i USER’S MANUAL Alpha-3R Series Direct Thermal Portable Printer ii Copyright Information © 2012 TSC Auto ID Technology Co., Ltd, The copyright in this manual, the software and firmware in the printer described therein are owned by TSC Auto ID Technology Co., Ltd, All rights reserved. CG Triumvirate is a trademark of Agfa Corporation. CG Triumvirate Bold Condensed font is under license from the Monotype Corporation. Windows is a registered trademark of Microsoft Corporation. All other trademarks are the property of their respective owners. Information in this document is subject to change without notice and does not represent a commitment on the part of TSC Auto ID Technology Co. No part of this manual may be reproduced or transmitted in any form or by any means, for any purpose other than the purchaser’s personal use, without the expressed written permission of TSC Auto ID Technology Co. iii Agency Compliance and Approvals CE CLASS B EN 55022:2006 +A1:2007 EN 55024:1998+A1:2001+A2:2003 EN 61000-4 SERIES REQULATIONS FCC CFR Title 47 Part 15 Subpart B:2011 Class B ICES-003 Issue 4:2004 Class B Wichtige Sicherheits-Hinweise 1. Bitte lesen Sie diese Hinweis sorgfältig durch. 2. Heben Sie diese Anleitung fűr den späteren Gebrauch auf. 3. Vor jedem Reinigen ist das Gerät vom Stromentz zu trennen. Verwenden Sie keine Flüssig-oder Aerosolreiniger. Am besten eignet sich ein angefeuchtetes Tuch zur Reinigung. 4. Die Netzanschluß-Steckdose soll nahe dem Gerät angebracht und leicht zugänglich sein. 5. Das Gerät ist vor Feuchtigkeit zu schűtzen. 6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten. Ein Kippen oder Fallen könnte Beschädigungen hervorrufen. 7. Beachten Sie beim Anschluß ans Stromnetz die Anschluß werte. 8. Dieses Gerät kann bis zu einer Auß entemperatur von maximal 40°C betrieben werden. Battery safety warning: DO NOT throw the battery in fire. DO NOT short circuit the contacts. DO NOT disassemble the battery. DO NOT throw the battery in municipal waste. The symbol of the crossed out wheeled bin indicates that the battery should not be placed in municipal waste. iv Class B: FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/ TV technician for help. CAUTION: Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment. RF exposure warning (WiFi) This equipment must be installed and operated in accordance with provided instructions and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be providing with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. SAR Value: 0.023 W/kg Canada, Industry Canada (IC) Notices This Class B digital apparatus complies with Canadian ICES-003 and RSS-210. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. v Radio Frequency (RF) Exposure Information The radiated output power of the Wireless Device is below the Industry Canada (IC) radio frequency exposure limits. The Wireless Device should be used in such a manner such that the potential for human contact during normal operation is minimized. This device has been evaluated for and shown compliant with the IC Specific Absorption Rate (“SAR”) limits when installed in specific host products operated in portable exposure conditions. (For WiFi) Canada, avis d'Industry Canada (IC) Cet appareil numérique de classe B est conforme aux normes canadiennes ICES-003 et RSS-210. Son fonctionnement est soumis aux deux conditions suivantes : (1) cet appareil ne doit pas causer d'interférence et (2) cet appareil doit accepter toute interférence, notamment les interférences qui peuvent affecter son fonctionnement. Informations concernant l'exposition aux fréquences radio (RF) La puissance de sortie émise par l’appareil de sans fil est inférieure à la limite d'exposition aux fréquences radio d'Industry Canada (IC). Utilisez l’appareil de sans fil de façon à minimiser les contacts humains lors du fonctionnement normal. Ce périphérique a été évalué et démontré conforme aux limites SAR (Specific Absorption Rate – Taux d'absorption spécifique) d'IC lorsqu'il est installé dans des produits hôtes particuliers qui fonctionnent dans des conditions d'exposition à des appareils portables. (For WiFi) vi Contents 1. Introduction ................................................. 1 1.1 Product Introduction ......................................................................................... 1 1.2 Product Features ............................................................................................... 2 1.2.1 Printer Standard Features ...................................................................... 2 1.2.2 Print…

