C-One 2 Quick Start and Regulatory Guide QSG180190 A30 | Non-Contractual Pictures | QSG180190 A30 C-One 2 Quick Start and Regulatory Guide WHAT'S IN THE BOX ? C-One 2 HF ASK C-One 2 HF iClass | LF Prox C-One 2 HF LEGIC | LF TM C-One 2 LF Agrident Page 2 | 15 DEVICE NOTICE BOX 1 2 3 HANDSTRAP CABLE MICRO USB | USB A STYLUS 4 5 6 PLUG |EUROPE POWER SUPPLY TEST REPORT 7 8 9 1 2 3 45 67 8 9 OR C-One 2 Quick Start and Regulatory Guide PRODUCT OVERVIEW led indicators 4.5’’ touch panel programmable key | scan key (P2) micro SD | micro SIM door microphone micro USB microphon e flash camera 2D imager RFID antenna speake r programmable key | scan key (P1) handstrapholder programmable key (P3) power key handstrapholder | Non-Contractual Pictures | RFID antenna C-One 2 HF ASK C-One 2 HF iClass | LF Prox C-One 2 HF LEGIC | LF TM C-One 2 LF Agrident Page 3 | 15 QSG180190 A30 tether back touch keys men u hom e receiver volume keys +/- C-One 2 Quick Start and Regulatory Guide Setting upyour device CAUTION Failure to completely reseal the Micro SD |Micro SIM card slot cover may lead to water or other liquids entering the casing which may cause damage to the device. MICRO SIM card installation •Open Micro SD |Micro SIM door. •To remove the Micro SIM card: Insert a removal tool (pin type) into the hole then push until the tray pops out. •Put the Micro SIM card on the tray. •Insert Micro SIM tray into SIM slot. •Close the door after installation. MICRO SD card installation •Open Micro SD |Micro SIM door. •Insert Micro SD card into Micro SD card slot. •Close the door after installation. NOTE Micro SIM card and Micro SD card should be purchased separately. Page 4 | 15 QSG180190 A30 CAUTION Donotuseinternalperipheralsduringchargingprocess. PleasemakesurethedevicebeingchargedfullywhenusingC-One²atfirsttime. PleaseensuretheMicroUSBportcleananddrybeforeinsertingaUSBcableforchargingtoavoidthe operatingissuesonthedevice. PleaseremovewaterormoisturefromtheMicroUSBportinstantlywithsoftclothwhenthedevicegets wet,toavoidtheoperatingissuesonthedevice. Charge the BATTERY BeforeusingtheC-One²chargethebatteryusingoneofthefollowingaccessoriesapprovedby COPPERNIC: 1.InsertthemicroUSBcableintotheC-One²andUSBAcableintothepowersupply. > Cable Micro USB |USB A is included in the device box. > Power supply is included in the device box. 2.InserttheJackPowerAdapterintothedockingstationandtheUSBAcableintothepowersupply. > Cable USB A | Jack Power Adapter is included in the docking station box. > Power supply is included in the docking station box. Setting upyour device Page 5 | 15 C-One 2 Quick Start and Regulatory Guide QSG180190 A30 BACK VIEW C-One 2 Quick Start and Regulatory Guide Setting upyour device LED indicators LED1 LED2 RedLED blinks(LED1) Lowbattery RedLED (LED1) Battery ischarging Green LED (LED1) Battery isfullycharged Blue LED blinks(LED2) BT devices connected or receiving messages/notifications Page 6 | 15 QSG180190 A30 C-One 2 Quick Start and Regulatory Guide Using your device TURNING ON | TURNING OFF yourdevice Power Off |Press and hold during 5 sec. the power button and select “Power off” in the dialog box. Reboot | Press and hold during 5 sec. the power button and select “Reboot” in the dialog window to restart the device. Suspend Mode | Press and release the power button to place the device in suspend mode. The display will be off and go into a low power state to conserve battery power. Reset | Press and hold the power button during 30s. Page 7 | 15 QSG180190 A30 C-One 2 Quick Start and Regulatory Guide Using your device DATA CAPTURE | photos & videos Use the rear camera to take photos and capture video. 1.Go to Home Screen > select “Camera” > Tap camera icon or screen to take a picture/switch to video icon and tap for video recording. 2.Using the rear camera to take photos and capture video. NOTE Ensure device memory or extend Micro SD card space is available. DATA CAPTURE | barcode scanner CAUTION Class2laserwhenopen. Donotstareintobeamorviewwithopticalinstruments. Complieswith21cfr1040.10and1040.11exceptfordeviationspursuanttolasernotice no.50,datedJune24,2007andIEC/EN60825-1:2014. NOTE Please remove the protector film before using scanner. Scan with the imager •Use "barcode manager" providedby Coppernic. Side-Key Remapping for scanning •Go to "Settings">Select "Remap key & Shortcut" •Select the key (P1, P2 : blue side keys) >Tap Remap Key >Tap Barcode Scan •The red laser aiming pattern turn on to assist in aiming, scan ready when beep sounds •Release the scan button. Page 8 | 15 QSG180190 A30 C-One 2 Quick Start and Regulatory Guide Using your device RFID C-One 2 HF ASK -C-One 2 HF iClass | LF Prox -C-One 2 HF LEGIC | LF TMwith RFID options to read, please put the TAG/CARD on the RFID area. C-One 2 LF AGRIDENTwith RFID options to read, please put the TAG/CARD on the RFID area. RFID READING AREA OPTION Stick LF AGRIDENT antenna RFID READING AREA RFID READING AREA Page 9 | 15 QSG180190 A30 C-One 2 Quick Start and Regulatory Guide Regulatory information CAUTION OnlyuseCOPPERNICapprovedaccessories. OperatingfrequenciesC-One 2 EUT Type Handheld Device Brand Name COPPERNIC Model Name C-ONE²/C-ONE²(WOS) Tx Frequency Bands (Unit: MHz) GSM 900 : 880 ~ 915 GSM 1800 : 1710 ~ 1785 WCDMA Band I : 1920 ~ 1980 WCDMA Band VIII : 880 ~ 915 LTE Band 1 : 1920 ~ 1980 LTE Band 3 : 1710 ~ 1785 LTE Band 7 : 2500 ~ 2570 LTE Band 8 : 880 ~ 915 LTE Band 20 : 832 ~ 862 LTE Band 28 : 703 ~ 748 WLAN : 2412 ~ 2472, 5180 ~ 5320, 5500 ~ 5700 Bluetooth : 2402 ~ 2480 RFID option HF ASK: 13.56MHz RFID option LF AGRIDENT: 134.2KHz RFID option HF iClass: 13.56 MHz RFID option LF Prox: 125KHz RFID option HF LEGIC: 13.56 MHz RFID option LF TM: 125KHz GPS : 1575.42 Maximum AVG Conducted Power (Unit: dBm) GSM 900 : 33.78 GSM 1800 : 31.12 WCDMA Band I : 23.68 WCDMA Band VIII : 23.77 LTE Band 1 : 24.52 LTE Band 3 : 23.98 LTE Band 7 : 23.97 LTE Band 8 : 23.99 LTE Band 20 : 23.99 LTE Band 28 : 23.94 802.11b : 15.83 802.11g : 16.72 802.11n HT20 (2.4GHz…
