YXG-ES700EPPanic button (emergency pendant)

Panic Button (ES700EP) S.O.S. Button for Personal Emergency Response System (PERS) Compact, user-friendly and modernly designed S.O.S. Button for Personal Emergency Response System (PERS) Portable & can be carried with various adaptors: as pendant, key-ring or watch strap Sends panic message to central monitoring station for further action 100% water sealed, with an internal battery for more than 7 years life cycle Suitable for various audiences in need of 24/7 monitoring With millions of systems and security peripherals installed internationally, Essence Security is a technological and market leader in the field of advanced security solutions for homes, offices and full-service central monitoring stations The ES700EP panic button and tag seamlessly integrates with the EverGuard and EverGuard Express control panels and other products from Essence Security International part of the Essence Group ES700EP Panic Button DESCRIPTION •When the panic button is pressed, a message is immediately sent to the Central Monitoring Station (CMS). •Central Service response can be configured to various parameters and corresponding actions. •Multiple wearing options – as a pendant, on a wrist band or with a key ring. RANGE & FREQUENCY •Up to 400 meters RF range (open air) •ECOP HW and SW bi-directional radio •Modulation and Frequency: BFSK , 868.3 MHz (Europe) 916.5MHz (US). POWER CONSUMPTION •Long operation period (over 7 years) •Uses one CR2025 Lithium Battery SIZE & WEIGHT •Size: •H-14.5mm/ L-53.2mm/ W-31.5mm •Weight: •16 gr. (including battery) without the various accessories ENVIRONMENTAL •Operating Ambient Temperature range •-10° - 55° Celsius •Water Immersion Resistant (IP67) COMPLIANCE •CE: EMC/EMI, ETSI EN 301 489-4, ETSI EN 301 489-1, EN 50130-4 •Radio: ETSI EN 300 220-3, ETSI EN 300 220-1, EN 50130-4 •Safety: EN/IEC 60950-1 •Security & Alarm systems: EN 50131-5-3 •Environmental Regulation: RoHS 2002/95/EC •Reliability (Mechanical & Environmental conditions): EN 50130-5 and IEC 60068 •Material: Polycarbonate Essence Security International (E.S.I.) Ltd. www.essence-grp.com +972-73-244-7777 [email protected] © 2013 Essence Security International (E.S.I.) Ltd. Information contained within this document may change without notice. Certifications and approvals: This device complies with FCC Rules Part 15 and with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Changes or modifications to this equipment not expressly approved by the party responsible for compliance (Essence Ltd.) could void the user’s authority to operate the equipment.

RF_160, Issue 03 Declaration of Authorization We Name: Essence Security International Ltd. Address: 12 Abba Eban avenue, Ackerstein Tower Bldg. D, P.O.Box 2073 City: Herzliya 4612001 Country: Israel Declare that: Name Representative of agent: ............. (1) Agent Company name: Hermon Laboratories Ltd. Address: Harakevet Industrial Zone City: Binyamina 30500 Country Israel is authorized to apply for Certification of the following product(s): Product description:  Panic button (emergency pendant) Type designation:  EP Trademark:  ES700EP on our behalf. Date: June 25, 2013 City: Herzliya Name: Amir Boim (2) Function: HW Director Signature: Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 16-Jul-10 RF_501, Issue 6 Page 1 of 1 Company Name: Essence Security International Ltd. Address : 12 Abba Eban avenue, Ackerstein Tower Bldg. D, City: Herzliya 4612001 Country: Israel To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: YXG-ES700EP Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: (notes 2, 3, 4, 5) Date: June 25, 2013 Name and signature of applicant: Amir Boim Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

, July 22, 2013 Telefication B.V. Attn: Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Application for certification of a wireless panic button (emergency pendant), FCC ID:YXG-ES700EP Dear Gentlemen, Please find attached our application for certification of a wireless panic button (emergency pendant), model ES700EP, FCC ID:YXG-ES700EP, prepared in accordance with FCC Rules part 2 and part 15 subpart C section 15.231(a). The product testing and this application for certification were performed by Hermon Laboratories, which is listed by FCC, Registration Numbers 90623, 90624. The FCC Designation Number is US1003. Hermon Labs responsible person is Mr. Michael Nikishin, tel: +972 4626 8440, fax:+972 4628 8277, e-mail: [email protected]. Please send an invoice to Hermon Labs. We hope this application satisfies your requirements Sincerely yours, Amir Boim, HW Director

Essence Security International Ltd. FCC ID:YXG-ES700EP IC:11061A-ES700EP Page 1 of 4 EXTERNAL PHOTOGRAPHS This document contains 3 photographs Essence Security International Ltd. FCC ID:YXG-ES700EP IC:11061A-ES700EP Page 2 of 4 Photograph No.1 ES700EP panic button front view Essence Security International Ltd. FCC ID:YXG-ES700EP IC:11061A-ES700EP Page 3 of 4 Photograph No.2 ES700EP panic button bottom view Essence Security International Ltd. FCC ID:YXG-ES700EP IC:11061A-ES700EP Page 4 of 4 Photograph No.3 ES700EP panic button side view

