XYN2761RF Remote Control

ruwido austria gmbh . Köstendorfer Str. 8 . Austria . t +43 6216 4571-0 . www.ruwido.com Page 1 of 5 This document is intellectual property of ruwido austria gmbh and contains confidential information. Reproduction, modification,. communication to third parties and any other use is strictly prohibited without prior written accordance of ruwido austria. © 2013. Revision Status Version Creation Date Author Remarks V0.1 08 June 2013 Ralph Leblhuber rf ruwido remote control and rf2ir dongle user guide DRAFT ruwido austria gmbh ruwido_r97_rf_quick_user_guide_v0.1-08june13-DRAFT Page 2 of 5 This document is intellectual property of ruwido austria gmbh and contains confidential information. Reproduction, modification,. communication to third parties and any other use is strictly prohibited without prior written accordance of ruwido austria. © 2013 user operating instructions for rf remote control and rf2ir dongle 1. Pairing of rf2ir dongle and remote control (1) rf2ir dongle Press “play/pause” and “ok” keys simultaneously for 5 seconds – red STB LED will flash. Plug in the rf2ir dongle (1) to an available USB port of your Set Top Box (2) within 30 seconds. Once paired the red LED will flash twice quickly and then stop. The remote control and the dongle are paired. The correct function can be verified by pressing any key – red STB LED will flash once. In case pairing failed no LED will flash when pressing a key. In this case the above procedure should be repeated. (2) rf remote control ruwido austria gmbh ruwido_r97_rf_quick_user_guide_v0.1-08june13-DRAFT Page 3 of 5 This document is intellectual property of ruwido austria gmbh and contains confidential information. Reproduction, modification,. communication to third parties and any other use is strictly prohibited without prior written accordance of ruwido austria. © 2013 2. Programming your TV Before you start to program your remote control, make sure your TV and set top box are switched on. Preparation: To speed up your programming process, the most used TV brands have 4- digit code that will be used in the programming process. Search for the 4-digit code of your TV brand. In case your TV brand is not listed please use code 0 0 0 1 to search for all brands. Please note that the search can take up to 15 minutes in that case. TV Brand List 0001 search for all brands 0010 Insignia 0017 LG 0011 Vizio 0018 Toshiba 0012 RCA 0019 Sony 0013 Sanyo 0020 Samsung 0014 Panasonic 0021 Philips 0015 Funai/Emerson 0022 Fluid 0016 Sharp Brand Search Press and hold options key for 3 seconds, until the green LED flashes twice. Enter the 4-digit code for the brand of your TV (see table above) within 10 seconds – the green LED flashes twice. Now, press and hold the power key until your TV switches off. As soon as your TV switches off, remove your finger from the power key and press select key to confirm – the green LED will flash twice. Now press the power key again to switch your TV back on. Now you can turn your TV and your set top box on/off simultaneously by pressing the power key; volume (vol+, vol-) and mute function will be controlled via the TV. After first set up make sure that the set top box and TV are both powered on. In case an invalid code has been entered the green LED will light up for 2 seconds. If no key code is being entered within 10 seconds the remote will time out and the programming procedure needs to be started again. ruwido austria gmbh ruwido_r97_rf_quick_user_guide_v0.1-08june13-DRAFT Page 4 of 5 This document is intellectual property of ruwido austria gmbh and contains confidential information. Reproduction, modification,. communication to third parties and any other use is strictly prohibited without prior written accordance of ruwido austria. © 2013 Notes:
factory default setting: no TV is programmed
once TV is programmed, volume (vol+, vol- and mute) will be controlled via the TV
for STB commands the LED will flash red, for TV commands LED will flash green (only if TV set has been programmed)
TV programming will remain if batteries are being removed / changed ruwido austria gmbh ruwido_r97_rf_quick_user_guide_v0.1-08june13-DRAFT Page 5 of 5 This document is intellectual property of ruwido austria gmbh and contains confidential information. Reproduction, modification,. communication to third parties and any other use is strictly prohibited without prior written accordance of ruwido austria. © 2013 DECLARATION User Information FCC 15.2: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Part 15 Statement. FCC 15.19/RSS Gen Issue 3 Sect. 7.1.3 This device complies with Part 15 of the FCC Rules and with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Statement Class B Digital Device FCC 15.105: NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this…

Text truncated - open the document above for the full version.

