YJ7-DCE045BLE Tag

ENGLISH DCE045 DeW ALT TOOL CONNECT™ TAG Definitions: Safety Alert Symbols and Words This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk of personal injury or property damage.  DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.  WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.  CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.  (Used without word) Indicates a safety related message. NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in property damage. WARNING: To reduce the risk of injury, read the instruction manual. If you have any questions or comments about this or any DeWALT tool, call us toll free at: 1-800-4-DeWALT (1-800-433-9258). GENERAL SAFETY WARNINGS  WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE 1 . This device contains a factory-installed coin cell battery. It cannot be removed or replaced. 2 . Chemical burn hazard. Keep out of reach of children. 3 . Do not use in extreme hot or cold conditions. Keep between -30 °F (-34 °C) and 140 °F (60 °C). 4 . Choking hazard. Keep out of reach of children. 5 . This device contains a lithium button/coin cell battery. Do not force open the device as the battery can cause severe internal burns and lead to death in as little as 2 hours if swallowed or enters the body. If the device is damaged in any way, stop using the device and keep it away from children. If you think batteries may have been swallowed or entered the body, seek immediate medical attention. 6 . If coin cell battery contents come into contact with the skin, immediately wash area with mild soap and water. If coin cell battery liquid gets into the eye, rinse water over the open eye for 15 minutes or until irritation ceases. If medical attention is needed, the battery electrolyte is composed of an organic solvent and lithium salts. 7 . Do not incinerate or dismantle this device. 8 . Under abusive conditions, liquid may be ejected from the device. Avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns. 9 . DO NOT dispose of device together with household waste material! Appliance that has reached the end of its life must be collected separately and returned to an environmentally compatible recycling facility. The label on your tool may include the following symbols. The symbols and their definitions are as follows: V ......................... volts Hz .......................hertz min .....................minutes or DC ......direct current ...................... Class I Construction (grounded) .../min ..............per minute BPM ....................beats per minute IPM .....................impacts per minute RPM .................... revolutions per minute sfpm ................... surface feet per minute SPM ....................strokes per minute A .........................amperes W ........................watts or AC ...........alternating current or AC/DC .... alternating or direct current ...................... Class II Construction (double insulated) n o .......................no load speed n .........................rated speed ......................earthing terminal .....................safety alert symbol .....................visible radiation ..................... wear respiratory protection .....................wear eye protection ..................... wear hearing protection ..................... read all documentation ...................... Tool Connect™ home Storage Recommendations The best storage place is one that is cool and dry, away from direct sunlight and excess heat or cold. Wireless Certifications and Safety Information •This device is CAN ICES-3(B)/NMB-3(B) compliant. •This device complies with Part 15 of the FCC rules and Industry Canada License-exempt RSS standard(s). Operation is subject to the following two conditions: -This device may not cause harmful interference, and -This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and adaptor. -Connect the equipment into an outlet on a circuit different from that to which the adaptor is connected. -Consult the dealer or an experienced radio/TV technician for help. •Changes or modifications to this equipment not expressly approved by the manufacturer could void the user’s authority to operate the device. This Class B digital apparatus complies with Canadian ICES-003. •Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference t…

Text truncated - open the document above for the full version.

Kirwan Magdamo Lead Project Engineer 701 East Joppa Road, Towson, MD 21286 T (410) 716 3563 Certification Application Attestation Statements Date: April 10, 2023 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: FCC ID: YJ7-DCE045 Statement for 47 CFR section 2.911(d)(5)(i) Stanley Black & Decker certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . Statement for 47 CFR section 2.911(d)(5)(ii) Stanley Black & Decker (“the applicant”) certifies that, as of the date of the filing of this application, the applicant ☐ - is / ☒ - is not identified on the Covered List as an entity producing “covered” equipment. Thank you, By: Kirwan Magdamo (Signature 2 ) (Print name) Title: Lead Project Engineer Company: Stanley Black & Decker Telephone: 410-716-3563 2 - Letters must be placed on appropriate letterhead.

Kirwan Magdamo Lead Project Engineer 701 East Joppa Road, Towson, MD 21286 T (410) 716 3563 U.S. Agent Designation for Service of Process (Applicant is Both Grantee and U.S. Agent) TO: American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information This letter is to confirm that the Applicant will also serve as the U.S. Agent for Service of Process as required by 47 CFR 2.911(d)(7). The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The Applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information changes. Applicant Company name: Stanley Black & Decker FRN #: 0019980119 Grantee Code: YJ7 Contact Name: Kirwan Magdamo Street Address: 701 East Joppa Road City/Province/Zip: Towson, MD 21286 Telephone No: 410-716-3563 Email: [email protected] Applicant Signature 1 : Date: April 10, 2023 Signed by (Printed Name/Title): Kirwan Magdamo, Lead Project Engineer 1 - Letters must be placed on appropriate letterhead.

