VICTOR READER STREAM USER GUIDE by HumanWare revision 23-20130423 HumanWare www.humanware.com STREAM User Guide 1 rev 23-20130423 User Guide HumanWare www.humanware.com STREAM User Guide 2 rev 23-20130423 About VICTOR READER STREAM HumanWare is proud to introduce VICTOR READER STREAM, the powerful digital talking book player. VICTOR READER STREAM is designed as an advanced high performance DAISY, MP3, and NISO player for students, professionals, or on-the-go people who have extensive reading needs. It allows you to transfer content from your PC to its removable flash memory card and provides advanced navigation of multiple formats including DAISY, MP3, NISO and electronic text. The VICTOR READER STREAM will be referred to as the Stream throughout this User guide to shorten the text. Copyright 2013. All rights reserved, Technologies HumanWare. This User Guide is protected by copyright belonging to HumanWare, with all rights reserved. The User Guide may not be copied in whole or in part, without written consent from HumanWare. HumanWare www.humanware.com STREAM User Guide 3 rev 23-20130423 Table of Contents 1. OVERVIEW OF VICTOR READER STREAM ..........................................................................6 1.1 UNPACKING THE PLAYER .................................................................................................... 6 1.2 PHYSICAL DESCRIPTION OF VICTOR READER STREAM .................................................. 6 1.2.1 Front Face of the Player .............................................................................................6 1.2.2 Left Side of the Player .................................................................................................6 1.2.3 Right Side of the Player ..............................................................................................7 1.2.4 Top Edge of the Player ...............................................................................................7 1.2.5 Bottom Edge of the Player ..........................................................................................7 1.2.6 Back side of the Player (Battery Compartment) .........................................................7 1.2.7 Recharging Battery .....................................................................................................7 1.2.8 NLS Book Cartridge (United States only) ...................................................................8 1.2.9 Copying Books from USB Devices or NLS cartridges ................................................8 1.3 POWER BUTTON ................................................................................................................. 8 1.3.1 Turning the Player On and Off ....................................................................................8 1.3.2 Player Reset Using Power Button ..............................................................................8 1.4 INSERTING OR REMOVING THE SD CARD ............................................................................. 9 1.4.1 SD Card Voice Label ..................................................................................................9 1.5 MEMORY CARD DETECTION ................................................................................................ 9 1.6 BOOKSHELF STRUCTURE .................................................................................................... 9 1.7 OTHER RESERVED FILE NAMES......................................................................................... 11 1.8 TRANSFERRING FILES BETWEEN YOUR COMPUTER AND STREAM ....................................... 11 1.9 USING STREAM WHILE CONNECTED TO THE COMPUTER ..................................................... 11 1.10 HUMANWARE COMPANION ................................................................................................ 11 2. BASIC FUNCTIONS .............................................................................................................. 12 2.1 CHANGING VOLUME, SPEED, TONE/PITCH ......................................................................... 12 2.1.1 Different Speed settings for TTS and Audio playback ............................................. 12 2.2 CHANGING BASS AND TREBLE (MUSIC BOOKSHELF) ........................................................... 12 2.3 PLAY/STOP ...................................................................................................................... 12 2.4 REWIND AND FAST FORWARD ........................................................................................... 12 2.5 SLEEP MODE AND TIME ANNOUNCEMENT ........................................................................... 13 2.6 SETTING THE DATE AND TIME ............................................................................................ 13 2.7 KEY DESCRIBER MODE ..................................................................................................... 14 3. NUMERIC KEY FUNCTIONS ................................................................................................ 15 3.1 NUMERIC KEY PAD LIST .................................................................................................... 15 3.2 NAVIGATION KEYS ............................................................................................................ 15 3.2.1 Undo navigation ....................................................................................................... 15 3.3 TIME JUMP NAVIGATION MODE .......................................................................................... 15 3.4 TEXT-TO-SPEECH NAVIGATION ELEMENTS ......................................................................... 15 3.5 SPELL MODE FOR TEXT CONTENT ..................................................................................... 16 3.6 SKIPPABLE ELEMENTS ....................................................................................................... 16 3.6.1 Recall skippable…

Text truncated - open the document above for the full version.