Text truncated - open the document above for the full version.

i USER’S MANUAL PR30/ GR30/ 3300 Series Direct Thermal Portable Printer ii Copyright Information © 2012 TSC Auto ID Technology Co., Ltd, The copyright in this manual, the software and firmware in the printer described therein are owned by TSC Auto ID Technology Co., Ltd, All rights reserved. CG Triumvirate is a trademark of Agfa Corporation. CG Triumvirate Bold Condensed font is under license from the Monotype Corporation. Windows is a registered trademark of Microsoft Corporation. All other trademarks are the property of their respective owners. Information in this document is subject to change without notice and does not represent a commitment on the part of TSC Auto ID Technology Co. No part of this manual may be reproduced or transmitted in any form or by any means, for any purpose other than the purchaser’s personal use, without the expressed written permission of TSC Auto ID Technology Co. iii Agency Compliance and Approvals CE CLASS B EN 55022:2006 +A1:2007 EN 55024:1998+A1:2001+A2:2003 EN 61000-4 SERIES REQULATIONS FCC CFR Title 47 Part 15 Subpart B:2011 Class B ICES-003 Issue 4:2004 Class B Wichtige Sicherheits-Hinweise 1. Bitte lesen Sie diese Hinweis sorgfältig durch. 2. Heben Sie diese Anleitung fűr den späteren Gebrauch auf. 3. Vor jedem Reinigen ist das Gerät vom Stromentz zu trennen. Verwenden Sie keine Flüssig-oder Aerosolreiniger. Am besten eignet sich ein angefeuchtetes Tuch zur Reinigung. 4. Die Netzanschluß-Steckdose soll nahe dem Gerät angebracht und leicht zugänglich sein. 5. Das Gerät ist vor Feuchtigkeit zu schűtzen. 6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten. Ein Kippen oder Fallen könnte Beschädigungen hervorrufen. 7. Beachten Sie beim Anschluß ans Stromnetz die Anschluß werte. 8. Dieses Gerät kann bis zu einer Auß entemperatur von maximal 40°C betrieben werden. Battery safety warning: DO NOT throw the battery in fire. DO NOT short circuit the contacts. DO NOT disassemble the battery. DO NOT throw the battery in municipal waste. The symbol of the crossed out wheeled bin indicates that the battery should not be placed in municipal waste. iv Class B: FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/ TV technician for help. CAUTION: Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment. RF exposure warning (WiFi) This equipment must be installed and operated in accordance with provided instructions and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be providing with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. SAR Value: 0.023 W/kg Canada, Industry Canada (IC) Notices This Class B digital apparatus complies with Canadian ICES-003 and RSS-210. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. v Radio Frequency (RF) Exposure Information The radiated output power of the Wireless Device is below the Industry Canada (IC) radio frequency exposure limits. The Wireless Device should be used in such a manner such that the potential for human contact during normal operation is minimized. This device has been evaluated for and shown compliant with the IC Specific Absorption Rate (“SAR”) limits when installed in specific host products operated in portable exposure conditions. (For WiFi) Canada, avis d'Industry Canada (IC) Cet appareil numérique de classe B est conforme aux normes canadiennes ICES-003 et RSS-210. Son fonctionnement est soumis aux deux conditions suivantes : (1) cet appareil ne doit pas causer d'interférence et (2) cet appareil doit accepter toute interférence, notamment les interférences qui peuvent affecter son fonctionnement. Informations concernant l'exposition aux fréquences radio (RF) La puissance de sortie émise par l’appareil de sans fil est inférieure à la limite d'exposition aux fréquences radio d'Industry Canada (IC). Utilisez l’appareil de sans fil de façon à minimiser les contacts humains lors du fonctionnement normal. Ce périphérique a été évalué et démontré conforme aux limites SAR (Specific Absorption Rate – Taux d'absorption spécifique) d'IC lorsqu'il est installé dans des produits hôtes particuliers qui fonctionnent dans des conditions d'exposition à des appareils portables. (For WiFi) vi Contents 1. Introduction ................................................. 1 1.1 Product Introduction ......................................................................................... 1 1.2 Product Features ............................................................................................... 2 1.2.1 Printer Standard Features ...................................................................... 2 1.2…

