1 miCoach X_CELL User Manual 2 Table of Contents 1. Welcome to miCoach 1.1 miCoach X_CELL Overview 1.2 miCoach X_CELL 1.3 Product Features 1.4 Product Compatibility 2. Using miCoach X_CELL with your smartphone 2.1 miCoach Sports App 2.2 Wearing miCoach X_CELL 2.3 Pairing miCoach X_CELL with your smartphone 2.4 Working out with miCoach X_CELL and your smartphone 3. Synchronizing your miCoach X_CELL using your smartphone 4. Replacing the X_CELL Battery 5. Care and Maintenance 6. Specifications 6.1 Technical data 6.2 Trademark & Copyright 6.3 Regulatory compliance 6.4 Medical disclaimer 6.5 Precautions 6.6 Trademark Footnote – Bluetooth® 7. Customer Service Information 7.1 Warranty 7.2 Support 3 1. Welcome to miCoach Thank you for your interest in miCoach and congratulations on purchasing the miCoach X_CELL. This user manual provides you with everything you need to know to use the miCoach X_CELL 1.1 miCoach X_CELL Overview ON/OFF button Battery cover Snaps to attach to Textile Strap or Compatible miCoach apparel Align the green dots to ensure the battery cover is closed 4 1.2 miCoach X_CELL The miCoach X_CELL can be used in the following scenarios: • On-pitch usage (e.g. Basketball, Football/Soccer, Tennis, Handball, American Football, etc.); miCoach X_CELL will log detailed data which will be used by the miCoach Sports App to provide an assessment of the player’s performance after the game or practice session. A minimum of 7 hours of activity data is logged by miCoach X_CELL. • As a regular Heart Rate Monitor during your training/exercise (e.g. Running, Fitness, etc.) by using the miCoach App. 1.3 Product Features Measures : • Sprint Force (acceleration - forward/backward movement) • Cut Force (right / left cuts / changes in direction) • Jump Force • Heart Rate • Workout Time On-Board Memory stores all measurements: A minimum of 7 hours of activity data is logged by miCoach X_CELL, with oldest or already downloaded data automatically being over- written by new data. Wireless data transfer: Workout data/performance is transferred wirelessly to your Bluetooth Smart Ready® (works with miCoach Sports app). Compare, share, compete View results on the miCoach Sports App using your smartphone. Compare and share with Facebook and Twitter. 5 1.4 Product Compatibility The miCoach X_CELL works in combination with the following products: Smartphones with Bluetooth Smart Ready® technology and Heart Rate compatible Garments 2. Using miCoach X_CELL with your smartphone 2.1 miCoach Sports App The miCoach Sports App is the key to communicating to X_CELL. You can load your latest data, manage results and get feedback on your performance. The app will tell you how you can improve as an athlete. Most important for users with miCoach X_Cell for smartphones: You must download the miCoach Sports App from the App Store before getting started. For additional product information, please visit micoach.com/setup 6 2.2 Wearing miCoach X_CELL There are two ways of wearing miCoach X_CELL: 1. With the Textile Strap (X_CELL on your chest) 2. With miCoach compatible apparel, such as a Techfit shirt (X_CELL on the back of your neck) Follow these steps to wear the miCoach X_CELL correctly: 1. Clip miCoach X_CELL to the two snaps on the Textile Transmitter Strap or heart rate- sensing garment, as shown in the image below: h 7 For Textile Strap usage: For Techfit Shirt usage: 2. The electrodes on the strap should be centered on your chest with the adidas logo on the front of the module positioned right side up (i.e. facing upwards). This is the same for the adidas sensing apparel. 2. The shirt should be fit tightly with no folds around your upper body (pull the shirt completely down while wearing it). 3. Adjust the Textile Transmitter Strap to fit tightly just below your pectoral muscles or breasts on your torso, against the skin. The strap should not dangle or move during activity. 3. The X_CELL device on your neck should be centered in between your shoulder in the center of your upper body. 4. For heart rate use: The Textile Transmitter Strap must be snuggly fitted and the sensor fabrics must be properly moistened in order to pick up the heart rate (if applicable) (see point 2). 4.For heart rate use: Make sure the heart rate sensors on the front of the Techfit shirt lie flat on the rib cage and don’t shift around as you move. The electrodes should be moistened in order to pick up your heart rate before working out. 5. Wear the X_CELL strapped to your body for a few minutes prior to your workout. Trouble-Shooting: - Lotions or oil between the skin and the strap/shirt may interfere with conductivity, so you may need to gently cleanse the skin to remove any residue. - Check that sizing instructions have been followed. Does the strap/shirt fit snugly? Is the heart rate sensor of the shirt flat on the rib cage? - Is the harness still well attached to the shirt? No peeling of the edges? 8 2.3 Pairing miCoach X_CELL with your smartphone Before pairing your miCoach X_CELL, make sure Bluetooth® is enabled in your smartphone’s settings. Once you have enabled Bluetooth® on your smartphone, pair your miCoach X_CELL with your smartphone. To do this:  Make sure you’re wearing the miCoach X_CELL correctly (see section 2.2 for details).  Activate Bluetooth® connection in miCoach X_CELL by a “quick press” of the ON/OFF button (see 1.1 for diagram). 2. Open the miCoach Sports App, go to Settings, select “Sensors” and add miCoach X_CELL. Note1: The miCoach Sports App searches for all X_CELLs (all Bluetooth® Smart devices) within range (2,5 meters). Make sure to select your miCoach X_CELL. Note2: In heart rate mode the miCoach X_CELL will automatically return to ultra-low power sleep mode when the device is no longer stimulated by your heartbeat. Trouble-shooting: If pairing fails, try the following: 1. Make sure you’re wearing the miCoach X_CELL correctly (see section 2.2 for details). 2. Ensure that your miCoach X_CELL is in range and there…