Antenna Location The location of the antenna is indicated in the picture below. It is a view from the bottom side of the unit. If you place the unit in your hand with the keypad in front of you, the antenna is located at the left side of key "7" at the edge of the enclosure.

The Testcenter facility ‘Dosimetric Test Lab’ within IMST GmbH is accredited by the German National ‘Deutsche Akkreditierungsstelle GmbH (DAkkS)’ for testing according to the scope as listed in the accreditation certificate: D-PL-12139-01-01. SAR_Appendix_Report_Nemko_60320_6130378_FCC_Body_2.4GHz_VictorReader Page 1 of 30 Appendix to SAR Report (SAR_Report_Nemko_60320_6130012_FCC_Body_2.4GHz_VictorReader_V2) Dosimetric Assessment of the Victor Reader Stream from HumanWare (FCC ID: XT5503VRC) (IC: 8670A-503VRC) According to the FCC Requirements November 19, 2013 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Customer HumanWare 445, Rue Du Parc-Industriel Longueuil, (Quebec) Canada J4H 3V7 The test results only relate to the items tested. This report shall not be reproduced except in full without the written approval of the testing laboratory. Dasy_Report_ FCC_Body_Card_850_1900_WCDMA II_WCDMA V_1.4.doc/20.06.2008/ABo SAR_Appendix_Report_Nemko_60320_6130378_FCC_Body_2.4GHz_VictorReader Page 2 of 30 Dasy_Report_ FCC_Body_Card_850_1900_WCDMA II_WCDMA V_1.4.doc/20.06.2008/ABo Executive Summary The device Victor Reader Stream is a new handheld media player from HumanWare operating in the 2450 MHz frequency range. The device has an integrated antenna and the system concepts used are the IEEE 802.11 b/g/n standards. There is no simultaneous transmission mode available. The objective of the measurements done by IMST was the dosimetric assessment of one device in body worn configuration in the IEEE 802.11 b/g/n standards. Since there was a special test software available, SAR tests in IEEE 802.11 b/g/n are conducted with a specific channel, bandwidth and maximum output power. The device was tested in two positions. Position one with the housing of the handheld (with headphones and microphone) in direct contact against the flat phantom and position two in PTT configuration (with attached headphones). The examinations have been carried out with the dosimetric assessment system „DASY4“. The measurements were made according to the 47 CFR § 2.1093 [47CFR] for evaluating compliance of mobile and portable devices with FCC limits for human exposure (general population) to radiofrequency emissions, IEEE 1528-2003 [IEEE1528-2003] and IC RSS 102 Issue 4. Additional information and guidelines given by the following FCC documents were used:  SAR Measurement Requirements for 100 MHz to 6 GHz [KDB 865664 D01 v01r01]  Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies [KDB 447498 D01 v05r01]  SAR Measurement Procedures for 802.11 a/b/g Transmitters [KDB 248227] All measurements have been performed in accordance to the recommendations given by SPEAG. SAR_Appendix_Report_Nemko_60320_6130378_FCC_Body_2.4GHz_VictorReader Page 3 of 30 Dasy_Report_ FCC_Body_Card_850_1900_WCDMA II_WCDMA V_1.4.doc/20.06.2008/ABo Compliance Statement The portable device Victor Reader Stream from HumanWare (FCC ID: XT5503VRC, IC: 8670A-503VRC) is in compliance with the following standards for uncontrolled exposure:  47 CFR § 2.1093 [47CFR]  IC RSS 102 Issue 4 [RSS 102],  IEEE Std. C95.1 - 1999 [C95.1-1999],  IEEE Std. C95.3 - 2002 [C95.3-2002],  IEEE 1528-2003 [IEEE 1528-2003],  The latest version of all relevant FCC OET KDB Procedures In addition to the original SAR report: “SAR_Report_Nemko_60320_6130012_FCC_Body_2.4GHz_VictorReader_V2” IMST has conducted SAR assessment for the following configurations:  Body worn (worst case channel) with attached headphones and microphone  PTT configuration with attached headphones, 25 mm distance The maximum results of SAR for the above mentioned configurations for the Victor Reader Stream are as follows: Test Position Frequency Band ChannelAccessory Position Highest Reported SAR 1g [W/kg] Body Worn IEEE 802.11 b 1 Headphones + Microphone 1 (Fig. 12) 0.671 prepared by: .............................................. reviewed by: .............................................. Alexander Rahn André van den Bosch test engineer quality assurance engineer SAR_Appendix_Report_Nemko_60320_6130378_FCC_Body_2.4GHz_VictorReader Page 4 of 30 Dasy_Report_ FCC_Body_Card_850_1900_WCDMA II_WCDMA V_1.4.doc/20.06.2008/ABo Table of Contents 1 SUBJECT OF INVESTIGATION .......................................................................................................... 