Kirwan Magdamo Lead Project Engineer 701 East Joppa Road, Towson, MD 21286 T (410) 716 3563 Authority to Act as Agent Date: April 10, 2023 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: _Adam Alger and Amanda Hauck of Laird Connectivity are authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. We also declare that the information provided to the FCC is true and correct to the best of our knowledge (47 CFR 2.911(d)) and we have been informed of the grantee responsibilities (47 CFR 2.909) with regard to certified equipment. Thank you, Agency Agreement Expiration Date: December 31, 2023 By: Kirwan Magdamo (Signature 1 ) (Print name) Title: Lead Project Engineer On behalf of: Stanley Black & Decker Telephone: 410-716-3563 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

Kirwan Magdamo Lead Project Engineer 701 East Joppa Road, Towson, MD 21286 T (410) 716 3563 Request for Confidentiality Date: April 10, 2023 Subject: Confidentiality Request for: YJ7-DCE045 and 9082A-DCE045 Pursuant to FCC 47 CFR 0.457(d) and 0.459 and/or IC RSP-100, Section 12.4, the applicant requests that a part of the subject application(s) be held confidential. Type of Confidentiality Requested ☐Short Term☒Permanent ☒Short Term--------------------------- ☒Short Term☐Permanent * 1 ☐Short Term☒Permanent ☐Short Term ☒Short Term ☒Permanent ☒Short Term ☐Permanent * 1 Exhibit Block Diagrams External Photos Internal Photos Operation Description/Theory of Operation Schematics Test Setup Photos User’s Manual Stanley Black & Decker has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality for FCC Applications: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public before the requested period has expired. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. 1 - The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. 2 - Please refer to https://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. --------------------------- Short Term Confidentiality for Industry Canada Applications: Starting May 2022, ISED will recognize short term confidentiality on certain exhibits until the intended date of marketing. The applicant requests the exhibits selected above as short term confidential be withheld from public view until: October 29, 2023. Sincerely, By: Kirwan Magdamo (Signature/Title 3 ) (Print name) 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

EXTERNAL PHOTOS Company Name Stanley Black and Decker Model # DCE045 FCC ID # YJ7-DCE045 IC # 9082A-DCE045 Page 1 of 2 EXTERNAL PHOTOS Company Name Stanley Black and Decker Model # DCE045 FCC ID # YJ7-DCE045 IC # 9082A-DCE045 Page 2 of 2

Lazer parameter setting Current pen: 2 Mark Loop: 1 Speed(mm/s): 1500 Current (A) 65 Frequency(KHz) 50 Q Pulse Width(ns) 200 Laser On TC(us) 100 Laser Off TC(us) 100 End TC(us) 200 Polygon TC(us) 200 Hight(cm) 34 1 2 3 4 5 6 7 89 1011 Item Parameter MODEL:DCE045 Tool Connect Tag FCC ID: YJ7-DCE045 IC: 9082A-DCE045 YYYY WW-L9 单位： mm 3:1 样式： A4 新设计 吴林华 2021-8-16 页码： 1/1 吴林华 2022-04-27 欧阳璟 2022-04-27 任素云 2022-04-27 未注公差列表: 0&1 PLC DEC:±0.30 2 PLC DEC:±0.10 角度 :±1.0° 后盖打码文件 BLE TAG - DCE045 DOC100511307 / 视图： 比例： 30mm 30mm Font settings MODEL:DCE045 Arial-1.53(mm) Tool Connect Tag FCC ID: YJ7-DCE045 IC: 9082A-DCE045 YYYY WW-L9 1 2 3 4 5 Item Parameter Arial-1.53(mm)Arial-1.53(mm)Arial-1.53(mm)Arial-1.53(mm) □本产品符合ROHS要求.□本产品符合AA要求.□本产品符合SONY要求. 环保要求：

INTERNAL PHOTOS Company Name Stanley Black and Decker Model # DCE045 FCC ID # YJ7-DCE045 IC # 9082A-DCE045 Page 1 of 2 INTERNAL PHOTOS Company Name Stanley Black and Decker Model # DCE045 FCC ID # YJ7-DCE045 IC # 9082A-DCE045 Page 2 of 2

