YXG-ES800ZWEZ-Wave extender

WeR@Home ™ Smart Living The WeR@Home ™ suite allows living life fully through smart connected homes • Home security and safety at the core • Notifications of security events and remote management of the home in real time • Modular and expandable - manage connected home devices with Z-Wave® expansion • Scenarios and rules for automation – decide which device, condition, or event will trigger which actions and at what time • Live HD video – anytime, on any screen • Save energy and money by ensuring that lights and air conditioning are turned off when not at home Product For more information, go to: http://www.essence-grp.com/smart-living/wer-at-home ESDSCERT002 Rev 2.2 The Z-Wave® Extender allows incorporation of 3 rd party Z-Wave® devices into the WeR@Home ™ System, integrating Smart Home applications with the Essence Security system. It features: • Single-element, compact Z-Wave® device controller • Allows Z-Wave® devices to be treated as integral elements in the WeR@Home ™ system • Enables support for Smart Devices such as light switches (on/off/dimmer), thermostats, and door locks • Powered by the WeR@Home ™ Hub • Simple and fast pairing process Z-Wave ® Extender ES800ZWE Z-Wave ® Home Automation Device Controller © 2015 Essence Security International (E.S.I.) Ltd. Information contained within this document may change without notice Specifications COMMUNICATION • Maximum RF Range: 30m (98 ft.) open air • Maximum Transmission: 25 mW (14 dBm) • Modulation and Frequency: GFSK Modulation • 868.42 MHz (in Europe) • 908.4 MHz (in USA, Canada, and Mexico ) • 921.42 MHz (in Australia) • 869 MHz (in Russia) – ES800ZWE-RU-M01: EIRP, no more than 10 mW • Bit Rate: up to 100 kbps • Data Security: 128bit AES encryption • Uses the Z-Wave® 500-series chip • The Z-Wave® protocol acts as the interface between the WeR@Home ™ proprietary RF network and the devices connected to the WeR@Home ™ System via the Z-Wave® mesh network. DIMENSIONS • Size: H: 5mm (0.2 in.), L: 58mm (2.28 in.), W: 24mm (0.94 in.) • Weight: 10 grams (0.03 lbs.) • Cable length: 15cm (5.9 in.) ENVIRONMENT • Storage Ambient Temperature range: -20 o C – +50 o C (-4 o F – +122 o F) • Operating Ambient Temperature range with battery: 0 o C – +50 o C (32 o F – +122 o F) • RF Operating Humidity: Up to 95% non-condensing CERTIFICATION • FCC: YXG-ES800ZWE • IC: 11061A-ES800ZWE Cet équipement a été testé et jugé conforme aux limites s’appliquant à un appareil numérique de classe B, conformément à la Partie 15 des réglementations de la FCC. Ces limites ont été élaborées pour offrir une protection raisonnable contre les interferences nuisibles dans une installation résidentille. Cet équipement génère, utilize et peut émettre de l’énergie de fréquence radio et, s’il n’est pas installé et utilize conformément aux instructions du fabricant, peut provoquer des interférences dangereuses pour les communications radio. Toutefois, rien ne garantit l’absence d’interférences dans une installation particuliére. Si cet équipement provoque des interférences nuisibles au niveau de la réception radio ou television, ce qui peut étre determine par la mise hors, puis sous tension de l’équipment, vous étes invite à essayer de corriger les interferences en pregnant les mesures suivantes: • Réorientez ou déplaces l’antenne réceptrice. • Augmentez la distance qui sépare l’équipement et le récepteur. • Branchez l’équipement à une prise d’un circuit different de celui auquel est branché le récepteur. • Consultez le revendeur ou un technician radio/television expérimenté pour obtenir de l’aide. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Changes or modifications to this equipment not expressly approved by the party responsible for compliance (Essence Ltd.) could void the user’s authority to operate the equipment. This device complies with FCC Rules Part 15 and with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.

Essence Security International Ltd. FCC ID:YXG-ES800ZWE IC:11061A-ES800ZWE Block diagram of ES800ZWE 908.4 MHz

, August 25, 2015 Telefication B.V. Attn: Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Application for certification of a Z-Wave extender, FCC ID:YXG-ES800ZWE Dear Gentlemen, Please find attached our application for certification of a Z-Wave extender, model ES800ZWE, FCC ID:YXG-ES800ZWE, prepared in accordance with FCC Rules part 2 and part 15 subpart C section 15.231. The product testing and this application for certification were performed by Hermon Laboratories, which is listed by FCC, Registration Numbers 90623, 90624. The FCC Designation Number is US1003. Hermon Labs responsible person is Mr. Michael Nikishin, tel: +972 4626 8440, fax:+972 4628 8277, e-mail: [email protected]. Please send an invoice to Hermon Labs. We hope this application satisfies your requirements Sincerely yours, Igal Zertser, RF Engineering TL