5 2 THE IEEE STANDARD C95.1 AND THE FCC EXPOSURE CRITERIA ............................................. 5 2.1 DISTINCTION BETWEEN EXPOSED POPULATION, DURATION OF EXPOSURE AND FREQUENCIES ........... 5 2.2 DISTINCTION BETWEEN MAXIMUM PERMISSIBLE EXPOSURE AND SAR LIMITS .................................... 6 2.3 GENERAL SAR LIMIT ...................................................................................................................... 6 3 THE FCC MEASUREMENT PROCEDURE ......................................................................................... 7 3.1 GENERAL REQUIREMENTS .............................................................................................................. 7 4 BODY-WORN CONFIGURATIONS ..................................................................................................... 7 4.1 POC (PTT) POSITION ..................................................................................................................... 8 4.2 PHANTOM REQUIREMENTS .............................................................................................................. 8 4.3 TEST TO BE PERFORMED ................................................................................................................ 8 4.4 ADDITIONAL INFORMATION FOR 802.11 A/B/G TRANSMITTERS ACCORDING KDB 248227 ................... 9 5 THE MEASUREMENT SYSTEM ........................................................................................................ 10 5.1 PHANTOMS..............................................................................................................…

Text truncated - open the document above for the full version.

SAR_Appendix_Report_Nemko_60320_6130378_FCC_Body_2.4GHz_Plots_VictorReader Page 1 of 4 The Testcenter facility ‘Dosimetric Test Lab’ within IMST GmbH is accredited by the German National ‘Deutsche Akkreditierungsstelle GmbH (DAkkS)’ for testing according to the scope as listed in the accreditation certificate: D-PL-12139-01-01. Appendix to SAR Report (SAR_Report_Nemko_60320_6130012_FCC_Body_2.4GHz_VictorReader_V2) Dosimetric Assessment of the Victor Reader Stream from HumanWare (FCC ID: XT5503VRC) (IC: 8670A-503VRC) According to the FCC Requirements SAR Distribution Plots November 20, 2013 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Customer HumanWare 445, Rue Du Parc-Industriel Longueuil, (Quebec) Canada J4H 3V7 The test results only relate to the items tested. This report shall not be reproduced except in full without the written approval of the testing laboratory. Dasy_Report_FCC_DECT_1900_1.1.doc/22.05.2006/CH SAR_Appendix_Report_Nemko_60320_6130378_FCC_Body_2.4GHz_Plots_VictorReader Page 2 of 4 dasy_report_fcc_DECT_1900_plots_1.0.doc/110.05.2006/ABo Table of Contents 1 SAR DISTRIBUTION PLOTS, BODY WORN, IEEE 802.11B ................................................................... 3 2 SAR DISTRIBUTION PLOTS, PTT CONFIGURATION, IEEE 802.11B .................................................. 