X3XMS-1Free Style CAMERA QBiC

QBiC MS-1 ©2013 Copyright ELMO Co., Ltd. All rights reserved. Any names, company names and product names referred to in this guide are trademarks or registered trademarks of the respective companies. START-UP GUIDE page 5 – IMPORTANT SAFEGUARDS page17- MEMO 2 MEMO 3 <<QBiC スタートアップガイド & 安全上の注意>> 目次 スタートアップガイド 箱の中身を確認する ............................................................................... 7 各部の総称 ................................................................................................ 8 準備する .................................................................................................. 11 充電方法 .............................................................................................. 11 MICROSDカードをセットする ...................................................... 13 電源を入れる/電源を切る ................................................................ 14 撮影する .................................................................................................. 14 動画を撮影する ................................................................................. 16 静止画を撮影する(通常撮影モード) .............................................. 16 静止画を撮影する(連続撮影モード) .............................................. 17 静止画を撮影する(インターバル撮影モード) .............................. 17 ライブビュー ........................................................................................... 18 QBICアプリケーションのインストール .................................... 18 WIFIで接続する................................................................................. 20 再生 .......................................................................................................... 28 本機で録画した映像をテレビやプロジェクタで再生する ...... 28 本機で録画した映像をスマートフォンで再生するエラー! ブックマークが定義 マスストレージ モード ....................................................................... 29 マスストレージ モードの 起動方法 .............................................. 29 その他の機能.......................................................................................... 30 本体のリセット手段 ......................................................................... 30 リモートコントロール ..................................................................... 30 アップデートについて ......................................................................... 31 4 安全上の注意 安全に御使用頂く為に － 必ずお守りください ........................... 33 使用上のご注意 ... エラー! ブックマークが定義されていません。 あらかじめご了承くださいエラー! ブックマークが定義されていませ 5 QBiC MS-1 START-UP GUIDE INTRODUCTION Thank you for purchasing QBiC MS-1 . ●This guide is intended to describe the usage and setting of the camera for the sake of appropriate usage and the user’s safety. ●Please read this guide and the IMPORTANT SAFEGUARDS carefully before using the camera. ●Please refer to the QBiC MS-1 INSTRUCTION MANUAL for any other setting and information. ●Please keep this guide for future reference. QBiC PACKAGE CONTENTS □ QBiC MS-1 □ USB cable (0.2m) □ Lens protection cover □ START-UP GUIDE & IMPORTANT SAFEGUARDS □ Warranty card This camera has been carefully packed with special attention to quality. However, should you find anything damaged or missing, please contact your dealer or ELMO. *This camera uses software covered by GPL/LGPL, which give users the right to obtain, modify, and redistribute the applicable software source code. For details, refer to the QBiC MS-1 INSTRUCTION MANUAL. 7 THE NAME OF EACH PART FRONT 8 BACK The maximum length of screws that can be used with the port is 5.5mm. Using longer screws than 5.5mm will damage the port. This product is guaranteed to be practical waterproof (waterproof against water drops for a short period). However, we do not guarantee its waterproof performance in the following conditions: - The Interface Terminal Cover has not been closed properly. 9 - The rubber packing of the Interface Terminal Cover or the camera body has been damaged due to deterioration or an external impact. - The Interface Terminal Cover has been opened or closed in places where there is a lot of dust or under the rain or by dirty or wet hand. 10 PREPARATIONS CHARGING This camera has a built-in battery. ＊The battery cannot be removed by the user. ＊The battery is not fully charged at the time of purchase. Charge the battery before using the camera for the first time. 1. Turn off the camera. Charging is not possible while the power is on. 2. Open the Interface Terminal Cover. Connect the micro B connector (smaller connector) of the supplied USB cable to the USB port of the camera. 3. Connect the USB plug of the USB cable to a USB port on your computer. Battery charging will start. The [Power LED] turns red while charging. 4. Battery is fully charged when the [Power LED] turns off. 11 12 INSERTING micro SD CARD 1. Open the Interface Terminal Cover. 2. Insert the micro SD card to the micro SD card slot. * Pay attention to the direction of the card when inserting the micro SD card. Insert the micro SD card until it clicks. Improper insertion of the card may cause error or damage the camera. *Refer to the QBIC MS-1 INSTRUCTION MANUAL for the compatible list of the micro SD card. 3. Close the Interface Terminal Cover. * Make sure to close the cover correctly. Otherwise the waterproof performance may be deteriorated, causing damage to the camera. 13 POWERING ON/OFF POWERING ON Press and hold (over 1second) the [Power Switch] to power on the camera. The [Power LED] turns blue. POWERING OFF Press and hold (over 1 second) the [Power Switch] to power off the camera. All LED’s turn off. (When the camera is connected to a computer or the optional AC adapter via the USB cable, charging will start and the [Power LED] turns red. *The power of the camera automatically goes off under the following conditions: - When the temperature of the camera exceeds the safety limit - When a defect is detected for the battery SHOOTING 14 With this camera, you can record movies and take photos. There are 3 modes of taking photos: “Normal Shooting”, “Continuous Shooting” and “Interval Shooting”. Recorded movies and photos are saved in the micro SD card. Each setting can…

