ZY4CM55Motionblinds Wifi Matter Bridge

RESET >50 cm Abstand >50 cm distance Dazu den Reset-Button auf der Rückseite der Bridge mit einem spitzen Gegenstand lange gedrückt halten und in einem dieser Reset-Modi loslassen. LED leuchtet grün: WLAN Credentials werden zurückgesetzt LED leuchtet rot: Zurücksetzen in den Werkszustand Wichtig: Nur wenn du den Button loslässt, wenn die LED in der gewünschten Farbe leuchtet, wird der entsprechende Reset-Modus ausgeführt. To reset, you need to press and hold the reset button on the back of the bridge with a thin object and release it in one of these reset modes. LED lights up green: WLAN credentials are reset. LED lights up red: Factory reset. Important: Only release the button when the LED is lit in the desired color to execute the corresponding reset mode. Zurücksetzen / Reset Coulisse B.V. Vonderweg 48, 7468DC Enter, The Netherlands CM-55 S/N: B8.0000.0000 MAC: 40-66-7a-38-ea-44 Reset-Taster Reset button 3 Scan the QR code on the bottom of the bridge. The QR code on the bottom side is essential for setting up the Matter Bridge and must therefore not be lost or damaged. Additional storage (e.g., as a photo) is recommended. Scanne den QR-Code auf der Unterseite der Bridge. Der QR-Code auf der Unterseite ist zwingend notwendig zur Inbetriebnahme der Matter Bridge und darf deshalb nicht verloren oder beschädigt werden. Eine zusätzliche Speicherung (bspw. als Foto) wird empfohlen. 4 Wähle Dein WLAN-Netzwerk aus der Liste und gib das zugehörige Netzwerkpasswort ein. Vorzugsweise „Passwort merken“ anhaken. Beim Verbindungsaufbau wechselt die LED der Bridge zu orange und nach erfolgreichem Verbinden schließlich zu grün. Jetzt ist die Matter Bridge in dein WLAN eingebunden. Select your Wifi network from the list and enter its network password. It’s recommended to tick „Remember password“. During the connection process, the bridge‘s LED will change to orange and fi nally to green after successful connection. Now the Matter Bridge is connected to your Wi-Fi. Inbetriebnahme / Getting Started 1 Connect your bridge to power using the power adapter (connect only to easily accessible power outlet!). The LED will illuminate blue, indicating that the bridge is in pairing mode. Verbinde deine Bridge über das Netzteil mit dem Strom (Anschluss nur an leicht zugängliche Steckdose!). Die LED leuchtet blau und signalisiert, dass sich die Bridge im Pairing Mode befi ndet. 2 Installiere und öffne die Motionblinds Matter bridge App. Install and start the Motionblinds Matter bridge App. 5 Now go to the home screen of the app. You can add home, rooms, devices, and additional bridges via the plus symbol. Gehe nun zum Home Screen der App. Über das Plus-Symbol kannst du Zuhause, Räume, Geräte und weitere Bridges hinzufügen. Eine detaillierte Bedienungsanleitung der App fi ndest du hier: For a detailed user manual of the app, scan the QR code below: DEENWerte || Values Geräte-KurzbezeichnungDevice short name Versorgungsspannung: Eingang SteckernetzteilPlug-in mains adapter: Input voltage Leistungsaufnahme SteckernetzteilPower consumption plug-in