XGK-ACERHIDCKaccess-ER HF/LF/BT HID CK

| Non-Contractual Pictures | QSG220139 A00 Access-ER-HF/LF HID Quick Start and Regulatory Guide DEVICEHANDSTRAPEU PLUG NOTICECABLE MICRO USB C | USB ABATTERY BOXPOWER SUPPLYTEST REPORT WHAT'S IN THE BOX ? Page 02 | 19 1 2 1 2 3 4 5 6 7 8 9 4 5 6 7 8 9 3 QSG220139 A00 Access-ER-HF/LF HID Quick Start and Regulatory Guide Access-ER HF/LF HID PRODUCT OVERVIEW | Non-Contractual Pictures | Page 03 | 19 2D imager led indicators 5’’ touch panel volume keys +/- P3 function key SCAN |KEY RIGHT menu keys RETURN | HOME | RECENT APPLICATIONS on | off button P1 function key KEY LEFT UP P2 function key SCAN |KEY LEFT DOWN USB-C connectors for charging battery latch battery door camera flash battery latch buckle for handstrap buckle for handstrap receiver extension connectors camera QSG220139A00 NFC/LF HID Antenna area Access-ER-HF/LF HID Quick Start and Regulatory Guide Access-ER HF/LF HID NFC/LF HID Antenna area Setting up your device NANO SIM |MICRO SD cards installation •Press the left and right latches at the same time and remove the battery. •Insert the Micro SD card into SD slot •Insert Nano SIM card into SIM slot Page 04 | 19 Micro SD card Nano SIM card (slot 1) Nano SIM 2 card (slot 2) QSG220139 A00 Access-ER-HF/LF HID Quick Start and Regulatory Guide NOTE Make sure that the latches are properly positioned to the left and right so that the battery door closes properly. CAUTION 1.Replace the battery onlywith an identical battery or with an equivalent type of battery recommended by Coppernic. 2.Please recycle used batteries in accordance with current regulations. Setting up your device Battery installation •Insert the battery, lower part first. •Press the upper side of the battery until you hear a "click". Page 05 | 19 QSG220139 A00 Access-ER-HF/LF HID Quick Start and Regulatory Guide Charge the BATTERY BeforeusingtheAccess-ER,pleasechargethebatteryusingoneofthefollowingaccessoriesapprovedbyCOPPERNIC. 1.InsertthemicroUSB-CcableintotheAccess-ERandtheUSBAcableintothepowersupply. > The Micro USB C | USB A cable is included in the device’s box. > The power supply is included in the device box. Page 06 | 19 Setting up your device CAUTION PleasemakesurethedevicebeingchargedfullywhenusingAccess-ERatfirsttime. DEVICE:Access-ER Remove the BATTERY •Press the left and right latches at the same time. •Remove the battery. Red LED blinks Low battery -Battery level <= 15% Red LED Battery is charging -Battery level > 15% and < 95% Green LED Battery is fully charged ->=95% LED indicators QSG220139 A00 Access-ER-HF/LF HID Quick Start and Regulatory Guide Setting up your device Page 07 | 19 Red LED Power connected and low battery power Green LED Connected to power supply and battery charged battery charger CAUTION Chargebatteriesintemperaturesfrom0°Cto40°C.Thedeviceorcradlealwaysperformsbatterycharginginasafeandintelligentmanner.Athigher temperatures(e.g.approximately+37°C)thedeviceorcradlemayforsmallperiodsoftimealternatelyenableanddisablebatterychargingtokeepthebatteryat acceptabletemperatures.TheAccess-ERanditscradleindicateswhenchargingisdisabledduetoabnormaltemperaturesviaitsLED. CRADLE: DS-ACCESS-1000 The LED indicator shows the connection status of the docking station as well as the battery charge status. 