YAIBM05-ANBT4.0 LE Module

InnoComm Mobile Technology Corporation 3F, No. 6, Hsin Ann Rd., Hsinchu Science Park, Hsinchu 30078, Taiwan TEL: +886-3-5781868 FAX: +886-3-5781187 BT4.0 Low Energy Module User Manual FCC ID: YAIBM05-AN Introduction This document describes pin definition, mechanical drawing and reflow data of Bluetooth Low Energy Module and hope it can helps designer to design in easier and manufacturing smoothly. Pin Definition Pin # Pin Name Direction VoltageDesription 1 VDD I 1.8 to3.3VInputpowercanrangefrom1.8Vto 3.3V 2 VSS I GNDGround 3 TEST0 I/O 1.8Vto3.3VMfg Test pin 0; MODE "POINTER". Internally pulled-up (active low) 4 TEST1 I/O 1.8Vto3.3VMfg Test pin 1; MODE "JOYSTICK". Internally pulled-up (active low) 5 SDA I/O 1.8Vto3.3VI2Cdatatointerfacewithsensors(gyro & accelerometer) for relative motion. May also interface to additional I2C memory. 6 SCL O 1.8Vto3.3VI2Cclocktointerfacewithsensors (gyro & accelerometer) for relative motion. May also interface to additional I2C memory. 7 TEST2 I/O 1.8Vto3.3VMfgTestpin2 8 GPIO_2 I/O 1.8Vto3.3VInterruptfromI2Caccelerometer. Internally pulled‐up. 9 GPIO_3 I/O 1.8Vto3.3VInterruptfromI2Cgyro.Internally pulled‐up. 10 GPIO_0 I/O 1.8Vto3.3V"A"button.Internallypulled‐up. 11 GPIO_1 I/O 1.8Vto3.3V"B"button.Internallypulled‐up. 12 GPIO_4 I/O 1.8Vto3.3V General I/O - UNUSED. Internally pulled-up. 13 GPIO_5 I/O 1.8Vto3.3V"HOME"button.Internallypulled‐up. 14 GPIO_6 I/O 1.8Vto3.3V"HELP"button.Internallypulled‐up. 15 GPIO_7 I/O 1.8Vto3.3V "PAUSE"button.Internallypulled‐up. 16 GPIO_10 I/O 1.8Vto3.3V LEDforplayer"1". 17 GPIO_11 I/O 1.8Vto3.3V LEDforplayer"2". 18 ADC_0 I 1.8Vto3.3VADCinputforXdirectiononjoystick. 19 ADC_1 I 1.8Vto3.3VADCinputforYdirectiononjoystick. 20 ADC_2 I 1.8Vto3.3VADCinputforbatteryvoltage. 21 GPIO_8 I/O 1.8Vto3.3VPowerLED. 22 GPIO_9 I/O 1.8Vto3.3VIRLED. 23 GPIO_12 I/O 1.8Vto3.3V GeneralI/O‐UNUSED.Internallypulled‐up. Mechanical Drawing Reflow data Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: ‐ Reorient or relocate the receiving antenna. ‐ Increase the separation between the equipment and receiver. ‐ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ‐ Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co‐located or operating in conjunction with any other antenna or transmitter. Radiation Exposure Statement: The product comply with the FCC portable RF exposure limit set forth for an uncontrolled environment and are safe for intended operation as described in this manual. The further RF exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such function is available. This device is intended only for OEM integrators under the following conditions: 1) The transmitter module may not be co‐located with any other transmitter or antenna. As long as 1 condition above is met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end‐product for any additional compliance requirements required with this module installed IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or co‐location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID can not be used on the final product. In these circumstances, the OEM integrator will be responsible for re‐evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. End Product Labeling The product can be kept as far as possible from the user body or set the device to lower output power if such function is available. The final end product must be labeled in a visible area with the following: “Contains FCC ID: YAIBM05‐AN”. The grantee's FCC ID can be used only when all FCC compliance requirements are met. Manual Information To the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module. The end user manual shall include all required regulatory information/warning as show in this manual.