Text truncated - open the document above for the full version.

i USER’S MANUAL TSC-30/ CN-30/ BP-30 Series Direct Thermal Portable Printer ii Copyright Information © 2012 TSC Auto ID Technology Co., Ltd, The copyright in this manual, the software and firmware in the printer described therein are owned by TSC Auto ID Technology Co., Ltd, All rights reserved. CG Triumvirate is a trademark of Agfa Corporation. CG Triumvirate Bold Condensed font is under license from the Monotype Corporation. Windows is a registered trademark of Microsoft Corporation. All other trademarks are the property of their respective owners. Information in this document is subject to change without notice and does not represent a commitment on the part of TSC Auto ID Technology Co. No part of this manual may be reproduced or transmitted in any form or by any means, for any purpose other than the purchaser’s personal use, without the expressed written permission of TSC Auto ID Technology Co. iii Agency Compliance and Approvals CE CLASS B EN 55022:2006 +A1:2007 EN 55024:1998+A1:2001+A2:2003 EN 61000-4 SERIES REQULATIONS FCC CFR Title 47 Part 15 Subpart B:2011 Class B ICES-003 Issue 4:2004 Class B Wichtige Sicherheits-Hinweise 1. Bitte lesen Sie diese Hinweis sorgfältig durch. 2. Heben Sie diese Anleitung fűr den späteren Gebrauch auf. 3. Vor jedem Reinigen ist das Gerät vom Stromentz zu trennen. Verwenden Sie keine Flüssig-oder Aerosolreiniger. Am besten eignet sich ein angefeuchtetes Tuch zur Reinigung. 4. Die Netzanschluß-Steckdose soll nahe dem Gerät angebracht und leicht zugänglich sein. 5. Das Gerät ist vor Feuchtigkeit zu schűtzen. 6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten. Ein Kippen oder Fallen könnte Beschädigungen hervorrufen. 7. Beachten Sie beim Anschluß ans Stromnetz die Anschluß werte. 8. Dieses Gerät kann bis zu einer Auß entemperatur von maximal 40°C betrieben werden. Battery safety warning: DO NOT throw the battery in fire. DO NOT short circuit the contacts. DO NOT disassemble the battery. DO NOT throw the battery in municipal waste. The symbol of the crossed out wheeled bin indicates that the battery should not be placed in municipal waste. iv Class B: FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/ TV technician for help. CAUTION: Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment. RF exposure warning (WiFi) This equipment must be installed and operated in accordance with provided instructions and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be providing with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. SAR Value: 0.023 W/kg Canada, Industry Canada (IC) Notices This Class B digital apparatus complies with Canadian ICES-003 and RSS-210. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. v Radio Frequency (RF) Exposure Information The radiated output power of the Wireless Device is below the Industry Canada (IC) radio frequency exposure limits. The Wireless Device should be used in such a manner such that the potential for human contact during normal operation is minimized. This device has been evaluated for and shown compliant with the IC Specific Absorption Rate (“SAR”) limits when installed in specific host products operated in portable exposure conditions. (For WiFi) Canada, avis d'Industry Canada (IC) Cet appareil numérique de classe B est conforme aux normes canadiennes ICES-003 et RSS-210. Son fonctionnement est soumis aux deux conditions suivantes : (1) cet appareil ne doit pas causer d'interférence et (2) cet appareil doit accepter toute interférence, notamment les interférences qui peuvent affecter son fonctionnement. Informations concernant l'exposition aux fréquences radio (RF) La puissance de sortie émise par l’appareil de sans fil est inférieure à la limite d'exposition aux fréquences radio d'Industry Canada (IC). Utilisez l’appareil de sans fil de façon à minimiser les contacts humains lors du fonctionnement normal. Ce périphérique a été évalué et démontré conforme aux limites SAR (Specific Absorption Rate – Taux d'absorption spécifique) d'IC lorsqu'il est installé dans des produits hôtes particuliers qui fonctionnent dans des conditions d'exposition à des appareils portables. (For WiFi) vi Contents 1. Introduction ................................................. 1 1.1 Product Introduction ......................................................................................... 1 1.2 Product Features ............................................................................................... 2 1.2.1 Printer Standard Features ...................................................................... 2…

Text truncated - open the document above for the full version.