4 SAR_Appendix_Report_Nemko_60320_6130378_FCC_Body_2.4GHz_Plots_VictorReader Page 3 of 4 dasy_report_fcc_DECT_1900_plots_1.0.doc/110.05.2006/ABo 1 SAR Distribution Plots, Body Worn, IEEE 802.11b Test Laboratory: Imst GmbH, DASY Yellow (II); File Name: Stream_5_ywhm_1_CH1_b_hs+micro.da4 DUT: Humanware; Type: Stream; Serial: 5 Program Name: IEEE 802.11 b Communication System: WLAN 2450; Frequency: 2412 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2412 MHz; σ = 1.87 mho/m; ε r = 51.4; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: EX3DV4 - SN3860; ConvF(7.47, 7.47, 7.47); Calibrated: 29.07.2013 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn631; Calibrated: 23.09.2013 - Phantom: SAM Glycol 1340; Type: QD 000 P40 CB; Serial: TP-1340 - Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Body Worn/Area Scan (10x13x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (measured) = 0.437 mW/g Body Worn/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 3.97 V/m; Power Drift = 0.179 dB Peak SAR (extrapolated) = 1.31 W/kg SAR(1 g) = 0.443 mW/g; SAR(10 g) = 0.169 mW/g Maximum value of SAR (measured) = 0.522 mW/g Fig. 1: SAR distribution for IEEE 802.11 b, body worn configuration, channel 1, position 1 with attached headphones and microphone (November 11, 2013) SAR_Appendix_Report_Nemko_60320_6130378_FCC_Body_2.4GHz_Plots_VictorReader Page 4 of 4 dasy_report_fcc_DECT_1900_plots_1.0.doc/110.05.2006/ABo 2 SAR Distribution Plots, PTT configuration, IEEE 802.11b Test Laboratory: Imst GmbH, DASY Yellow (II); File Name: Stream_5_ywhm_3_CH1_b_hs_25mm.da4 DUT: Humanware; Type: Stream; Serial: 5 Program Name: IEEE 802.11 b Communication System: WLAN 2450; Frequency: 2412 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2412 MHz; σ = 1.71 mho/m; ε r = 39.4; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: EX3DV4 - SN3860; ConvF(7.38, 7.38, 7.38); Calibrated: 29.07.2013 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn631; Calibrated: 23.09.2013 - Phantom: SAM Glycol 1340; Type: QD 000 P40 CB; Serial: TP-1340 - Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Body Worn/Area Scan (10x13x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (measured) = 0.021 mW/g Body Worn/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 2.22 V/m; Power Drift = -0.194 dB Peak SAR (extrapolated) = 0.035 W/kg SAR(1 g) = 0.019 mW/g; SAR(10 g) = 0.011 mW/g Fig. 2: SAR distribution for IEEE 802.11b, PTT configuration, channel 1, position 2 with attached headphones, 25 mm distance (November 11, 2013).

The Testcenter facility ‘Dosimetric Test Lab’ within IMST GmbH is accredited by the German National ‘Deutsche Akkreditierungsstelle GmbH (DAkkS)’ for testing according to the scope as listed in the accreditation certificate: D-PL-12139-01-01. SAR_Report_Nemko_60320_6130012_FCC_Body_2.4GHz_VictorReader_2 Page 1 of 28 Report Dosimetric Assessment of the Victor Reader Stream from HumanWare (FCC ID: XT5503VRC) (IC: 8670A-503VRC) According to the FCC Requirements May 06, 2013 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Customer HumanWare 445, Rue Du Parc-Industriel Longueuil, (Quebec) Canada J4H 3V7 This revised version supersede all previous versions of the report The test results only relate to the items tested. This report shall not be reproduced except in full without the written approval of the testing laboratory. Dasy_Report_ FCC_Body_Card_850_1900_WCDMA II_WCDMA V_1.4.doc/20.06.2008/ABo SAR_Report_Nemko_60320_6130012_FCC_Body_2.4GHz_VictorReader_2 Page 2 of 28 Dasy_Report_ FCC_Body_Card_850_1900_WCDMA II_WCDMA V_1.4.doc/20.06.2008/ABo Executive Summary The device Victor Reader Stream is a new handheld media player from HumanWare operating in the 2450 MHz frequency range. The device has an integrated antenna and the system concepts used are the IEEE 802.11 b/g/n standards. There is no simultaneous transmission mode available. The objective of the measurements done by IMST was the dosimetric assessment of one device in body worn configuration in the IEEE 802.11 b/g/n standards. Since there was a special test software available, SAR tests in IEEE 802.11 b/g/n are conducted with a specific channel, bandwidth and maximum output power. The device was tested in two positions with the housing of the handheld in direct contact against the flat phantom. The examinations have been carried out with the dosimetric assessment system „DASY4“. The measurements were made according to the Supplement C to OET Bulletin 65 of the Federal Communications