FCC ID: YAIBM05-AN Report No.: RF140825C07 Modular Approval Request Letter Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch September 15, 2014 Dear Application Examiner, InnoComm Mobile Technology Corporation, It’s a BT4.0 LE Module, FCC ID: YAIBM05-AN would like to have your authorization as a modular device. The requirements of section 15.212 of FCC rules have been met and shown on the following statements. 1. “The modular transmitter must have its own RF shielding.”: The radio portion of this module has been shielded, please see exhibition External Photo. 2. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data inputs, it is integrated in chip BLE CC2541. 3. “The modular transmitter must have its own power supply regulation.” The part number of this regulator is BLE CC2541. 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).” The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. 5. “The modular transmitter must be tested in a stand-alone configuration” The EUT was tested in a stand-alone configuration via extender. Please see section Photographs of Test Configuration in the test report, the EUT was plugged in this extender. 6. “The modular transmitter must be labeled with its own FCC ID number.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. FCC ID: YAIBM05-AN Report No.: RF140825C07 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. 8. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Please contact me if you have any further questions. Thanks for your attention. Best Regards, Robert Huang Senior Engineer Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch

Page 1

MODIFICATION VERDESCRIPTIONDATEENGINEER

Page 1

FCC ID: YAIBM05-AN Report No.: RF140825C07 OPERATIONAL DESCRIPTION The transmitter of the EUT (BT4.0 LE Module) is powered from 3.3Vdc from host equipment. The antenna is PCB antenna without antenna connector. For more detailed instruction, please take a look at the user’s manual.

Report No.: SA140825C07 1 of 6 Report Format Version 5.0.1 RF EXPOSURE REPORT REPORT NO.: SA140825C07 MODEL NO.: BM05 FCC ID: YAIBM05-AN RECEIVED: Aug. 25, 2014 TESTED: Aug. 28 ~ Aug. 29, 2014 ISSUED: Sep. 01, 2014 APPLICANT: InnoComm Mobile Technology Corporation ADDRESS: 3F, No. 6, Hsin Ann Rd., Hsinchu Science Park, Hsinchu 30078, Taiwan ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. Report No.: SA140825C07 2 of 6 Report Format Version 5.0.1 Table of Contents RELEASE CONTROL RECORD .............................................................................................. 3 1. CERTIFICATION ........................................................................................................... 4 2. EVALUATION RESULT ................................................................................................. 5 3. SAR TEST EXCLUSION THRESHOLDS ..................................................................... 6 4. CONCLUSION .............................................................................................................. 6 Report No.: SA140825C07 3 of 6 Report Format Version 5.0.1 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA140825C07 Original release. Sep. 01, 2014 Report No.: SA140825C07 4 of 6 Report Format Version 5.0.1 1. CERTIFICATION PRODUCT:BT4.0 LE Module MODEL NO.:BM05 BRAND:InnoComm Mobile APPLICANT:InnoComm Mobile Technology Corporation TESTED:Aug. 28 ~ Aug. 29, 2014 TEST SAMPLE:ENGINEERING SAMPLE STANDARDS: FCC Part 2 (Section 2.1093) KDB 447498 D03 IEEE C95.1 The above equipment (model: BM05) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE : Sep. 01, 2014 Suntee Liu / Specialist APPROVED BY : , DATE : Sep. 01, 2014 Ken Liu / Senior Manager Report No.: SA140825C07 5 of 6 Report Format Version 5.0.1 2. EVALUATION RESULT Following FCC KDB 447498 D01 “General SAR test exclusion guidance” The corresponding SAR Exclusion Threshold condition, listed below: 1) The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where  f(GHz) is the RF channel transmit frequency in GHz .  Power and distance are rounded to the nearest mW and mm before calculation.  The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. 2) At 100 MHz to 6 GHz and for test separation distances > 50 mm, the SAR test exclusion threshold is determined according to the following: a) [(Threshold at 50 mm in step 1) + (test separation distance - 50mm)·( f(MHz)/150)] mW, at 100MHz to 1500 MHz b) [(Threshold at 50 mm in step 1) + (test separation distance - 50 mm)·10] mW at > 1500 MHz and ≤ 6 GHz 3) At frequencies below 100 MHz, the following may be considered for SAR test exclusion. a) The threshold at the corresponding test separation distance at 100 MHz in step 2) is multiplied by [1 + log(100/f(MHz))] for test separation distances > 50 mm and < 200 mm. b) The threshold determined by the equation in a) for 50 mm and 100 MHz is multiplied by ½ for test separation distances ≤ 50 mm. c) SAR measurement procedures are not established below 100 MHz. When SAR test exclusion cannot be applied, a KDB inquiry is required to determine SAR evaluation requirements for any test results to be acceptable. Report No.: SA140825C07 6 of 6 Report Format Version 5.0.1 3. SAR TEST EXCLUSION THRESHOLDS Maximum measured transmitter power: Frequency (GHz) Max. Power (mW) Min. test separation distance (mm) SAR test exclusion calculation value (NOTE 2) 1-g SAR test exclusion thresholds Result 2.402 ~ 2.480 2.999 5 0.929 3 Pass NOTE: 1. The antenna type is PCB antenna with -3.22dBi gain. 2. Calculate SAR test exclusion thresholds from condition “1” formulas. 4. CONCLUSION Since Sourc…