A Company: Stanley Black & Decker Page 1 of 13 Name: DCE045 Report: TR3600F Model: DCE045 Quote: NBO-01-2022-004577-2 Serial: Engineering Sample Test Report C-3600F Equipment Under Test: DCE045 Requirement(s): FCC 1.1310 ISED RSS-102 Test Date(s): 6/7/2023 Prepared for: Stanley Black & Decker Attn: Kirwan Magdamo 701 East Joppa Road Towson, MD 21286 Report Issued by: Anthony Smith, EMC Engineering Specialist Signature: Date: 7/27/2023 Report Reviewed by: Adam Alger, Laboratory Manager Signature: Date: 07/27/2023 Report Constructed by: Anthony Smith, EMC Engineering Specialist Signature: Date: 7/18/2023 This test report may not be reproduced, except in full, without approval of Laird Connectivity LLC Company: Stanley Black & Decker Page 2 of 13 Name: DCE045 Report: TR3600F Model: DCE045 Quote: NBO-01-2022-004577-2 Serial: Engineering Sample CONTENTS Contents ........................................................................................................................................................ 2 Laird Connectivity Test Services in Review ............................................................................................... 3 1 Test Report Summary ........................................................................................................................... 4 2 Client Information ................................................................................................................................. 5 2.1 Equipment Under Test (EUT) Information .................................................................................... 5 2.2 Product Description ...................................................................................................................... 5 2.3 Modifications Incorporated for Compliance ................................................................................. 5 2.4 Deviations and Exclusions from Test Specifications ..................................................................... 5 2.5 Programming Information ............................................................................................................ 5 3 References ............................................................................................................................................ 6 4 Uncertainty Summary ........................................................................................................................... 7 5 Test Data ............................................................................................................................................... 8 5.1 Antenna Port Conducted Emissions .............................................................................................. 8 6 FCC 1-G SAR Test Exclusion Calculations ............................................................................................ 11 6.1 Power Calculations ...................................................................................................................... 11 6.2 Distance ....................................................................................................................................... 11 6.3 SAR Test Exclusion Calculation .................................................................................................... 11 6.4 Result .......................................................................................................................................... 11 7 IC Exemption Calculation for Routine SAR Evaluation ........................................................................ 12 7.1 Power Calculations ...................................................................................................................... 12 7.2 Distance ....................................................................................................................................... 12 7.3 Exemption Limits ......................................................................................................................... 12 7.4 SAR Test Exclusion Calculation .................................................................................................... 12 7.5 Result .......................................................................................................................................... 12 8 Revision History .................................................................................................................................. 13 Company: Stanley Black & Decker Page 3 of 13 Name: DCE045 Report: TR3600F Model: DCE045 Quote: NBO-01-2022-004577-2 Serial: Engineering Sample Laird Connectivity Test Services in Review The Laird Connectivity LLC laboratory located at W66 N220 Commerce Court Cedarburg, Wisconsin, 53012 USA is recognized through the following organizations: A2LA – American Association for Laboratory Accreditation Accreditation based on ISO/IEC 17025:2017 with Electrical (EMC) Scope A2LA Certificate Number: 1255.01 Scope of accreditation includes all test methods listed herein unless otherwise noted Federal Communications Commission (FCC) – USA Accredited Test Firm Registration Number: 953492 Recognition of two 3 meter Semi-Anechoic Chambers Innovation, Science and Economic Development Canada Accredited U.S. Identification Number: US0218 Recognition of two 3 meter Semi-Anechoic Chambers Company: Stanley Black & Decker Page 4 of 13 Name: DCE045 Report: TR3600F Model: DCE045 Quote: NBO-01-2022-004577-2 Serial: Engineering Sample 1 TEST REPORT SUMMARY On 6/7/2023 the Equipment Under Test (EUT), DCE045, as provided by Stanley Black & Decker was tested to the following requirements: Portable Device Requirements Description Method Result FCC: 1.1310 Radiofrequency Radiation Exposure Limits Distance ≤ 5mm 1g-SAR Reported IC: RSS-102 Radiofrequency Radiation Exposure Limits Distance 10mm 1g-SAR Reported Notice: The results relate only to the item tested as configured and described in this report. Any additional configurati…

Text truncated - open the document above for the full version.