Declaration Letter We, the undersigned TSC Auto ID Technology Co., Ltd., hereby declare. The device FCC ID: VTV0481202 and IC ID: 10524A-0481202 complete below list. The different of thirteen model is shown as below: Control Method Shipment Control Firmware Control Model No. Cable Print Speed (Unit：ips) Alpha-3RW USB, RS-232 1.5, 2, 2.5, 3, 3.5, 4 TSC-30W USB 1.5, 2, 3, 4 CN-30W USB 2, 3, 3.5, 4 BP-30W USB 2, 2.5, 3, 3.5, 4 PR30W USB 2, 2.5, 3, 4 GR30W USB 2, 3, 4 3300W USB 1.5, 2, 3, 3.5, 4 TSC-30RW RS-232 1.5, 2, 3, 4 CN-30RW RS-232 2, 3, 3.5, 4 BP-30RW RS-232 2, 2.5, 3, 3.5, 4 PR30RW RS-232 2, 2.5, 3, 4 GR30RW RS-232 2, 3, 4 3300RW RS-232 1.5, 2, 3, 3.5, 4 (1)The different models of the system where the module is identical. (2) The different model with different Cable, but electrical characteristic and I/O Port are the same. (3) The print speed is firmware control Sincerely, ----------------------------------------------------------- Lion Ho / Senior Engineer TSC Auto ID Technology Co., Ltd. Tel: +886-2-2218-6789 Fax: +886-2-2218-5678 Email: [email protected]

Report No.: 124446R-RFUSP28V01 Page : 1 of 16 Attachment 2 : EUT Detailed Photographs (1) EUT Photo (2) EUT Photo

TSC Auto ID Technology Co., Ltd. FCC ID.: VTV0481202 9F., No. 95, Minquan Rd. Xindian Dist. New Taipei City 23141, Taiwan (R.O.C.)Tel : +886-2-2218-6789 FCC ID Label

TSC Auto ID Technology Co., Ltd. FCC ID.: VTV0481202 9F., No. 95, Minquan Rd. Xindian Dist. New Taipei City 23141, Taiwan (R.O.C.)Tel : +886-2-2218-6789 The FCC ID and DoC will be placed on the equipment as shown in the photograph below. TSC Auto ID Technology Co., Ltd. FCC ID.: VTV0481202 9F., No. 95, Minquan Rd. Xindian Dist. New Taipei City 23141, Taiwan (R.O.C.)Tel : +886-2-2218-6789 TSC Auto ID Technology Co., Ltd. FCC ID.: VTV0481202 9F., No. 95, Minquan Rd. Xindian Dist. New Taipei City 23141, Taiwan (R.O.C.)Tel : +886-2-2218-6789 TSC Auto ID Technology Co., Ltd. FCC ID.: VTV0481202 9F., No. 95, Minquan Rd. Xindian Dist. New Taipei City 23141, Taiwan (R.O.C.)Tel : +886-2-2218-6789 TSC Auto ID Technology Co., Ltd. FCC ID.: VTV0481202 9F., No. 95, Minquan Rd. Xindian Dist. New Taipei City 23141, Taiwan (R.O.C.)Tel : +886-2-2218-6789 TSC Auto ID Technology Co., Ltd. FCC ID.: VTV0481202 9F., No. 95, Minquan Rd. Xindian Dist. New Taipei City 23141, Taiwan (R.O.C.)Tel : +886-2-2218-6789 TSC Auto ID Technology Co., Ltd. FCC ID.: VTV0481202 9F., No. 95, Minquan Rd. Xindian Dist. New Taipei City 23141, Taiwan (R.O.C.)Tel : +886-2-2218-6789

