WMUHAC-WRW-E1Pulse reader for Elster

WRW-E1 electronic backpack Installation and operation instructions WRW-E1 pulse reader P1 Content 1. Overview .......................................................................................................................................................................... 2 2. Metering Module Feature ................................................................................................................................................. 2 3. Product Assembly ............................................................................................................................................................. 4 4. Operating instructions for metering module ..................................................................................................................... 5 5. Precautions and handling of common problems ............................................................................................................... 5 6. Instruction of production configuration tool ..................................................................................................................... 5 6.4. Supported software ................................................................................................................................................ 7 6.4.1. Software installation ................................................................................................................................... 7 6.5. Production Test Flow .......................................................................................................................................... 11 6.6. Precautions for production setup ......................................................................................................................... 12 7. Infrared upgrade function ............................................................................................................................................... 12 7.1. Supported software .............................................................................................................................................. 12 7.1.1. Software installation ................................................................................................................................. 12 7.1.2. Software interface .................................................................................................................................... 12 7.2. Upgrading Flow ................................................................................................................................................... 13 Disclaimers ......................................................................................................................................................................... 14 WRW-E1 pulse reader P2 1. Overview The Pulse Reader (ID: WRW-E1) integrates hall metering, acquisition, communication and transmission. It can be able to monitor abnormal conditions such as magnetic interference, low voltage of battery and disassembly in real time, and actively report it to the management platform. The pulse reader and the gateway form a star network, which is convenient for network maintenance, with high reliability and strong scalability. It complies with LoRaWAN1.0.2 standard protocol. 2. Metering Module Feature 2.1. Electrical characteristics No. Feature Function Description 1 Working frequency It’s compatible with LoRaWAN®,EU868,AU915 are optional 2 Maximum transmitting power It’s in accordance with the requirements of power limit in different areas of the LoRaWAN protocol 3 Working temperature -20°C ～ +55°C 4 Working voltage +3.2V ～ +3.8V 5 Transmitting distance ＞ 10km 6 Lifespan ＞ 8 years （ use one ER18505 lithium battery ） 7 Waterproof degree IP68 2.2. Feature Description No. Feature Function Description 1 Data reporting There are two data reporting methods. Touch to report data: touch the button twice, touch the LED light to light up, lift up the LED light to go out. It must be greater than 2S at the first touch, it must be completed within 5S at the second touch after the first touch and it’s less than 2S, otherwise it’s invalid. Actively reporting at regular time: The period and time of timing reporting can be set. The value range of the timing reporting period is 600~86400S, and the value range of the timing reporting time is 0~23H. After setting, the reporting time is calculated according to the DeviceEui of the metering module, the regular reporting period, and the scheduled reporting time. The default value of the regular reporting period is 28800S, and the default value of the scheduled reporting time is 6H. 2 Measurement Support 10L/P single hall 3 Power-down storage Support power-down storage function,there is no need to re-initialize the measurement value after power-off WRW-E1 pulse reader P3 4 Magnetic attack detection It detects every 2S. When a malicious magnetic attack is detected, an alarm flag of magnetic attack and a historical magnetic attack will be generated immediately. If there is no magnetic attack detected for continuous 10 seconds, the alarm flag will be automatically cleared. The historical magnetic attack alarm flag must be successfully reported to the cloud platform before it can be automatically cleared. Neither the detected nor the cleared magnetic attack alarm will actively report data. 5 Low voltage alarm When the battery voltage is lower than 3.2V and the duration is longer than 30S, a low-voltage alarm flag will be generated; when the battery voltage is greater than 3.4V and the duration is greater than 60S, the low-voltage alarm will be cleared; the battery voltage 3.2V to 3.4V will not handle the low-voltage alarm flag. Neither detection of low-voltage alarm nor clearing of low-voltage alarm will actively report data. The accuracy of voltage detection is less than 0.1V. 6 Disassembly alarm It detects every 2s,when it detects maliciously disassemble,it will …

Text truncated - open the document above for the full version.