1.InserttheJackPowerAdapterintothedockingstationandthepowersupplyintothesocket. > Power supply is included in the docking station box. BACK VIEW QSG220139 A00 Access-ER-HF/LF HID Quick Start and Regulatory Guide Using your device TURNING ON | TURNING OFF yourdevice Power On |Press and hold for 3 seconds the ON | OFF button. Power Off |Press and hold for 2 seconds the ON | OFF button and select “Power off” in the dialog box. Reboot | Press and hold for 2 seconds the ON | OFF button and select “Reboot” in the dialog window to restart the device. Suspend Mode | Press and release the ON | OFF button to place the device in suspend mode. The display will be off and go into a low power state to conserve battery power. Reset | Press and hold the ON | OFF button during 30s. Page 08 | 19 QSG220139 A00 Access-ER-HF/LF HID Quick Start and Regulatory Guide Using your device DATA CAPTURE | photos & videos Use cameras to take photos and record videos. 1.Go to the Home screen > select "Camera" > press the camera icon to take a picture/ switch to the video icon and press for video recording. 2.Press the icon to switch between cameras (front | back). NOTE Ensure device memory or extend Micro SD card space is available. Highly suggest to use camera app which is included in Android OS already. Using 3rd party application may cause any malfunction. DATA CAPTURE | barcode scanner CAUTION Class2laserwhenopen. Donotstareintobeamorviewwithopticalinstruments. Complieswith21cfr1040.10and1040.11exceptfordeviationspursuanttolasernoticeno.50,datedJune24,2007andIEC/EN60825- 1:2014. Scan with the imager •Use the "B-Manager" application provided by Coppernic to set up the reader and the "B-Scan" application to read a barcode. Page 09 | 19 QSG220139 A00 Access-ER-HF/LF HID Quick Start and Regulatory Guide Using your device DATA CAPTURE | barcode scanner Side-Key Remapping for scanning •Go to "Settings" > Select "Remap key & Shortcut". •Select function keys P1, P2 or P3. •Press the "Remap Shortcut" button. •Press the ""B-Scan"" button. •Press the scan button to trigger a capture. •The red laser lights up to assist aiming, and the scan is ready when the beep sounds. RFID LF HID Please put the card on the HF/LF HID antenna area Page 10 | 19 QSG220139 A00 Access-ER-HF/LF HID Quick Start and Regulatory Guide Regulatory information OperatingfrequenciesAccess-ER Page 11 | 19 EUT typeHandheldDevice Brand NameCoppernic Model NameAccess-ER Tx Frequency Bands (Unit: MHz) GSM 850 : 824 ~ 845 GSM 1900 : 1850 ~ 1910 WCDMA Band II : 1850 ~ 1910 WCDMA Band IV : 1710 ~ 1755 WCDMA Band V : 824 ~ 849 LTE Band 2 : 1850 ~ 1910 LTE Band 4 : 1710 ~ 1755 LTE Band 5 : 824 ~ 849 LTE Band 7 : 2500 ~ 2570 LTE Band 17 : 704 ~ 716 LTE Band 26 : 814 ~ 849 LTE Band 41 : 2…

