X5NLBP-054Bluetooth headset

PS3 BLUETOOTH HEADSET USER MANUAL Thank You for purchasing the PS3 Bluetooth Headset. products are built to the highest manufacturing standards and tested throughout its development. Please read through this manual before using the PS3 Bluetooth Headset. BRIEF INTRODUCTION This PS3 Bluetooth Headset is designed for PS3 platform, also compatible with other Bluetooth device. PRODUCT INTRODUCTION 1. PS3 Bluetooth Headset 1PCS 2. USB Charging Cable 1PCS PRODUCT FEATURES 1. Bluetooth Headset 2.0 technolo gy designed specifically for PlayStation 3 2. Works with most cell phones that support Bluetooth 2.0 3. Compact ergonomic fit stays co mfortably on your ear all day 4. Noise reducing microphone BATTERY CHARGING 1. Insert the USB Charging cable into the charging socket, and connect the USB cable to PS3 or PC. 2. When charging, the LED indicator will turn RED. If the battery is flat, the LED indicator might need 1 minute to turn RED. 3. Full Battery charge can take upto 2 hours. 4. When fully charged, the LED indicator will turn Green. OPERATION INSTRUCTION (PS3 PLATFORM) 1. Turn on PS3 console, select (A ccessory Settings) under (Settings) in the home menu. 2. Select [Manage Bluetooth Devices]. If you have registered one or more Bluetooth devices, a list of registered devices will be displayed. 3. Hold the “P button” for 5 seconds until the LED indicator turns Purple. Then extend the micropho ne whilst continuing to hold down the P button. 4. If the LED indicator flashes Blue after extending the microphone, please repeat step 3. 5. Select [Register New Device]. If you have not registered any Bluetooth devices, you will be aske d if you want to register the device. Select [Yes] to continue. 6. Select [Start Scanning]. Your PS3 console will display a list of Bluetooth devices within range of the system. 7. Select the “ PS3 Bluetooth Headset”, Complete registration by entering the pass key (0000), using the X key to edit. 8. After success pairing, go back to the (Accessory Settings), select (Audio Device Settings ) to test the headset. Change "Input Device" and "Output Device" to “ PS3 Bluetooth Headset”. Try speaking and watch the “Microphone Level“ move. To test the Headset mute function touch the P button to un-mute touch the P button again. 9. If the connection between the PS3 console and a Bluetooth device is lost, you can reestablis h the connection. Select [Input Device] or [Output Device], press ▲ button, and then select [Connect] from the options menu to connect the devices PRECAUTION AND MAINTENANCE Please review the following guidelines to ensure optimal performance of the product. 1. Please make sure there is no extreme pressure put on this product. 2. Don’t dismantle this product without permission. 3. This product should be situated away from heat sources such as radiators and heaters. 4. Keep this product dry and avoid contacting with damp or wet areas. Playstation3/PS3 is a registered trademark of SONY Inc. This product is not approved, sponsored or endorsed by SONY Inc. This product is not manufactured for SONY Inc. FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2 ) this device must accept any interference received, includin g interference that may cause undesired operation. Changes or modifications not ex pressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a pa rticular installation. If this equipment does cause harmful interference to radio or television reception, which can be determin ed by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help.

Date: 2010-3-5 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: X5NLBP-054 To Whom It May Concern: This letter is to ascertain that SHENZHEN XINGDASHINE ELECTRONICS CO., LTD. Product Bluetooth headset has been the units used for conducting FCC compliance testing, the DoC part will be tested by FCC recognized test lab. If you have any question or concerns, pls. contact us. Sincerely, July Zheng/ Sales E-mail : [email protected] Phone : 0755-33800723 Fax : 0755-33800724 Address : D3 East Xintang Industrial Zone, Baishixia, Fuyong, Baoan, Shenzhen, Guangdong, China

