X9PBKB78HBTablet Case with Bluetooth� Keyboard

BL-BKB78HA BT3.0 Instruction Manual ·Contents 1、Bluetooth keyboard 1PCS 2、Instruction manual 1PCS 3、USB Charging cable 1PCS ·Product Features 1、 use Broadcom20730 main control chip, have Bluetooth3.0 interface. 2、industry leading bluetooth solutions, WIDCOMM BTW (Microsoft officially designated software) bluetooth software 3、Ultra slim body with scissors -switch keys frame design. The ergonomic design enable users to work long time without fatigue and comfortable handling feel. 4、With aluminum back plate design,the keyboard is super light and durable. 5、Mute design: effectively avoid other person sleeping(especially for one room with several person). 6、Support iPad,Iphone,Mac,Windows and Android system etc.It’s more convenient for you. 7、Work Environment:Temperature 0-55 °C,humidity: 20%-80% 8、Built in lithium battery,avoid changing battery frequently. ·Specification 1、executive standard: bluetooth V3.0 2、maximum operating distance: 10 meters 3、modulation mode: 2.4 G straight sequence fh (FHSS) 4、transmit power: Class 2 levels 5、working voltage: 3.7V 6、working current: <2.0 MA 7、standby current: 1.0 MA 8、sleep current55uA 9、charging current: 150MA 10、standby time: 160days 11、theoretical use time: 30days 12、continuous uninterrupted use time: 120hours 13、theoretical charging time: 2.5 hours 14、lithium battery capacity: 230mAh 15、lithium battery life span: three years 16、the lithium battery type: 4.0 * 20 * 35MM 17、the key dynamics: 60 + 10g 18、buttons life: 5 million times 19、Dimension:L246mm*W191.5mm*H9.6mm ·Bluetooth keyboard installation 1． Keyboard pair with iPad procedure: （1）、Turn on the swith”ON”,the blue indicator light 5 seconds then extinguished which advise you the keyboard be turned on.Please see below instruction picture. （2）、 Press “Connect”button,”Status” indicator twinkle which advise you is pairing. （3）、Click the setting button of IPAD and IPHONE,Then choose the General and bluetooth.Turn on the bluetooth,then the IPAD will searching bluetooth device . （4）、After the IPAD and IPHNE find out the bluetooth device and connect the bluetooth keyboard(see blow picture),IPAD will advise you input the password. Then press “Enter”key. Warning :There are no advise when you input the password.Please make sure input correct and press enter button. （5）、If IPAD and keyboard connect success.The Status indicator will extinguished .You can use the keyboard. ·How to place iPad and keyboard. 1、Turn on the”open” switch,the stand will stand up automatically as follow pictures: 2、Put your iPad into the groove of keyboard.The stand will support the iPad perfect. ·Keyboard and iPad hotkeys specification. Press this button can return iPad home page. Press this button can control IPAD screen brightness dark. Press this button can control IPAD screen brightness light. When in use IPAD edit the document by this button to call up and hidden IPAD virtual keyboard. IPAD locked in on this key, IPAD into the screen saver pictures interface IPAD in boot state, press this button can enter the IPAD search page. Press this button can change the input language of iPad. When the IPAD in music broadcast, click this button can control music upgrade . IPAD in boot state, press this button can control the play/pause music. When the IPAD in music broadcast, click this button can control music downwards. Press this button can be mute, click again, hold "cancel mute . Press this button can increase the volume. Press this button can lock IPAD screen. ·Charging When you use keyboard in process,the status tinkle which advise you the battery is shortage.You should charging. （1）、Separate put the USB terminal cable plug into the PC and keyboard.As follow picture. （2）、When you charging,the red light on.When the light off,the battery is full enough.