adapter Versorgungsspannung und maximale StromaufnahmeSupply voltage and current consumption, max. Leistungsaufnahme RuhebetriebStandby power consumption SchutzartDegree of protection UmgebungstemperaturAmbient temperature Abmessungen (B x L x H)Dimensions (W x L x H) GewichtWeight Funk-FrequenzbänderRadio frequency bands Funk-EmpfängerkategorieReceiver category CM-55 100 – 240V / 50 Hz <10W 5V DC / max. 1,5A <1W IP 20 5 – 35 °C 90 x 90 x 23 mm 80g WLAN + Bluetooth: 2.400 – 2.480 GHz SRD: 433 MHz SRD Kategorie 2 Typ. Funk-FreifeldreichweiteTyp. open air RF range Duty CycleDuty Cycle >100 m WLAN + Bluetooth: <100%, 433 MHz: <10% Technische Änderungen vorbehalten Subject to technical changes Netzteil Stecker (USB-C) - Dieses Symbol bedeutet positive und negative Spannungsausgabe Power adapter (USB-C) - This icon means voltage output positive and negative polarity The power adapter model: CW0501500 – Shenzhen Cenwell Technology Co. – Longhua, Shenzhen, Guangdong, China Schutzklasse II Gerät mit doppelter Isolierung. Kein Anschluß an den Schutzleiter notwendig. This equipment is a Class II or double insulated electrical appliance. It has been designed in such a way that it does not require a safety connection to electrical earth. Nur für den Gebrauch in Innenräumen / Indoor use only Gleichspannung / Direct current Wechselspannung / Alternating current Dieses Produkt trägt das Entsorgungssymbol für Elektromüll und elektronische Geräte (WEEE). Das bedeutet, dass dieses Produkt gemäß der europäischen Direktive 2012/19/EU gehandhabt werden muss, um mit minimalen umweltspezifi schen Auswirkungen recycelt oder zerlegt werden zu können. Weitere Informationen erhaltst du von deiner regionalen Behörden. Elektronikprodukte, die nicht durch den selektiven Entsorgungsvorgang erfasst werden, stellen durch das Vorhandensein potenziell gefährlicher Substanzen umwelt- und gesundheitsrelevante Risiken dar. This product bears the selective sorting symbol for waste electrical and electronic equipment (WEEE). This means that this product must be handled pursuant to European Directive 2012/19/ EC in order to be recycled or dismantled to minimize its impact on the environment. For further information, please contact your local or regional authorities. Electronic products not included in the selective sorting process are potentially dangerous for the environment and human health due to the presence of hazardous substances. Anleitung sorgfältig lesen und aufbewahren Read the manual carefully and keep it in a safe place Coulisse B.V. Vonderweg 48, 7468DC Enter, The Netherlands CM-55 S/N: B8.0000.0000 MAC: 40-66-7a-38-ea-44 Reset-Taster Status LED QR-Code zur Inbetriebnahme QR code for setup Reset button Netzteilbuchse USB-C USB-C power supply socket Matter Wi-Fi Bridge Bitte beachte die umseitigen Sicherheitshinweise Please observe the safety instructions on the back page DE EN Documentation 2024, Coulis…

Text truncated - open the document above for the full version.

