Z9M-PAN-1-2WIRELESS CURRENT SENSOR

Panoramic Power System P3E™ Sensor Installation Guide Sensor Installation Guide 2 Copyright Notice Copyright © 2012 Panoramic Power Ltd. All rights reserved. Sensor Installation Guide 3 Documented Releases Revision Number Revision Description Revision Date 1 New version October 2011 2 Updates April 2012 Sensor Installation Guide 4 Contents Overview .................................................................................................. 5 Workflow .................................................................................................. 5 Unpacking the Hardware ........................................................................ 5 Safety Precautions .................................................................................... 6 Hardware Description ............................................................................. 6 Mapping the Site ...................................................................................... 7 Installing a Sensor .................................................................................... 7 Attaching the Sensors to the Circuits ...................................................... 7 Registering the Installed Sensor ............................................................. 9 Post Installation Troubleshooting .......................................................... 10 Monitoring Sensor Activity ................................................................... 10 Uninstalling a Sensor ............................................................................. 10 Sensor Specifications .............................................................................. 10 Troubleshooting ..................................................................................... 12 Support ................................................................................................... 12 Sensor Installation Guide 5 Overview Panoramic Power P3E™ System monitors electrical energy consumption at individual circuit level and detects excess usage allowing organizations to identify and reduce energy and maintenance expenses. P3E consists of wireless, self-powered sensors engineered to allow for rapid, non-invasive installation, with almost no disturbance to operations. Sensors are easily attached to circuit breakers by just snapping them on to the outgoing electrical wire. They monitor the flow of electricity through the resulting magnetic field and also use the field as a power source. The sensors do not require any maintenance. Data collected by the sensors is sent to a bridge, which, in turn, transfers the information to the P3E server through the Internet, using Cloud technology. The sensors report the energy consumption to the bridge at sub-minute intervals. Consumption reports can be retrieved through the system. This user guide explains how to install the sensors. Workflow Sensor installation consists of the following steps: 1. Map the circuits. See Panoramic Power Deployment Tool User Guide. 2. Physically attach the sensors to the wires (this guide). 3. Monitors the proper functioning of the sensors. See Panoramic Power Deployment Tool User Guide. Unpacking the Hardware Sensors are shipped in 30-unit packs. The package includes the following items: • 30 sensors. • 1 sensor opener Sensor Installation Guide 6 Safety Precautions • The sensor must be installed only on an insulated conductor. • The conductor’s diameter and maximum current must match the specification printed on the sensor. • The sensor should be installed and removed only by a qualified electrician. • Installation must not be performed on a live wire for reasons of safety and random shock hazard. Power supply to the panel must be shut off before and during installation. • The sensor must not be installed lying or touching busbars or any other non-insulated, exposed conductors. • Installation is possible both on external entry/exit conductors before the terminal strip, as well as both ends of the circuit breaker. The least cramped, most accessible location should be chosen for installation. The sensor should be installed such that the arrow points in the direction of the load. Hardware Description This procedure must be carried out only by a certified electrician. The following sensors are supported: • 32A/63A , snapped-in cover. • 225A, screwed cover. Sensor Installation Guide 7 The sensors are shipped closed, in order to protect the core from dust and other pollutants. Open a sensor only when preparing to install it. Figure 1. 32A/63A Figure 2. 225A Figure 3. Core The sensor comes with a label fixed on it, containing a unique ID. Mapping the Site See Panoramic Power Deployment Guide. Installing a Sensor This process is divided into two stages: • Physically attaching the sensors to the circuit wires; • Registering the installation in Panoramic Power System. Attaching the Sensors to the Circuits To install a sensor, follow these steps: 1. Open the cover of the electrical panel board. 2. Make sure you have a plan that indicates the circuits to be monitored and the sensor IDs associates with each such circuit. Identify the circuit breaker on which you would like to install the sensor. Sensor Installation Guide 8 The ID appears on the label fixed to the sensor. 3. Pick a sensor and slide the opener into position from the labeled side towards the cover. Figure 4. Slide opener into position 4. Snap the opener's pins into the four holes (in 225A unscrew the cover). Figure 5. Snap the opener into the sensor holes. Sensor Installation Guide 9 5. Press the two sides of the opener to release the sensor cover. Figure 6. Press the opener to release the cover. 6. Make sure the four core surfaces are free of dust or any other particles. If necessary, wipe it with a dry cloth Note Whenever possible, avoid installing the sensor behind wires and position it at the front of the panel board. 7. Place the opening of the sensor on a clean section of the electrical cable with t…

Text truncated - open the document above for the full version.

