Arada Systems, Inc. 4633 Old Ironsides Drive, Suite 415, Santa Clara, CA95054, USA MaxR-7102 Mini PCI User’s Manual 1. Product Overview The MaxR-7102 series PCI adapter cards contain an Atheros AR9220 chip for IEEE 802.11b/g/n Wireless LAN applications. The mini PCI adapter cards support key security features like Wi-Fi Protected Access (WPA), WPA2, WEP and 802.1x. 2. Packaging Contents The mini PCI card package contains the following item(s): 1 x Wireless Mini PCI Adapter 3. Installation guide Shut down the power of the platform Align the PCI adapter with the Mini PCI socket on the platform Adjust and push down the PCI adapter gently until the metal locking levers on the Mini PCI socket is latched. (Please take note that the PCI adapter can only fit in one direction due to the keyed notch. Wrong orientation will cause improper installation and may damage the Mini PCI socket) Connect the antenna(s) on the mini PCI module Reboot on the platform Install drivers if necessary 4. Frequency 802.11b/g/n: 2412 ~ 2472 MHz 5. FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: Arada Systems, Inc. 4633 Old Ironsides Drive, Suite 415, Santa Clara, CA95054, USA Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. 6. FCC Caution Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is not possible. This device and its antenna(s) must not be co-located or operation in conjunction with any other antenna or transmitter. 7. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. 8. Important Notes This module is intended for OEM integrator. The OEM integrator is still responsible for the FCC compliance requirement of the end product, which integrates this module. 20cm minimum distance has to be able to be maintained between the antenna and the users for the host this module is integrated into. Under such configuration, the FCC radiation exposure limits set forth for a population/uncontrolled environment can be satisfied. Any changes or modifications not expressly approved by the manufacturer could void the user's authority to operate this equipment. Arada Systems, Inc. 4633 Old Ironsides Drive, Suite 415, Santa Clara, CA95054, USA 9. Label for end product must include “Contains FCC ID: XZB-MAXR7102” or “A RF transmitter inside, FCC ID: XZB-MAXR7102”
AradaSystems,Inc 4633OldIronsldesDriveSuite415SantaClaraCalifornia95054UnitedStates Tel:4087739298 Fax:4087163238 AdHocModeFunctionDeclaration Date:2011/7/11 FCCID: XZB-MAXR7102 ToWhomit mayconcern, We,theundersigned,declarethattheEUT(ModelName:MAXR7102)doesn'thaveAdHocfunctionon "non-US/Canadafrequencies". Regards, FCCGranteecontactpersoninformation. Applicant'scompanyaddress AradaSystems, Inc 4633 OldIronsidesDriveSuite415SantaClaraCalifornia 95054UnitedStates Applicant'scompanyname Signature JobTitleandDept. PraveenSingh/CEO E-Mail [email protected] Tel. 4087739298
AradaSystems,Inc 4633OldIronsldesDriveSuite415SantaClaraCalifornia95054UnitedStates Tel:4087739298 Fax:4087163238 ConfidentialLetter Date:2011/7/11 FederalCommunicationsCommission AuthorizationandEvaluationDivision FCCID: XZB-MAXR7102 ConfidentialityRequest PursuanttoSections0.457and0.459oftheCommission'sRules,theApplicantHerebyrequestsconfidential treatmentofinformationaccompartingthisApplicationAsoutlinedbelow: 1.BlockDiagram 2.CircuitDiagram 3.OperationalDescription Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarilyreleasedtothepublic. ThepublicdisclosureofthesemattersmightbeharmfultotheApplicantandprovideunjustifiedbenefitstoits competitors. TheApplicantunderstandsthatpursuanttoRule 0.457,disclosureofthisApplicationandallaccompanying documentationwillnotbemadebeforethedateoftheGrantforthisapplication Sincerely, Applicant'scompanyaddress AradaSystems,Inc 4633 OldIronsldesDriveSuite415SantaClaraCalifornia 95054UnitedStates Applicant'scompanyname Signature JobTitleandDept. PraveenSingh/ CEO E-Mail [email protected] Tel. 4087739298
AradaSystems,Inc 4633OldIronsldesDriveSuite415SantaClaraCalifornia95054UnitedStates Tel:4087739298 Fax:4087163238 DoCAttestationLetter Date:2011/7/11 WeAradaSystems,Inc,asthegranteeofthisprojectFCCID:XZB-MAXR7102, wouldliketodeclarethat thecompositeportioncategorizedascomputerperipheralhasbeenauthorizedundertheDeclarationof Conformityprocedures. Regards. FCCGranteecontactpersoninformation. Applicant'scompanyaddress AradaSystems.Inc 4633OldIronsidesDriveSuite415SantaClaraCalifornia 95054UnitedStates Applicant'scompanyname Signature JobTitleandDept. E-Mail PraveenSingh1CEO [email protected] Tel. 4087739298
Report No.: 121728 SPORTON International Inc. PAGE NUMBER : A1 OF A5 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 30, 2011 FAX : 886-2-2696-2255 Photographs of EUT Report No.: 121728 SPORTON International Inc. PAGE NUMBER : A2 OF A5 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 30, 2011 FAX : 886-2-2696-2255 Report No.: 121728 SPORTON International Inc. PAGE NUMBER : A3 OF A5 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 30, 2011 FAX : 886-2-2696-2255 Report No.: 121728 SPORTON International Inc. PAGE NUMBER : A4 OF A5 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 30, 2011 FAX : 886-2-2696-2255 Report No.: 121728 SPORTON International Inc. PAGE NUMBER : A5 OF A5 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 30, 2011 FAX : 886-2-2696-2255
MaxR-7102 Mini PCI Label 35.4 mm 14.7 mm
Report No.: 121728 SPORTON International Inc. PAGE NUMBER : A1 OF A4 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 30, 2011 FAX : 886-2-2696-2255 Photographs of EUT Report No.: 121728 SPORTON International Inc. PAGE NUMBER : A2 OF A4 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 30, 2011 FAX : 886-2-2696-2255 Report No.: 121728 SPORTON International Inc. PAGE NUMBER : A3 OF A4 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 30, 2011 FAX : 886-2-2696-2255 Report No.: 121728 SPORTON International Inc. PAGE NUMBER : A4 OF A4 TEL : 886-2-2696-2468 ISSUED DATE : Jun. 30, 2011 FAX : 886-2-2696-2255