2024-08-05 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for FCC ID: ZY4CM55 [Coulisse B.V.] certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Signature: Name: Bas Klein Tuente 2024-01-25 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for FCC ID: 2BAXLCK24NS Coulisse B.V. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Signature: Name: Bas Klein Tuente

U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company FCC US Agent, LLC FRN: 0033402884 Contact Name: Tim Payne Street Address3722 Illinois Avenue City/Province/Zip: Saint Charles, IL, 60174 Telephone No: +1 708-571-3148 Email: [email protected] Signature: Signed by Tim Payne: This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: Coulisse B.V. FRN: 0021133137 Grantee Code: ZY4 FCC ID: ZY4CM55 Contact Name: Bas Klein Tuente Street Address: Vonderweg 48 City/Province/Zip: 7468DC Enter, Netherlands Telephone No: +31 547855555 Email: [email protected] Signature: Date: 2024-09-17 Signed by Bas Klein Tuente Manager Engineering

Date: 2024-08-05 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (Motionblinds Wifi Matter Bridge / CM-55 / FCC ID: ZY4CM55) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (Block Diagrams, Schematics, Operational Descriptions) required to be submitted with this application be permanently withheld from public review. The above documents are company proprietary information that could never get into the possession of your competition. Please contact me if there is any information you may need. Sincerely, Signature: Name: Bas Klein Tuente Applicant: Coulisse B.V. Address: Vonderweg 48, 7468DC Enter, Netherlands TEL: +31 547855555

date: 2024-08-05 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Eurofins Electrical Testing Service (Shenzhen) Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signature: Name: Bas Klein Tuente Applicant: Coulisse B.V. Address: Vonderweg 48, 7468DC Enter, Netherlands TEL: +31 547855555

Related to EFGX24060324-IE-02-E01&E02&E03&04 Radiofrequency radiation exposure evaluation: mobile devices RESULT : Pass Test Specification Test item : Motionblinds Wifi Matter Bridge Identification / Type No. : CM-55 FCC ID : ZY4CM55 Test standard : CFR47 FCC Part 2: Section 2.1091 CFR47 FCC Part 1: Section 1.1310 FCC KDB Publication 447498 D04  FCC requirements FCC requirement: Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 20cm normally can be maintained between the user and the device. MPE Calculation Method according to KDB 447498 D04 Related to EFGX24060324-IE-02-E01&E02&E03&04 a) EUT RF Exposure Evaluation operations For 433.92MHz, E.I.R.P = 89.27- 95.2 = -5.93dBm Test Mode Measured Power (dBm) ERP (dBm) ERP (mW) Minimum Separation Distances (cm) Limit (mW) BLE 9.10 10.37 10.89 20 3060 BR+EDR 11.88 13.15 20.65 2.4GHz band Wi-Fi 13.93 14.82 30.33 433.92MHz -5.93 -5.93 0.255 20 885 Multi TX Calculation: BLE/BR+EDR/2.4G Wi-Fi: 10.89+20.65+30.33/3060 ≈ 0.02 433.92MHz: 0.255/885 ≈ 0.003 All simultaneous transmission possibilities are 0.02 + 0.003 = 0.023 ＜1

