ZY4ABC23Curtain Motor

indoor use only !! 1.3A 1.3B User manual Curtain MotorABC-23-W120WARNING: Important safety instructions. F ollo w all instructions, since incorrect installation can lead to severe injury.Do not make repairs yourself. Do not attempt to open the device or disassemble it. You run the risk of electric shock and voiding the limited warranty. No user-serviceable parts are inside. WARNING: 1. General informationThe ABC-23 is a curtain motor to motorize curtain tracks. The motor can be operated with a coulisse remote contr ol or manually by pulling on the curtain. Limits and favorite position are set with the remote control. 1. 2. 1. 2. Step 6: Exit the program-mode b y pressing the program button again Then set the right endposition Use the left and right buttons to go to the left endposition Set the position by pressing the center + left button First set the left endposition Step 5: Set endpositions Use the left and right buttons to go to the right endposition Set the position by pressing the center + right button Action confi rmed: curtain stops stepping for 3 secondsAction confi rmed: curtain stops stepping for 3 seconds Exit program mode: Shortly press program button 1.3 Connectors and buttons Program button IMPORTANT : When the mains cable is permanently connected, a readily accessible disconnect device shall be incorporated external to the motor.When there is a pluggable connecter installed on the mains cable, the socket-outlet shall be installed near the motor and shall be easily accessible. Mains cable 230V 120V Neutral Blue White Phase Brown Black Ground Yellow-green Green 2. Programming and operating (also possible by using ‘SingleSelect ’, see manual r emote control*) 2.1 First use Step 1: Connect the motor with the pow ersupply S tep 2: Set the curtain in program-mode by pushing the program button Step 3: Pair the curtain to a channel/remote Choose channel by pressing the ChannelSelect button Pair/unpair by pressing the program button on the backside of the remote Press the left + right to change the rotation direction Step 4: Switch the rotating direction Set to program mode: Shortly press program button Program mode: Curtain is stepping... Action confi rmed: curtain stops stepping for 3 secondsAction confi rmed: curtain stops stepping for 3 seconds If you press left and the curtain goes right, the rotation direction of the curtain has to be switched. *Manuals are also available on our website www .coulisse.com 220 250 15 70 52 1.1 General dimensions Type Pow er S upply Rated Power Torq-Speed Curtain weight ABC-23-W 230V AC 50Hz 0.23A - 45W 0,8Nm, 20 cm/s 50kg ABC-23-W120 120V AC 60Hz 0.46A - 45W 0,8Nm, 24 cm/s 50kg 1.2 Performances Type Max operating time Operating temp. M ax. channels to pair Deg. of protection ABC-23-W & W(120) 4 min. 5 - 60° 32 channels IP20 Coulisse B.V., Vonderweg 48, 7468 DC E nter, The Netherlands ABC-23-U_R0_ Do not make repairs yourself . D o not attempt to open the device or disassemble it. You run the risk of electric shock and voiding the limited warranty. No user-serviceable parts are inside. WARNING: - Do not let children play with the curtain and/or remote control.- Only use powersupplies or batteries that comply with the specifi cations on the motor.- In case of malfunction, unplug the device or remove the batteries and contact your dealer.- Take care that the curtain can move freely and is not blocked by objects.- Take care that the powersupply cable is out of reach for children.- Do not paint the device.- Keep the device dry. 5. Service & Support 4.2 Cleaning Follow these general rules when cleaning the outside of the device and its components:- Make sur e the device is unplugged. - U se a damp, soft, lint-free cloth. Avoid getting moisture in openings. - Don’t use aerosol sprays, solvents, alcohol, or abrasives. Do not make repairs yourself. Do not attempt to open the device or disassemble it. You run the risk of electric shock and voiding the limited warranty. No user-serviceable parts are inside. WARNING: Online ResourcesFor the latest information and updated manuals go to www.coulisse.com.Obtaining Warranty ServiceFirst follow the advice in this booklet and then go to your local dealer. If the product appears to be damaged or does not function properly, go to your local dealer for instructions on how to obtain warranty service. 3. Tips & Troubleshooting Please check www.coulisse.com for the latest tips and troubleshooting guide. 4. Safety & Cleaning 4.1 Safety GB0 Shortly press pr ogram button P rogram mode: is stepping... - Reset to factory defaults & Erase all paired channels/remotes Hold program button untill curtain stops stepping for the second time (ca. 10 sec.) 10 sec 2.2 Operating - Control by remote (see manual r emote control) 2.4 Reset Shortly press pr ogram button P rogram mode: is stepping... - Reset to factory defaults Hold program button untill curtain stops stepping and steps once (ca. 15 sec.) 15 sec Additional curtain settings: Available S witch rotation direction Yes Favorite position Yes Domotica Box Yes 2.5 Additional curtain settings We refer to the manual of the Coulisse Remote control to set the additional curtain settings. - M anual Control (by pulling) From factory default ‘Direct take over’ is activated. A motor will take over the command directly and runs to it’s endlimit. Switch this function off when it is recommended that the motor must move in small steps. 2.3 Direct take over Pull curtain to start the motor Curtain mov es to end limit - M anual Control (by button) Shortly press program button Pr ogram mode: Blind is stepping... Hold program button untill blind stops stepping (5 sec. ) 5 sec Hold program button for mor e than 2 sec. C urtain moves as long as button is pressed (max. 15 sec.) For moving in opposite direction release button and hold program button again for more than 2 sec. Disclaimer:© Copyright CoulisseAll rights reserved. No part of this publication may be r eproduced, stored in a retrieval sys…

Text truncated - open the document above for the full version.