mikes-testingpartners gmbh File No. T36953-00-00HS, page 1 of 3 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.: +49(0)9424-94810  Fax: +49(0)9424-9481240 Rev. No. 1.2, 2013-04-04 EMI − T E S T R E P O R T Attachment A to Test Report No. : T36953-00-00HS 15. July 2013 ______________________________________________________________________________________________ Date of issue Type / Model Name : 2761 Product Description : Remote control Applicant : ruwido austria gmbh Address : Koestendorfer Str. 8 5202 NEUMARKT, AUSTRIA Manufacturer : ruwido austria gmbh Address : Koestendorfer Str. 8 5202 NEUMARKT, AUSTRIA Licence holder : ruwido austria gmbh Address : Koestendorfer Str. 8 5202 NEUMARKT, AUSTRIA The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test results without the written permission of the test laboratory. mikes-testingpartners gmbh File No. T36953-00-00HS, page 2 of 3 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.: +49(0)9424-94810  Fax: +49(0)9424-9481240 Rev. No. 1.2, 2013-04-04 Contents 1 P h o t o d o c u m e n t a t i o n o f t h e E U T 3 1.1 External view: 3 1.2 Internal views Fehler! Textmarke nicht definiert. 1.3 Antenna structure: Fehler! Textmarke nicht definiert. mikes-testingpartners gmbh File No. T36953-00-00HS, page 3 of 3 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.: +49(0)9424-94810  Fax: +49(0)9424-9481240 Rev. No. 1.2, 2013-04-04 1 P h o t o d o c u m e n t a t i o n o f t h e E U T 1.1 External view: Top view Bottom view

Christa Jäger Project Specialist - Global Market Access (GMA) / Certification mikes-testingpartners gmbh 94342 Strasskirchen Germany FCC ID no. X YN2761 for remote control Dear Sirs, O ur customer has decided to not put the FCC ID on the outside of the device. It will be placed inside the battery compartment in accordance to the FCC requirements. Please see our explanation below: A s an option to placing the FCC label on the exterior of the device, the FCC label may be placed in a user accessible area if the following conditions are met: • The device is handheld (notebook computers are considered as handheld); The device is handheld. • The FCC identifier is visible at the time of purchase. Marketing the device without the battery installed when the label is in the battery compartment is acceptable. The FCC ID on the box, or additional documentation directing the user where to find the FCC label, also satisfies this requirement; The FCC ID, IC certification number and model number are inside the battery compartment and the battery is not installed when the device is marketed. Additionally, the user manual directs the user where to find the FCC ID, IC certification number and model number within the battery compartment. • The user accessible area must not require any special tools for access, and the FCC label must not be placed on a removable part; The battery compartment does not require special tools. The FCC ID, IC certification number and model number are not on a removable part. • The FCC ID, Model Number, or FCC logo must be on the label and must meet all general labelling requirements or policies that apply for Certification, Verification or DoC. The FCC ID, IC certification number and model number do meet the applicable labelling requirements. B est regards, Rafael Jaburek Head of Quality ruwido austria gmbh Köstendorfer Straße 8 5202 Neumarkt a. W. Austria

mikes-testingpartners gmbh File No. T36953-00-00HS, page 1 of 4 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.: +49(0)9424-94810  Fax: +49(0)9424-9481240 Rev. No. 1.2, 2013-04-04 EMI − T E S T R E P O R T Attachment A to Test Report No. : T36953-00-00HS 15. July 2013 ______________________________________________________________________________________________ Date of issue Type / Model Name : 2761 Product Description : Remote control Applicant : ruwido austria gmbh Address : Koestendorfer Str. 8 5202 NEUMARKT, AUSTRIA Manufacturer : ruwido austria gmbh Address : Koestendorfer Str. 8 5202 NEUMARKT, AUSTRIA Licence holder : ruwido austria gmbh Address : Koestendorfer Str. 8 5202 NEUMARKT, AUSTRIA The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test results without the written permission of the test laboratory. mikes-testingpartners gmbh File No. T36953-00-00HS, page 2 of 4 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.: +49(0)9424-94810  Fax: +49(0)9424-9481240 Rev. No. 1.2, 2013-04-04 Contents 1 P h o t o d o c u m e n t a t i o n o f t h e E U T 3 1.1 External view: 3 1.2 Internal views 3 1.3 Antenna structure: 4 mikes-testingpartners gmbh File No. T36953-00-00HS, page 3 of 4 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.: +49(0)9424-94810  Fax: +49(0)9424-9481240 Rev. No. 1.2, 2013-04-04 1 P h o t o d o c u m e n t a t i o n o f t h e E U T 1.1 External view: Top view Bottom view 1.2 Internal views Bottom view : mikes-testingpartners gmbh File No. T36953-00-00HS, page 4 of 4 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.: +49(0)9424-94810  Fax: +49(0)9424-9481240 Rev. No. 1.2, 2013-04-04 1.3 Antenna structure:

FCC ID: XYN2761 IC ID: 8748A-2761 mikes-testingpartners gmbh File No. T36953-00-00HS, page 1 of 26 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.3, 2013-04-04 EMI − T E S T R E P O R T - FCC Part 15.249, RSS210 - Test Report No. : T36953-00-00HS 26. July 2013 ______________________________________________________________________________________________ Date of issue Type / Model Name : 2761 Product Description : Remote control Applicant : ruwido austria gmbh Address : Koestendorfer Str. 8 5202 NEUMARKT, AUSTRIA Manufacturer : ruwido austria gmbh Address : Koestendorfer Str. 8 5202 NEUMARKT, AUSTRIA Licence holder : ruwido austria gmbh Address : Koestendorfer Str. 8 5202 NEUMARKT, AUSTRIA Test Result according to the standards listed in clause 1 test standards: POSITIVE The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test results without the written permission of the test laboratory. FCC ID: XYN2761 IC ID: 8748A-2761 mikes-testingpartners gmbh File No. T36953-00-00HS, page 2 of 26 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.3, 2013-04-04 Contents 1 T E S T S T A N D A R D S 3 2 S U M M A R Y 4 2.1 GENERAL REMARKS: 4 2.2 Test result summery 5 2.3 FINAL ASSESSMENT: 5 3 E Q U I P M E N T U N D E R T E S T 6 3.1 Photo documentation of the EUT – Please see attachment A 6 3.2 Power supply system utilised 6 3.3 Short description of the equipment under test (EUT) 6 4 T E S T E N V I R O N M E N T 7 4.1 Address of the test laboratory 7 4.2 Environmental conditions 7 4.3 Statement of the measurement uncertainty 7 4.4 Measurement protocol for FCC and IC 8 4.5 Determination of worst case measurement conditions 8 5 T E S T C O N D I T I O N S A N D R E S U L T S 9 5.1 AC power line conducted emissions 9 5.2 Field strength of fundamental 9 5.3 Out-of-band emission, radiated 11 5.4 EBW and OBW 22 5.5 Correction for pulse operation (duty cycle) 25 5.6 Antenna application 25 6 U S E D T E S T E Q U I P M E N T A N D A C C E S S O R I E S 26 Attachment A see separate supplement FCC ID: XYN2761 IC ID: 8748A-2761 mikes-testingpartners gmbh File No. T36953-00-00HS, page 3 of 26 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.3, 2013-04-04 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules and Regulations Part 15, Subpart A - General (September, 2012) Part 15, Subpart A, Section 15.31 Measurement standards Part 15, Subpart A, Section 15.33 Frequency range of radiated measurements Part 15, Subpart A, Section 15.35 Measurement detector functions and bandwidths FCC Rules and Regulations Part 15, Subpart C - Intentional Radiators (September, 2012) Part 15, Subpart C, Section 15.203 Antenna requirement Part 15, Subpart C, Section 15.204 External radio frequency power amplifiers and antenna modifications Part 15, Subpart C, Section 15.205 Restricted bands of operation Part 15, Subpart C, Section 15.207 Conducted limits Part 15, Subpart C, Section 15.209 Radiated emission limits, general requirements Part 15, Subpart C, Section 15.249 Operation within the bands 902 - 928 MHz, 2400 - 2483.5 MHz, 5725 - 5875 MHz, and 24.0 - 24.25 GHz ANSI C63.4: 2003 Methods of Measurement of Radio-Noise Emissions from Low- Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. ANSI C95.1:2005 IEEE Standard for Safety Levels with respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz CISPR 16-4-2: 2003 Uncertainty in EMC measurement CISPR 22: 2005 Information technology equipment EN 55022: 2006 FCC ID: XYN2761 IC ID: 8748A-2761 mikes-testingpartners gmbh File No. T36953-00-00HS, page 4 of 26 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.3, 2013-04-04 2 S U M M A R Y 2.1 GENERAL REMARKS: The EUT is a 2.4 GHz – transceiver chip MCP24J40 for low power data transmission supporting 3 channels in the 2.4 GHz band. Due to integrated antenna all measurements are performed radiated. Variants of the EUT There are no variants. Antennas The following integrated antenna is used with the EUT: - Inverted F antenna (PCB) The antennas cannot be dispatched by the user. Operation frequency and channel plan The operating frequency is 2400 MHz to 2483.5 MHz. Channel Frequency (MHz) 1 2425 2 2450 3 2475 Transmit operating modes The EUT use OQPSK and provide following data rate: 250 kbps (kbps = kilobits per second) FCC ID: XYN2761 IC ID: 8748A-2761 mikes-testingpartners gmbh File No. T36953-00-00HS, page 5 of 26 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.3, 2013-04-04 2.2 Test result summery Operating in the 2400 MHz – 2483.5 MHz band: FCC Rule Part RSS Rule Part Description Result 15.35(c) RSS-Gen, 4.5 Pulsed operation passed 15.203 RSS Gen, 7.1.2 Antenna requirement passed 15.204 RSS Gen, 7.1.1 External radio frequency power amplifiers passed 15.205(a) RSS-Gen, 7.2.2 Emissions in restricted bands passed 15.207(a) RSS Gen, 7.2.4 AC power line conducted emissions passed 15.215(c) EBW passed RSS-Gen, 4.6.1 OBW passed 15.249(a) RSS-210, A2.9(a) Field strength of fundamental passed 15.249(d) RSS Gen, 7.2.5 Out-of-band emission, radiated passed RSS-Gen, 7.2.6 Transmitter frequency stability not applicable The mentioned RSS Rule Parts in the above table are related to: RSS Gen, Issue 3, December 2010 RSS 210, Issue 8, December 2010 RSS 102, Issue 4, March 2010 2.3 FINAL ASSESSMENT: The equipment under test fulfills the EMI requirements cited in clause 1 test standards. Date of receipt of test sample : acc. to storage records Testing commenced on : 28 June 2013 Testing concluded on : 08 July 2013 Checked by: Tested by: Klaus Gegenfurtner Dipl.-Ing.(FH) Manager: Radio Group Hermann Smetana Dipl.-Ing.(FH) Radio Senior Exper…

