X9PBL-BKB700BLUETOOTH KEYBOARD

BL-BKB700 SAMSUNG Galaxy Tab Manual Catalogue • Product Detail...................................................（1） • Product Features...................................................（1） Specifications................................................ ...（1） Important Notes ...................................................（1） • Connection for SAMSUNG Galaxy Tab ...........................（2） • Charging procedure...................................................... ...（3） • Keyboard Hotkey specifies.......................................（4） • Storage ......................................................... （4） Matters need attention ................................................... （5） • troubleshooting...................................................（5） product detail 1、bluetooth keyboard 1PC 2、protective case 1PC 3、 manual 1PC 4、 USB charging cable 1PC Product Features 1、 With Broadcom2042 as main control chip ,with bluetooth 2.0 interface . 2、 Use industry leading bluetooth solutions ,WIDCOMM BTW Bluetooth software which is specified software by Microsoft offical. 3、 Specially for SamSung ，it will be more conveninet for SamSung Galaxy Tab . 4.Unique design ,effectively avoid noise pollution . 5.Wafterproof design except for the parts about connector from switch and charging . 6.Support with computer and mobile . 7、 working temperature 0-55 humidity 20%-80% 8、Built-in lithium battery design save the frequent change of battery . Specifications: 1.Executive standard :Bluetooth V2.0 2.Maximun operation distance :10meters. 3.Modulation mode : FHSS 2.4G 4.Transmit power: scale-up 2 levels. 5.Working voltage : 3.0-5.0 6.Working current: ＜5.0MA 7.Standby current: ＜2.5 MA 8、Sleeping current：＜200UA 9、charging current： 150MA±20MA 10、standy time： 50days 11、theoretical charging time： 17days（estimate each day 4 working hours） 12、continuous uninterrupted use time： 70hours 13、theoretical charging time： 3 hours 14、lithium battery capacity :minimum:370MAH Maximum：390MAH 15、lithium battery life： 3years 16、lithium battery size： 4.5*24*47MM 17、the key dynamics： 60±20g 18、key life： 500 million times 19、Operation temperature ： -20－70°C 20、storage temperature ： -30－70°C Important Notes: Connection for keyboard with SAMSUNG Calaxy Tab: （1）、 As shown in figure ,will turn to switch ON keyboard powerin three seconds ,Bluetooth indicatorlights and power after long bright 5 seconds,and then extinguished ,right now the keyboad start work。 （2）、According to a keyboard to connect(Bluetooth)yards keys,flashing ,Power indicatorlights,hints You keyboad long brighthas entered into the working condition of yards. (3)Click setting buttons on the SAMSUNG Calaxy Tab，SAMSUNG Calaxy Tab into Settings area ； then we select Wireless and netowrk ，then click Bluetooth option in BluetoothSettings Click Scan devices，Now the SAMSUNG Calaxy Tab into search state ,looking for bluetooth devices. (4)、SAMSUNG Calaxy Tab into search state, looking for bluetooth devices and search to bluetooth keyboard (see below ) , SAMSUNG Calaxy Tab will show you on the keyboad input password (5)、then we input the password and click enter key 。 (6)、After success of SAMSUNG Calaxy Tab and keyboard connections ,Power indicator light ,says the keyboard to long success ,power indicator code is to remind you long bright keyboard not in use when closed keyboard power,at the keyboard use process if found power indicator light flashing ,says the keyboard electricity shortage ,please charge Charging procedure （2）、 Theory charging time for 3 hours. Keyboard and SAMSUNG GALAXY Tab Hotkey Specifies： Press this button we can open call records in Samsung Galaxy Tab.. Press this button we can open menu fuction in Samsung Galaxy Tab . Press this button we can return home page in Samsung Galaxy Tab . Press this button we can finish return function . Press this buttion we can finish search function . Press this button we can increase the volume . press this button we can reduce the volume / When you use skype by SAMSUNG Calaxy Tab ,we can use emoticon , same with our keyboard , you can see the emoticon symbol in our keyboard , so when you use Skype ,you can press it and click to send . Storage Matters need to attention 。 （1）、Keyboard and SAMSUNG Calaxy Tab can not establish connections: ①、please check your SAMSUNG Calaxy Tab bluetooth device is already open and went in search of state. ②、Hold and release the keyboard after bluetooth keyboard pairing button ,a flashing lights statel. ③、keyboard an SAMSUNG Galaxy Tab connected in 10 meters from working range. ④、SAMSUNG Calaxy Tab bluetooth devise have change,if there is a need to match again . ⑤、your Samsung Galaxy Tab is also connected to the other bluetooth terminal and confirm bluetooth devised speed.。 ⑥、Check your battery ,if there is electricity shortage ,please charge FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to co…

Text truncated - open the document above for the full version.