(theoretical charging time 2hours) ·Storage (1)、When you don’t want to use the keyboard and carry,please close the back stand.Then put iPad cover the keyboard,the screen of iPad will turn off automatically. （2）、When you don’t want to use the keyboard and carry.Don’t forget turn off the power switch of keyboard.In order to extend your battery life span. （3）、If you want to store the keyboard long time.Don’t forget charging the keyboard around 1hour till the battery half which can extend your battery life span. ·Troubleshooting Keyboard and IPAD cannot establish connections ①、please check your iPad bluetooth device is already open and went in search of state. ②、 Press and release the”connect” button of keyboard ,check the Status indicator flash or not. ③、keyboard and iPad connected within 10 meters from working range. ④、Bluetooth devices of iPad changing or not, if it is,need to match again. ⑤、Your iPad bluetooth device is also connected to the other bluetooth terminal and confirm Ipad bluetooth device speed. ⑥、Checking your battery, if there is electricity shortage, please charge. This equipment already through the class B digital equipment testing The FCC, the federal communications commission interference statements: This equipment already through the class B digital equipment testing The FCC regulations in accordance with article 15 for the regulations set is to give the installation process may cause harm on the environment to provide the necessary protection. This equipment in use process will produce radio radiation. If do not follow the instructions for installation and use may affect the radio and TV receiving signal, can pass open and close this equipment to test. Users can try to use the following measures to avoid such interference: 1、 change the direction of receiving antenna or is rearrange the antenna position. 2、 the admiral equipment in circuit with the antenna connection distinguishes the connection. 3、 Ask for distributor or experienced people. This device complies with Part 15 of the FCC Rules Operation is subject to the following tow conditions: 1、 This device may not cause harmful interference 2、 This device must accept any interference received,including interfer…

Text truncated - open the document above for the full version.

FCC IC: X9PBKB78HB Label Location on EUT FCC ID Label: Size: 20mm * 30 mm BLUETOOTH KEYBOARD M/N: BKB78HB FCC ID: X9PBKB78HB SHENZHEN PAOLUY SILICONE TECHNOLOGY CO.,LTD Made in China

FCC ID TEST REPORT for BLUETOOTH KEYBOARD MODEL: BKB78HB, BKB78HA FCC ID: X9PBKB78HB Test Report Number: 12120976 Issued Date: December 25, 2012 Issued for SHENZHEN PAOLUY SILICONY TECHNOLOGY CO., LTD. Ath Building 5th floor, Forzen Industrial park, Fuyuan 2nd Road, Heping Village Fuyong Town, Baoan District, Shenzhen, China Issued By: SHENZHEN TIMEWAY TECHNOLOGY CONSULTING CO., LTD. 5/F,Block 4, Anhua Industrial Zone., No.8 Tairan Rd. Chegongmiao, Futian District Shenzhen, China TEL: +86-755-83448688 FAX: +86-755-83442996 Report No.: 12120976 Issued: December 25, 2012 Revised: None FCC ID: X9PBKB78HB TRF No.: FCC PART 15C-15.247/A0 Page 2 of 71 TEST CERTIFICATION Product: BLUETOOTH KEYBOARD Model: BKB78HB, BKB78HA Applicant: SHENZHEN PAOLUY SILICONY TECHNOLOGY CO., LTD Ath Building 5th floor, Forzen Industrial park, Fuyuan 2nd Road, Heping Village Fuyong Town, Baoan District, Shenzhen, China Factory: SHENZHEN PAOLUY SILICONY TECHNOLOGY CO., LTD Ath Building 5th floor, Forzen Industrial park, Fuyuan 2nd Road, Heping Village Fuyong Town, Baoan District, Shenzhen, China Trade Mark: N/A Tested: November 28 ~ December 23, 2012 Test Voltage: DC 5 