XYMPICO4A351WDCPico Base station

WiMAX RNU4000BS Base Station User Manual Doc: RNU4000BS_UM_V-03.1 Preface Material RNU4000BS User Manual II Runcom Technologies Ltd. About this Guide This User Manual describes the procedures for commissioning, mounting, installing and managing the RNU4000BS Base Station. Notice This document contains proprietary and confidential material of Runcom Ltd. Any unauthorized reproduction, use or disclosure of this material, or any part thereof, is strictly prohibited. This document is solely for the use of Runcom Ltd. employees and authorized Runcom Ltd. customers. The material furnished in this document is believed to be accurate and reliable. However, no responsibility is assumed by Runcom Ltd. for the use of this material. Runcom Ltd. reserves the right to make changes to the material at any time and without notice. All other trademarks are the property of their respective owners. Other company and brand products and service names are trademarks or registered trademarks of their respective holders. Safety Precautions To avoid injury and to prevent equipment damage, observe the safety precautions below.  Only qualified personnel should be allowed to install, replace, and service the equipment. The device cannot be sold retail, to the general public or by mail order. It must be sold to dealers. Installation must be controlled. Installation must be performed by licensed professionals. Installation requires special training. The Runcom radios and antennas should be installed ONLY by experienced installation professionals who are familiar with local building and safety codes and, wherever applicable, are licensed by the appropriate government regulatory authorities. Failure to do so may void product warranty and may expose the end user or the service provider to legal and financial liabilities.  Always observe standard safety precautions during installation, operation and maintenance of this product.  This equipment must be installed according to country national electrical codes.  Any changes and modifications to the device and the accessories must be approved by Runcom.  All equipment and accessories must be installed in a restricted access area.  Observe all the labels on the equipment, providing operation details and warnings.  Read and follow the installation instructions provided in this manual.  The outdoor base station should be positioned more than 2 meters from humans.  In case of using cables that are not provided with the equipment package, ensure these cables comply with the regulatory inspection authorities and are the responsibility of the customer.  Do not move or ship equipment unless it is properly packed in its original wrapping and shipping containers. Electrical Shock Prevention  When connecting equipment to the AC and DC voltage supplies, ensure proper polarity.  Disconnect the power source before installing or maintaining the power wiring. RNU4000BS User Manual Preface Material Runcom Technologies Ltd. L III  Do not operate the equipment if there is any failure or damage to electrical components.  Do not touch exposed connections, components or wiring when power is on.  Install the equipment and the grounded DC supply circuits in adjacent cabinets.  Protect the DC power source with an adjacent circuit breaker.  The equipment must be properly grounded before attempting to operate or perform any repairs. RF Exposure To avoid RF exposure - Installation of antennas must comply with the FCC RF exposure requirements. Radio Interference This equipment generates and radiates radio frequency energy and if not installed and used in accordance with the instruction manual, may cause interference to radio communications. To avoid interferences:  Avoid conjunction with any other antenna or transmitter.  In case of Radio Interference: Relocate the antenna and Increase separation between the equipment and the receiver (e.g. connect to a separate circuit or outlet).  When using an external antenna, the external antenna must not be co-located or operating in conjunction with any other antenna or transmitter NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. RNU4000BS User Manual Table of Contents Runcom Technologies Ltd. V Table of Contents 1 Introducing the RNU4000BS BS ....................................................................................... 1 1.1 Coverage Configurations .............................................................................................................. 3 1.2 RNU4000BS Interfaces and Accessories ......................................................................................... 5 1.2.1 GPS, Power and Communication Interfaces .......................................................................... 5 1.2.2 BS RF Antenna Interfaces ................................................................................................... 6 1.3 Supported Antennas ...................................................................…

Text truncated - open the document above for the full version.