Text truncated - open the document above for the full version.

Report No.: RF140825C07 1 of 36 Report Format Version 5.1.0 FCC TEST REPORT REPORT NO.: RF140825C07 MODEL NO.: BM05 FCC ID: YAIBM05-AN RECEIVED: Aug. 25, 2014 TESTED: Aug. 28 ~ Aug. 29, 2014 ISSUED: Sep. 01, 2014 APPLICANT: InnoComm Mobile Technology Corporation ADDRESS: 3F, No. 6, Hsin Ann Rd., Hsinchu Science Park, Hsinchu 30078, Taiwan ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the com pliance or non-compliance to the specification This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF140825C07 2 of 36 Report Format Version 5.1.0 Table of Contents RELEASE CONTROL RECORD .............................................................................................................. 4 1. CERTIFICATION .......................................................................................................................... 5 2. SUMMARY OF TEST RESULTS ................................................................................................. 6 2.1 MEASUREMENT UNCERTAINTY .............................................................................................. 6 3. GENERAL INFORMATION .......................................................................................................... 7 3.1 GENERAL DESCRIPTION OF EUT ............................................................................................ 7 3.2 DESCRIPTION OF TEST MODES .............................................................................................. 8 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL .............................................. 9 3.3 DESCRIPTION OF SUPPORT UNITS ...................................................................................... 11 3.3.1 CONFIGURATION OF SYSTEM UNDER TEST ....................................................................... 11 3.4 GENERAL DESCRIPTION OF APPLIED STANDARDS ........................................................... 12 4. TEST TYPES AND RESULTS ................................................................................................... 13 4.1 RADIATED EMISSION AND BANDEDGE MEASUREMENT ................................................... 13 4.1.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT................................. 13 4.1.2 TEST INSTRUMENTS ............................................................................................................... 14 4.1.3 TEST PROCEDURES ............................................................................................................... 15 4.1.4 DEVIATION FROM TEST STANDARD ..................................................................................... 15 4.1.5 TEST SETUP ............................................................................................................................. 16 4.1.6 EUT OPERATING CONDITIONS .............................................................................................. 16 4.1.7 TEST RESULTS ........................................................................................................................ 17 4.2 CONDUCTED EMISSION MEASUREMENT ............................................................................ 21 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ......................................................... 21 4.2.2 TEST INSTRUMENTS ............................................................................................................... 21 4.2.3 TEST PROCEDURES ............................................................................................................... 22 4.2.4 DEVIATION FROM TEST STANDARD ..................................................................................... 22 4.2.5 TEST SETUP ............................................................................................................................. 23 4.2.6 EUT OPERATING CONDITIONS .............................................................................................. 23 4.2.7 TEST RESULTS ........................................................................................................................ 24 4.3 6dB BANDWIDTH MEASUREMENT ........................................................................................ 26 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT ...................................................................... 26 4.3.2 TEST SETUP ..........................................................................................…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 RADIATED EMISSION TEST
