7signal Solutions, Inc. 526 S. Main Street Akron, Ohio 44311 855-763-9526 February 12, 2014 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR 7signal Sapphire Eye, model 2001, FCC ID: YLF-INDR-EYE01 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the schematic, block diagram, theory of operation, and parts list, required to be submitted with this application be permanently withheld from public review. The above documents are company proprietary information that could never get into the possession of our competition. Please contact me if there is any information you may need. Sincerely, Donald Sloan SVP, Engineering 7signal Solutions, Inc.

7signal Solutions, Inc. 526 S. Main Street Akron, Ohio 44311 855-763-9526 February 12, 2014 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Short Term Confidentiality Request For Sapphire Eye, Model 2001 and FCC ID: YLF-INDR-EYE01 To Whom It May Concern: In accordance with sections 0.457 and 0.459 of CFR 47, 7signal Solutions requests short-term Confidentiality of following sections of this application for a period of 45 days after grant is issued. Test setup photos External photos Internal photos User’s manual These documents contain detailed system and equipment descriptions and related information about the product, which 7signal Solutions considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, 7signal Solutions feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Donald Sloan SVP, Engineering 7signal Solutions, Inc.

12VDC EXTERNAL ANTENNA FCC ID: YLF-INDR-EYE01 IC:11766A-INEY2001 Meets FCC Part 15 SEE MANUAL BEFORE USE LISEZ LE MANUEL AVANT D'UTILIZER CE PRODUIT ETHERNET 10/100 PoE THE WI-FI PERFORMANCE COMPANY NOTES: 1) ARTWORK # LBL01001 REV 2 2) SEE DRAWING FILE (SAME NUMBER AND REVISION) FOR SIZE, COLOR, AND LABEL STOCK DEFINITION 3) RED OUTLINES ON LABEL FOR REGISTRATION ONLY - DO NOT PRINT

Photograph 1. Antenna bd back side Photograph 2. Antenna board Photograph 3. Antennas Photograph 4. Processor board back side Photograph 5. Processor board

7signal Solutions Sapphire Eye model 2001 antenna patterns 3/12/14 The Sapphire Eye 2001 has an internal sectored antenna system comprised of 6 broadband etched copper antennas arranged in a circle on a single circuit board. Each antenna has a horizontal (azimuth) beamwidth of 60 degrees. Each covers one 60-degree sector in the horizontal azimuth plane. See photo in Figure 1. Figure 1. Sapphire Eye SE2001 Internal 6-Sector Antenna board Each sector’s antenna gain is 6dBi. The antenna switching network (center of board layout) allows the single Wi-Fi radio on the processor board to select which antenna sector is desired at any one time. The SE2001 antenna system was designed to match the previous generation Sapphire Eye (FCC ID: YLF- ABGN-EYE-APU3) with regard to beamwidth and gain, and thus all pattern plots are shown in comparison to the APU-3 antenna, herein called the Reference antenna. The Reference antenna was originally measured and characterized at a calibrated antenna range at VTT Technical Research Centre of Finland. The Reference antenna is a slot-coupled patch gain antenna, shown below in Figure 2. Red: layer 1 ground plane Yellow: ground plane slots Blue: layer 2 driven element Yellow: layer 3 patch radiators (2.4 & 5 GHz) Figure 2. Reference Patch Antenna construction The following gain and directivity plots shown in Figures 3 and 4 below were taken in a calibrated antenna range at VTT Technical Research Center in Espoo, Finland. These are shown since they are the reference antennas for the current Device Under Test (DUT), or Sapphire Eye model 2001. Figure 3. Reference Patch Antenna Horizontal Pattern with 7dBi Gain Figure 4. Reference Patch Antenna Elevation Pattern with 7dBi Gain The horizontal-plane pattern of the Sapphire Eye 2001 antenna under test (DUT) is plotted below in red as compared to the Reference antenna plot in blue. The DUT exhibits about 6dBi of gain and a 6dB beamwidth of approximately 75 degrees as shown in Figure 5 below. The elevation measurements are similarly plotted below in Figure 6 as compared to the 7dBi Reference antenna from 0 degrees (straight down) through 180 degrees (overhead). Figure 6. Device Under Test (DUT) Antenna Elevation Directivity and Gain plot at 2.4GHz Figure 5. Device Under Test (DUT) Antenna Horizontal Directivity and Gain plot at 2.4GHz Similar plots at 5.4GHz for horizontal (azimuth) gain and directivity as well as elevation gain and directivity, are shown below in Figures 7 and 8, relative to the 7dBi Reference antenna. End of document, Sapphinre Eye model 2001 6-sector PCB antenna and switching system. Figure 7. Device Under Test (DUT) Antenna Horizontal Directivity and Gain plot at 5.4GHz Figure 8. Device Under Test (DUT) Antenna Elevation Directivity and Gain plot at 5.4GHz
