WNG-DON-30-FSKReceiver Dongle

DON-30-FSK User Manual (V0.2) Page 1 of 2 Dongle Receiver (DON-30-FSK) User Manual DON-30-FSK (dongle) is a receiver dongle for receiving signal from ILB-21-FSK (Indication light). Plug dongle to central monitor and then its Red and Green LED will blink alternatively for indicating powerup initialization. Red LED indication 1. Standby indication if there have no signal from the light. 2. Transmit data. Green LED indication 1. Blinking when received signal from the light. DON-30-FSK User Manual (V0.2) Page 2 of 2 IMPORTANT NOTICE This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received, including interference that may cause undesired operation. Notice: Any changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/ TV technician for help. History Version Description V0.1 - 1 st release. V0.2 - Added Product Name, IMPORTANT NOTICE for FCC.

Safety Human Exposure 1.1 Radio Frequency Exposure Compliance 1.1.1 Electromagnetic Fields RESULT: Pass Test Specification Test item : Receiver Dongle Identification / Type No. : DON-30-FSK FCC ID : WNG-DON-30-FSK Test standard : CFR47 FCC Part 2: Section 2.1093 FCC KDB Publication 447498 v06 Measurement Record: EIRP[dBm] = E[dBuV/m]− 95.2 Since maximum peak output power of the transmitter is -24.41 dBm ≈ 0.00362mW < 22mW. Hence the EUT is excluded from SAR evaluation according to FCC KDB Publication 447498 D01 General RF Exposure Guidance v06.

AN1603‐433 Multilayer Chip Antenna for 433MHz Wireless Communication RainSun Corporation http://www.rainsun.com 1of 9 Jun, 2008 Ver.1.4 AN1603 Multilayer Chip Antenna ◆Features Li hi hd lfil 16 0(L)X3 1 (W)X1 65 (H)yLight weight and low profile 16.0mm(L)X3.1mm(W)X1.65mm(H) yOmni‐directional in azimuth Lead (Pb) Free ◆Applications y433MHz wireless communications y433MHz Modules yOther ISM band 420MHz~660MHz Wireless Application Specifications Center frequency 433MHz Peak gain Operation temperature Storage temperature VSWR Input Impedance 0.5dBi -40 ~ +85 ̊C -40 ~ +85 ̊C 2.0 (Max) 50 Ohm Power handling Bandwidth Azimuth beamwidth Polarization 3W (Max) 8MHz Omni-directional Linear RainSun Corporation http://www.rainsun.com 2of 9 Jun, 2008 Ver.1.4 Pin configuration Pin NoPin assignment 1Feedtermination 2 1 1Feed termination 2Feed point mark 3Solder termination 3 Dimensions 3 SymbolDimensions (mm)SymbolDimensions (mm) A 16.00±0.10 B 3.10±0.10 C 0.60±0.05 H 1.65±0.20 PCB foot printer RainSun Corporation http://www.rainsun.com 3of 9 Jun, 2008 Ver.1.4 Recommended Test Board Pattern Top view Bottom view Board thickness : 0.6mm Board material : FR4 Unit : cm SMA connector Ground Plane 50 Ohm Transmission line Fig-1 Testing Setup Measurement Testing Instrument: Anritsu37369CVNA(VectorNetworkAnritsu 37369C VNA(Vector Network Analyzer) VNA calibrate with 1 path reflection only calibration sequence on test board feed point. RainSun Corporation http://www.rainsun.com 4of 9 Jun, 2008 Ver.1.4 The test board dimension and it’s layout is the same as recommended Test Board. Return loss Typical Electrical Characteristics 433 MHz Smith Chart Marker data: 1:f 430MHz1 : f=430 MHz 2 : f=433 MHz 3 : f=436 MHz RainSun Corporation http://www.rainsun.com 5of 9 Jun, 2008 Ver.1.4 3DPtt3D Pattern Theta Free-Spec, 433 MHz Phi Free-Spec, 433 MHz To t a l RainSun Corporation http://www.rainsun.com 6of 9 Jun, 2008 Ver.1.4 Free-Spec, 433 MHz Typical Soldering Profile for Lead‐free Process ) 340°C Peak temp 340°C Temperature ( °C ) 300°C 150°C 25 sec. 5 sec. Pre-heating Time (sec.) Do not exceed 30 secs. 260°C 10 sec, max Reflow Soldering e mperature ( °C ) 260°C 230°C 180°C T e 60 sec. 30 sec. Pre-heating RainSun Corporation http://www.rainsun.com 7of 9 Jun, 2008 Ver.1.4 Time (sec.) Packing Blister Tape Specifications SymbolDimensionToleranceUnit W24.00 ±0.30 mm P8.00 ±0.10 mm P22.00 ±0.10 mm Ao4.70 + 0.10 ‐3.20 mm Bo16.20 ±0.10 mm Ko1.90 ±0.10 mmKo1.90 ±0.10 mm F11.50 ±0.10 mm E1.75 ±0.10 mm D1.50 + 0.10 ‐0.00 mm P400 ±010 RainSun Corporation http://www.rainsun.com 8of 9 Jun, 2008 Ver.1.4 Po4.00 ±0.10 mm t0.30 ±0.05 mm Reel Specifications Quantity l Tape Width () A () C () B(mm) E () W () W 1 ()Per Reel(mm)(mm)(mm) B (mm) (mm)(mm)(mm) 3,00024 330±1 13.0±0.5 100.0±0.5 2.2±0.5 24.0±0.5 28.9±0.2 RainSun Corporation http://www.rainsun.com 9of 9 Jun, 2008 Ver.1.4

