X5NLBI-170WII 2in1 remote

WII-2in1Remote instruction ModelLBI-170 1, Product NameWII 2in1 remote 2 Product packge 1Wii 2in1 remote 1PCS 2Instruciton 1PCS 3Product function 1Same function as original desige of wii Nintendo 2New add additional function is Motionplus 4, Operation 1 Switch on machine power 2 Load in AA 1.5V Battery 3 Press main machine’sSYNCkeythen press remote’sSYNCkey,the remote’s led become from flash to natural status! 5, Cautions 1Do not be exposed it! 2Do not put it in fire! 3Do not open it 4Do not greatly strike it! SYNC Direction A HOME Power 1 2 Channel direction B Battery cover This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. FCC Statement:

SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 SHENZHEN XINGDASHINE ELECTRONICS CO., LTD. (2010-10-15) To: Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: X5NLBI-170 We hereby request confidential treatment of information accompanying this application as outlined below: - Block diagram - Operation description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 and 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signature July Zheng/ Sales E-mail : [email protected] Phone : 0755-33800723 Fax : 0755-33800724 Address : D3 East Xintang Industrial Zone, Baishixia, Fuyong, Baoan, Shenzhen, Guangdong, China

2206 Ringwood Avenue, San Jose, CA 95131, USA Tel: +1(408) 526 1188, Fax: +1(408) 526 1088, Email: [email protected] , URL: www.siemic.com October 18, 2010 To: FCC From: SIEMIC, INC. RE: Applicant: SHENZHEN XINGDASHINE ELECTRONICS CO., LTD. FCC ID: X5NLBI-170, Request for supercede of test report and confidentiality request letter. Per customer’s request, the EUT model number in test report was corrected from LBI- 017 to LBI-170. Besides, confidentiality is requested on the block diagram, operational description and schematics. Therefore, we are asking to kindly replace the test report and confidentiality request letter with revised copies. Thank you, Choon Ooi SIEMIC, INC. 2206 Ringwood Ave., San Jose, CA 95131 Tel: 408-526-1188 Ext 209 Fax: 408-526-1088

External of EUT External of EUT

FCC ID Label FCC ID: X5NLBI-170 Made in China

FCC ID Label Location Proposed Label Location on EUT

Internal of EUT Internal of EUT Internal of EUT

SHENZHEN EMTEK CO., LTD. REPORT NO: ES100907027F FCC ID: X5NLBI-170 DATE: 10/12/2010 Page 1 of 23 ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT OF WII 2in1 remote MODEL No.: LBI-170 FCC ID: X5NLBI-170 REPORT NO: ES100907027F ISSUE DATE: October 12, 2010 Prepared for SHENZHEN XINGDASHINE ELECTRONICS CO., LTD. D3 East Xintang Industrial Zone, Baishixia, Fuyong, Baoan, Shenzhen, Guangdong, China Prepared by SHENZHEN EMTEK CO., LTD Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China TEL: 86-755-26954280 FAX: 86-755-26954282 SHENZHEN EMTEK CO., LTD. REPORT NO:ES100907027F FCC ID: X5NLBI-170 DATE: 10/12/2010 Page 2 of 19 VERIFICATION OF COMPLIANCE Applicant: SHENZHEN XINGDASHINE ELECTRONICS CO., LTD. D3 East Xintang Industrial Zone, Baishixia, Fuyong, Baoan, Shenzhen, Guangdong, China Product Description: WII 2in1 remote Model Number: LBI-170 File Number: ES100907027F Date of Test: September 27, 2010 to October 11, 2010 We hereby certify that: The above equipment was tested by SHENZHEN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2009) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.249. The test results of this report relate only to the tested sample identified in this report. Approved By David Lee / Q.A. Manager SHENZHEN EMTEK CO., LTD. SHENZHEN EMTEK CO., LTD. REPORT NO:ES100907027F FCC ID: X5NLBI-170 DATE: 10/12/2010 Page 3 of 19 Ta b l e o f C o n t e n t s 1. GENERAL INFORMATION ................................................................................................. 4 1.1 PRODUCT DESCRIPTION........................................................................................................................... 4 1.2 RELATED SUBMITTAL(S) / GRANT (S) ..................................................................................................... 4 1.3 TEST METHODOLOGY.............................................................................................................................. 4 1.4 SPECIAL ACCESSORIES............................................................................................................................ 4 1.5 EQUIPMENT MODIFICATIONS.................................................................................................................. 4 1.6 TEST FACILITY........................................................................................................................................ 5 2. SYSTEM TEST CONFIGURATION .................................................................................... 6 2.1 EUT CONFIGURATION............................................................................................................................. 6 2.2 EUT EXERCISE........................................................................................................................................ 6 2.3 TEST PROCEDURE.................................................................................................................................... 6 2.4 LIMITATION............................................................................................................................................. 6 2.5 CONFIGURATION OF TESTED SYSTEM..................................................................................................... 9 3. SUMMARY OF TEST RESULTS ....................................................................................... 10 4. DESCRIPTION OF TEST MODES .................................................................................... 10 5. RADIATED EMISSION TEST ............................................................................................ 11 5.1 MEASUREMENT PROCEDURE................................................................................................................. 11 5.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................................... 11 5.3 MEASUREMENT EQUIPMENT USED: ...................................................................................................... 12 5.4 OUT OF BAND RADIATED MEASUREMENT RESULT.............................................................................. 12 5.5 RADIATED MEASUREMENT PHOTOS:.................................................................................................... 18 6. ANTENNA APPLICATION ........................................................................................................... 19 6.1 ANTENNA REQUIREMENT........................................................................................................................... 19 SHENZHEN EMTEK CO., LTD. REPORT NO:ES100907027F FCC ID: X5NLBI-170 DATE: 10/12/2010 Page 4 of 19 1. GENERAL INFORMATION 1.1 Product Description The SHENZHEN XINGDASHINE ELECTRONICS CO., LTD. Model: LBI-170 (referred to as the EUT in this report) The EUT is an short range, lower power, WII 2in1 remote designed as an “Input Device”. It is designed by way of utilizing the GFSK modulation achieves the system operating. A major technical descriptions of EUT is described as following: A). Operation Frequency: 2402MHz-2480MHz B). Modulation: GFSK C). Number of Channel: 79 D). Antenna Designation: PCB trace antenna E). Duty cycle: 100% F). Transmitter power: max 0dBm G).Power Supply: DC 2*1.5V Battery 1.2 Related Submittal(s) / Grant (s) This submittal(s) (test report) is intended for FCC ID: X5NLBI-170 filing to comply with Section 15.249 of the FCC Part 15, Subpart C Rules. The composite system (receiver) is compliance with Subpart B is authorized under a DoC procedure. 1.3 Test Methodology Both conducted and radiated testing were performed according to the procedures in ANSI C63.4…

Text truncated - open the document above for the full version.

RADIATED EMISSION TEST