Appendix A: 20dB Emission Bandwidth Test Result TestMode Antenna Frequency[MHz] 20db EBW[MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict DH5 Ant1 2402 0.945 2401.523 2402.468 --- --- 2441 0.945 2440.523 2441.468 --- --- 2480 0.942 2479.526 2480.468 --- --- 2DH5 Ant1 2402 1.323 2401.322 2402.645 --- --- 2441 1.317 2440.325 2441.642 --- --- 2480 1.317 2479.325 2480.642 --- --- 3DH5 Ant1 2402 1.311 2401.331 2402.642 --- --- 2441 1.311 2440.331 2441.642 --- --- 2480 1.311 2479.331 2480.642 --- --- Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 2DH5_Ant1_2402 2DH5_Ant1_2441 2DH5_Ant1_2480 3DH5_Ant1_2402 3DH5_Ant1_2441 3DH5_Ant1_2480 Appendix B: Occupied Channel Bandwidth Test Result TestMode Antenna Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict DH5 Ant1 2402 0.82785 2401.5690 2402.3969 --- --- 2441 0.84273 2440.5614 2441.4041 --- --- 2480 0.82864 2479.5676 2480.3963 --- --- 2DH5 Ant1 2402 1.1781 2401.3947 2402.5728 --- --- 2441 1.1757 2440.3943 2441.5700 --- --- 2480 1.1769 2479.3946 2480.5715 --- --- 3DH5 Ant1 2402 1.1833 2401.3948 2402.5781 --- --- 2441 1.1774 2440.3973 2441.5747 --- --- 2480 1.1802 2479.3969 2480.5771 --- --- Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 2DH5_Ant1_2402 2DH5_Ant1_2441 2DH5_Ant1_2480 3DH5_Ant1_2402 3DH5_Ant1_2441 3DH5_Ant1_2480 Appendix C: Maximum conducted output power Test Result Peak Test Mode Antenna Frequency[MHz] Conducted Peak Powert[dBm] Conducted Limit[dBm] Verdict DH5 Ant1 2402 8.51 ≤30 PASS 2441 9.24 ≤30 PASS 2480 8.80 ≤30 PASS 2DH5 Ant1 2402 10.69 ≤30 PASS 2441 11.47 ≤30 PASS 2480 11.06 ≤30 PASS 3DH5 Ant1 2402 11.14 ≤30 PASS 2441 11.88 ≤30 PASS 2480 11.42 ≤30 PASS Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 2DH5_Ant1_2402 2DH5_Ant1_2441 2DH5_Ant1_2480 3DH5_Ant1_2402 3DH5_Ant1_2441 3DH5_Ant1_2480 Appendix D: Carrier frequency separation Test Result TestMode Antenna Frequency[MHz] Result[MHz] Limit[MHz] Verdict DH5 Ant1 Hop 1.022 ≥0.945 PASS 2DH5 Ant1 Hop 1.008 ≥0.882 PASS 3DH5 Ant1 Hop 1.148 ≥0.874 PASS Test Graphs DH5_Ant1_Hop 2DH5_Ant1_Hop 3DH5_Ant1_Hop Appendix E: Time of occupancy Test Result TestMode Antenna Frequency[MHz] BurstWidth [ms] TotalHops [Num] Result[s] Limit[s] Verdict DH5 Ant1 Hop 2.880 106.67 0.307 ≤0.4 PASS 2DH5 Ant1 Hop 2.888 106.67 0.308 ≤0.4 PASS 3DH5 Ant1 Hop 2.889 106.67 0.308 ≤0.4 PASS Test Graphs DH5_Ant1_Hop 2DH5_Ant1_Hop 3DH5_Ant1_Hop Appendix F: Number of hopping channels Test Result TestMode Antenna Frequency[MHz] Result[Num] Limit[Num] Verdict DH5 Ant1 Hop 79 ≥15 PASS 2DH5 Ant1 Hop 79 ≥15 PASS 3DH5 Ant1 Hop 79 ≥15 PASS Test Graphs DH5_Ant1_Hop 2DH5_Ant1_Hop 3DH5_Ant1_Hop Appendix G: Band edge measurements Test Result TestMode Antenna ChName Frequency[MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 Low 2402 8.08 -43.57 ≤-11.92 PASS High 2480 8.50 -45.86 ≤-11.5 PASS Low Hop_2402 7.40 -46.94 ≤-12.6 PASS High Hop_2480 8.21 -46.46 ≤-11.8 PASS 2DH5 Ant1 Low 2402 7.70 -43.41 ≤-12.3 PASS High 2480 8.61 -45.9 ≤-11.39 PASS Low Hop_2402 4.72 -46.95 ≤-15.28 PASS High Hop_2480 8.72 -46.91 ≤-11.28 PASS 3DH5 Ant1 Low 2402 7.85 -43.72 ≤-12.15 PASS High 2480 8.21 -45.59 ≤-11.79 PASS Low Hop_2402 5.53 -46.56 ≤-14.47 PASS High Hop_2480 8.28 -46.54 ≤-11.72 PASS Test Graphs DH5_Ant1_Low_2402 DH5_Ant1_High_2480 DH5_Ant1_Low_Hop_2402 DH5_Ant1_High_Hop_2480 2DH5_Ant1_Low_2402 2DH5_Ant1_High_2480 2DH5_Ant1_Low_Hop_2402 2DH5_Ant1_High_Hop_2480 3DH5_Ant1_Low_2402 3DH5_Ant1_High_2480