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 2010-03-01 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, SHENZHEN XINGDASHINE ELECTRONICS CO., LTD. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): (Bluetooth headset, LBP-054) We affirm that between SIEMIC and SHENZHEN XINGDASHINE ELECTRONICS CO., LTD. any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Signature July Zheng/ Sales E-mail : [email protected] Phone : 0755-33800723 Fax : 0755-33800724 Address : D3 East Xintang Industrial Zone, Baishixia, Fuyong, Baoan, Shenzhen, Guangdong, China

External of EUT External of EUT

FCC ID Label： FCC ID: X5NLBP-054 Made in China

FCC ID Label Location Proposed Label Location on EUT

Internal of EUT Internal of EUT

AT24C32 V+ V- Blue Red + - POWER pairing L4 15nH C13 15pF ANT 1 UNBAL 2 DC 3 BAL 4 BAL 5 GND 6 GND U2 LFB212G45BA1A220 L2 0.4PF L1 6.8NH C14 10NF SPK C19 10NF MIC C10 100NF C9 100NF L3 15nH R21 2K2 C5 15pF 1 3 4 2 Y1 16M C12 3.3PF C11 10PF C8 10nF R16 220K 1% R17 150K 1% 1 PIO11 2 PIO0 3 PIO1 4 VREGENABLE 5 VDD-RADIO 6 RF_P 7 RF_N 8 VDD-LO 9 VREG-IN 10 VREG-OUT 11 SPK- 12 SPK+ 13 VDD-ANA 14 MIC_P 42 SPI-MISO 41 SPI-CSB 40 TEST-EN 39 SPI-MOSI 38 RST 37 PIO6 36 PIO5 35 PIO4 34 VDD-CORE 33 PIO7 32 PCM-OUT 31 PCM-SYNC 30 PCM-CLK 29 PCM-IN 43 SPI-CLK 44 VDD-PADS 45 VDD-CHG 46 BAT-P 47 LX 48 BAT_N 49 LED0 50 LED1 51 PIO10 52 PIO3 53 PIO8 54 PIO9 55 VDD-PIO 56 PIO2 28 UART-TX 57 VSS 26 UART-CTS 25 VDD-UART 24 UART-RTS 23 UART-RX 22 VDD-UART 21 AIO0 20 AIO1 19 AIO2 18 VDD-ANA 17 XTAL-OUT 16 XTAL-IN 15 MIC_N U3 BC413159A11(QFN) R23 2R2 C6 2.2UF SW3 R6 120K 1 2 BATTERY L5 10UH R19 470R R18 470R LED2 LED1 1 A0 2 A1 3 A2 4 GND 5 SDA 6 SCL 7 WP 8 VCC U1 R14 4K7 R13 4K7 R12 4K7 SW2 C16 10nF C3 100nF R3 2R2 1 2 CHARGER SW1 C15 10nF R20 0R C18 4.7UF C20 10UF SW4 E B C Q3 MMBT3904 R2 100K R9 10K R22 10K R10 10K R1 10K E B C Q1 MMBT3904 E B C Q2 MMBT3904 R8 100K 1 VIN 2 VSS 3 CE 5 VOUT 4 BYP U4 RCR3132-272SK R15 10K C2 100nF C4 100nF C7 10nF R7 220K C1 220nF E B C Q5 MMBT3904 R5 10K C17 4U7 R11 470R LED3 R24 10K C21 10nF C22 10nF C23 15pF R4 100K L6 *** +1V8 +1V8 +1V8 +1V8 VBAT +1V8 SPI-MOSI SPI-CSB SPI-MISO SPI-CLK +1V8 VBAT +1V8 VBAT +1V8 +1V8 +1V8 +1V8 +1V8 5V VBAT 5V +1V8 VBUS VBAT 5V VBAT

