR Bluetooth Basic Rate N/A Not Applicable BT Bluetooth NIST National Institute of Standards and Technology BT LE Bluetooth Low Energy NS No signal detect. BW BandWidth NSA Normalized Site Attenuation Cal Int Calibration Interval NVLAP National Voluntary Laboratory Accreditation Pro gram CCK Complementary Code Keying OBW Occupied Band Width Ch., CH Channel OFDM Orthogonal Frequency Division Multiplexing CISPR Comite International Special des Perturbations Radioelectri ques P/M Power meter CW Continuous Wave PCB Printed Circuit Board DBPSK Differential BPSK PER Packet Error Rate DC Direct Current PHY Physical Layer D-factor Distance factor PK Peak DFS Dynamic Frequency Selection PN Pseudo random Noise DQPSK Differential QPSK PRBS Pseudo-Random Bit Sequence DSSS Direct Sequence Spread Spectrum PSD Power Spectral Density EDR Enhanced Data Rate QAM Quadrature Amplitude Modulation EIRP, e.i.r.p. Equivalent Isotropically Radiated Power QP Quasi-Peak EMC ElectroMagnetic Compatibility QPSK Quadri-Phase Shift Keying EMI ElectroMagnetic Interference RBW Resolution Band Width EN European Norm RDS Radio Data System ERP, e.r.p. Effective Radiated Power RE Radio Equipment EU European Union RF Radio Frequency EUT Equipment Under Test RMS Root Mean Square Fac. Factor RSS Radio Standards Specifications FCC Federal Communications Commission Rx Receiving FHSS Frequency Hopping Spread Spectrum SA, S/A Spectrum Analyzer FM Frequency Modulation SG Signal Generator Freq. Frequency SVSWR Site-Voltage Standing Wave Ratio FSK Frequency Shift Keying TR Test Receiver GFSK Gaussian Frequency-Shift Keying Tx Transmitting GNSS Global Navigation Satellite System VBW Video BandWidth GPS Global Positioning System Vert. Vertical Hori. Horizontal WLAN Wireless LAN Test Report No. : 14500810H-A-R1 Page : 4 of 49 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 CONTENTS PAGE SECTION 1: Customer Information ...................................................................................................... 5 SECTION 2: Equipment Under Test (EUT) .......................................................................................... 5 SECTION 3: Test Specification, Procedures & Results ....................................................................... 6 SECTION 4: Operation of EUT during testing ..................................................................................... 9 SECTION 5: Conducted Emission .....…

Text truncated - open the document above for the full version.

Test Report No. : 14500810H-A-R1 Page : 46 of 49 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 APPENDIX 3: Photographs of Test Setup Conducted Emission Photo 1 Photo 2 Test Report No. : 14500810H-A-R1 Page : 47 of 49 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 Radiated Spurious Emission Photo 1 Photo 2 Test Report No. : 14500810H-A-R1 Page : 48 of 49 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 Worst Case Position Below 1 GHz (Horizontal: X-axis / Vertical: X-axis) Above 1 GHz (Horizontal: X-axis / Vertical: Z-axis) X-axis Y-axis Z-axis Test Report No. : 14500810H-A-R1 Page : 49 of 49 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 Antenna Terminal Conducted Tests Photo 1 Photo 2 End of Report

Page 3 of 6 Antenna Under Test Report/アンテナ テストレポー ト HRM1086ANT001 HRM1086 Ver.1.2 Approved Product and Technology R&D Division Hosiden Corporation 2 Antenna Appearance/ アンテナ外観 Appearance of the antenna is shown in the following figure (red square shows the antenna): アンテナの外観を下図に示す （赤枠部がアンテナ）。 Figure 1: Antenna Appearance/ アンテナ外観 3 Antenna gain measurement / アンテナゲインの測定 The antenna gain of this product was measured using a three-dimensional measurement system. 本製品のアンテナゲインは3次元測定システムを用いて測定した Figure 2: Antenna gain measurement / アンテナゲインの測定 Y X Z