Text truncated - open the document above for the full version.

Coppernic 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – EquipmentType Company name: Coppernic Address: 20,rue Georges Claude Aix en Provence France 13290 Product Name: access-ER HF/LF/BT HID CK FCC ID: XGK-ACERHIDCK Model(s): access-ER 2.911(d)(5)(i) EquipmentType We, [Coppernic] (“the applicant”) certify that the equipment for which authorization is sought through certification is not: • Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules. • Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Marc Piepers Date: 3/14/2023 Title and Company name: Chief Technical Officer / Coppernic NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Coppernic 2.911 (d)(5)(ii) Applicant Attestation v1.3 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Coppernic Address: 20,rue Georges Claude Aix en Provence France 13290 Product Name: access-ER HF/LF/BT HID CK FCC ID: XGK-ACERHIDCK Model(s): access-ER 2.911(d)(5)(ii) Applicant filing We, [Coppernic] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 ,established pursuant to §1.50002 of this chapter,as an entity producing coveredcommunications equipment. Yours sincerely, Name: Marc Piepers Date: 3/14/2023 Title and Company name: Chief Technical Officer / Coppernic NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

THREE STONES MEDIA LLC U.S. Agent Letter of Attestation To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Date: 03-09-2023 Ref: Attestation Statement – Part2.911(d)(7) filing FCC ID:XGK-ACERHIDCK Coppernic (“the applicant”) certifies that, as of the date of the filing of the application, THREE STONES MEDIA LLC(“the agent”) is our designated U.S. agent for service of process for the abovereference FCC ID. The applicant accepts to maintain an agent for service of process in the United States forno less than one year after either the grantee has permanently terminated all marketing and importation of theapplicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicialproceeding involving the equipment, whichever is later. The applicant further acknowledges it is ourresponsibility to inform the FCC whenever the agent information changes. THREE STONES MEDIA LLC ("the agent) understand it is the agent's obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address. Designated U.S. Agent Company Name: THREE STONES MEDIA LLC FRN: 0033401761 GC: 2A99E Address: 1200 Broadway St. APT 329, Los Angeles, CA90015 Signature: Contact Person: Sijie Zhang Tel: +1 267 909 3692 Email: [email protected] Applicant Company Name: Coppernic Address:20,rue Georges Claude Aix en Provence France 13290 Signature: Contact Person: Marc Piepers Tel:0033442652565 Email: [email protected]

Coppernic Agent Authorization Letter (2023-03-09) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park Sanwei, Xixiang, Bao'an District, Shenzhen, Guangdong, China Alex.li [email protected] to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Marc Piepers / Chief Technical Officer Date/City: 2023-03-09 / Aix en Provence Phone: 0033442652565 Fax: 0033442515732 E-mail: [email protected]

Coppernic Long Term Confidentiality Request Letter (2023-03-09) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR Product: access-ER HF/LF/BT HID CK Model: access-ER FCC ID: XGK-ACERHIDCK To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the • Schematic Diagram • Block Diagram • Part List / BOM List / PCB Layout • Operational Description • Tune-up Procedure • FCC Software Security Requirements for UNII devices Required to be submitted with this application be permanently withheld from public review. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Please contact me if there is any information you may need. Sincerely, Marc Piepers / Chief Technical Officer Date/City: 2023-03-09 / Aix en Provence Phone: 0033442652565 Fax: 0033442515732 E-mail: [email protected]

Coppernic Short Term Confidentiality Request Letter (2023-03-09) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Short Term Confidentiality Request For Product: access-ER HF/LF/BT HID CK Model: access-ER FCC ID: XGK-ACERHIDCK To Whom It May Concern: In accordance with sections 0.457 and 0.459 of CFR 47, < Coppernic >. requests short-term Confidentiality of following sections of this application for a period of 180 days after grant is issued. Test setup photos External photos Internal photos User’s manual These documents contain detailed system and equipment descriptions and related information about the product, which < Coppernic > considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, < Coppernic > feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Marc Piepers / Chief Technical Officer Date/City: 2023-03-09 / Aix en Provence Phone: 0033442652565 Fax: 0033442515732 E-mail: [email protected]

ATTACHMENT PHOTOGRAPHS OF EUT Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8 Photo 9 Photo 10 Photo 11 Photo 12

Regulatory label specification Access-ER P. Porte STD 220131 A30 03/03/23 1/3 LABEL SPECIFICATION The regulatory label is defined for the Access-ER product. COPPERNIC Model: access-ER Handheld Device Rating: +5V 3.0 A Serial No.: EXXXXXXXXXX IMEI1: XXXXXXXXXXXXXXX IMEI2: XXXXXXXXXXXXXXX MFD: XXX/XXXX Depend on product 33 mm 29,5 mm 13 mm Regulatory label specification Access-ER P. Porte STD 220131 A30 03/03/23 2/3 For the access-ER HF/LF/BT HID CK: P/N: ACCESS-ER-XXX3XXX Product Name: access- ER HF/LF/BT HID CK Model Name:access-ER FCC ID: XGK-ACERHIDCK IC: 8402A- ACERHIDCK HVIN:ACERHIDCK MADE IN FRANCE Regulatory label specification Access-ER P. Porte STD 220131 A30 03/03/23 3/3 LABEL POSITION : The label must be stick in this area : : Product Label