Essence Security International Ltd. FCC ID:YXG-ES700EP IC:11061A-ES700EP Page 1 of 1 Label The label is affixed on the rear side of the panic button as shown below. The label material is PVC with a permanent adhesive. Label location Label with FCC ID:YXG-ES700EP and IC:11061A-ES700EP will be located here. The statement according to FCC part 15 §15.19(a)(3) is placed in User’s Manual, page 2 (Application exhibit User_manual_24390). FCC ID:YXG-ES700EP IC:11061A-ES700EP

Essence Security International Ltd. FCC ID:YXG-ES700EP IC:11061A-ES700EP Page 1 of 5 INTERNAL PHOTOGRAPHS This document contains 4 photographs Essence Security International Ltd. FCC ID:YXG-ES700EP IC:11061A-ES700EP Page 2 of 5 Photograph No.1 ES700EP panic button internal view Essence Security International Ltd. FCC ID:YXG-ES700EP IC:11061A-ES700EP Page 3 of 5 Photograph No.2 ES700EP panic button PCB front view Essence Security International Ltd. FCC ID:YXG-ES700EP IC:11061A-ES700EP Page 4 of 5 Photograph No.3 PCB second side view Essence Security International Ltd. FCC ID:YXG-ES700EP IC:11061A-ES700EP Page 5 of 5 Photograph No.4 ES700EP panic button antenna

Panic Button (ES700EP) S.O.S. Button for Personal Emergency Response System (PERS) Compact, user‐friendly and modernly designed S.O.S. Button for Personal Emergency Response System (PERS) Portable & can be carried with various adaptors: as pendant, key‐ring or watch strap Sends panic message to central monitoring station for further action 100% water sealed, with an internal battery for more than 7 years life cycle Suitable for various audiences in need of 24/7 monitoring With millions of systems and security peripherals installed internationally, Essence Security is a technological and market leader in the field of advanced security solutions for homes, offices and full‐service central monitoring stations The ES700EP panic button and tag seamlessly integrates with the EverGuard and EverGuard Express control panels and other products from Essence Security International part of the Essence Group ES700EP Panic Button DESCRIPTION •When the panic button is pressed, a message is immediately sent to the Central Monitoring Station (CMS). •Central Service response can be configured to various parameters and corresponding actions. •Multiple wearing options –as a pendant, on a wrist band or with a key ring. RANGE & FREQUENCY •Up to 400 meters RF range (open air) •ECOP HW and SW bi‐directional radio •Modulation and Frequency: BFSK , 868.3 MHz (Europe) 916.5MHz (US). POWER CONSUMPTION •Long operation period (over 7 years) •Uses one CR2025 Lithium Battery SIZE & WEIGHT •Size: •H‐14.5mm/ L‐53.2mm/ W‐31.5mm •Weight: •16 gr. (including battery) without the various accessories ENVIRONMENTAL •Operating Ambient Temperature range •‐10°‐55°Celsius •Water Immersion Resistant (IP67) COMPLIANCE •CE: EMC/EMI, ETSI EN 301 489‐4, ETSI EN 301 489‐1, EN 50130‐4 •Radio: ETSI EN 300 220‐3, ETSI EN 300 220‐1, EN 50130‐4 •Safety: EN/IEC 60950‐1 • Security & Alarm systems: EN 50131‐5‐3 •Environmental Regulation: RoHS 2002/95/EC •Reliability (Mechanical & Environmental conditions): EN 50130‐5 and IEC 60068 •Material: Polycarbonate Essence Security International (E.S.I.) Ltd. www.essence‐grp.com+972‐73‐244‐7777 info@essence‐grp.com © 2013 Essence Security International (E.S.I.) Ltd. Information contained within this document may change without notice. Certifications and approvals: Essence Security International (E.S.I.) Ltd. www.essence‐grp.com+972‐73‐244‐7777 info@essence‐grp.com © 2013 Essence Security International (E.S.I.) Ltd. Information contained within this document may change without notice. The CR2025 battery provide power. This produce the right regulated voltage needed by the entire circuit. The main micro-controller gets data from tag. It interacts with the RF-transceiver chip. The product have a single indication LED. Block Diagram Description EFM32 RTC Pushbutton INT Testingand Debuginterface Programming I/F CR2025 Lithium 3V Battery Permanent Magnet 2LEDS PWM SPI INT CC1101 SPI SW 26MHz 916.5MHz