Panoramic Power P3E™ System monitors electrical energy consumption at individual circuit level and detects, via P3E™ sensors attached to the circuits, excess usage, allowing organizations to identify and reduce energy and maintenance expenses. The Panoramic Power P3E™ sensors are non-invasive, self-powered, miniature wireless devices that snap-fit around the hot-wires in an electrical panel board. The sensor is powered by harvesting energy from the hot-wire via inductive coupling using current transformer. The sensor has a low power RF Transmitter which uses 2 Level GFSK modulation scheme. The Data to be transmitted includes: 1. Hot-wire current sampled by the current transformer 2. On message (as soon as there is enough power for the sensor to operate) 3. Off message (last message before the sensor is losing power due to the shutting off the power from the hot-wire

Test Report E118362.00 Panoramic Power Ltd. Page 1 of 31 ITL FCCMASVE 1.25 26 March 2003 DATE: 10 July 2012 I.T.L. (PRODUCT TESTING) LTD. FCC Radio Test Report for Panoramic Power Ltd. Equipment under test: Wireless Self-Powered Branch- Circuit Level Current Sensor PAN-1-2-225-US Written by: ____________________________ I. Smilansky, Documentation Approved by: _____________________________ A. Sharabi, Test Engineer Approved by: _____________________________ I. Raz, EMC Laboratory Manager This report must not be reproduced, except in full, without the written permission of I.T.L. (Product Testing) Ltd. This report relates only to items tested. Test Report E118362.00 Panoramic Power Ltd. Page 2 of 31 ITL FCCMASVE 1.25 26 March 2003 Measurement/Technical Report for Panoramic Power Ltd. Equipment under test: Wireless Self-Powered Branch-Circuit Level Current Sensor FCC ID: Z9M-PAN-1-2 This report concerns: Original Grant: x Class I change: Class II change: 47CFR15 Section 15.249 Measurement procedure used is KDB 558074 D01 18 January 2012 and ANSI C63.4-2003. Application for Certification Applicant for this device: prepared by: (different from "prepared by") Ishaiahou Raz Adi Shamir ITL (Product Testing) Ltd. Panoramic Power Ltd. Kfar Bin Nun 20 Atir Yeda St. D.N. Shimshon 99780 Kfar Saba, 44643 Israel Israel Tel: +972-8- 918-6117 Tel: 972-9- 766-7600 Fax: +972-8- 915-3101 Fax: 972-9- 766-7610 Email: [email protected] Email: [email protected] Test Report E118362.00 Panoramic Power Ltd. Page 3 of 31 ITL FCCMASVE 1.25 26 March 2003 TABLE OF CONTENTS 1. GENERAL INFORMATION ------------------------------------------------------------------------------- 4 1.1 Administrative Information ................................................................................. 4 1.2 List of Accreditations ......................................................................................... 5 1.3 Product Description ........................................................................................... 6 1.4 Test Methodology .............................................................................................. 6 1.5 Test Facility ....................................................................................................... 6 1.6 Measurement Uncertainty ................................................................................. 6 2. SYSTEM TEST CONFIGURATION --------------------------------------------------------------------- 7 2.1 Justification ........................................................................................................ 7 2.2 Special Accessories .......................................................................................... 7 2.3 Equipment Modifications ................................................................................... 7 2.4 Configuration of Tested System ........................................................................ 7 3. RADIATED MEASUREMENTS TEST SETUP PHOTOS ----------------------------------------- 8 4. FIELD STRENGTH OF FUNDAMENTAL ------------------------------------------------------------- 9 4.1 Test Specification .............................................................................................. 9 4.2 Test Procedure .................................................................................................. 9 4.3 Test Results....................................................................................................... 9 4.4 Test Instrumentation Used, Field Strength of Fundamental ........................... 14 5. SPURIOUS RADIATED EMISSION 9 KHZ - 30 MHZ ---------------------------------------------15 5.1 Test Specification ............................................................................................ 15 5.2 Test Procedure ................................................................................................ 15 5.3 Test results ...................................................................................................... 15 5.4 Test Instrumentation Used, Radiated Measurements 9 kHz – 30 MHz .......... 16 5.5 Field Strength Calculation ............................................................................... 16 6. SPURIOUS RADIATED EMISSION 30 MHZ- 10 GHZ --------------------------------------------17 6.1 Test Specification ............................................................................................ 17 6.2 Test Procedure ................................................................................................ 17 6.3 Test Results..................................................................................................... 17 6.4 Test Instrumentation Used, Radiated Measurements 30 MHz – 10 GHz ....... 20 6.5 Field Strength Calculation ............................................................................... 20 7. BAND EDGE ATTENUATION --------------------------------------------------------------------------21 7.1 Test Specification ............................................................................................ 21 7.2 Test Procedure ................................................................................................ 21 7.3 Test Results..................................................................................................... 21 7.4 Test Instrumentation Used, Band Edge Attenuation ....................................... 24 8. APPENDIX A - CORRECTION FACTORS ----------------------------------------------------------25 8.1 Correction factors for CABLE ......................................................................... 25 8.2 Correction factors for CABLE ......................................................................... 26 8.3 Correction factors for CABLE ......................................................................... 27 12.6 Correction factors for LOG PERIODIC ANTENNA ........................................ 28 8.4 Correction factors for LOG PERIODIC ANTENNA .…