Report No.: 124446R-RFUSP28V01 Page : 2 of 16 (3) EUT Photo (4) EUT Photo Report No.: 124446R-RFUSP28V01 Page : 3 of 16 (5) EUT Photo (6) EUT Photo Report No.: 124446R-RFUSP28V01 Page : 4 of 16 (7) EUT Photo (8) EUT Photo Report No.: 124446R-RFUSP28V01 Page : 5 of 16 (9) EUT Photo (10) EUT Photo modular location Report No.: 124446R-RFUSP28V01 Page : 6 of 16 (11) EUT Photo (12) EUT Photo Report No.: 124446R-RFUSP28V01 Page : 7 of 16 (13) EUT Photo (14) EUT Photo Report No.: 124446R-RFUSP28V01 Page : 8 of 16 (15) EUT Photo (16) EUT Photo Antenna Report No.: 124446R-RFUSP28V01 Page : 9 of 16 (17) EUT Photo (18) EUT Photo Report No.: 124446R-RFUSP28V01 Page : 10 of 16 (19) EUT Photo (20) EUT Photo Report No.: 124446R-RFUSP28V01 Page : 11 of 16 (21) EUT Photo (22) EUT Photo Report No.: 124446R-RFUSP28V01 Page : 12 of 16 (23) EUT Photo (24) EUT Photo Report No.: 124446R-RFUSP28V01 Page : 13 of 16 (25) EUT Photo (26) EUT Photo Report No.: 124446R-RFUSP28V01 Page : 14 of 16 (27) EUT Photo (28) EUT Photo Report No.: 124446R-RFUSP28V01 Page : 15 of 16 (29) EUT Photo (30) EUT Photo Report No.: 124446R-RFUSP28V01 Page : 16 of 16 (31) EUT Photo

Report No：124446R-HPUSP09V01 Page: 1 of 22 SAR Test Report Product Name ：Printer Model No. ：TSC-30W, CN-30W, BP-30W, PR30W, GR30W, 3300W, TSC-30RW, CN-30RW, BP-30RW, PR30RW, GR30RW, 3300RW, Alpha-3RW Applicant ： TSC Auto ID Technology Co., Ltd. Address ： 9F., No. 95, Minquan Rd. Xindian Dist. New Taipei City 23141, Taiwan (R.O.C.) Date of Receipt ：2012/04/23 Issued Date ：2012/06/28 Report No. ：124446R-HPUSP09V01 Report Version ：V1.0 The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of Quie Tek Corporation. Report No：124446R-HPUSP09V01 Page: 2 of 22 Test Report Certification Issued Date: 2012/06/28 Report No.:124446R-HPUSP09V01 Product Name ： Printer Applicant ： TSC Auto ID Technology Co., Ltd. Address ： 9F., No. 95, Minquan Rd. Xindian Dist. New Taipei City 23141, Taiwan (R.O.C.) Manufacturer ： TSC Auto ID Technology Co., Ltd. Model No. ： TSC-30W, CN-30W, BP-30W, PR30W, GR30W, 3300W, TSC-30RW, CN-30RW, BP-30RW, PR30RW, GR30RW, 3300RW, Alpha-3RW Trade Name ： TSC FCC ID ： VTV0481202 Applicable Standard： FCC Oet65 Supplement C June 2001 IEEE Std. 1528-2003 47CFR § 2.1093 Measurement procedures ： KDB 447498 , KDB 248227, KDB616217 Test Result ： Max. SAR Measurement (1g) 0.023 W/kg Application Type ： Certification The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of Quie Tek Corporation. Documented By ： (Adm. Assistant / April Chen ) Tested By ： (Engineer / Wen Lee) Approved By ： (Manager / Vincent Lin) Report No：124446R-HPUSP09V01 Page: 3 of 22 TABLE OF CONTENTS Description Page 1. General Information.............................................................................. 5 1.1 EUT Description ............................................................................................................5 1.2 Antenna List ................................................................................................................... 5 1.3 Test Environment ...........................................................................................................6 2. SAR Measurement System .................................................................. 7 2.1 DASY5 System Description .......................................................................................... 7 2.1.1 Applications ................................................................................................................ 8 2.1.2 Area Scans................................................................................................................... 8 2.1.3 Zoom Scan (Cube Scan Averaging)............................................................................ 8 2.1.4 Uncertainty of Inter-/Extrapolation and Averaging .................................................... 8 2.2 DASY5 E-Field Probe ................................................................................................... 9 2.2.1 Isotropic E-Field Probe Specification ......................................................................... 9 2.3 Boundary Detection Unit and Probe Mounting Device ............................................... 10 2.4 DATA Acquisition Electronics (DAE) and Measurement Server ............................... 10 2.5 Robot ............................................................................................................................ 11 2.6 Light Beam Unit........................................................................................................... 11 2.7 Device Holder ..............................................................................................................12 2.8 SAM Twin Phantom .................................................................................................... 12 3. Tissue Simulating Liquid ................................................................... 13 3.1 The composition of the tissue simulating liquid .......................................................... 13 3.2 Tissue Calibration Result ............................................................................................. 13 3.3 Tissue Dielectric Parameters for Head and Body Phantoms ....................................... 14 4. SAR Measurement Procedure ........................................................... 15 4.1 SAR System Check ...................................................................................................... 15 4.1.1 Dipoles ...................................................................................................................... 15 4.1.2 System Check Result ................................................................................................ 15 4.2 SAR Measurement Procedure ...................................................................................... 16 5. SAR Exposure Limits ......................................................................... 17 6. Test Equipment List............................................................................ 18 7. Measurement Uncertainty .................................................................. 19 8. Average Power Measurement............................................................ 20 9. Test Results......................................................................................... 21 9.1 SAR Test Results Summary ......................................................................................... 21 Appendix ............................................................................................................................ 22 Report No：124446R-HPUSP09V01 Page: 4 of 22 Appendix A. SAR System Check Data Appendix B. SAR measurement Data Appendix C. Test Setup Photographs & EUT Photographs Appendix D. Probe Calibration Data Appendix E. Dipole Calibration Data Report No：124446R-HPUSP09V01 Page: 5 of 22 1. General Information 1.1 EUT Description Product Name Printer Tra…