ATTACHMENT PHOTOGRAPHS OF EUT Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8 NFC/RFID ANT Photo 9 Photo 10 Photo 11 Photo 12 Photo 13 Photo 14 Photo 15 Photo 16 Photo 17 Photo 18 Photo 19 Photo 20 Photo 21 Photo 22 BT/WIFI ANT Photo 23 Photo 24 GSM/WCDMA/LTE Main ANT LTE AUX ANT

PCTA200 Antenna Specifications DV 2020/06/01 Antenna Team © Askey Computer Corp. -CONFIDENTIAL Agenda 2 •Antenna Location •Antenna Dimension •Antenna Passive Result –LTE-Main Antenna –LTE-AUXAntenna –GPS_Wi-Fi Antenna –NFC Antenna © Askey Computer Corp. -CONFIDENTIAL 3 Antenna Location LTE-AUX Antenna LTE-Main Antenna NFC GPS_Wi-Fi Antenna AntennaAntenna type Antenna Manufacturer LTE-MainPIFA INPAQ TECHNOLOGY CO., LTD LTE-AUXPIFA INPAQ TECHNOLOGY CO., LTD GPS_Wi-FiPIFA NFCLoop © Askey Computer Corp. -CONFIDENTIAL 4 Antenna Dimension LTE-MainAntenna LTE-AUX/ GPS/ Wi-Fi/NFC Antenna © Askey Computer Corp. -CONFIDENTIAL LTE-Main Antenna 5 © Askey Computer Corp. -CONFIDENTIAL 1 2 3 4 5 6 7 8 9 10 11 500 700 900 1100 1300 1500 1700 1900 2100 2300 2500 2700 2900 VSWR Frequency (MHz) 02-80 01-80 08-80 04-80 00-82 6 LTE-Main S-parameters © Askey Computer Corp. -CONFIDENTIAL 7 LTE-Main Performance B19TXB19RX B5TXB5RX B20RXB20TXB8TXB8RX B28 TXB28RXB26TXB26RX Frequency (MHz) 699704710716729734740746748751756777782787791806821824836849862869880894900915925940960 Spec 151515151515151515151515202020202020202020202020202020 Tune Code 02-8018.9618.7618.4818.1719.318.1117.6416.4415.816.2715.6917.3918.5919.2219.7319.7416.0315.412.7610.288.4357.4966.2464.8164.4583.7023.3182.7742.34 01-8013.4413.5913.713.7115.3814.7714.6313.9713.5114.0313.9917.9220.0121.5422.9627.5228.5228.8928.3627.6825.3523.4119.9615.0313.4610.28.6186.7295.263 08-808.7558.9399.0639.10910.339.989.9239.4729.1539.4619.44611.9913.5514.615.6819.1320.8521.6323.326.630.6532.5334.4133.2532.1826.7422.5416.4611.42 04-804.6134.8124.9785.15.9865.8675.955.7335.5585.7515.7667.3038.3239.0079.70111.8612.8413.3114.3916.4419.7221.6624.9828.8831.0333.6132.5425.3116.64 00-820.6320.6460.6940.7340.9631.0021.121.1521.1481.2281.271.6421.882.0672.2683.0273.3093.4143.6774.0394.7025.0565.7066.5827.289.7212.8819.9829.73 B38 B4TXB2TXB2RXB4RXB7TXB7RX B3TXB3RXB1TXB1RXB41 Frequency (MHz) 171017301750175517701785180518401850188019001910192019301950196019801990201020182025211021402155217023002350240025002515253525552570259526202630265526802690 Spec 35353535353535353535353535353535303030303535353535353535353535 Tune Code 02-80 36.4238.9545.6647.9953.3458.8159.4160.3261.8262.1859.4657.9155.2652.952.9855.2851.7149.5747.9848.147.7532.9733.3932.4831.7528.9930.362934.0535.4936.0639.6243.0645.2448.2451.8150.1740.134.86 01-80 36.5139.0645.7648.0753.4858.959.4860.3461.862.0959.3757.8255.1652.7952.8755.1651.5849.4547.8848.0347.6432.933.3332.4231.728.9930.392935.0135.4736.0339.5843.0545.2248.1751.7449.9539.7835.61 08-80 37.2639.846.4748.854.1859.5459.9460.3261.6761.5858.757.1154.4952.1352.1454.4150.9348.8547.3447.4847.1532.5733.0132.1431.4629.0830.5329.0633.6535.1635.8239.3442.5243.7946.1149.4748.5640.0135.16 04-80 