Text truncated - open the document above for the full version.

Report No.: 13C0155R-RFUSP26V00 Page : 1 of 9 Attachment 2 : EUT Detailed Photographs (1) EUT Photo (2) EUT Photo Report No.: 13C0155R-RFUSP26V00 Page : 2 of 9 (3) EUT Photo (4) EUT Photo

ELMO COMPANY, LIMITED FCC ID.: X3XMS-1 6-14, Meizen-cho, Mizuho-ku, Nagoya, 467-8567, JAPAN Tel : +81-52-811-5136 FCC ID Label

ELMO COMPANY, LIMITED FCC ID.: X3XMS-1 6-14, Meizen-cho, Mizuho-ku, Nagoya, 467-8567, JAPAN Tel : +81-52-811-5136 The FCC ID Label will be placed on the equipment as shown in the photograph below.

Report No.: 13C0155R-RFUSP26V00 Page : 3 of 9 (5) EUT Photo (6) EUT Photo Report No.: 13C0155R-RFUSP26V00 Page : 4 of 9 (7) EUT Photo (8) EUT Photo Antenna WLAN Chip Report No.: 13C0155R-RFUSP26V00 Page : 5 of 9 (9) EUT Photo (10) EUT Photo Report No.: 13C0155R-RFUSP26V00 Page : 6 of 9 (11) EUT Photo (12) EUT Photo Report No.: 13C0155R-RFUSP26V00 Page : 7 of 9 (13) EUT Photo (14) EUT Photo Report No.: 13C0155R-RFUSP26V00 Page : 8 of 9 (15) EUT Photo (16) EUT Photo Report No.: 13C0155R-RFUSP26V00 Page : 9 of 9 (17) EUT Photo (18) EUT Photo

Report No.: 13C0155R-RFUSP26V00 Page: 1 of 3 RF Exposure Evaluation declaration Product Name Free Style CAMERA QBiC Model No. MS-1 FCC ID X3XMS-1 Applicant ELMO COMPANY, LIMITED Address 6-14, Meizen-cho, Mizuho-ku, Nagoya, 467-8567, JAPAN Date of Receipt Dec. 03, 2013 Date of DeclarationFeb. 10, 2014 Report No. 13C0155R-RFUSP26V00 The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by TAF or any agency of the U.S. Government Report No.: 13C0155R-RFUSP26V00 Page: 2 of 3 1. RF Exposure Evaluation 1.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 300-1500 -- -- F/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 300-1500 -- -- F/1500 6 1500-100,000 -- -- 1 30 F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. 1.2. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. The temperature and related humidity: 18°Cand 78％ RH. Report No.: 13C0155R-RFUSP26V00 Page: 3 of 3 1.3. Test Result of RF Exposure Evaluation Product : Free Style CAMERA QBiC Test Item : RF Exposure Evaluation Test Site : No.3 OATS Output Power Into Antenna & RF Exposure Evaluation Distance (1.5dBi): Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm2) 157.7611 0.044333 Note: Power density is much lower than the limit (1 mW/cm2).