3DH5_Ant1_Low_Hop_2402 3DH5_Ant1_High_Hop_2480 Appendix H: Conducted Spurious Emission Test Result TestMode Antenna Frequency[MHz] FreqRange [MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 2402 Reference 8.24 8.24 --- PASS 30~1000 8.24 -41.85 ≤-11.76 PASS 1000~26500 8.24 -43.29 ≤-11.76 PASS 2441 Reference 8.85 8.85 --- PASS 30~1000 8.85 -41.31 ≤-11.15 PASS 1000~26500 8.85 -45.37 ≤-11.15 PASS 2480 Reference 8.49 8.49 --- PASS 30~1000 8.49 -40.37 ≤-11.51 PASS 1000~26500 8.49 -47.48 ≤-11.51 PASS 2DH5 Ant1 2402 Reference 8.31 8.31 --- PASS 30~1000 8.31 -43.04 ≤-11.69 PASS 1000~26500 8.31 -43.2 ≤-11.69 PASS 2441 Reference 8.97 8.97 --- PASS 30~1000 8.97 -41.43 ≤-11.03 PASS 1000~26500 8.97 -45.65 ≤-11.03 PASS 2480 Reference 8.49 8.49 --- PASS 30~1000 8.49 -41.18 ≤-11.51 PASS 1000~26500 8.49 -47.59 ≤-11.51 PASS 3DH5 Ant1 2402 Reference 8.28 8.28 --- PASS 30~1000 8.28 -41.9 ≤-11.72 PASS 1000~26500 8.28 -43.62 ≤-11.72 PASS 2441 Reference 8.83 8.83 --- PASS 30~1000 8.83 -41.17 ≤-11.17 PASS 1000~26500 8.83 -45.54 ≤-11.17 PASS 2480 Reference 7.95 7.95 --- PASS 30~1000 7.95 -41.25 ≤-12.05 PASS 1000~26500 7.95 -47.57 ≤-12.05 PASS Test Graphs DH5_Ant1_2402_0~Reference DH5_Ant1_2402_30~1000 DH5_Ant1_2402_1000~26500 DH5_Ant1_2441_0~Reference DH5_Ant1_2441_30~1000 DH5_Ant1_2441_1000~26500 DH5_Ant1_2480_0~Reference DH5_Ant1_2480_30~1000 DH5_Ant1_2480_1000~26500 2DH5_Ant1_2402_0~Reference 2DH5_Ant1_2402_30~1000 2DH5_Ant1_2402_1000~26500 2DH5_Ant1_2441_0~Reference 2DH5_Ant1_2441_30~1000 2DH5_Ant1_2441_1000~26500 2DH5_Ant1_2480_0~Reference 2DH5_Ant1_2480_30~1000 2DH5_Ant1_2480_1000~26500 3DH5_Ant1_2402_0~Reference 3DH5_Ant1_2402_30~1000 3DH5_Ant1_2402_1000~26500 3DH5_Ant1_2441_0~Reference 3DH5_Ant1_2441_30~1000 3DH5_Ant1_2441_1000~26500 3DH5_Ant1_2480_0~Reference 3DH5_Ant1_2480_30~1000 3DH5_Ant1_2480_1000~26500 Appendix I: Duty Cycle Test Result TestMode Antenna Frequency[ MHz] ON Time [ms] Period [ms] Duty Cycle [%] Duty Cycle Factor[dB] DH5 Ant1 2402 2.88 3.75 76.80 1.15 2441 2.88 3.75 76.80 1.15 2480 2.87 3.74 76.74 1.15 2DH5 Ant1 2402 2.89 3.75 77.07 1.13 2441 2.89 3.75 77.07 1.13 2480 2.88 3.75 76.80 1.15 3DH5 Ant1 2402 2.89 3.75 77.07 1.13 2441 2.89 3.75 77.07 1.13 2480 2.89 3.75 77.07 1.13 Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 2DH5_Ant1_2402 2DH5_Ant1_2441 2DH5_Ant1_2480 3DH5_Ant1_2402 3DH5_Ant1_2441 3DH5_Ant1_2480 Appendix J: Emissions in Restricted Bands Test Result Mode: DH5-2402 NO. Freq. [MHz] Level [dBμV/m] Factor [dB/m] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Polarity Verdict 1 2310 47.85 8.69 74.00 26.15 150 154 Vertical PASS 2 2321.6 49.66 8.80 74.00 24.34 150 81 Vertical PASS 3 2330.16 49.72 8.85 74.00 24.28 150 140 Vertical PASS 4 2343.52 50.41 8.99 74.00 23.59 150 360 Vertical PASS 5 2369.44 50.67 9.15 74.00 23.33 150 348 Vertical PASS 6 2390 51.69 11.47 74.00 22.31 150 57 Vertical PASS NO. Freq. [MHz] Level [dBμV/m] Factor [dB/m] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Polarity