Hermon Laboratories Ltd. Harakevet Industrial Zone, Binyamina 30500, Israel Tel. +972-4-6288001 Fax. +972-4-6288277 E-mail: [email protected] Page 1 of 42 Report ID: ESSRAD_FCC.24390.docx Date of Issue: 4-Jul-13 ELECTRICAL TESTING 0839.01 TEST REPORT ACCORDING TO: FCC CFR 47 Part 15 subpart C, section 15.231 (a) and subpart B RSS-210 issue 8 Annex 1, ICES-003 Issue 5:2012 FOR: Essence Security International Ltd. Emergency Pendant Model: ES700EP FCC ID:YXG-ES700EP IC:11061A-ES700EP This report is in conformity with ISO/ IEC 17025. The "A2LA Accredited" symbol endorsement applies only to the tests and calibrations that are listed in the scope of Hermon Laboratories accreditation. The test results relate only to the items tested. This test report shall not be reproduced in any form except in full with the written approval of Hermon Laboratories Ltd. Report ID: ESSRAD_FCC.24390.docx Date of Issue: 4-Jul-13 Page 2 of 42 Table of contents 1 Applicant information ..................................................................................................................................................... 3 2 Equipment under test attributes .................................................................................................................................... 3 3 Manufacturer information .............................................................................................................................................. 3 4 Test details .................................................................................................................................................................... 3 5 Tests summary .............................................................................................................................................................. 4 6 EUT description ............................................................................................................................................................. 5 6.1 General information ....................................................................................................................................................... 5 6.2 Test configuration .......................................................................................................................................................... 5 6.3 Changes made in EUT .................................................................................................................................................. 5 6.4 EUT test positions ......................................................................................................................................................... 6 6.5 Transmitter characteristics ............................................................................................................................................ 7 7 Transmitter tests according to 47CFR part 15 subpart C and RSS-210 Annex 1requirements .................................... 8 7.1 Periodic operation requirements ................................................................................................................................... 8 7.2 Field strength of emissions .......................................................................................................................................... 11 7.3 Occupied bandwidth test ............................................................................................................................................. 25 7.4 Antenna requirements ................................................................................................................................................. 27 8 Unintentional emissions .............................................................................................................................................. 28 8.1 Radiated emission measurements .............................................................................................................................. 28 9 APPENDIX A Test equipment and ancillaries used for tests ....................................................................................... 34 10 APPENDIX B Measurement uncertainties ................................................................................................................... 35 11 APPENDIX C Test laboratory description ................................................................................................................... 36 12 APPENDIX D Specification references ....................................................................................................................... 36 13 APPENDIX E Test equipment correction factors ......................................................................................................... 37 14 APPENDIX F Abbreviations and acronyms ................................................................................................................. 42 Report ID: ESSRAD_FCC.24390.docx Date of Issue: 4-Jul-13 Page 3 of 42 1 Applicant information Client name: Essence Security International Ltd. Address: 12 Abba Edan avenue, Ackerstein Tower Bldg. D,P.O.Box 2073, Herzliya 4612001, Israel Telephone: +972 7324 47735 Fax: +972 9772 9962 E-mail: [email protected] Contact name: Mr. Ilya Feldman 2 Equipment under test attributes Product name: Emergency Pendant Product type: Transceiver Model(s): ES700EP Serial number: 00001F09 Hardware version: V1 Software release: 1.4.3 Receipt date 5/30/2013 3 Manufacturer information Manufacturer name: Essence Security International Ltd. Address: 12 Abba Edan avenue, Ackerstein Tower Bldg. D,P.O.Box 2073, Herzliya 4612001, Israel Telephone: +972 7324 47735 Fax: +972 9772 9962 E-Mail: [email protected] Contact name: Mr. Ilya Feldman 4 Test details Project ID: 24390 Location: Hermon Laboratories Ltd. Harakevet Industrial Zone, Binyamina 30500, Israel Test started: 5/30/2013 Test completed: 6/19/2013 Test sp…

Text truncated - open the document above for the full version.

Essence Security International Ltd. FCC ID:YXG-ES700EP IC:11061A-ES700EP Page 1 of 5 SETUP PHOTOGRAPHS This document contains 4 photographs Essence Security International Ltd. FCC ID:YXG-ES700EP IC:11061A-ES700EP Page 2 of 5 Photograph No.1 Setup for spurious emission field strength measurements in the anechoic chamber below 30 MHz Essence Security International Ltd. FCC ID:YXG-ES700EP IC:11061A-ES700EP Page 3 of 5 Photograph No.2 Setup for spurious emission field strength measurements in the anechoic chamber in 30 – 1000 MHz range Essence Security International Ltd. FCC ID:YXG-ES700EP IC:11061A-ES700EP Page 4 of 5 Photograph No.3 Setup for spurious emission field strength measurements in the anechoic chamber above 1000 MHz range Essence Security International Ltd. FCC ID:YXG-ES700EP IC:11061A-ES700EP Page 5 of 5 Photograph No.4 Setup for occupied bandwidth measurements