Shenzhen HAC Telecom Technology Co., LTD * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter 4/21/2023 ATTN.: Reviewing Engineer Per section 2.911(d)(7) of the FCC rules, Shenzhen HAC Telecom Technology Co., LTD (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process: Company Name: JOC Australia Inc Physical U.S. Company Address: 18351 Colima Road Ste 585 Rowland Heights,California,91748 United States of America Agent contact name/Title : Benjamin.Smith/Vice President Agent Email Address: [email protected]/[email protected] Tel No.: +1(626) 217 4778 FRN No.: 0033379421 The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Agent Signed (if different to Applicant): Signed: Signed: Printed name: Koala Zhang Printed name: Benjamin. Smith Title: CEO Title: Vice President Company Name: Shenzhen HAC Telecom Company Name: JOC Australia Inc Technology Co., LTD Date: 4/21/2023 Date: 4/21/2023

Shenzhen HAC Telecom Technology Co., LTD Agent Authorization Company: Shenzhen HAC Telecom Technology Co., LTD Address: Fl 9, Block A, Bldg 1, Shenzhen International Innovation Valley, Xingke 1st Street, Nanshan, Shenzhen, China Product Name: Pulse reader for Elster Model Number(s): WRW-E1 Product Description: Pulse reader for Elster We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2023.03.31 Name: Jiankuai Li Title: PM Company: SHENZHEN STS TEST SERVICES CO.,LTD.

Shenzhen HAC Telecom Technology Co., LTD Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2023.03.31 Subject; Request for Confidentiality FCC ID: WMUHAC-WRW-E1 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Signature: Date: 2023.03.31 Name: Jiankuai Li Title: PM Company: SHENZHEN STS TEST SERVICES CO.,LTD.

Page 1 of 3 Report No.: STS2302125 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: WRW-E1 Photo 1 Photo 2 Page 2 of 3 Report No.: STS2302125 Photo 3 Photo 4 Page 3 of 3 Report No.: STS2302125 Photo 5 Photo 6

FCC Label W:15mm L:30mm Pulse reader for Elster Model: WRW-E1 FCC ID: WMUHAC-WRW-E1

Page 1 of 3 Report No.: STS2302125 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: WRW-E1 Photo 1 Photo 2 Page 2 of 3 Report No.: STS2302125 Photo 3 Photo 4 SRD Antenna Page 3 of 3 Report No.: STS2302125 Photo 5 Photo 6

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS2302125H02 Issued for Shenzhen HAC Telecom Technology Co., LTD Fl 9, Block A, Bldg 1, Shenzhen International Innovation Valley, Xingke 1st Street, Nanshan, Shenzhen, China Product Name: Pulse reader for Elster Brand: Model Number: WRW-E1 Series Model(s): N/A FCC ID: WMUHAC-WRW-E1 Test Standard: FCC 47CFR §2.1093 S T L A B S Page 2 of 9 Report No.: STS2302125H02 Test Report Certification Applicant’s Name ................. : Shenzhen HAC Telecom Technology Co., LTD Address ................................. : Fl 9, Block A, Bldg 1, Shenzhen International Innovation Valley, Xingke 1st Street, Nanshan, Shenzhen, China Manufacturer's Name .......... : Shenzhen HAC Telecom Technology Co., LTD Address ................................. : Fl 9, Block A, Bldg 1, Shenzhen International Innovation Valley, Xingke 1st Street, Nanshan, Shenzhen, China Product Description Product Name ........................ : Pulse reader for Elster Brand ................................... : Model Number ....................... : ... : WRW-E1 Series Model(s) ..................... : N/A Standards ............................. : FCC 47CFR §2.1093 447498 D04 Interim General RF Exposure Guidance v01 This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ........................................... : Date of receipt of test item ..................... : 21 Feb. 2023 Date (s) of performance of tests ............. : 21 Feb. 2023 ~ 30 Mar. 2023 Date of Issue .......................................... : 30 Mar. 2023 Test Result.............................................. : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory : (Bovey Yang) Page 3 of 9 Report No.: STS2302125H02 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 5 2. FCC 47CFR §2.1091 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 9 Page 4 of 9 Report No.: STS2302125H02 Revision History Rev. Issue Date Report No. Effect Page Contents 00 30 Mar. 2023 STS2302125H02 ALL Initial Issue Page 5 of 9 Report No.: STS2302125H02 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name Pulse reader for Elster Brand Model Number WRW-E1 Series Model(s) N/A Model Difference N/A Product Description The EUT is Pulse reader for Elster. Operation Frequency: 903.3-926.8MHz Modulation Type: GFSK Antenna gain: 0dBi Antenna Designation: Helical Antenna Battery Rated Voltage:3.6V Charge Limit Voltage: Not rechargeable Capacity: 4000mAh Hardware Version HAC-MLW2 Software Version N/A 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 6 of 9 Report No.: STS2302125H02 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS Follow the maximum permissible exposure (MPE) limits specified in 447498 D04 Interim General Radio Frequency Exposure Guidelines v01. The gain of the antenna used in the product was extracted from the supplied antenna data sheet and the maximum total power input to the antenna was also measured. Calculate the distance from the product to the MPE limit by the formula. 2.2 LIMIT For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: Page 7 of 9 Report No.: STS2302125H02 (C) Or using below table and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half-wave dipole (1.64 linear value). RF Source frequency (MHz) Threshold ERP(watts) 0.3-1.34 1,920 R 2 . 1.34-30 3,450 R 2 /f 2 . 30-300 3.83 R 2 . 300-1,500 0.0128 R 2 f. 1,500-100,000 19.2R 2 . Page 8 of 9 Report No.: STS2302125H02 For multiple RF sources: Multiple RF sources are exempt if: (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating…