37.0239.5546.2148.5553.959.3259.8460.3761.7861.8559.0557.4954.8452.5152.5454.8551.3449.2547.7147.8447.4732.8333.2732.3731.6929.1230.4829.0633.8635.3535.939.514345.148.0351.4449.1138.6132.56 00-82 36.7139.1945.8248.1853.5558.9359.5460.1861.6461.6858.9557.4254.8352.4752.4754.7551.2949.1747.5847.6947.3132.7433.2232.331.6128.8830.1928.8433.6135.1135.5939.1442.6444.647.751.249.4439.233.07 Efficiency Unit: (%) © Askey Computer Corp. -CONFIDENTIAL 8 LTE-Main Peak Gain Frequency (MHz)699704710716729734740746748751756777782787791806821824836849862869880894900915925940960 Peak Gain (dBi) -2.85-2.74-2.82-2.96-2.60-2.78-2.90-3.20-3.65-3.31-3.56-3.73-3.24-2.68-2.30-1.12-0.86-0.76-0.80-0.82-0.53-0.30-0.19-0.51-0.62-0.39-0.70-2.05-1.19 Frequency (MHz)171017301750175517701785180518401850188019001910192019301950196019801990201020182025211021402155217023002350240025002515253525552570259526202630265526802690 Peak Gain (dBi) 0.571.101.711.932.233.002.352.222.251.931.931.851.601.261.131.250.720.520.800.981.030.870.880.800.550.040.150.121.020.910.761.361.391.471.421.591.350.27-0.47 Unit: (dBi) © Askey Computer Corp. -CONFIDENTIAL LTE-Main Pattern B28(734MHz)B26(836MHz)B5(836MHz) B19(849MHz)B20(849MHz)B8(894MHz) © Askey Computer Corp. -CONFIDENTIAL LTE-Main Pattern B4(1730MHz)B3(1770MHz)B2(1880MHz) B1(1950MHz)B7(2535MHz)B38(2595MHz) © Askey Computer Corp. -CONFIDENTIAL LTE-Main Pattern B39(1900MHz)B41(2595MHz) © Askey Computer Corp. -CONFIDENTIAL LTE-AUX Antenna 12 © Askey Computer Corp. -CONFIDENTIAL 13 LTE-AUX S-parameters 1 2 3 4 5 6 7 8 9 10 11 500 700 900 1100 1300 1500 1700 1900 2100 2300 2500 2700 2900 VSWR Frequency (MHz) © Askey Computer Corp. -CONFIDENTIAL 14 LTE-AUX Performance B19 RX B20 RXB5 RX B28 RXB26 RXB8 RX Frequency (MHz)699704710716729734740746748751756777782787791806821824836849862869880894900915925940960 Spec 6.36.36.36.36.36.36.36.36.36.36.36.36.36.36.36.36.36.36.36.36.36.36.36.3 AUX 9.8110.3110.7911.2813.9414.1015.3615.7115.6416.8317.6624.7226.9228.1729.7236.4634.9034.7330.3924.8719.1716.3212.599.829.378.518.267.206.40 B38 B4 RXB7 RX B3 RXB2 RXB1 RXB41 Frequency (MHz)171017301750175517701785180518401850188019001910192019301950196019801990201020182025211021402155217023002350240025002515253525552570259526202630265526802690 Spec 12.512.512.512.512.512.512.512.512.512.512.512.512.512.512.512.512.512.512.512.515.815.815.815.815.815.815.815.815.815.8 AUX 16.7013.5013.4513.8014.7316.1717.7822.1024.0729.6331.9532.6132.1931.7332.5234.2232.6431.2228.6328.0627.3215.3813.0712.9712.5910.0711.0011.2017.6318.9620.4324.7327.3929.1830.6432.8233.7233.2632.00 Efficiency Unit: (%) © Askey Computer Corp. -CONFIDENTIAL GPS_Wi-Fi Antenna 15 © Askey Computer Corp. -CONFIDENTIAL 16 GPS_Wi-Fi S-parameters 1 2 3 4 5 6 7 8 9 10 11 1000 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000 VSWR Frequency (MHz) © Askey Computer Corp. -CONFIDENTIAL 17 GPS_Wi-Fi Performance GPSWi-Fi 2.4GHzWi-Fi 5GHz Frequency1575.4216022400245025005150535057255825 Spec202030303035353535 Efficiency(% ) 26.09 %25.26 %32.46 %40.10 %39.59 %39.53 %38.07 %40.15 %41.79 % © Askey Computer Corp. -CONFIDENTIAL 18 Wi-Fi Peak Gain Frequency2400245025005150535057255825 Peak Gain (dBi) 0.763.001.461.073.002.231.65 Unit: (dBi) © Askey Com…