A Company: Stanley Black & Decker Page 1 of 15 Name: DCE045 Report: TR3600G Model: DCE045 Quote: NBO-01-2022-004577-2 Serial: Engineering Sample Test Report C-3600G Equipment Under Test: DCE045 Requirement(s): FCC 15.203 RSS-GEN 6.8 Test Date(s): 6/5/2023-6/7/2023 Prepared for: Stanley Black & Decker Attn: Kirwan Magdamo 701 East Joppa Road Towson, MD 21286 Report Issued by: Anthony Smith, EMC Engineering Specialist Signature: Date: 7/18/2023 Report Reviewed by: Adam Alger, Laboratory Manager Signature: Date: 7/18/2023 Report Constructed by: Anthony Smith, EMC Engineering Specialist Signature: Date: 7/18/2023 This test report may not be reproduced, except in full, without approval of Laird Connectivity LLC Company: Stanley Black & Decker Page 2 of 15 Name: DCE045 Report: TR3600G Model: DCE045 Quote: NBO-01-2022-004577-2 Serial: Engineering Sample CONTENTS Contents ........................................................................................................................................................ 2 Laird Connectivity Test Services in Review ............................................................................................... 3 1 Test Report Summary ........................................................................................................................... 4 2 Client Information ................................................................................................................................. 5 2.1 Equipment Under Test (EUT) Information .................................................................................... 5 2.2 Product Description ...................................................................................................................... 5 2.3 Modifications Incorporated for Compliance ................................................................................. 5 2.4 Deviations and Exclusions from Test Specifications ..................................................................... 5 2.5 Programming Information ............................................................................................................ 5 2.6 Additional Information .................................................................................................................. 6 3 References ............................................................................................................................................ 7 4 Uncertainty Summary ........................................................................................................................... 8 5 Test Data ............................................................................................................................................... 9 5.1 Antenna Port Conducted Emissions .............................................................................................. 9 5.2 Radiated RF Output Power ......................................................................................................... 12 5.3 Antenna Gain .............................................................................................................................. 13 6 Figure .................................................................................................................................................. 14 7 Revision History .................................................................................................................................. 15 Company: Stanley Black & Decker Page 3 of 15 Name: DCE045 Report: TR3600G Model: DCE045 Quote: NBO-01-2022-004577-2 Serial: Engineering Sample Laird Connectivity Test Services in Review The Laird Connectivity LLC laboratory located at W66 N220 Commerce Court Cedarburg, Wisconsin, 53012 USA is recognized through the following organizations: A2LA – American Association for Laboratory Accreditation Accreditation based on ISO/IEC 17025:2017 with Electrical (EMC) Scope A2LA Certificate Number: 1255.01 Scope of accreditation includes all test methods listed herein unless otherwise noted Federal Communications Commission (FCC) – USA Accredited Test Firm Registration Number: 953492 Recognition of two 3 meter Semi-Anechoic Chambers Innovation, Science and Economic Development Canada Accredited U.S. Identification Number: US0218 Recognition of two 3 meter Semi-Anechoic Chambers Company: Stanley Black & Decker Page 4 of 15 Name: DCE045 Report: TR3600G Model: DCE045 Quote: NBO-01-2022-004577-2 Serial: Engineering Sample 1 TEST REPORT SUMMARY On 6/5/2023 to 6/7/2023 the Equipment Under Test (EUT), DCE045, as provided by Stanley Black & Decker was tested to the following requirements: Antenna Requirements Requirements Description Method Result FCC 15.203 Antenna Requirement ANSI C63.10 Pass RSS-GEN 6.8 Transmit Antenna ANSI C63.10 Pass Notice: The results relate only to the item tested as configured and described in this report. Any additional configurations, modes of operation, or modifications made to the equipment under test after the specified test date(s) are at the decision of the client and may not apply to the data seen in this test report. The decision rule for Pass / Fail assessment to the specification or standard listed in this test report has been agreed upon by the client and laboratory to be as follows: Measurement Type Rule Emissions – Amplitude 1 dB below specified limit Emissions – Frequency 1% less than the specification Immunity Tested at specified level Company: Stanley Black & Decker Page 5 of 15 Name: DCE045 Report: TR3600G Model: DCE045 Quote: NBO-01-2022-004577-2 Serial: Engineering Sample 2 CLIENT INFORMATION Company Name Stanley Black & Decker Contact Person Kirwan Magdamo Address 701 East Joppa Road Towson, MD 21286 2.1 Equipment Under Test (EUT) Information The following information has been supplied by the client Product Name DCE045 Model Number DCE045 Serial Number Engineering Sample Additional Information FCC ID: YJ7DCE045 IC ID: 9082A-DCE045 2.2 Product D…

Text truncated - open the document above for the full version.

TEST SETUP PHOTOS Company Name Stanley Black and Decker Model # DCE045 FCC ID # YJ7-DCE045 IC # 9082A-DCE045 Page 1 of 1 Vertical Orientation (from Front of Pedestal) Horizontal Orientation (from Front of Pedestal) Flat Orientation (from Rear of Pedestal) Below 1 GHz Radiated Emissions Above 1 GHz Radiated Emissions Conducted Measurements