WiMAX RNU4000BS Base Station User Manual Doc: Runcom RNU4000BS User Manual RN-PMG-041112 V-3.4 Preface Material RNU4000BS User Manual II Runcom Technologies Ltd. About this Guide This User Manual describes the procedures for commissioning, mounting, installing and managing the RNU4000BS Base Station. Notice This document contains proprietary and confidential material of Runcom Ltd. Any unauthorized reproduction, use or disclosure of this material, or any part thereof, is strictly prohibited. This document is solely for the use of Runcom Ltd. employees and authorized Runcom Ltd. customers. The material furnished in this document is believed to be accurate and reliable. However, no responsibility is assumed by Runcom Ltd. for the use of this material. Runcom Ltd. reserves the right to make changes to the material at any time and without notice. All other trademarks are the property of their respective owners. Other company and brand products and service names are trademarks or registered trademarks of their respective holders. Safety Precautions To avoid injury and to prevent equipment damage, observe the safety precautions below. • Only qualified personnel should be allowed to install, replace, and service the equipment. The device cannot be sold retail, to the general public or by mail order. It must be sold to dealers. Installation must be controlled. Installation must be performed by licensed professionals. Installation requires special training. The Runcom radios and antennas should be installed ONLY by experienced installation professionals who are familiar with local building and safety codes and, wherever applicable, are licensed by the appropriate government regulatory authorities. Failure to do so may void product warranty and may expose the end user or the service provider to legal and financial liabilities. • Always observe standard safety precautions during installation, operation and maintenance of this product. • This equipment must be installed according to country national electrical codes. • Any changes and modifications to the device and the accessories must be approved by Runcom. • All equipment and accessories must be installed in a restricted access area. • Observe all the labels on the equipment, providing operation details and warnings. • Read and follow the installation instructions provided in this manual. • The outdoor base station should be positioned more than 2 meters from humans. • In case of using cables that are not provided with the equipment package, ensure these cables comply with the regulatory inspection authorities and are the responsibility of the customer. • Do not move or ship equipment unless it is properly packed in its original wrapping and shipping containers. Electrical Shock Prevention • When connecting equipment to the AC and DC voltage supplies, ensure proper polarity. • Disconnect the power source before installing or maintaining the power wiring. • Do not operate the equipment if there is any failure or damage to electrical components. • Do not touch exposed connections, components or wiring when power is on. RNU4000BS User Manual Preface Material Runcom Technologies Ltd. L III • Install the equipment and the grounded DC supply circuits in adjacent cabinets. • Protect the DC power source with an adjacent circuit breaker. • The equipment must be properly grounded before attempting to operate or perform any repairs. RF Exposure To avoid RF exposure - Installation of antennas must comply with the FCC RF exposure requirements. Radio Interference This equipment generates and radiates radio frequency energy and if not installed and used in accordance with the instruction manual, may cause interference to radio communications. To avoid interferences: • Avoid conjunction with any other antenna or transmitter. • In case of Radio Interference: Relocate the antenna and Increase separation between the equipment and the receiver (e.g. connect to a separate circuit or outlet). • When using an external antenna, the external antenna must not be co-located or operating in conjunction with any other antenna or transmitter NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. Note: Contention Based Protocol (CBP) MUST be activated for the specified band (3.675-3.700GHz) wherever FCC rules and regulations are enforced. Failure to comply makes the operation of this device illegal. RNU4000BS User Manual Table of Contents Runcom Technologies Ltd. V Table of Contents 1 Introducing the RNU4000BS BS ....................................................................................... 1 1.1 Coverage Configurations ..............................................................................................................3 1.2 RNU4000BS Interfaces and Accessories.........................................................................................5 1.2.1 GPS, Power and Communication Interfaces....................................................................…

Text truncated - open the document above for the full version.