Commission (FCC) Guidelines [OET 65] for evaluating compliance of mobile and portable devices with FCC limits for human exposure (general population) to radiofrequency emissions and IC RSS 102 Issue 4. Additional information and guidelines given by the following FCC documents were used:  SAR Measurement Requirements for 100 MHz to 6 GHz [KDB 865664 D01 v01]  Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies [KDB 447498 D01 v05]  SAR Measurement Procedures for 802.11 a/b/g Transmitters KDB 248227 Rev. 1.2 All measurements have been performed in accordance to the recommendations given by SPEAG. SAR_Report_Nemko_60320_6130012_FCC_Body_2.4GHz_VictorReader_2 Page 3 of 28 Dasy_Report_ FCC_Body_Card_850_1900_WCDMA II_WCDMA V_1.4.doc/20.06.2008/ABo Compliance Statement The portable device Victor Reader Stream from HumanWare (FCC ID: XT5503VRC, IC: 8670A-503VRC) is in compliance with the IC RSS 102 Issue 4 [RSS 102] and Federal Communications Commission (FCC) Guidelines [OET 65] for uncontrolled exposure. SAR assessment in body worn was conducted with a distance of 0 mm between the housing of the device and the flat phantom. The maximum results of SAR for the Victor Reader Stream are as follows: Test Position Frequency Band Channel Position Highest Reported SAR 1g [W/kg] Body Worn IEEE 802.11 b 1 1 (Fig. 10) 0.749 prepared by: .............................................. reviewed by: .............................................. Alexander Rahn André van den Bosch test engineer quality assurance engineer SAR_Report_Nemko_60320_6130012_FCC_Body_2.4GHz_VictorReader_2 Page 4 of 28 Dasy_Report_ FCC_Body_Card_850_1900_WCDMA II_WCDMA V_1.4.doc/20.06.2008/ABo Table of Contents 1 SUBJECT OF INVESTIGATION .......................................................................................................... 5 2 THE IEEE STANDARD C95.1 AND THE FCC EXPOSURE CRITERIA ............................................. 5 2.1 DISTINCTION BETWEEN EXPOSED POPULATION, DURATION OF EXPOSURE AND FREQUENCIES ........... 6 2.2 DISTINCTION BETWEEN MAXIMUM PERMISSIBLE EXPOSURE AND SAR LIMITS .................................... 6 2.3 GENERAL SAR LIMIT ...................................................................................................................... 7 3 THE FCC MEASUREMENT PROCEDURE ......................................................................................... 7 3.1 GENERAL REQUIREMENTS .............................................................................................................. 7 3.2 TESTS IN BODY WORN CONFIGURATION ACCORDING KDB 447498 .................................................. 7 3.3 ADDITIONAL INFORMATION FOR 802.11 A/B/G TRANSMITTERS ACCORDING KDB 248227 ................... 8 4 THE MEASUREMENT SYSTEM .......................................................................................................... 9 4.1 PHANTOM .................................................................................................................................... 10 4.2 PROBE ......................................................................................................................................... 11 4.3 MEASUREMENT PROCEDURE ........................................................................................................ 12 4.4 UNCERTAINTY ASSESSMENT ......................................................................................................... 13 5 OUTPUT POWER VALUES ............................................................................................................... 14 5.1 TUNE-UP INFORMATION ................................................................................................................ 14 6 SAR TEST RESULTS ........................................................................................................................ 15 7 EVALUATION ..........................................................................................…

Text truncated - open the document above for the full version.