Report No.: FR121728 FCC ID: XZB-MAXR7102 Page No. : 1 of 3 Appendix B. Maximum Permissible Exposure Report No.: FR121728 FCC ID: XZB-MAXR7102 Page No. : 2 of 3 1. Maximum Permissible Exposure 1.1. Applicable Standard Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.25 m normally can be maintained between the user and the device. (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz ; *Plane-wave equivalent power density 1.2. MPE Calculation Method E (V/m) = d GP30 Power Density: Pd (W/m²) = 377 2 E E = Electric field (V/m) P = Peak RF output power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between radiator and human body (m) The formula can be changed to Pd = 2 377 30 d GP From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. Report No.: FR121728 FCC ID: XZB-MAXR7102 Page No. : 3 of 3 1.3. Calculated Result and Limit Antenna Type : Dipole Antenna Max Conducted AV Power for IEEE 802.11g: 24.30 dBm Directional Antenna Gain (dBi) Antenna Gain (numeric) Average Output Power (dBm) Average Output Power ( mW ) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 4.81 3.0271 24.3010 269.2177 0.162212 1 Complies NOTE: Directional gain =1.8dBi + 10log(2)=4.81dBi
SPORTON International Inc. No. 52, Hwa Ya 1st Rd., Kwei-Shan Hsiang, TaoYuan Hsien, Taiwan, R.O.C. Ph: 886-3-327-3456 / FAX: 886-3-327-0973 / www.sporton.com.tw Report Format Version: 02 FCC RADIO TEST REPORT Applicant’s company Arada System, Inc Applicant Address 4633 Old Ironsides Drive, Suite 415 Santa Clara, CA 95054 FCC ID XZB-MAXR7102 Manufacturer’s company Arada System, Inc Manufacturer Address 4633 Old Ironsides Drive, Suite 415 Santa Clara, CA 95054 Product Name 802.11b/g/n WLAN mini-PCI card Brand Name Arada Model Name MaxR-7102 Test Rule Part(s) 47 CFR FCC Part 15 Subpart C § 15.247 Test Freq. Range 2400 ~ 2483.5MHz Received Date Feb. 17, 2011 Final Test Date Jun. 23, 2011 Submission Type Original Equipment Statement Test result included is only for the IEEE 802.11n, IEEE 802.11b/g part of the product. The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in compliance with the limit given in ANSI C63.10-2009 and 47 CFR FCC Part 15 Subpart C. The test equipment used to perform the test is calibrated and traceable to NML/ROC. Report No.: FR121728 Report Format Version: 02 Page No. : i of ii FCC ID: XZB-MAXR7102 Issued Date :Jul. 11, 2011 Table of Contents 1. CERTIFICATE OF COMPLIANCE ......................................................................................................................... 1 2. SUMMARY OF THE TEST RESULT .......................................................................................................................... 2 3. GENERAL INFORMATION .................................................................................................................................. 3 3.1. Product Details .................................................................................................................................................................................... 3 3.2. Accessories ......................................................................................................................................................................................... 5 3.3. Table for Filed Antenna....................................................................................................................................................................... 5 3.4. Table for Carrier Frequencies ............................................................................................................................................................. 6 3.5. Table for Test Modes ........................................................................................................................................................................... 7 3.6. Table for Testing Locations .................................................................................................................................................................. 7 3.7. Table for Supporting Units ................................................................................................................................................................... 8 3.8. Table for Parameters of Test Software Setting ..................................................................................................................................... 8 3.9. Test Configurations ............................................................................................................................................................................. 9 4. TEST RESULT ................................................................................................................................................... 11 4.1. AC Power Line Conducted Emissions Measurement ......................................................................................................................... 11 4.2. Peak Output Power Measurement .................................................................................................................................................... 15 4.3. Power Spectral Density Measurement .............................................................................................................................................. 18 4.4. 6dB Spectrum Bandwidth Measurement .......................................................................................................................................... 25 4.5. Radiated Emissions Measurement .................................................................................................................................................... 31 4.6. Band Edge Emissions Measurement ................................................................................................................................................. 49 4.7. Antenna Requirements ..................................................................................................................................................................... 58 5. LIST OF MEASURING EQUIPMENTS ................................................................................................................... 59 6. TEST LOCATION.............................................................................................................................................. 61 7. TAF CERTIFICATE OF ACCREDITATION ............................................................................................................. 62 APPENDIX A. TEST PHOTOS ........................................................................................................................ A1 ~ A7 APPENDIX B. MAXIMUM PERMISSIBLE EXPOSURE ........................................................................................... B1 ~B3 Report No.: FR121728 Report Format Version: 02 Page No. : ii of ii FCC ID: XZB-MAXR71…