Report No.: 13C0155R-RFUSP26V00 Page : 1 of 110 FCC Test Report Product Name Free Style CAMERA QBiC Model No MS-1 FCC ID. X3XMS-1 Applicant ELMO COMPANY, LIMITED Address 6-14, Meizen-cho, Mizuho-ku, Nagoya, 467-8567, JAPAN Date of Receipt Dec. 03, 2013 Issue Date Feb. 10, 2014 Report No. 13C0155R-RFUSP26V00 Report Version V1.0 The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by TAF or any agency of the U.S. Government. Report No.: 13C0155R-RFUSP26V00 Page : 2 of 110 Test Report Certification Issue Date: Feb. 10, 2014 Report No.: 13C0155R-RFUSP26V00 Product Name Free Style CAMERA QBiC Applicant ELMO COMPANY, LIMITED Address 6-14, Meizen-cho, Mizuho-ku, Nagoya, 467-8567, JAPAN Manufacturer ELMO COMPANY, LIMITED Model No. MS-1 FCC ID. X3XMS-1 EUT Rated Voltage DC 3.7V by battery EUT Test Voltage AC 120V/60Hz Trade Name ELMO Applicable Standard FCC CFR Title 47 Part 15 Subpart C: 2012 ANSI C63.10: 2009, KDB 558074 Test Result Complied The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by TAF or any agency of the U.S. Government. Documented By : ( Senior Adm. Specialist / Rita Huang ) Tested By : ( Engineer / Jack Hsu ) Approved By : ( Director / Vincent Lin ) Report No.: 13C0155R-RFUSP26V00 Page : 3 of 110 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION .....................................................................................................5 1.1. EUT Description............................................................................................................................5 1.2. Operational Description ................................................................................................................7 1.3. Tested System Details....................................................................................................................8 1.4. Configuration of Tested System ....................................................................................................8 1.5. EUT Exercise Software .................................................................................................................8 1.6. Test Facility ...................................................................................................................................9 2. Conducted Emission..................................................................................................................10 2.1. Test Equipment............................................................................................................................10 2.2. Test Setup ....................................................................................................................................10 2.3. Limits ..........................................................................................................................................11 2.4. Test Procedure .............................................................................................................................11 2.5. Uncertainty ..................................................................................................................................11 2.6. Test Result of Conducted Emission.............................................................................................12 3. Peak Power Output ...................................................................................................................14 3.1. Test Equipment............................................................................................................................14 3.2. Test Setup ....................................................................................................................................14 3.3. Limits ..........................................................................................................................................14 3.4. Test Procedure .............................................................................................................................14 3.5. Uncertainty ..................................................................................................................................14 3.6. Test Result of Peak Power Output...............................................................................................15 4. Radiated Emission .....................................................................................................................18 4.1. Test Equipment............................................................................................................................18 4.2. Test Setup ....................................................................................................................................19 4.3. Limits ..........................................................................................................................................20 4.4. Test Procedure .............................................................................................................................21 4.5. Uncertainty ..................................................................................................................................21 4.6. Test Result of Radiated Emission................................................................................................22 5. RF antenna conducted test........................................................................................................34 5.1. Test Equipment............................................................................................................................34 5.2. Test Setup ....................................................…

Text truncated - open the document above for the full version.

Report No.: 13C0155R-RFUSP26V00 Page : 48 of 110 Product : Free Style CAMERA QBiC Test Item : RF Antenna Conducted Spurious Test Site : No.3 OATS Test Mode : Mode 2: Transmit (802.11g 6Mbps) Channel 01 (2412MHz) Report No.: 13C0155R-RFUSP26V00 Page : 49 of 110 Report No.: 13C0155R-RFUSP26V00 Page : 50 of 110 Report No.: 13C0155R-RFUSP26V00 Page : 51 of 110 Report No.: 13C0155R-RFUSP26V00 Page : 52 of 110 Channel 06 (2437MHz) Report No.: 13C0155R-RFUSP26V00 Page : 53 of 110 Report No.: 13C0155R-RFUSP26V00 Page : 54 of 110 \\\ Report No.: 13C0155R-RFUSP26V00 Page : 55 of 110 Report No.: 13C0155R-RFUSP26V00 Page : 56 of 110 Channel 11 (2462MHz) Report No.: 13C0155R-RFUSP26V00 Page : 57 of 110 Report No.: 13C0155R-RFUSP26V00 Page : 58 of 110 Report No.: 13C0155R-RFUSP26V00 Page : 59 of 110 Report No.: 13C0155R-RFUSP26V00 Page : 60 of 110 Product : Free Style CAMERA QBiC Test Item : RF Antenna Conducted Spurious Test Site : No.3 OATS Test Mode : Mode 3: Transmit (802.11n MCS0 7.2Mbps 20M-BW) Channel 01 (2412MHz) Report No.: 13C0155R-RFUSP26V00 Page : 61 of 110 Report No.: 13C0155R-RFUSP26V00 Page : 62 of 110 Report No.: 13C0155R-RFUSP26V00 Page : 63 of 110