SHENZHEN PAOLUY SILICONE TECHNOLOGY CO.,LTD Date:December 29, 2011 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: X9PBL-BKB700 To Whom It May Concern: This letter is to ascertain that SHENZHEN PAOLUY SILICONE TECHNOLOGY CO.,LTD. Product BLUETOOTH KEYBOARD has been the units used for conducting FCC compliance testing, the DoC part will be tested by FCC recognized test lab. If you have any question or concerns, pls. contact us. Sincerely, Signature： Name : Yang Xiaogang Title: Quality Manager Company Name: SHENZHEN PAOLUY SILICONE TECHNOLOGY CO.,LTD Address: NO.31 FURONG ROAD.GUSHU VILLAGE.XIXIANG TOWN.BAOAN DISTRICT.SHENZHEN Email: [email protected] Telephone: 0755-33819221 FAX:0755-33813083

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 p 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 SHENZHEN PAOLUY SILICONE TECHNOLOGY CO.,LTD December 29, 2011 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, SHENZHEN PAOLUY SILICONE TECHNOLOGY CO.,LTD hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product description：BLUETOOTH KEYBOARD model name：BL-BKB700 We affirm that between SIEMIC and SHENZHEN PAOLUY SILICONE TECHNOLOGY CO.,LTD, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Signature： Name : Yang Xiaogang Title: Quality Manager Company Name: SHENZHEN PAOLUY SILICONE TECHNOLOGY CO.,LTD Address: NO.31 FURONG ROAD.GUSHU VILLAGE.XIXIANG TOWN.BAOAN DISTRICT.SHENZHEN Email: [email protected] Telephone: 0755-33819221 FAX:0755-33813083

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (current) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 1.0 2.0 August – 11 - 2008 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 2.0 SHENZHEN PAOLUY SILICONE TECHNOLOGY CO.,LTD December 29, 2011 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Confidentiality Request regarding application for certification of FCC ID: X9PBL-BKB700 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Operational Description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signature： Name : Yang Xiaogang Title: Quality Manager Company Name: SHENZHEN PAOLUY SILICONE TECHNOLOGY CO.,LTD Address: NO.31 FURONG ROAD.GUSHU VILLAGE.XIXIANG TOWN.BAOAN DISTRICT.SHENZHEN Email: [email protected] Telephone: 0755-33819221 FAX:0755-33813083

Annex B. EUT External Photo EUT - Front View EUT - Rear View EUT - Top View EUT - Bottom View EUT - Left View EUT - Right View

Model number: BL-BKB700 FCC ID: X9PBL-BKB700 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Label Location

Annex B. EUT Internal Photo Main PCB Board Top View Main PCB Board Bottom View Bluetooth Module PCB Board Top View Bluetooth Antenna

2.67 2.67 FCC ID : X9PBL-BKB700 Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB 447498 (2)(a)(i) Frequency Range Center frequency (MHz) 60/f SAR Limitation (mw) Low Frequency (MHz) High Frequency(MHz) 2402 2480 2441 24.58 Maximum measured transmitter power Conducted Power (mw) Max Antenna Gain (dBi) EIRP (mw) 1.68 2 Threshold at which no SAR required is 24.58 mw. Maximum Tx power is mw EIRP. Conclusion: No SAR is required. SIMULTANEOUS TRANSMISSION EVALUATION N/A