Text truncated - open the document above for the full version.

- 1 - SPECIFICATION FOR APPROVAL CUSTOMER： CUSTOMER PARTNO： SUPPLIER： PRODUCT MODEL：HAC-TH915-M15A02 PRODUCT NAME ：HAC-TH915-M15A02 PRODUCT CODE ：M04-0102040R0A CUSTOMER SIGNATURE： CUSTOMER SEAL： SUPPLIER SIGNATURE： SUPPLIER SEAL： NOTE: PLEASE RETURN THIS COPY AS A CERTIFICATION OF YOUR APPROVAL Prepared by： Date： 2022.08.02 Add： Tel: 0755-86503881 Fax: 0755-27801677 - 2 - VERSION INFORMATION Version DATE REVISION DESCRIPTION PREPARED CHECKED APPROVED V1.0 S0SS.08.0S - 3 - PERFORMANCE PARAMETER 1. Electrical Characteristics 1 Frequency Range 880MHz-960MHz 2 V.S.W.R <3.0 3 Gain 0 dBi 4 Impendence 50Ω 5 Polarization 2. Mechanical parameters 1 Measure Φ0.6mm 2 Colour Environment Condition 1 Working Temp -30°C~80°C - 4 - TESTING CURVE Matching circuit - 5 - TESTING CURVE Performance test V.S.W.R Data list Freq/MHz 880 915 960 VSWR 2.27 1.47 2.39 - 6 - TESTING CURVE Passive testing Efficiency and Gain - 7 - Data Iist Freq (MHz) Gain(dBi) Efficiency(%) 880 -1.07 43.67 885 -0.74 44.08 890 -0.37 44.35 895 0.15 46.20 900 0.57 47.81 905 0.94 49.41 910 0.85 47.68 915 0.69 45.95 920 0.64 45.33 925 0.90 48.90 930 0.87 48.70 935 0.85 51.34 940 0.60 53.29 945 0.35 53.85 950 0.32 54.48 955 0.04 51.00 - 8 - TESTING CURVE 3D Map 2D Figure 4 RoHS Compliant G P A B C 备注： 1. 0.6mm,线径公差为±0.05;材质为不锈钢镀镍线，要可容易焊锡;盐雾过48小时。 2. 未标注的转角为直角。 3. 未标注转角公差为±2度。 4. 转角外圆弧尺寸建议为： R1.0-R1.2。 5. 光洁无油污， 变形，无伤痕，无尖角，无毛刺。 ShenZhen MyAntenna RF Technology Co.,Ltd 6. 符合ROHS。 Third Angle Project HAC-TH915-M15A02 Date D 0~10 ±0.05 0.02 Part Name 弹簧 Designed by D 10~18 ±0.10 Φ0.03 Part No. M04-0102040R0A Checked by MD 18~30 ±0.12 0.02 Material RF A New drawing 20220729 30~40 ±0.15 0.04 Treatment Approved by Rev Description Date Remark 40~ ±0.20 Angle ±0 .5° Color Unit mm Scale 1:1 Rev A 1 2 3 4 5 6 7 8 SCHEDULE DRAWIN G - 9 - A B C 8 6 2 3 5 7 1 - 10 - ANTENNA PLACEMENT DIAGRAM