Report No.: 13C0155R-RFUSP26V00 Page : 64 of 110 Channel 06 (2437MHz) Report No.: 13C0155R-RFUSP26V00 Page : 65 of 110 Report No.: 13C0155R-RFUSP26V00 Page : 66 of 110 Report No.: 13C0155R-RFUSP26V00 Page : 67 of 110 Report No.: 13C0155R-RFUSP26V00 Page : 68 of 110 Channel 11 (2462MHz) Report No.: 13C0155R-RFUSP26V00 Page : 69 of 110 Report No.: 13C0155R-RFUSP26V00 Page : 70 of 110 Report No.: 13C0155R-RFUSP26V00 Page : 71 of 110 Report No.: 13C0155R-RFUSP26V00 Page : 72 of 110 6. Band Edge 6.1. Test Equipment RF Radiated Measurement: The following test equipments are used during the band edge tests: Test Site Equipment Manufacturer Model No./Serial No. Last Cal. Bilog Antenna Schaffner Chase CBL6112B/2673 Sep., 2013 X Horn Antenna Schwarzbeck BBHA9120D/D305 Sep., 2013 Horn Antenna Schwarzbeck BBHA9170/208 Jul., 2013 X Pre-Amplifier Agilent 8447D/2944A09549 Sep., 2013 X Spectrum Analyzer Agilent E4407B / US39440758 May, 2013 Test Receiver R & S ESCS 30/ 825442/018 Sep., 2013 X Coaxial Cable QuieTek QTK-CABLE/ CAB5 Feb., 2014 X Controller QuieTek QTK-CONTROLLER/ CTRL3 N/A Site # 3 X Coaxial Switch Anritsu MP59B/6200265729 N/A Note: 1. All instruments are calibrated every one year. 2. The test instruments marked by “X” are used to measure the final test results. 6.2. Test Setup RF Radiated Measurement: EUT FRP Dome The height of broad band or Dipole Antenna was scanned from 1M to 4M. The distance between antenna and turn table was 3M regards to the standard ado pted. 3m 80cm To Receiver Pre- Amplifier Report No.: 13C0155R-RFUSP26V00 Page : 73 of 110 6.3. Limits Emissions radiated outside of the specified frequency bands, except for harmonics, shall be attenuated by at least 20dB below the level of the fundamental or to the general radiated emission limits in paragraph 15.209, whichever is the lesser attenuation. 6.4. Test Procedure The EUT was setup according to ANSI C63.10: 2009 and tested according to DTS test procedure of KDB558074 for compliance to FCC 47CFR 15.247 requirements. The EUT is placed on a turn table which is 0.8 meter above ground. The turn table is rotated 360 degrees to determine the position of the maximum emission level. The EUT was positioned such that the distance from antenna to the EUT was 3 meters. The antenna is scanned from 1 meter to 4 meters to find out the maximum emission level. This is repeated for both horizontal and vertical polarization of the antenna. In order to find the maximum emission, all of the interface cables were manipulated according to ANSI C63.10: 2009 on radiated measurement. 6.5. Uncertainty ± 3.9 dB above 1GHz ± 3.8 dB below 1GHz Report No.: 13C0155R-RFUSP26V00 Page : 74 of 110 6.6. Test Result of Band Edge Product : Free Style CAMERA QBiC Test Item : Band Edge Data Test Site : No.3 OATS Test Mode : Mode 1: Transmit (802.11b 1Mbps) RF Radiated Measurement (Horizontal): Channel No. Frequency (MHz) Correct Factor (dB) Reading Level (dBμV) Emission Level (dBμV/m) Peak Limit (dBμV/m) Average Limit (dBμV/m) Result 01 (Peak) 2384.400 31.487 25.045 56.532 74.00 54.00 Pass 01 (Peak) 2390.000 31.509 24.142 55.651 74.00 54.00 Pass 01 (Peak) 2397.200 31.545 30.244 61.788 -- -- Pass 01 (Peak) 2400.000 31.561 27.205 