Text truncated - open the document above for the full version.

Power of Attorney Date: ____Aug 28, 2012____ To Whom It May Concern: Hellen Wang, whom from SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Shenzhen Branch is authorized to act on our behalf, until otherwise notified, for applications to PHOENIX TESTLAB GmbH. We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b) , to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: ___12 months_____

Request for Confidentiality Date: Dec 10, 2012 Subject: Confidentiality Request for: _FCC ID:ZLGXCELL _____ Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual *Note: ______(Insert Explanation as Necessary)______ adidas AG has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify PHOENIX in the event information regarding the product or the product is made available to the public. PHOENIX will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. The asterisked items (*) require further justification before permanent confidentiality will be allowed. These also currently require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be: “The EUT is FULLY potted using a non-removable epoxy based material. Removal of potting material causes irreparable damage to internal circuitry. See photographs exhibits that outline the device before and after potting.”

1 Photographs - EUT Constructional Details Test mode: Z51349

SZ997 ADIDAS LASER MARKING (ON REAR CAB) SN:11122334444444 MODEL: Z51349 FCC ID: ZLGXCELL Made in China IC:9722A-XCELL SN: XXX12360000007 MODEL: Z51349 M M / Y Y 1:1 Font:AdiHaus(4pt) Font:AdiHaus(4pt) Height:1mm 5MM 7MM Laser Marking information: 111 = 107 (Product Id) 22 = 12(2012), 13(2013) ... (Production year) 33 = 01, 02... (Production week) 4444444 = 0000001, 0000002...(Serialized number) MODEL: Z51349 MM/YY MM = 01~12 (Production month) YY = 12(2012), 13(2013)... (Production year)

1 Photographs - EUT Constructional Details Test mode: Z51349

SGS-CSTC Standards Technical Services Ltd. No. 1 W orkshop, M-10, Middle section, Science & Technology Park, Nanshan District, Shenzhen, Guangdong, China 518057 Telephone: +86 (0) 755 2601 2053 Fax: +86 (0) 755 2671 0594 Email: [email protected] Report No.: SZEM130600335601 Page: 1 of 41 Authorized Signature: Jack Zhang EMC Laboratory Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 1 Cover page FCC REPORT Application No: SZEM1306003356RF Applicant: adidas Canada Ltd. Manufacturer: IDT Technology Limited Factory: IDT Technology Limited Product Name: X_CELL Model No.(EUT): Z51349 Add Model No.: adidas FCC ID: ZLGXCELL Standards: 47 CFR Part 15, Subpart C (2012) Date of Receipt: 2013-06-27 Date of Test: 2013-07-12 to 2013-07-22 Date of Issue: 2013-07-30 Test Result: PASS * * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Ltd. Report No.: SZEM130600335601 Page: 2 of 41 “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 2 Test Summary Test Item Test Requirement Test method Result Antenna Requirement 47 CFR Part 15, Subpart C Section 15.203/15.247 (c) ANSI C63.10 2009 PASS Conducted Peak Output Power 47 CFR Part 15, Subpart C Section 15.247 (b)(3) KDB558074 D01 PASS 6dB Occupied Bandwidth 47 CFR Part 15, Subpart C Section 15.247 (a)(2) KDB558074 D01 PASS Power Spectral Density 47 CFR Part 15, Subpart C Section 15.247 (e) KDB558074 D01 PASS Pseudorandom Frequency Hopping Sequence 47 CFR Part 15, Subpart C Section 15.247(b)(4)&TCB Exclusion List (7 July 2002) ANSI C63.10 (2009) PASS Band-edge for RF Conducted Emissions 47 CFR Part 15, Subpart C Section 15.247(d) KDB558074 D01 PASS RF Conducted Spurious Emissions 47 CFR Part 15, Subpart C Section 15.247(d) KDB558074 D01 PASS Radiated Spurious Emissions 47 CFR Part 15, Subpart C Section 15.205/15.209 ANSI C63.10 2009 PASS Band Edge (Radiated Emission) 47 CFR Part 15, Subpart C Section 15.205/15.209 ANSI C63.10 2009 PASS SGS-CSTC Standards Technical Services Ltd. Report No.: SZEM130600335601 Page: 3 of 41 “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercis…

Text truncated - open the document above for the full version.

1 Photographs - EUT Test Setup (Test Model No.: Z51349) 1.1 Radiated Emission