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No.: STS2302125W02 Issued for Shenzhen HAC Telecom Technology Co., LTD Fl 9, Block A, Bldg 1, Shenzhen International Innovation Valley, Xingke 1st Street, Nanshan, Shenzhen, China Product Name: Pulse reader for Elster Brand: Model Number: WRW-E1 Series Model(s): N/A FCC ID: WMUHAC-WRW-E1 Test Standard: FCC Part 15.249 S T L A B S Page 2 of 34 Report No.: STS2302125W02 TEST RESULT CERTIFICATION Applicant’s Name .................: Shenzhen HAC Telecom Technology Co., LTD Address ..................................: Fl 9, Block A, Bldg 1, Shenzhen International Innovation Valley, Xingke 1st Street, Nanshan, Shenzhen, China Manufacture's Name ............: Shenzhen HAC Telecom Technology Co., LTD Address ..................................: Fl 9, Block A, Bldg 1, Shenzhen International Innovation Valley, Xingke 1st Street, Nanshan, Shenzhen, China Product Description Product Name ........................: Pulse reader for Elster Brand .....................................: Model Number ........................: WRW-E1 Series Model(s) ......................: N/A Test Standards ......................: FCC Part15.249 Test Procedure .......................: ANSI C63.10-2013 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ............................: Date of receipt of test item ......: 21 Feb. 2023 Date of performance of tests ..: 21 Feb. 2023 ~ 30 Mar. 2023 Date of Issue ..........................: 30 Mar. 2023 Test Result .............................: Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory : (Bovey Yang) Page 3 of 34 Report No.: STS2302125W02 Table of Contents Page 1. SUMMARY OF TEST RESULTS 5 1.1 TEST FACTORY 6 1.2 MEASUREMENT UNCERTAINTY 6 2. GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF THE EUT 7 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 TEST SOFTWARE AND POWER LEVEL 9 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 11 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3. EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.2 RADIATED EMISSION MEASUREMENT 15 4. BANDWIDTH TEST 30 4.1 TEST PROCEDURE 30 4.2 TEST SETUP 30 4.3 EUT OPERATION CONDITIONS 30 4.4 TEST RESULTS 31 5. ANTENNA REQUIREMENT 33 5.1 STANDARD REQUIREMENT 33 5.2 EUT ANTENNA 33 APPENDIX- PHOTOS OF TEST SETUP 34 Page 4 of 34 Report No.: STS2302125W02 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 30 Mar. 2023 STS2302125W02 ALL Initial Issue Page 5 of 34 Report No.: STS2302125W02 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part 15.249 , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A 15.203 Antenna Requirement Pass 15.249 Radiated Spurious Emission Pass 15.249 Radiated Band Edge Emission Pass 15.249 Field Strength of fundamental Pass 15.215(c) 20dB Bandwidth Pass NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2013. Page 6 of 34 Report No.: STS2302125W02 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±1.197dB 2 Unwanted Emissions, conducted ±2.896dB 3 All emissions, radiated 9K-30MHz ±3.84dB 4 All emissions, radiated 30M-1GHz ±3.94dB 5 All emissions, radiated 1G-6GHz ±4.59dB 6 All emissions, radiated>6G ±5.22dB 7 Conducted Emission (9KHz-150KHz) ±2.14dB 8 Conducted Emission (150KHz-30MHz) ±2.54dB Page 7 of 34 Report No.: STS2302125W02 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name Pulse reader for Elster Brand Model Number WRW-E1 Series Model(s) N/A Model Difference N/A Product Description The EUT is a Pulse reader for Elster. Operation Frequency: 903.3-926.8MHz Modulation Type: GFSK Antenna Type: Helical Antenna Antenna Gain(Peak): 0dBi Based on the application, features, or specification exhibited in User Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User Manual. Channel List Please refer to the Note 3. Battery Rated Voltage:3.6V Charge Limit Voltage: Not rechargeable Capacity: 4000mAh Hardware version number HAC-MLW2 Software version number N/A Connecting I/O Port(s) Please refer to the Note 1. Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User Manual. 2. The antenna information refer the manufacturer provide report, applicable only to the tested sample identified in the report. Due to the incorrect antenna information, a series of problems such as the accuracy of the test results will be borne by the customer. Page 8…

Text truncated - open the document above for the full version.

Page 1 of 1 FCC ID: WMUHAC-WRW-E1 DXX Setup photo Model Number: WRW-E1 DXX radiation L DXX radiation H