SAR_Report_Nemko_60320_6130012_FCC_Body_2.4GHz_Plots_VictorReader Page 1 of 7 The Testcenter facility ‘Dosimetric Test Lab’ within IMST GmbH is accredited by the German National ‘Deutsche Akkreditierungsstelle GmbH (DAkkS)’ for testing according to the scope as listed in the accreditation certificate: D-PL-12139-01-01. Appendix for the Report Dosimetric Assessment of the Victor Reader Stream from HumanWare (FCC ID: XT5503VRC) (IC: 8670A-503VRC) According to the FCC Requirements SAR Distribution Plots May 06, 2013 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Customer HumanWare 445, Rue Du Parc-Industriel Longueuil, (Quebec) Canada J4H 3V7 The test results only relate to the items tested. This report shall not be reproduced except in full without the written approval of the testing laboratory. Dasy_Report_FCC_DECT_1900_1.1.doc/22.05.2006/CH SAR_Report_Nemko_60320_6130012_FCC_Body_2.4GHz_Plots_VictorReader Page 2 of 7 dasy_report_fcc_DECT_1900_plots_1.0.doc/110.05.2006/ABo Table of Contents 1 SAR DISTRIBUTION PLOTS, BODY WORN, IEEE 802.11B .................................................................. 3 2 SAR Z-AXIS SCANS (VALIDATION) ........................................................................................................... 7 3 SAR Z-AXIS SCANS (MEASUREMENTS) .................................................................................................. 7 SAR_Report_Nemko_60320_6130012_FCC_Body_2.4GHz_Plots_VictorReader Page 3 of 7 dasy_report_fcc_DECT_1900_plots_1.0.doc/110.05.2006/ABo 1 SAR Distribution Plots, Body Worn, IEEE 802.11b Test Laboratory: Imst GmbH, DASY Yellow (II); File Name: Stream_5_ywhm_1_CH6_b.da4 DUT: Humanware; Type: Stream; Serial: 5 Program Name: IEEE 802.11 b Communication System: WLAN 2450; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2437 MHz; σ = 1.93 mho/m; ε r = 53.6; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: EX3DV4 - SN3536; ConvF(7.55, 7.55, 7.55); Calibrated: 24.09.2012 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn631; Calibrated: 20.09.2012 - Phantom: SAM Glycol 1340; Type: QD 000 P40 CB; Serial: TP-1340 - Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Body Worn/Area Scan (10x13x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (measured) = 0.377 mW/g Body Worn/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 3.77 V/m; Power Drift = -0.091 dB Peak SAR (extrapolated) = 1.31 W/kg SAR(1 g) = 0.436 mW/g; SAR(10 g) = 0.163 mW/g Maximum value of SAR (measured) = 0.493 mW/g Fig. 1: SAR distribution for IEEE 802.11b, channel 6, position 1 (February 18, 2013; Ambient Temperature: 21.8 °C; Liquid Temperature: 21.4 °C). SAR_Report_Nemko_60320_6130012_FCC_Body_2.4GHz_Plots_VictorReader Page 4 of 7 dasy_report_fcc_DECT_1900_plots_1.0.doc/110.05.2006/ABo Test Laboratory: Imst GmbH, DASY Yellow (II); File Name: Stream_5_ywhm_2_CH6_b.da4 DUT: Humanware; Type: Stream; Serial: 5 Program Name: IEEE 802.11 b Communication System: WLAN 2450; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2437 MHz; σ = 1.93 mho/m; ε r = 53.6; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: EX3DV4 - SN3536; ConvF(7.55, 7.55, 7.55); Calibrated: 24.09.2012 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn631; Calibrated: 20.09.2012 - Phantom: SAM Glycol 1340; Type: QD 000 P40 CB; Serial: TP-1340 - Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Body Worn/Area Scan (10x13x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (measured) = 0.072 mW/g Body Worn/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 1.89 V/m; Power Drift = 0.143 dB Peak SAR (extrapolated) = 0.156 W/kg SAR(1 g) = 0.070 mW/g; SAR(10 g) = 0.032 