RF_160, Issue 03 Declaration of Authorization We Name: Essence Security International Ltd. Address: 12 Abba Eban avenue, Ackerstein Tower Bldg. D, P.O.Box 2073 City: Herzliya 4612001 Country: Israel Declare that: Name Representative of agent: ............. (1) Agent Company name: Hermon Laboratories Ltd. Address: Harakevet Industrial Zone City: Binyamina 30500 Country Israel is authorized to apply for Certification of the following product(s): Product description:  Z-Wave extender Type designation (model): ES800ZWE Trademark: NA on our behalf. Date: August 9, 2015 City: Herzliya Name: Igal Zertser (2) Function: RF Engineering TL Signature: Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

Declaration of periodic operation We Essence Security International Ltd Name: Igal Zertser Address: 12 Abba Eban Avenue, Ackerstein Towers Bldg. D, P.O. Box 2073 City: Herzliya 4612001 Country: Israel. declare that the EUT ES800ZWE is controlled only by the ES8000WG hub. ES800ZWE is not otherwise supervised and does not have keep-a-live messaging functionality. ES800ZWE is a completely passive device. Date: 16/8/2015 Name: Igal Zertser Function: RF Engineering TL Signature:

FCC, Request for non-disclosure Date: 16-Jul-10 RF_501, Issue 6 Page 1 of 1 Company Name: Essence Security International Ltd. Address : 12 Abba Eban avenue, Ackerstein Tower Bldg. D, City: Herzliya 4612001 Country: Israel To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: YXG-ES800ZWE Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: (notes 2, 3, 4, 5) Date: August 25, 2015 Name and signature of applicant: Igal Zertser Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

Essence Security International Ltd. FCC ID:YXG-ES800ZWE IC:11061A-ES800ZWE Page 1 of 4 EXTERNAL PHOTOGRAPHS This document contains 3 photographs Essence Security International Ltd. FCC ID:YXG-ES800ZWE IC:11061A-ES800ZWE Page 2 of 4 Photograph No.1 ES800ZWE Z-wave extender general view Essence Security International Ltd. FCC ID:YXG-ES800ZWE IC:11061A-ES800ZWE Page 3 of 4 Photograph No.2 ES800ZWE Z-wave extender front view Essence Security International Ltd. FCC ID:YXG-ES800ZWE IC:11061A-ES800ZWE Page 4 of 4 Photograph No.3 ES800ZWE Z-wave extender rear side view

Essence Security International Ltd. FCC ID:YXG-ES800ZWE IC:11061A-ES800ZWE Page 1 of 1 Label The label is affixed on the side of the Z-wave extender as shown below. The label material is PVC with a permanent adhesive. Label location Label with FCC ID:YXG-ES800ZWE and IC:11061A-ES800ZWE is located here. The statement according to FCC part 15 §15.19(a)(3) is placed in User’s Manual, page 1 (Application exhibit User_manual_27287).

Essence Security International Ltd. FCC ID:YXG-ES800ZWE IC:11061A-ES800ZWE Page 1 of 4 INTERNAL PHOTOGRAPHS This document contains 3 photographs Essence Security International Ltd. FCC ID:YXG-ES800ZWE IC:11061A-ES800ZWE Page 2 of 4 Photograph No.1 Z-wave extender PCB internal view Essence Security International Ltd. FCC ID:YXG-ES800ZWE IC:11061A-ES800ZWE Page 3 of 4 Photograph No.2 Z-wave extender PCB front view Essence Security International Ltd. FCC ID:YXG-ES800ZWE IC:11061A-ES800ZWE Page 4 of 4 Photograph No.3 Z-wave extender PCB second side view

The Control Panel’s mains power adapter provides the power directly to the Z-Wave ® Extender board and through the board – to the Control Panel. The board’s Z-Wave ® -specific micro-controller communicates data with the WeR@Home ™ Control Panel through a UART serial port and interacts via the RF notch filter with the Z-Wave ® end-devices. Operational Description For more information, go to: http://www.essence-grp.com/smart-living/wer-at-home ESUGSL001 v1.1 The ES800ZWE is a Z-Wave ® controller dongle integrating into the WeR@Home ™ Control Panel to allow incorporation of 3rd party Z-Wave ® devices into the WeR@Home ™ system and thus integrating Smart Home applications with Essence security system. It features: • Single element – A lightweight Z-Wave ® controller • Fully compatible with the WeR@Home ™ system • Powered by the WeR@Home ™ Control Panel’s power adaptor • Low Power consuming • Simple and fast pairing process • Supported Z-wave ® devices – binary switch (on/off/dimmer), thermostat and door lock • Easy to install • Utilizes cutting-edge technology • Radio Modulation, Frequency, Data Rate and Nominal Radio Coverage: • 2FSK for 9.6/40 Kbps, 2GFSK for 100 Kbps • Main frequency – US 908.40/908.42MHz, EU 868.40/868.42MHz • SAW filter – US Center frequency = 908MHz with BW≤20MHz, EU 868MHz with BW≤20MHz • Data Rate – 9.6/40 Kbps (NRZ) • Nominal Radio Coverage – 400 meters Z-Wave ® Extender ES800ZWE Incorporating Z-Wave ® Devices into the WeR@Home ™ System © 2015 Essence Security International (E.S.I.) Ltd. Information contained within this document may change without notice Block Diagram Description