05/03/2012 1 552295 D01 CBT Guidance for 3650 3700 Band v01r01 Guidance regarding contention based protocol for devices operating in the 3650-3700 MHz Band under Part 90Z Document Overview This document identifies several questions / information to help determine the contention based protocol capability of a device that may operate in the 3650 – 3700 MHz under part 90Z of our rules. These questions are intended to be used as a guide by the applicant to describe how their system meets the requirements for 3650-3700 contention based protocol. The list is not intended to be exhaustive and may be modified in the future. There may be follow-up questions based on the responses provide by the applicant for authorization. Applicants seeking certification for systems as complying with restricted contention based protocol (3650 to 3675 MHz) that permit operation on a co-channel with like systems (similar systems) may seek equipment authorization from a Telecommunications Certification Body (TCB) using the Permit but Ask procedure as described in Section 3 . Applicants seeki ng certification for systems as complying with the unrestricted contention based protocol for operation in the 3650 to 3700MHz band that permit operation on a co-channel with similar or different systems (recognizing other systems) must apply to the FCC for equipment authorization. 1. Restricted Certification under Part 90Z (3650-3675 Band) In order to ensure that a device complies with the requirements of restricted contention based protocol, the following information should be provided in the application. 1.1. Restricted Protocol Description 1.1.1. Although the restricted protocol does not have the extended requirement to recognize all other systems it is still mandatory to incorporate a contention based protocol that provides satisfactory sharing of spectrum with similar systems. 1.1.2. Address the key requirements for operation using restricted contention based protocol opportunities for other transmitters to operate. Please note that this requires recognizing like systems (similar to yours) that permit operation on a co-channel. 1.1.3. Provide any additional manuals and operational descriptions to allow the reviewer to understand the product and its operation. 1.2. Describe the method to permit occupancy 1.3. Describe the action taken if two or more transmitters simultaneously access the same channel by the master and the client devices. 1.4. Describe opportunities for other similar systems to operate. Address how or if a different system operator using the same technology can operate in the same band. 05/03/2012 2 552295 D01 CBT Guidance for 3650 3700 Band v01r01 2. Unrestricted Certification under Part 90Z (3650-3700 Band) In order to ensure that a device complies with the requirements of unrestricted contention based protocol, the following information should be provided in the application. 2.1. Unrestricted Protocol Description Address the key requirements for operation using unrestricted contention based protocol. Please note that this requires recognizing other systems (both similar to yours and different from yours) that operate on a co-channel. Indicate the strategy for sharing the spectrum in terms of: Does the system use spectrum sensing to determine if the other devices are transmitting and then find ways to share the bandwidth, or Have some other strategy? 2.2. Threshold detection to determine occupancy 2.2.1. Describe how your system determines if another system is using the spectrum. At what detection level – relative to 0 dBi receive antenna gain (busy channel threshold) does the device determine if another system is operating on the spectrum? Answer: One of the important parameters, the WiMax TDD system measures, is the environment noise level. The Base Station (BST - the master) is measuring the noise level in the initialization phase (before the start of any transmission). It also measures the noise level, every configured frame number, during operational time. The system can operate in 10MHz BW or 5MHz BW. Based on 10MHz BW, the noise level with no interferences is detected. If no interference, the noise level will be -98dBm (10MHz BW assuming 0dBi receive antenna gain). If there is interference the noise level is increased, accordingly, and determines that another system is operating on the same frequency spectrum. 2.2.2. How long does the system observe to determine if the channel is busy – at the initial time and in between communications? Answer: The observation time is taken in the initialization processes, right after power on (before starting to transmit), during 500msec, and after that during the normal operation in frames that are not occupied by users (clients) or by measuring the noise by reading the S/N from the users. 2.2.3. What is the bandwidth being monitored versus bandwidth occupied for all modes of operation? Answer: The BW being monitored is according to the operational BW. In case of 10MHz operation the BW being monitored is 10MHz. 2.2.4. How much variability is provided to the system operator to adjust busy channel detection threshold? Answer: The detection threshold is detected and monitored in the BST and the user. The threshold in which actions are taken is configurable. 2.2.5. What is the operating system threshold (receive threshold) compared to the monitoring threshold (busy channel threshold)? Answer: Operating system threshold (Receive threshold) and busy channel threshold are configurable. Usually the figures are: Receive threshold: At noise lower than -92dBm Busy channel threshold: At noise higher than -92dBm 2.2.6. What additional checks does the system perform to determine if the spectrum is being used before initiating a transmission? Answer: Beside the noise measuring, during initialization, the BST is measuring the noise in normal operation as well by "looking" on clear frames (when no user is transmitting by analyzing its S/N). 2.2.7. Do the master and the client per…

Text truncated - open the document above for the full version.

Page 1 of 1 23-Aug-2012 Statement FCC ID:XYMPICO4A351WDC DC voltages/currents supplied to elements of the final radio frequency amplifying device MicroMobio P/N MMPA573LA for normal operation over the power range: Vdc=5V and Idc=1.7A. Sincerely, Yonatan Zvi Hardware Team Manager Runcom Technologies Ltd.