mW/g Maximum value of SAR (measured) = 0.078 mW/g Fig. 2: SAR distribution for IEEE 802.11b, channel 6, position 2 (February 18, 2013; Ambient Temperature: 21.8 °C; Liquid Temperature: 21.4 °C). SAR_Report_Nemko_60320_6130012_FCC_Body_2.4GHz_Plots_VictorReader Page 5 of 7 dasy_report_fcc_DECT_1900_plots_1.0.doc/110.05.2006/ABo Test Laboratory: Imst GmbH, DASY Yellow (II); File Name: Stream_5_ywhm_1_CH1_b.da4 DUT: Humanware; Type: Stream; Serial: 5 Program Name: IEEE 802.11 b Communication System: WLAN 2450; Frequency: 2412 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2412 MHz; σ = 1.9 mho/m; ε r = 53.4; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: EX3DV4 - SN3536; ConvF(7.55, 7.55, 7.55); Calibrated: 24.09.2012 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn631; Calibrated: 20.09.2012 - Phantom: SAM Glycol 1340; Type: QD 000 P40 CB; Serial: TP-1340 - Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Body Worn/Area Scan (10x13x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (measured) = 0.371 mW/g Body Worn/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 3.78 V/m; Power Drift = -0.015 dB Peak SAR (extrapolated) = 1.50 W/kg SAR(1 g) = 0.495 mW/g; SAR(10 g) = 0.185 mW/g Maximum value of SAR (measured) = 0.561 mW/g Fig. 3: SAR distribution for IEEE 802.11b, channel 1, position 1 (February 18, 2013; Ambient Temperature: 21.8 °C; Liquid Temperature: 21.4 °C). SAR_Report_Nemko_60320_6130012_FCC_Body_2.4GHz_Plots_VictorReader Page 6 of 7 dasy_report_fcc_DECT_1900_plots_1.0.doc/110.05.2006/ABo Test Laboratory: Imst GmbH, DASY Yellow (II); File Name: Stream_5_ywhm_1_CH11_b.da4 DUT: Humanware; Type: Stream; Serial: 5 Program Name: IEEE 802.11 b Communication System: WLAN 2450; Frequency: 2462 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2462 MHz; σ = 1.97 mho/m; ε r = 53.7; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: EX3DV4 - SN3536; ConvF(7.55, 7.55, 7.55); Calibrated: 24.09.2012 - Senso…

Text truncated - open the document above for the full version.

SAR_Report_Nemko_60320_6130012_FCC_VictorReaderCalData The Testcenter facility ‘Dosimetric Test Lab’ within IMST GmbH is accredited by the German National ‘Deutsche Akkreditierungsstelle GmbH (DAkkS)’ for testing according to the scope as listed in the accreditation certificate: D-PL-12139-01-01. Appendix for the Report Dosimetric Assessment of the Victor Reader Stream from HumanWare (FCC ID: XT5503VRC) (IC: 8670A-503VRC) According to the FCC Requirements Calibration Data May 06, 2013 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Customer HumanWare 445, Rue Du Parc-Industriel Longueuil, (Quebec) Canada J4H 3V7 The test results only relate to the items tested. This report shall not be reproduced except in full without the written approval of the testing laboratory. Dasy_Report_FCC_DECT_1900_1.1.doc/22.05.2006/CH The Testcenter facility ‘Dosimetric Test Lab’ within IMST GmbH is accredited by the German National ‘Deutsche Akkreditierungsstelle GmbH (DAkkS)’ for testing according to the scope as listed in the accreditation certificate: D-PL-12139-01-01. Cal_D2450V2_SN709_1211 Page 1 of 8 Calibration Certificate Certificate No: Cal_D2450V2_SN709_1211 Object: D2450V2 SN: 709 Date of Calibration: December 30, 2011 Next Calibration: December 2013 Object Condition: In Tolerance Calibration Equipment used: Test Equipment Serial Number Last calibration Calibrated by Next calibration Powermeter E4416A GB41050414 Nov 10 Rohde&Schwarz (200954-D-K-15012- 01-00-2010-11) Nov 12 Power Sensor E9301H US40010212 Nov 10 Rohde&Schwarz (200944-D-K-15012- 01-00-2010-11) Nov 12 Powermeter E4417A GB41050441 Nov 10 Rohde&Schwar…