Text truncated - open the document above for the full version.

Report No.: 124446R-RFUSP28V01 Page : 1 of 105 Test Report Product Name Printer Model No TSC-30W, CN-30W, BP-30W, PR30W, GR30W, 3300W, TSC-30RW, CN-30RW, BP-30RW, PR30RW, GR30RW, 3300RW, Alpha-3RW FCC ID. VTV0481202 Applicant TSC Auto ID Technology Co., Ltd. Address 9F., No. 95, Minquan Rd. Xindian Dist. New Taipei City 23141, Taiwan (R.O.C.) Date of Receipt April 23, 2012 Issue Date July 17, 2012 Report No. 124446R-RFUSP28V01 Report Version V1.0 The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by NVLAP any agency of the U.S. Government Report No.: 124446R-RFUSP28V01 Page : 2 of 105 Test Report Certification Issue Date: July 17, 2012 Report No.: 124446R-RFUSP28V01 Product Name Printer Applicant TSC Auto ID Technology Co., Ltd. Address 9F., No. 95, Minquan Rd. Xindian Dist. New Taipei City 23141, Taiwan (R.O.C.) Manufacturer TSC Auto ID Technology Co., Ltd. Model No. TSC-30W, CN-30W, BP-30W, PR30W, GR30W, 3300W, TSC-30RW, CN-30RW, BP-30RW, PR30RW, GR30RW, 3300RW, Alpha-3RW FCC ID. VTV0481202 EUT Rated Voltage DC 7.4V (Power by Battery), DC 12V(Power by Adapter) EUT Test Voltage AC 120V/60Hz Trade Name TSC Applicable Standard FCC CFR Title 47 Part 15 Subpart C: 2010 ANSI C63.4: 2003 Test Result Complied The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by NVLAP any agency of the U.S. Government Documented By: ( Senior Adm. Specialist / Rita Huang ) Tested By : ( Engineer / Alan Chen ) Approved By : ( Manager / Vincent Lin ) Accredited by NIST (NVLAP) NVLAP Lab Code: 200533-0 Report No.: 124446R-RFUSP28V01 Page : 3 of 105 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION .....................................................................................................5 1.1. EUT Description............................................................................................................................5 1.2. Operational Description ................................................................................................................7 1.3. …