Hermon Laboratories Ltd. Harakevet Industrial Zone, Binyamina 30500, Israel Tel. +972-4-6288001 Fax. +972-4-6288277 E-mail: [email protected] Page 1 of 50 Report ID: ESSRAD_FCC.27287_rev1.docx Date of Issue: 25-Aug-15 ELECTRICAL TESTING 0839.01 TEST REPORT ACCORDING TO: FCC 47 CFR PART 15 subpart C, section 15.231; subpart B and RSS-210 issue 8 Annex 1; CES-003 Issue 5:2012 FOR: Essence Security International Ltd. Z-Wave extender Model: ES800ZWE FCC ID:YXG-ES800ZWE IC:11061A-ES800ZWE This report is in conformity with ISO/ IEC 17025. The "A2LA Accredited" symbol endorsement applies only to the tests and calibrations that are listed in the scope of Hermon Laboratories accreditation. The test results relate only to the items tested. This test report shall not be reproduced in any form except in full with the written approval of Hermon Laboratories Ltd. Report ID: ESSRAD_FCC.27287_rev1.docx Date of Issue: 25-Aug-15 Page 2 of 50 Table of contents 1 Applicant information ..................................................................................................................................................... 3 2 Equipment under test attributes .................................................................................................................................... 3 3 Manufacturer information .............................................................................................................................................. 3 4 Test details .................................................................................................................................................................... 3 5 Tests summary .............................................................................................................................................................. 4 6 EUT description ............................................................................................................................................................. 5 6.1 General information ....................................................................................................................................................... 5 6.2 Ports and lines .............................................................................................................................................................. 5 6.3 Support and test equipment .......................................................................................................................................... 5 6.4 Changes made in EUT .................................................................................................................................................. 5 6.5 Test configuration .......................................................................................................................................................... 5 6.6 EUT test positions ......................................................................................................................................................... 6 6.7 Transmitter characteristics ............................................................................................................................................ 7 7 Transmitter tests according to 47CFR part 15 subpart C and RSS-210 Annex 1 requirements .................................... 8 7.1 Periodic operation requirements ................................................................................................................................... 8 7.2 Field strength of emissions .......................................................................................................................................... 10 7.3 Occupied bandwidth test ............................................................................................................................................. 23 7.4 Conducted emissions .................................................................................................................................................. 26 7.5 Antenna requirements ................................................................................................................................................. 29 8 Unintentional emissions .............................................................................................................................................. 30 8.1 Conducted emissions .................................................................................................................................................. 30 8.2 Radiated emission measurements .............................................................................................................................. 34 9 APPENDIX A Test equipment and ancillaries used for tests ....................................................................................... 40 10 APPENDIX B Measurement uncertainties ................................................................................................................... 41 11 APPENDIX C Test laboratory description ................................................................................................................... 42 12 APPENDIX D Specification references ....................................................................................................................... 42 13 APPENDIX E Test equipment correction factors ......................................................................................................... 43 14 APPENDIX F Abbreviations and acronyms ................................................................................................................. 50 Report ID: ESSRAD_FCC.27287_rev1.docx Date of Issue: 25-Aug-15 Page 3 of 50 1 Applicant information Client name: Essence Security International Ltd. Address: 12 Abba Eban Avenue, Ackerstein Towers Bldg. D, P.O.B. 2073, Herzliya 4612001, Israel Telephone: +972 73 244 7735 Fax: +972 9772 9962 E-mail…

Text truncated - open the document above for the full version.

Essence Security International Ltd. FCC ID:YXG-ES800ZWE IC:11061A-ES800ZWE Page 1 of 7 SETUP PHOTOGRAPHS This document contains 6 photographs Essence Security International Ltd. FCC ID:YXG-ES800ZWE IC:11061A-ES800ZWE Page 2 of 7 Photograph No.1 Setup for spurious emission field strength measurements in the anechoic chamber below 30 MHz Essence Security International Ltd. FCC ID:YXG-ES800ZWE IC:11061A-ES800ZWE Page 3 of 7 Photograph No.2 Setup for spurious emission field strength measurements in the anechoic chamber in 30 – 1000 MHz range Essence Security International Ltd. FCC ID:YXG-ES800ZWE IC:11061A-ES800ZWE Page 4 of 7 Photograph No.3 Setup for spurious emission field strength measurements in the anechoic chamber above 1000 MHz range Essence Security International Ltd. FCC ID:YXG-ES800ZWE IC:11061A-ES800ZWE Page 5 of 7 Photograph No.4 Setup for field strength emission measurements, EUT close view Essence Security International Ltd. FCC ID:YXG-ES800ZWE IC:11061A-ES800ZWE Page 6 of 7 Photograph No.5 Setup for OBW measurements Essence Security International Ltd. FCC ID:YXG-ES800ZWE IC:11061A-ES800ZWE Page 7 of 7 Photograph No.6 Setup for conducted emission measurements at AC power lines