Verdict 1 2310 48.38 8.69 74.00 25.62 150 288 Horizontal PASS 2 2317.44 50.49 8.71 74.00 23.51 150 97 Horizontal PASS 3 2340.4 51.01 8.87 74.00 22.99 150 133 Horizontal PASS 4 2357.6 50.54 9.14 74.00 23.46 150 60 Horizontal PASS 5 2375.28 50.48 9.33 74.00 23.52 150 260 Horizontal PASS 6 2390 51.14 11.47 74.00 22.86 150 154 Horizontal PASS Mode: DH5-2480 NO. Freq. [MHz] Level [dBμV/m] Factor [dB/m] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Polarity Verdict 1 2483.5 48.88 9.16 74.00 25.12 150 224 Vertical PASS 2 2488.0351.03 9.19 74.00 22.97 150 139 Vertical PASS 3 2490.1450.52 9.21 74.00 23.48 150 68 Vertical PASS 4 2491.5050.51 9.22 74.00 23.49 150 202 Vertical PASS 5 2497.7550.24 9.25 74.00 23.76 150 141 Vertical PASS 6 2500 48.98 9.27 74.00 25.02 150 274 Vertical PASS NO. Freq. [MHz] Level [dBμV/m] Factor [dB/m] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Polarity Verdict 1 2483.5 51.34 9.16 74.00 22.66 150 29 Horizontal PASS 2 2484.0954.74 9.17 74.00 19.26 150 83 Horizontal PASS 3 2484.2253.75 9.17 74.00 20.25 150 238 Horizontal PASS 4 2486.4552.21 9.19 74.00 21.79 150 81 Horizontal PASS 5 2489.0652.79 9.20 74.00 21.21 150 263 Horizontal PASS 6 2500 49.86 9.27 74.00 24.14 150 292 Horizontal PASS NO. Freq. [MHz] Level [dBμV/m] Factor [dB/m] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Polarity Verdict 1 2484.0946.49 9.17 54.00 7.51 150 83 Horizontal PASS Mode: 2DH5-2402 NO. Freq. [MHz] Level [dBμV/m] Factor [dB/m] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Polarity Verdict 1 2310 47.56 8.10 74.00 26.44 150 33 Vertical PASS 2 2324.48 49.29 8.12 74.00 24.71 150 240 Vertical PASS 3 2336.88 50.26 8.14 74.00 23.74 150 30 Vertical PASS 4 2352.16 49.12 8.18 74.00 24.88 150 53 Vertical PASS 5 2367.12 49.73 8.31 74.00 24.27 150 208 Vertical PASS 6 2390 48.22 8.50 74.00 25.78 150 171 Vertical PASS NO. Freq. [MHz] Level [dBμV/m] Factor [dB/m] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Polarity Verdict 1 2310 48.03 8.10 74.00 25.97 150 253 Horizontal PASS 2 2321.6 49.85 8.11 74.00 24.15 150 74 Horizontal PASS 3 2340.32 49.90 8.14 74.00 24.10 150 39 Horizontal PASS 4 2353.68 51.00 8.19 74.00 23.00 150 141 Horizontal PASS 5 2370.64 50.30 8.33 74.00 23.70 150 1 Horizontal PASS 6 2390 48.53 8.50 74.00 25.47 150 45 Horizontal PASS Mode: 2DH5-2480 NO. Freq. [MHz] Level [dBμV/m] Factor [dB/m] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Polarity Verdict 1 2483.5 48.94 9.16 74.00 25.06 150 291 Vertical PASS 2 2486.1051.07 9.18 74.00 22.93 150 16 Vertical PASS 3 2488.5850.77 9.19 74.00 23.23 150 171 Vertical PASS 4 2490.7151.28 9.21 74.00 22.72 150 163 Vertical PASS 5 2494.06 50.33 9.24 74.00 23.67 150 4 Vertical PASS 6 2500 49.11 9.27 74.00 24.89 150 21 Vertical PASS NO. Freq. [MHz] Level [dBμV/m] Factor [dB/m] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Polarity Verdict 1 2483.5 51.98 9.16 74.00 22.02 150 102 Horizontal PASS 2 2485.6152.22 9.18 74.00 21.78 150 213 Horizontal PASS 3 2489.8652.12 9.21 74.00 21.88 150 213 Horizontal PASS 4 2493.2352.2…

Text truncated - open the document above for the full version.