Text truncated - open the document above for the full version.

Report No.: S22101403919008 Version.1.1 Page 1 of 24 FCC Test Report FCC ID: XGK-ACERHIDCK Product: access-ER HF/LF/BT HID CK Trade Name: COPPERNIC Model Number: access-ER Family Model: N/A Report No.: S22101403919008 Prepared for Coppernic 20,rue Georges Claude Aix en Provence France 13290 Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen 518126 P.R. China Tel. 400-800-6106, 0755-2320 0050, 0755-2320 0090 Website: http://www.ntek.org.cn Report No.: S22101403919008 Version.1.1 Page 2 of 24 TEST RESULT CERTIFICATION Applicant’s name ................. : Coppernic Address ................................. : 20,rue Georges Claude Aix en Provence France 13290 Manufacturer's Name .......... : Askey Computer Corp. Address ................................. : 10F, No.119, JianKang RD.,Zhonghe Dist.,New Taipei City,23585 Taiwan,R.O.C Taiwan Product description Product name ........................... : access-ER HF/LF/BT HID CK Model and/or type reference : access-ER, N/A Sample number S221014039020 Standards ............................. : FCC part 15C:2018 ANSI C63.10:2013 This device described above has been tested by Shenzhen NTEK Testing Technology Co., Ltd., and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of Shenzhen NTEK Testing Technology Co., Ltd., this document may be altered or revised by Shenzhen NTEK Testing Technology Co., Ltd., personnel only, and shall be noted in the revision of the document. The test results of this report relate only to the tested sample identified in this report. Date of Test ............................................ : Date (s) of performance of tests ............. : Oct 17, 2022 ~ Jan 03, 2023 Date of Issue ........................................... : Jan 09, 2023 Test Result ............................................... : Pass Testing Engineer : (Allen Liu) Authorized Signatory : (Alex Li) Report No.: S22101403919008 Version.1.1 Page 3 of 24 Table of Contents Page 1 . TEST SUMMARY 4 1.1 FACILITIES AND ACCREDITATIONS 5 1.2 LABORATORY ACCREDITATIONS AND LISTINGS 5 1.3 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST SETUP 9 2.3 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL 10 2.4 MEASUREMENT INSTRUMENTS LIST 11 3 . EMC EMISSION TEST 12 3.1 CONDUCTED EMISSION MEASUREMENT 12 3.1.1 POWER LINE CONDUCTED EMISSION 12 3.1.2 TEST PROCEDURE 13 3.1.3 TEST SETUP 13 3.1.4 EUT OPERATING CONDITIONS 13 3.1.5 TEST RESULTS 14 3.2 RADIATED EMISSION MEASUREMENT 16 3.