10/14/2012 1 552295 D01 CBT Guidance for 3650 3700 Band v01r01 Guidance regarding contention based protocol for devices operating in the 3650-3700 MHz Band under Part 90Z Document Overview This document identifies several questions / information to help determine the contention based protocol capability of a device that may operate in the 3650 – 3700 MHz under part 90Z of our rules. These questions are intended to be used as a guide by the applicant to describe how their system meets the requirements for 3650-3700 contention based protocol. The list is not intended to be exhaustive and may be modified in the future. There may be follow-up questions based on the responses provide by the applicant for authorization. Applicants seeking certification for systems as complying with restricted contention based protocol (3650 to 3675 MHz) that permit operation on a co-channel with like systems (similar systems) may seek equipment authorization from a Telecommunications Certification Body (TCB) using the Permit but Ask procedure as described in Section 3 . Applicants seeking certification for systems as complying with the unrestricted contention based protocol for operation in the 3650 to 3700MHz band that permit operation on a co-channel with similar or different systems (recognizing other systems) must apply to the FCC for equipment authorization. 1. Restricted Certification under Part 90Z (3650-3675 Band) In order to ensure that a device complies with the requirements of restricted contention based protocol, the following information should be provided in the application. 1.1. Restricted Protocol Description 1.1.1. Although the restricted protocol does not have the extended requirement to recognize all other systems it is still mandatory to incorporate a contention based protocol that provides satisfactory sharing of spectrum with similar systems. 1.1.2. Address the key requirements for operation using restricted contention based protocol opportunities for other transmitters to operate. Please note that this requires recognizing like systems (similar to yours) that permit operation on a co-channel. 1.1.3. Provide any additional manuals and operational descriptions to allow the reviewer to understand the product and its operation. 1.2. Describe the method to permit occupancy 1.3. Describe the action taken if two or more transmitters simultaneously access the same channel by the master and the client devices. 1.4. Describe opportunities for other similar systems to operate. Address how or if a different system operator using the same technology can operate in the same band. 10/14/2012 2 552295 D01 CBT Guidance for 3650 3700 Band v01r01 2. Unrestricted Certification under Part 90Z (3650-3700 Band) In order to ensure that a device complies with the requirements of unrestricted contention based protocol, the following information should be provided in the application. 2.1. Unrestricted Protocol Description Address the key requirements for operation using unrestricted contention based protocol. Please note that this requires recognizing other systems (both similar to yours and different from yours) that operate on a co-channel. Indicate the strategy for sharing the spectrum in terms of: Does the system use spectrum sensing to determine if the other devices are transmitting and then find ways to share the bandwidth, or Have some other strategy? 2.2. Threshold detection to determine occupancy 2.2.1. Describe how your system determines if another system is using the spectrum. At what detection level – relative to 0 dBi receive antenna gain (busy channel threshold) does the device determine if another system is operating on the spectrum? Answer:
One of the important parameters, the WiMax TDD (Time-Division Duplex) system measures, is the environment noise level. The Base Station (BST - the master) is measuring the noise level in the initialization phase (before the start of any transmission). It also measures the noise level, every configured frame number, during operational time.
The system can operate in 10MHz BW (bandwidth) or 5MHz BW. Based on 10MHz BW, the noise level with no interferences is detected. If no interference, the noise level will be below -92dBm (10MHz BW assuming 0dBi receive antenna gain). If there is interference the noise level is increased above -92dBm and determines that another system is operating on the same frequency spectrum.
In addition the system provides opportunity to other systems, by freeing the current frequency, every configured number of frames (default=200 frames=1sec) for configured number of frames (default=200) 2.2.2. How long does the system observe to determine if the channel is busy – at the initial time and in between communications? Answer:
The observation time is taken in the initialization processes, right after power on (before starting to transmit), during 500msec.
Also observation is made during normal operation, in frames/slots that are not occupied by users (clients). The base-station take care that there will be free slots, for observation. 2.2.3. What is the bandwidth being monitored versus bandwidth occupied for all modes of operation? Answer :
The BW being monitored is according to the operational BW. In case of 10MHz operation the BW being monitored is 10MHz . 2.2.4. How much variability is provided to the system operator to adjust busy channel detection threshold? Answer:
The default value of the threshold, to define busy channel, is -92dBm. The configuration range is between -62dBm to -92dBm. 10/14/2012 3 552295 D01 CBT Guidance for 3650 3700 Band v01r01 2.2.5. What is the operating system threshold (receive threshold) compared to the monitoring threshold (busy channel threshold)? Answer:
Operating system threshold (Receive threshold) and busy channel threshold are configurable. The range is -88dBm to -97dBm. Default thresholds, are: o Receive threshold: lower than -92dBm o Busy channel threshold: higher or equal to -92dBm 2.2.6…

Text truncated - open the document above for the full version.