58.766 -- -- Pass 01 (Peak) 2413.000 31.646 61.780 93.426 -- -- Pass 01 (Average) 2384.400 31.487 12.403 43.890 74.00 54.00 Pass 01 (Average) 2390.000 31.509 12.657 44.166 74.00 54.00 Pass 01 (Average) 2397.200 31.545 24.009 55.553 -- -- Pass 01 (Average) 2398.000 31.549 24.732 56.281 -- -- Pass 01 (Average) 2400.000 31.561 20.056 51.617 -- -- Pass 01 (Average) 2414.800 31.660 58.318 89.978 -- -- Pass Figure Channel 01: Horizontal (Peak) Figure Channel 01: Horizontal (Average) Report No.: 13C0155R-RFUSP26V00 Page : 75 of 110 Note:1. All readings above 1GHz are performed with peak and/or average measurements as necessary. 2. Peak measurements: RBW = 1MHz, VBW = 3 MHz, Sweep: Auto. 3. Average measurements: RBW = 1MHz, VBW = 10 Hz, Sweep: Auto. 4. “ * ”, means this data is the worst emission level. 5. Measurement Level = Reading Level + Correct Factor. 6. The average measurement was not performed when the peak measured data under the limit of average detection. Report No.: 13C0155R-RFUSP26V00 Page : 76 of 110 Product : Free Style CAMERA QBiC Test Item : Band Edge Data Test Site : No.3 OATS Test Mode : Mode 1: Transmit (802.11b 1Mbps) RF Radiated Measurement (Vertical): Channel No. Frequency (MHz) Correct Factor (dB) Reading Level (dBμV) Emission Level (dBμV/m) Peak Limit (dBμV/m) Average Limit (dBμV/m) Result 01 (Peak) 2372.200 30.998 25.367 56.365 74.00 54.00 Pass 01 (Peak) 2390.000 30.915 24.365 55.280 74.00 54.00 Pass 01 (Peak) 2397.000 30.905 35.878 66.783 -- -- Pass 01 (Peak) 2400.000 30.912 32.225 63.137 -- -- Pass 01 (Peak) 2413.600 30.960 70.095 101.055 -- -- Pass 01 (Average) 2372.200 30.998 12.798 43.796 74.00 54.00 Pass 01 (Average) 2390.000 30.915 13.432 44.347 74.00 54.00 Pass 01 (Average) 2397.000 30.905 31.248 62.153 -- -- Pass 01 (Average) 2397.200 30.905 31.537 62.442 -- -- Pass 01 (Average) 2400.000 30.912 26.640 57.552 -- -- Pass 01 (Average) 2414.800 30.968 66.663 97.631 -- -- Pass Figure Channel 01: Vertical (Peak) Figure Channel 01: Vertical (Average) Report No.: 13C0155R-RFUSP26V00 Page : 77 of 110 Note:1. All readings above 1GHz are performed with peak and/or average measurements as necessary. 2. Peak measurements: RBW = 1MHz, VBW = 3 MHz, Sweep: Auto. 3. Average measurements: RBW = 1MHz, VBW = 10 Hz, Sweep: Auto. 4. “ * ”, means this data is the worst emission level. 5. Measurement Level = Reading Level + Correct Factor. 6. The average measurement was not performed when the peak measured data under the limit of average detection. Report No.: 13C0155R-RFUSP26V00 Page : 78 of 110 Product : Free Style CAMERA QBiC Test Item : Band Edge Data Test Site : No.3 OATS Test Mode : Mode 1: Transmit (802.11b 1Mbps) RF Radiated Measurement (Horizontal): Channel No. Frequency (MHz) Correct Factor (dB) Reading Level (dBμV) Emission L…

Text truncated - open the document above for the full version.

Report No.: 13C0155R-RFUSP26V00 Page : 1 of 3 Attachment 1: EUT Test Setup Photographs Front View of Conducted Test Back View of Conducted Test Report No.: 13C0155R-RFUSP26V00 Page : 2 of 3 Front View of Radiated Test Back View of Radiated Test Report No.: 13C0155R-RFUSP26V00 Page : 3 of 3 Front View of Radiated Test (Horn) Back View of Radiated Test (Horn)
