XBAZW097Dry Contact Sensor Gen5

View the expanded manual: http://aeotec.com/support Aeotec by Aeon Labs Dry Contact Sensor. From Aeotec by Aeon Labs' intelligence series and our Gen5 range, comes the Dry Contact Sensor. It is a fully functional Z-Wave ® sensor that can detect a variety of dry contact signals. You just need to connect the matched external sensor on it such as a water level sensor, dry contact switch, dry contact relay, or other possible dry contact sensors. The Dry Contact Sensor can be used if the external sensor is a dry contact device. The Dry Contact Sensor is also a security Z-wave device that supports Over The Air (OTA) for firmware updates. The installation of your Dry Contact Sensor has two major steps: the Main Package contents: 1. Sensor Unit. 2. Back Mounting Plate. 3. CR123A Battery. 4. Double-Sided Tape(×2). 5. Screws (×2). Familiarize yourself with your Dry Contact Sensor. 12 3 4 5 External Sensor teminal Network LED Latch Button Action Button Fast Wiring Button Battery Quick start. Installing your Dry Contact Sensor. Adding your Sensor to your Z-Wave network. Connect the External Sensor to your Dry Contact Sensor. Sensor and the External Sensor. Powered by batteries, your Dry Contact Sensor will use wireless technology to talk to your Z-Wave network once installed. The Dry Contact Sensor should be installed inside your home and should not be installed outdoors in elements such as rain and snow. 1. Press and hold the Latch Button to unlock the Sensor Unit from the Back Mounting Plate: 2. Affix your Back Mounting Plate to a surface. The Back Mounting Plate can be affixed using screws or double-sided tape. If you are using screws, attach the Back Mounting Plate to the respective surface using the two 20mm screws provided. The following instructions will tell you how to link your Dry Contact Sensor to your Z-Wave network via If you are using double-sided tape, wipe the two surfaces clean of any oil or dust with a damp towel. When the surface has completely dried, peel one side of the tape back and attach it to the corresponding section on the rear side of the Back Mounting Plate. You can choose an External Sensor to be connected to your Dry Contact Sensor according to your needs or main application. Step1. Use the wire stripper cut the metallic part of External Sensor wire and make sure the length of metallic part is about 8mm to 9mm. 1. Remove the spacing tab to connect the batteries on your Dry Contact Sensor. Its Network LED will begin to blink when you short press the Action Button on the back of Sensor. 2. If your Z-Stick is plugged into a gateway or a computer, unplug it. 3. Take your Z-Stick to your Dry Contact Sensor. 4. Press the Action Button on your Z-Stick. The LED on your Z-Stick should begin to blink slowly. 5. Press the Action Button on your Dry Contact Sensor. 6. If your Dry Contact Sensor has been successfully linked to your Z-Wave network, its Network LED will no longer blink when you short press 1. Remove the spacing tab to connect the batteries on your Dry Contact Sensor. Its Network LED will begin to blink when you short press the Action Button on the back of Sensor. 2. Take your Minimote to your Dry Contact Sensor. 3. Press the Include button on your Minimote. 4. Press the Action Button on your Dry Contact Sensor. 5. If your Dry Contact Sensor has been successfully linked to your Z-Wave network, its Network LED will no longer blink. If the linking was unsuccessful an Aeotec by Aeon Labs’ Z-Stick or Minimote controller. If you are using another Z-Wave controller as your main controller, please refer to their respective manual on how add new devices to your network. If you’re using a Z-Stick: the Action Button on the back of the Dry Contact Sensor. If the linking was unsuccessful and the Network LED continues to blink, repeat the steps above. 7. Press the Action Button on the Z-Stick to take it out of inclusion mode. If you’re using a Minimote: and the Network LED continues to blink, repeat the above steps. 6. Press any button on your Minimote to take it out of inclusion mode. With your Dry Contact Sensor now working as a part of your smart home, you’ll be able to configure it from your home control software or phone application. Please refer to your software’s user guide for precise instructions on configuring Dry Contact Sensor to your needs. 8~9mm 8~9mm External Sensor Step2. Press and hold the Fast Wiring Button and then put the External Sensor wires into the connectors. Release the Fast Wiring Button, the external sensor wires will be clamped with the Dry Contact Sensor. Press and hold the Latch Button, and then push the Sensor into the Back Mounting Plate. Note: 1. The External Sensor should base on the principle of dry contact but not wet contact. 2. The length of External Sensor wire should not more than 5 meters and the size of wire should between 18AWG to 20AWG that can bear the tension of 25N. 3. The frequency of state change for the external sensor should be less than 4Hz or the minimum triggering time should be more than 250ms. Attach your Sensor to its External Mounting Plate. In order to send your Sensor new configuration commands from your Z-Wave controller or gateway, it will need to be woken up. 1. Remove your Sensor unit from its Back Mounting Plate, press and hold the Action Button on the back of the Sensor unit for 5 seconds and then release the Action Button. This will trigger and send a wake up notification command to your controller/gateway. 2. If you want your Sensor to keep awake for a longer time, quick press the Action Button on the back of the Sensor unit 3 times, then your Sensor will wake up for 10 minutes and the Network LED will remain solid while it is awake. Send a wake up notification. Advanced functions. Back Mounting Plate or agents, and/or (ii) arising from or relating to any actual or alleged infringement or misappropriation of any patent, trademark, mask work, copyright, trade secret or any actual or alleged violation of any other i…