Contention Based Protocol – Runcom Reply 31-Oct-12 Runcom Technologies Ltd. 1 Guidance regarding contention based protocol for devices operating in the 3650-3700 MHz Band under Part 90Z FCC ID: XYMPICO4A351WDC Document Overview This document identifies several questions / information to help determine the contention based protocol capability of a device that may operate in the 3650 – 3700 MHz under part 90Z of our rules. These questions are intended to be used as a guide by the applicant to describe how their system meets the requirements for 3650-3700 contention based protocol. The list is not intended to be exhaustive and may be modified in the future. There may be follow-up questions based on the responses provide by the applicant for authorization. Applicants seeking certification for systems as complying with restricted contention based protocol (3650 to 3675 MHz) that permit operation on a co-channel with like systems (similar systems) may seek equipment authorization from a Telecommunications Certification Body (TCB) using the Permit but Ask procedure as described in Section 3 . Applicants seeking certification for systems as complying with the unrestricted contention based protocol for operation in the 3650 to 3700MHz band that permit operation on a co-channel with similar or different systems (recognizing other systems) must apply to the FCC for equipment authorization. This Contention Based Protocol (CBP) description is for the base station operating in the unrestricted band. 1. Restricted Certification under Part 90Z (3650-3675 Band) – Not applicable In order to ensure that a device complies with the requirements of restricted contention based protocol, the following information should be provided in the application. 1.1. Restricted Protocol Description 1.1.1. Although the restricted protocol does not have the extended requirement to recognize all other systems it is still mandatory to incorporate a contention based protocol that provides satisfactory sharing of spectrum with similar systems. 1.1.2. Address the key requirements for operation using restricted contention based protocol opportunities for other transmitters to operate. Please note that this requires recognizing like systems (similar to yours) that permit operation on a co-channel. 1.1.3. Provide any additional manuals and operational descriptions to allow the reviewer to understand the product and its operation. 1.2. Describe the method to permit occupancy 1.3. Describe the action taken if two or more transmitters simultaneously access the same channel by the master and the client devices. 1.4. Describe opportunities for other similar systems to operate. Address how or if a different system operator using the same technology can operate in the same band. 31-Oct-12 Contention Based Protocol – Runcom Reply 2 Runcom Technologies Ltd. 2. Unrestricted Certification under Part 90Z (3650-3700 Band) In order to ensure that a device complies with the requirements of unrestricted contention based protocol, the following information should be provided in the application. 2.1. Unrestricted Protocol Description Address the key requirements for operation using unrestricted contention based protocol. Please note that this requires recognizing other systems (both similar to yours and different from yours) that operate on a co-channel. Indicate the strategy for sharing the spectrum in terms of: Does the system use spectrum sensing to determine if the other devices are transmitting and then find ways to share the bandwidth, or Have some other strategy? 2.2. Threshold detection to determine occupancy 2.2.1. Describe how your system determines if another system is using the spectrum. At what detection level – relative to 0 dBi receive antenna gain (busy channel threshold) does the device determine if another system is operating on the spectrum? Answer:
One of the important parameters, the WiMax TDD (Time-Division Duplex) system measures, is the environment noise level. The Base Station (BST - the master) is measuring the noise level in the initialization phase (before the start of any transmission). It also measures the noise level, every configured frame number, during operational time.
The system can operate in 10MHz BW (bandwidth) or 5MHz BW. Based on 10MHz BW, the noise level with no interferences is detected. If no interference, the noise level will be below -92dBm (10MHz BW assuming 0dBi receive antenna gain). If there is interference the noise level is increased above -92dBm and determines that another system is operating on the same frequency spectrum.
In addition the system provides opportunity to other systems, by freeing the current frequency, every configured number of frames (default=200 frames=1sec) for configured number of frames (default=200) 2.2.2. How long does the system observe to determine if the channel is busy – at the initial time and in between communications? Answer:
The observation time is taken in the initialization processes, right after power on (before starting to transmit), during 500msec.
Also observation is made during normal operation, in frames/slots that are not occupied by users (clients). The base-station take care that there will be free slots, for observation. 2.2.3. What is the bandwidth being monitored versus bandwidth occupied for all modes of operation? Answer :
The BW being monitored is according to the operational BW. In case of 10MHz operation the BW being monitored is 10MHz . 2.2.4. How much variability is provided to the system operator to adjust busy channel detection threshold? Answer:
The default value of the threshold, to define busy channel, is -92dBm. The configurati…