SHENZHEN EMTEK CO., LTD. REPORT NO:E1001107F FCC ID: X5NLBP-054 DATE: 03/01/2010 Page 1 of 22 ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C AND CANADIAN RSS-210 ISSUE 6 REQUIREMENT OF Bluetooth headset MODEL No.: LBP-054 FCC ID: X5NLBP-054 REPORT NO: E1001107F ISSUE DATE: March 1, 2010 Prepared for SHENZHEN XINGDASHINE ELECTRONICS CO., LTD. D3 East Xintang Industrial Zone, Baishixia, Fuyong, Baoan, Shenzhen, Guangdong, China Prepared by SHENZHEN EMTEK CO., LTD Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China TEL: 86-755-26954280 FAX: 86-755-26954282 SHENZHEN EMTEK CO., LTD. REPORT NO:E1001107F FCC ID: X5NLBP-054 DATE: 03/01/2010 Page 2 of 22 VERIFICATION OF COMPLIANCE Applicant: SHENZHEN XINGDASHINE ELECTRONICS CO., LTD. D3 East Xintang Industrial Zone, Baishixia, Fuyong, Baoan, Shenzhen, Guangdong, China Product Description: Bluetooth headset Model Number: LBP-054 File Number: E1001107F Date of Test: January 23, 2010 to March 1, 2010 We hereby certify that: The above equipment was tested by SHENZHEN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2003) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.249. also, the model complies with Canadian RSS-210 Issue 6 standard. The test results of this report relate only to the tested sample identified in this report. Approved By David Lee / Q.A. Manager SHENZHEN EMTEK CO., LTD. SHENZHEN EMTEK CO., LTD. REPORT NO:E1001107F FCC ID: X5NLBP-054 DATE: 03/01/2010 Page 3 of 22 Table of Contents 1. GENERAL INFORMATION ................................................................................................. 4 1.1 P RODUCT D ESCRIPTION ........................................................................................................................... 4 1.2 R ELATED S UBMITTAL ( S ) / G RANT ( S ) ..................................................................................................... 4 1.3 T EST M ETHODOLOGY .............................................................................................................................. 4 1.4 S PECIAL A CCESSORIES ............................................................................................................................ 4 1.5 E QUIPMENT M ODIFICATIONS .................................................................................................................. 4 1.6 T EST F ACILITY ........................................................................................................................................ 5 2. SYSTEM TEST CONFIGURATION .................................................................................... 6 2.1 EUT C ONFIGURATION ............................................................................................................................. 6 2.2 EUT E XERCISE ........................................................................................................................................ 6 2.3 T EST P ROCEDURE .................................................................................................................................... 6 2.4 L IMITATION ............................................................................................................................................. 6 2.5 C ONFIGURATION OF T ESTED S YSTEM ..................................................................................................... 8 3. SUMMARY OF TEST RESULTS ......................................................................................... 8 4. DESCRIPTION OF TEST MODES ...................................................................................... 9 5. CONDUCTED EMISSIONS TEST ..................................................................................... 10 5.1 M EASUREMENT P ROCEDURE :................................................................................................................ 10 5.2 T EST SET-UP (B LOCK D IAGRAM OF C ONFIGURATION ) ....................................................................... 10 5.3 MEASUREMENT EQUIPMENT USED: ...................................................................................................... 10 5.4 C ONDUCTED E MISSION L IMIT .............................................................................................................. 10 5.5 M EASUREMENT R ESULT :....................................................................................................................... 11 5.6 CONDUCTED MEASUREMENT PHOTOS: ................................................................................................ 13 6. RADIATED EMISSION TEST ............................................................................................ 14 6.1 M EASUREMENT P ROCEDURE ................................................................................................................. 14 6.2 T EST SET-UP (B LOCK D IAGRAM OF C ONFIGURATION ) ....................................................................... 14 6.3 MEASUREMENT EQUIPMENT USED: ...................................................................................................... 15 6.4 O UT OF B AND R ADIATED M EASUREMENT R ESULT .............................................................................. 15 6.5 R ADIATED M EASUREMENT P HOTOS : ................................................................................................... 21 7. ANTENNA APPLICATION................................................................................................. 22 7.1 ANTENNA REQUIREMENT........................................................................................................................... 22 SHENZHEN EMTEK CO., LTD. R…

Text truncated - open the document above for the full version.

CONDUCTED EMISSION RADIATED EMISSION TEST