SHENZHEN PAOLUY SILICONE TECHNOLOGY CO., LTD BLUETOOTH KEYBOARD Main Model: BL-BKB700 December 28, 2011 Report No.: 11021555-15.247 (This report supersedes NONE) Modifications made to the product : None This Test Report is Issued Under the Authority of: Peter Cai Compliance Engineer Alex Liu Technical Manager This test report may be reproduced in full only. Test result presented in this test report is applicable to the representative sample only. Title: RF Test Report for BLUETOOTH KEYBOARD MainModel: BL-BKB700 To: FCC 15.247: 2011 Report No: 11021555-15.247 Issue Date: December 28, 2011 Page: 2 of 54 www.siemic.com.cn Laboratory Introduction ATION SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China, Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. Accreditations for Conformity Assessment Country/Region Accreditation Body Scope USA FCC, A2LA EMC , RF/Wireless , Telecom Canada IC, A2LA, NIST EMC, RF/Wireless , Telecom Taiwan BSMI , NCC , NIST EMC, RF, Telecom , Safety Hong Kong OFTA , NIST RF/Wireless ,Telecom Australia NATA, NIST EMC, RF, Telecom , Safety Korea KCC/RRA, NIST EMI, EMS, RF , Telecom, Safety Japan VCCI, JATE, TELEC, RFT EMI, RF/Wireless, Telecom Mexico NOM, COFETEL, Caniety Safety, EMC , RF/Wireless, Telecom Europe A2LA, NIST EMC, RF, Telecom , Safety Accreditations for Product Certifications Country/Region Accreditation Body Scope USA FCC TCB, NIST EMC , RF , Telecom Canada IC FCB , NIST EMC , RF , Telecom Singapore iDA, NIST EMC , RF , Telecom EU NB EMC & R&TTE Directive Japan MIC, (RCB 208) RF , Telecom Hong Kong OFTA (US002) RF , Telecom Title: RF Test Report for BLUETOOTH KEYBOARD MainModel: BL-BKB700 To: FCC 15.247: 2011 Report No: 11021555-15.247 Issue Date: December 28, 2011 Page: 3 of 54 www.siemic.com.cn This page has been left blank intentionally. Title: RF Test Report for BLUETOOTH KEYBOARD MainModel: BL-BKB700 To: FCC 15.247: 2011 Report No: 11021555-15.247 Issue Date: December 28, 2011 Page: 4 of 54 www.siemic.com.cn CONTENTS 1 EXECUTIVE SUMMARY & EUT INFORMATION .......................................................................................... 5 2 TECHNICAL DETAILS.......................................................................................................................................... 6 3 MODIFICATION ..................................................................................................................................................... 7 4 TEST SUMMARY .................................................................................................................................................... 8 5 MEASUREMENTS, EXAMINATION AND DERIVED RESULTS................................................................... 9 ANNEX A. TEST INSTRUMENT & METHOD ........................................................................................................ 43 ANNEX B. EUT AND TEST SETUP PHOTOGRAPHS ........................................................................................... 49 ANNEX C. TEST SETUP AND SUPPORTING EQUIPMENT ................................................................................ 50 ANNEX D. USER MANUAL / BLOCK DIAGRAM / SCHEMATICS / PART LIST ............................................ 54 Title: RF Test Report for BLUETOOTH KEYBOARD MainModel: BL-BKB700 To: FCC 15.247: 2011 Report No: 11021555-15.247 Issue Date: December 28, 2011 Page: 5 of 54 www.siemic.com.cn 1 EXECUTIVE SUMMARY & EUT INFORMATION The purpose of this test programme was to demonstrate compliance of the SHENZHEN PAOLUY SILICONE TECHNOLOGY CO., LTD, BLUETOOTH KEYBOARD, and model: BL-BKB700 against the current Stipulated Standards. The BLUETOOTH KEYBOARD has demonstrated compliance with the FCC 15.247: 2011. EUT Information EUT Description : BLUETOOTH KEYBOARD Main Model : BL-BKB700 Serial Model : N/A Antenna Gain : Bluetooth Antenna Gain: 2dBi Input Power : Lithium Battery 3.7V DC 380mAh USB 5V Charge Classification Per Stipulated Test Standard : Spread Spectrum System/Device Title: RF Test Report for BLUETOOTH KEYBOARD MainModel: BL-BKB700 To: FCC 15.247: 2011 Report No: 11021555-15.247 Issue Date: December 28, 2011 Page: 6 of 54 www.siemic.com.cn 2 TECHNICAL DETAILS Purpose Compliance testing of BLUETOOTH KEYBOARD with stipulated standard Applicant / Client SHENZHEN PAOLUY SILICONE TECHNOLOGY CO., LTD NO.31 FURONG ROAD.GUSHUVILLAGE. XIXIANGTOWN.BAOAN DISTRICT.SHENZHEN Manufacturer SHENZHEN PAOLUY SILICONE TECHNOLOGY CO., LTD NO.31 FURONG ROAD.GUSHUVILLAGE. XIXIANGTOWN.BAOAN DISTRICT.SHENZHEN Laboratory performing the tests SIEMIC Nanjing (China) Laboratories NO.2-1,Longcang Dadao, Yuhua Economic Development Zone, Nanjing, China Tel:+86(25)86730128/86730129 Fax:+86(25)86730127 Email:[email protected] Test report reference number 11021555-15.247 Date EUT received December 12, 2011 Standard applied FCC 15.247: 2011 Dates of test (from – to) December 27 to December 28, 2011 No of Units #1 Equipment Category DSS Trade Name PAOLUY RF Operating Frequency (ies) 2402MHz - 2480MHz Number of Channels 79 Modulation GFSK FCC ID X9PBL-BKB700 IC ID 8475A-BTKB08 Title: RF Test Report for BLUETOOTH KEYBOARD MainModel: BL-BKB700 To: FCC 15.247: 2011 Report No: 11021555-15.247 Issue Date: December 28, 2011 Page: 7 of 54 www.siemic.com.cn 3 MODIFICATION NONE Title: RF Test Report for BLUETOOTH KEYBOARD MainModel: BL-BKB700 To: FCC 15.247: 2011 Report No: 11021555-15.247 Issue Date: December 28, 2011 Page: 8 of 54 www.siemic.com.cn 4 TEST SUMMA…