EUROFINS ELECTRICAL TESTING SERVICE (SHENZHEN) CO., LTD. RADIO TEST - REPORT FCC Compliance Test Report for Product name: Motionblinds Wifi Matter Bridge Model name: CM-55 FCC ID: ZY4CM55 Test Report Number: EFGX24060324-IE-02-E03 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. Phone: +86-0755-829118671 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, Fax: +86-0755-82910749 No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China Page 1 of 26 1 General Information 3 1.1 Notes 3 1.2 Testing laboratory 4 1.3 Details of applicant 4 1.4 Details of manufacturer 4 1.5 Application details 5 1.6 Test item 5 1.7 Test standards 6 2 Technical test 7 2.1 Summary of test results 7 2.2 Test environment 7 2.3 Measurement uncertainty 7 2.4 Test mode 8 2.5 Test equipment utilized 9 2.6 Auxiliary equipment used during test 10 2.7 Test software information: 10 2.8 Test setup- 11 2.9 Test results 13 3 Technical Requirement 14 3.1 Conducted emission AC power port 14 3.2 Duty cycle 15 3.3 20dB Occupied bandwidth 16 3.4 99% Occupied Bandwidth 17 3.5 Carrier frequency separation 18 3.6 Number of hopping frequencies 19 3.7 Time of occupancy (dwell time) 20 3.8 Peak Output Power 21 3.9 Conducted Band-edge & Spurious Emissions 22 3.10 Radiated emissions for transmitter 23 3.11 Hopping sequence requirement 26 4 Test Setup Photos 27 5 External Photo 27 6 Internal Photos 27 7 Appendix 27 Test Report No.: EFGX24060324-IE-02-E03 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 3 of 27 1 General Information 1.1 Notes The results of this test report relate exclusively to the item tested as specified in chapter “Description of test item” and are not transferable to any other test items. Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. is not responsible for any generalisations and conclusions drawn from this report. Any modification of the test item can lead to invalidity of test results and this test report may therefore be not applicable to the modified test item. The test report may only be reproduced or published in full. Reproducing or publishing extracts of the report requires the prior written approval of the Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. This document is subject to the General Terms and Conditions and the Testing and Certification System of Eurofins Electrical Testing Service (Shenzhen) Co., Ltd., available on request or accessible at www.eurofins.com. Operator: 2024-08-23 Bruce Zheng / Project Engineer Date Eurofins-Lab. Name / Title Signature Technical responsibility for area of testing: 2024-08-23 Albert Xu / Lab Manager Date Eurofins-Lab. Name / Title Signature Test Report No.: EFGX24060324-IE-02-E03 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 4 of 27 1.2 Testing laboratory Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone : +86-755-82911867 Fax : +86-755-82910749 The Laboratory has passed the Accreditation by the American Association for Laboratory Accrediation (A2LA). The Accreditation number is 5376.01 The Laboratory has been listed by industry Canada to perform electromagnetic emission measurements, The CAB identifier is CN0088 1.3 Details of applicant Name : Coulisse B.V. Address : Vonderweg 48, 7468DC Enter, Netherlands Telephone : ./. Fax : ./. 1.4 Details of manufacturer Name : Coulisse B.V. Address : Vonderweg 48, 7468DC Enter, Netherlands Telephone : ./. Fax : ./. Test Report No.: EFGX24060324-IE-02-E03 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 5 of 27 1.5 Application details Date of receipt of application : 2024-06-19 Date of receipt of test item : 2024-06-19 Date of test : 2024-06-19 to 2024-08-05 Date of issue : 2024-08-23 1.6 Test item Product type : Motionblinds Wifi Matter Bridge Test Model : CM-55 Sample ID : 240621-01-003 Brand : ./. Serial number : ./. Ratings : DC 5.0V from USB port Test voltage : 120V FCC ID : ZY4CM55 RadioTechnical data Frequency range : 2402MHz – 2480MHz Radio Tech. : Bluetooth Basic Rate+Enhanced Data Rate Frequency channel : CH0 – CH78, Total 79 channels Modulation : GFSK, π/4 DQPSK, 8DPSK Antenna type : PCB antenna Maximum antenna gain : 3.42 dBi Additional information : ./. The above sample(s) and sample information was/were submitted and identified on behalf of the applicant. Eurofins assures objectivity and impartiality of the test, and fulfills the obligation of confidentiality for applicant’s commercial infor- mation and technical documents. Test Report No.: EFGX24060324-IE-02-E03 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 6 of 27 1.7 Test standards Test Standards FCC Part 15 Sub- part C PART 15 - RADIO FREQUENCY DEVICES Subpart C - Intentional Radiators Test Method 1: ANSI C63.4-2014, American National Standard for Methods of Measurement of Radio-Noise Emis- sions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. 2: ANSI C63.10-2013, American National Standard for Testing Unlicensed Wireless Devices. 3: KDB558074 D01 15.247 Meas Guidance v05r02 Test Report No.: EFGX24060324-IE-02-E03 Eurofins Electrical Testing Service (Sh…