V(DC From Adapter, Adapter input 120Vac, 60Hz) Applicable Standards: FCC Part 15 Subpart C: 2011 ANSI C63.4:2003 Deviation from Applicable Standard None The above equipment has been tested by SHENZHEN TIMEWAY TECHNOLOGY CONSULTING CO., LTD. and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Tested By: Date: 2012-12-25 (Brown Lu) Check By: Date: 2012-12-25 (Terry Tang) Approved By: Date: 2012-12-25 (Jack Chung) Report No.: 12120976 Issued: December 25, 2012 Revised: None FCC ID: X9PBKB78HB TRF No.: FCC PART 15C-15.247/A0 Page 3 of 71 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1 FACILITIES AND ACCREDITATIONS 6 1.1. FACILITIES 6 1.1.1 ACCREDITATIONS 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 9 2.4 CONFIGURATION OF SYSTEM UNDER TEST 10 2.5 DESCRIPTION OF SUPPORT UNITS (CONDUCTED MODE) 11 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BELOW 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30M – 1000 MHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 24 3.2.9 TEST RESULTS (RESTRICTED BANDS REQUIREMENTS) 30 4 . NUMBER OF HOPPING CHANNEL 36 4.1 APPLIED PROCEDURES / LIMIT 36 4.1.1 TEST PROCEDURE 36 4.1.2 DEVIATION FROM STANDARD 36 Report No.: 12120976 Issued: December 25, 2012 Revised: None FCC ID: X9PBKB78HB TRF No.: FCC PART 15C-15.247/A0 Page 4 of 71 Table of Contents Page 4.1.3 TEST SETUP 36 4.1.4 EUT OPERATION CONDITIONS 36 4.1.5 TEST RESULTS 37 5 . AVERAGE TIME OF OCCUPANCY 38 5.1 APPLIED PROCEDURES / LIMIT 38 5.1.1 TEST PROCEDURE 38 5.1.2 DEVIATION FROM STANDARD 38 5.1.3 TEST SETUP 39 5.1.4 EUT OPERATION CONDITIONS 39 5.1.5 TEST RESULTS 40 6 . HOPPING CHANNEL SEPARATION MEASUREMENT 46 6.1 APPLIED PROCEDURES / LIMIT 46 6.1.1 TEST PROCEDURE 46 6.1.2 DEVIATION FROM STANDARD 46 6.1.3 TEST SETUP 46 6.1.4 EUT OPERATION CONDITIONS 46 6.1.5 TEST RESULTS 47 7 . BANDWIDTH TEST 53 7.1 APPLIED PROCEDURES / LIMIT 53 7.1.1 TEST PROCEDURE 53 7.1.2 DEVIATION FROM STANDARD 53 7.1.3 TEST SETUP 53 7.1.4 EUT OPERATION CONDITIONS 53 7.1.5 TEST RESULTS 54 8 . PEAK OUTPUT POWER TEST 60 8.1 APPLIED PROCEDURES / LIMIT 60 8.1.1 TEST PROCEDURE 60 8.1.2 DEVIATION FROM STANDARD 60 8.1.3 TEST SETUP 60 8.1.4 EUT OPERATION CONDITIONS 60 8.1.5 TEST RESULTS 61 9. Antenna Application 62 9.1 Antenna requirement 66 9.2 Result 66 10. EUT TEST PHOTO 67 11 PHOTOGRAPHS OF EUT 68 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Report No.: 12120976 Issued: December 25, 2012 Revised: None FCC ID: X9PBKB78HB TRF No.: FCC PART 15C-15.247/A0 Page 5 of 71 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(a)(1) Hopping Channel Separation PASS 15.247(b)(1) Peak Output Power PASS 15.247(c) Radiated Spurious Emission PASS 15.247(a)(iii) Number of Hopping Frequency PASS 15.247(a)(iii) Dwell Time PASS 15.247(a)(1) Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Report No.: 12120976 Issued: December 25, 2012 Revised: None FCC ID: X9PBKB78HB TRF No.: FCC PART 15C-15.247/A0 Page 6 of 71 1 FACILITIES AND ACCREDITATIONS 1.1. FACILITIES All measurement facilities used to collect the measurement data are located at East 5/Block 4 Anhua Industrial Zone, No.8, Tairan Road, Chegongmiao, Futian District, Shenzhen, Guangdong, China The sites are constructed in conformance with the requirements of ANSI C63.4 and CISPR Publication 22. All receiving equipment conforms to CISPR Publication 16-1, “Radio Interference Measuring Apparatus and Measurement Methods.” 1.1.1 ACCREDITATIONS The testing quality ability of our laboratory meet with "Quality Law of People's Republic of China" Clause 19. The testing quality system of our laboratory meet with ISO/IEC-17025 requirements, which is approved by CNAL. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: CNAL-LAB Code: L2292 The EM…