Text truncated - open the document above for the full version.

FCC ID: XYN2761 IC ID: 8748A-2761 mikes-testingpartners gmbh File No. T36953-00-00HS, page 9 of 25 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.3, 2013-04-04 5 T E S T C O N D I T I O N S A N D R E S U L T S 5.1 AC power line conducted emissions For test instruments and accessories used see section 6 Part A 4. 5.1.1 Description of the test location Test location: NONE Remarks: Not applicable the EUT is battery driven. 5.2 Field strength of fundamental For test instruments and accessories used see section 6 Part CPR 3. 5.2.1 Description of the test location Test location: Anechoic chamber 2 Test distance: 3 m 5.2.2 Photo documentation of the test set-up 5.2.1 Applicable standard According to FCC Part 15C, Section 15.249(a): The field strength of emissions from intentional radiators operated within these frequency bands shall comply with the effective limits. FCC ID: XYN2761 IC ID: 8748A-2761 mikes-testingpartners gmbh File No. T36953-00-00HS, page 11 of 25 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.3, 2013-04-04 5.3 Out-of-band emission, radiated For test instruments and accessories used see section 6 Part SER1, SER 2, SER 3. 5.3.1 Description of the test location Test location: OATS 1 Test location: Anechoic chamber 2 Test distance: 3 m 5.3.2 Photo documentation of the test set-up Test setup 9 kHz – 30 MHz: Test setup 30 MHz – 1000 MHz: FCC ID: XYN2761 IC ID: 8748A-2761 mikes-testingpartners gmbh File No. T36953-00-00HS, page 12 of 25 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.3, 2013-04-04 Test setup 1 GHz – 18 GHz: Test setup 18 GHz – 25 GHz: FCC ID: XYN2761 IC ID: 8748A-2761 mikes-testingpartners gmbh File No. T36953-00-00HS, page 21 of 25 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.3, 2013-04-04 5.4 EBW and OBW For test instruments and accessories used see section 6 Part MB. 5.4.1 Description of the test location Test location: Anechoic chamber 2 Test distance: 3 m 5.4.2 Photo documentation of the test set-up 5.4.3 Applicable standard According to FCC Part 15, Section 15.215(c): Intentional radiators operating under the alternative provisions to the general emission limits, as contained in Section 15.217 through Section 15.257, must be designed to ensure that the 20 dB bandwidth of the emission is contained within the frequency band designated in the rule section under which the equipment is operated. 5.4.4 Description of Measurement The bandwidth is measured at an amplitude level reduced from the reference level by a specified ratio of -20 dB (99%). The x-dB-down (OBW) function of the analyser is used. The measurement is performed with normal modulation in TX continuous mode. Spectrum analyser settings: RBW: 100 kHz, VBW: 300 kHz, Span: 10 MHz, Trace mode: max. hold, Detector: max. peak;