Test Report No.: EFGX22110323-IE-01-E04 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 101 and 201, Building 2, Dongfangming Industrial Area, No 83. Dabao Rd., Area 33 Shanghe Neibourhood, Xin’an Community, Bao’an District, Shenzhen, P.R. China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 1 of 21 EUROFINS ELECTRICAL TESTING SERVICE (SHENZHEN) CO., LTD. RADIO TEST - REPORT FCC Compliance Test Report Product name: Receiver Dongle Model name: DON-30-FSK FCC ID: WNG-DON-30-FSK Test Report Number: EFGX22110323-IE-01-E04 Test Report No.: EFGX22110323-IE-01-E04 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 101 and 201, Building 2, Dongfangming Industrial Area, No 83. Dabao Rd., Area 33 Shanghe Neibourhood, Xin’an Community, Bao’an District, Shenzhen, P.R. China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 2 of 21 Content 1 General Information 3 1.1 Notes 3 1.2 Testing laboratory 4 1.3 Details of approval holder 4 1.4 Details of Manufacturer 4 1.5 Application details 4 1.6 Test item 4 1.7 Test standards 5 2 Technical test 6 2.1 Summary of test results 6 2.2 Test environment 6 2.3 Measurement uncertainty 6 2.4 Test mode 6 2.5 Test equipment utilized 7 2.6 Auxiliary Equipment Used during Test: 7 2.7 Test software information 7 2.8 Customized Configurations 7 2.9 Test Environments 7 2.10 Test results 8 3 Technical Requirement 9 3.1 Conducted Emission 9 3.2 Automatically Deativate 10 3.3 20dB bandwidth 12 3.4 Field strength of fundamental , Field strength of spurious emission for transmitter and Restricted bands 14 Test Report No.: EFGX22110323-IE-01-E04 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 3 of 21 1 General Information 1.1 Notes The results of this test report relate exclusively to the item tested as specified in chapter “Description of test item” and are not transferable to any other test items. Eurofins Product Testing Service (Shenzhen) Co., Ltd. is not responsible for any generalisations and conclusions drawn from this report. Any modification of the test item can lead to invalidity of test results and this test report may therefore be not applicable to the modified test item. The test report may only be reproduced or published in full. Reproducing or publishing extracts of the report requires the prior written approval of the Eurofins Product Testing Service (Shenzhen) Co., Ltd. This document is subject to the General Terms and Conditions and the Testing and Certification System of Eurofins Product Testing Service (Shenzhen) Co., Ltd., available on request or accessible at www.eurofins.com. Operator: 2023-01-18 Bruce Zheng / Project Engineer Date Eurofins-Lab. Name / Title Signature Technical responsibility for area of testing: 2023-01-18 Abert Xu / Lab Manager Date Eurofins-Lab. Name / Title Signature Test Report No.: EFGX22110323-IE-01-E04 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 4 of 21 1.2 Testing laboratory Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone : +86-755-82911867 Fax : +86-755-82910749 The Laboratory has passed the Accreditation by the American Association for Laboratory Accrediation (A2LA). The Accreditation number is 5376.01 The Laboratory has been listed by industry Canada to perform electromagnetic emission measurements, The CAB identifier is CN0088 1.3 Details of approval holder Name : Rondish Co. Ltd Address : UNIT G&H, 4/F, Block 1, KWAI TAK IND. CTR, 15-33 K HONGKONG, China Telephone : ./. Fax : ./. 1.4 Details of Manufacturer Name : Rondish Co. Ltd Address : UNIT G&H, 4/F, Block 1, KWAI TAK IND. CTR, 15-33 K HONGKONG, China Telephone : ./. Fax : ./. 1.5 Application details Date of receipt of application : 2022-11-23 Date of receipt of test item : 2022-11-23 Date of test : 2022-11-23 to 2023-01-11 Date of issue : 2023-01-18 1.6 Test item Product type : Receiver Dongle Model name : DON-30-FSK Brand : Rondish Serial number : N/A Ratings : USB input: 5.0V, Class III Test voltage : 5VDC FCC ID : WNG-DON-30-FSK PMN : Receiver Dongle Additional information : N/A RadioTechnical data Frequency range : 434.40MHz Radio Tech. : N/A Frequency channel : 1 Channel Modulation : FSK Antenna type : Chip antenna Test Report No.: EFGX22110323-IE-01-E04 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 5 of 21 1.7 Test standards Test Standards FCC Part 15 Subpart C PART 15 - RADIO FREQUENCY DEVICES Subpart C - Intentional Radiators Test Method 1: ANSI C63.4-2014, American National Standard for Methods of Measurement of Radio-Noise Emis- sions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. 2: ANSI C63.10-2013, American National Standard for Testing Unlicensed Wireless Devices. Test Report No.: EFGX22110323-IE-01-E04 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 6 of 21 2 Technical test 2.1 Summary of test results No deviations from the technical specification(s) were ascertained in the course of the tests performed. or The deviations as specified were ascertained in the course of the tests performed. 2.2 Test environment Temperature : 20 ... 25°C Relative humidity …