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT 16 3.2.2 TEST PROCEDURE 17 3.2.3 TEST SETUP 18 3.2.4 TEST RESULTS 19 4. BANDWIDTH TEST 22 4.1 TEST PROCEDURE 22 4.2 TEST SETUP 22 4.3 TEST RESULT 23 5. ANTENNA APPLICATION 24 5.1 Antenna Requirement 24 5.2 Result 24 Report No.: S22101403919008 Version.1.1 Page 4 of 24 1. TEST SUMMARY Test procedures according to the technical standards: EMC Emission Standard Test Item FCC Rules Limit Judgment Remark FCC part 15C:2018 ANSI C63.10:2013 Conducted Emission §15.207 Class B PASS Radiated Emission §15.209 Class B PASS ANTENNA APPLICATION §15.203 / PASS NOTE: (1) ’N/A’ denotes test is not applicable in this Test Report (2) For client’s request and manual description, the test will not be executed. Report No.: S22101403919008 Version.1.1 Page 5 of 24 1.1 FACILITIES AND ACCREDITATIONS All measurement facilities used to collect the measurement data are located at 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen 518126 P.R. China. The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.10 and CISPR Publication 22. 1.2 LABORATORY ACCREDITATIONS AND LISTINGS Site Description CNAS-Lab. : The Laboratory has been assessed and proved to be in compliance with CNAS-CL01:2006 (identical to ISO/IEC 17025:2005) The Certificate Registration Number is L5516. IC-Registration : The Certificate Registration Number is 9270A. CAB identifier:CN0074 FCC- Accredited : Test Firm Registration Number: 463705. Designation Number: CN1184 A2LA-Lab. : The Certificate Registration Number is 4298.01 This laboratory is accredited in accordance with the recognized International Standard ISO/IEC 17025:2005 General requirements for the competence of testing and calibration laboratories. This accreditation demonstrates technical competence for a defined scope and the operation of a laboratory quality management system (refer to joint ISO-ILAC-IAF Communiqué dated 8 January 2009). Name of Firm : Shenzhen NTEK Testing Technology Co., Ltd. Site Location : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen 518126 P.R. China. 1.3 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. A. Conducted Measurement : Test Site Method Measurement Frequency Range U,(dB) NOTE NTEKC01 ANSI 150 KHz ~ 30MHz 3.2 B. Radiated Measurement : Test Site Method Measurement Frequency Range U,(dB) NOTE NTEKA01 ANSI 30MHz ~ 1000MHz 4.7 1GHz ~12.4GHz 5.0 Report No.: S22101403919008 Version.1.1 Page 6 of 24 Revision History Report No. Version Description Issued Date S22101403919008 Rev.01 Initial issue of report Jan 09, 2023 Report No.: S22101403919008 Version.1.1 Page 7 of 24 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product Feature and Specification Equipment access-ER HF/LF/BT HID CK Trade Name COPPERNIC FCC ID XGK-ACERHIDCK Model No. access-ER Family Model N/A Model Difference N/A Operating Frequency 125KHz Modulation Technique Induction Antenna Type N/A Adapter Adapte…

Text truncated - open the document above for the full version.

Radiated Measurement Photos Conducted Measurement Photos