July 23, 2012 To: SIEMIC, INC. 775 Montague Expressway Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, ______ Coulisse B.V. ___hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product Description: Curtain motor Model name: ABC-23-W120 FCC ID: ZY4ABC23 We affirm that between SIEMIC and _ Coulisse B.V. __, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities.

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 July 23 2012 To : Federal Communications Commission Authorization and Evaluation Division 775 Montague Expressway Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: ZY4ABC23 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application.

Lable Location：

Antenna

Page 1 of 54 FCC ID: ZY4ABC23 ACCURATE TECHNOLOGY CO. LTD REPORT NO. ATE20121494 FCC CERTIFICATION On Behalf of Coulisse B.V. Curtain motor Model No.: ABC-23-W120 FCC ID: ZY4ABC23 Prepared for : Coulisse B.V. Address : Vonderweg 48, 7468 DC Enter The Netherlands Prepared by : ACCURATE TECHNOLOGY CO. LTD Address : F1, Bldg. A, Changyuan New Material Port, Keyuan Rd. Science & Industry Park, Nanshan, Shenzhen, Guangdong P.R. China Tel: (0755) 26503290 Fax: (0755) 26503396 Report Number : ATE20121494 Date of Test : Jul. 4-Aug.6, 2012 Date of Report : Aug. 6, 2012 Page 2 of 54 FCC ID: ZY4ABC23 ACCURATE TECHNOLOGY CO. LTD REPORT NO. ATE20121494 TABLE OF CONTENTS Description Page Test Report Certification 1. GENERAL INFORMATION .......................................................................................................... 4 1.1. Description of Device (EUT)....................................................................................................................4 1.2. Description of Test Facility ......................................................................................................................4 1.3. Measurement Uncertainty.........................................................................................................................5 2. MEASURING DEVICE AND TEST EQUIPMENT ..................................................................... 6 3. SUMMARY OF TEST RESULTS................................................................................................... 7 4. FUNDAMENTAL AND HARMONICS RADIATED EMISSION FOR SECTION 15.249(A) 8 4.1. Block Diagram of Test Setup....................................................................................................................8 4.2. The Emission Limit ..................................................................................................................................9 4.3. Configuration of EUT on Measurement ...................................................................................................9 4.4. Operating Condition of EUT ....................................................................................................................9 4.5. Test Procedure ........................................................................................................................................10 4.6. The Field Strength of Radiation Emission Measurement Results ..........................................................11 5. SPURIOUS RADIATED EMISSION FOR SECTION 15.249(D) ............................................. 14 5.1. Block Diagram of Test Setup..................................................................................................................14 5.2. The Emission Limit For Section 15.249(d) ............................................................................................15 5.3. EUT Configuration on Measurement .....................................................................................................15 5.4. Operating Condition of EUT ..................................................................................................................15 5.5. Test Procedure ........................................................................................................................................16 5.6. The Emission Measurement Result ........................................................................................................17 6. BAND EDGES ................................................................................................................................. 20 6.1. The Requirement ....................................................................................................................................20 6.2. EUT Configuration on Measurement .....................................................................................................20 6.3. Operating Condition of EUT ..................................................................................................................20 6.4. Test Procedure ........................................................................................................................................20 6.5. The Measurement Result ........................................................................................................................20 7. ANTENNA REQUIREMENT........................................................................................................ 27 7.1. The Requirement ....................................................................................................................................32 7.2. Antenna Construction .............................................................................................................................32 APPENDIX I ( TEST CURVES) Page 3 of 54 FCC ID: ZY4ABC23 ACCURATE TECHNOLOGY CO. LTD REPORT NO. ATE20121494 Test Report Certification Applicant : Coulisse B.V. Manufacturer : NINGBO DOOYA MECHANIC & ELECTRONIC TECHNOLOGY CO., LTD EUT Description : Curtain motor (A) MODEL NO.: ABC-23-W120 (B) Trade Name. Coulisse B.V. (C) POWER SUPPLY: 120V /60Hz Measurement Procedure Used: FCC Rules and Regulations Part 15 Subpart C Section 15.249 ANSI C63.4: 2003 The device described above is tested by ACCURATE TECHNOLOGY CO. LTD to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 15 Subpart C Section15.249 limits. The measurement results are contained in this test report and ACCURATE TECHNOLOGY CO. LTD is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the Equipment Under Test (EUT) is to be technically compliant with the FCC requirements. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of ACCURATE TECHNOLOGY CO. LTD. Date of Test : Jul. 4-Aug. 6, 2012 Prepared by : (Engine…

Text truncated - open the document above for the full version.

Radiated Spurious emission (up to 1G) Radiated Spurious emission (above 1G) Conducted emission:
