ZYAPRODIGY4KMini Android PC

Xtreamer Prodigy 4K Xtreamer Prodigy 4K Xtreamer Prodigy 4K Xtreamer Prodigy 4K Xtreamer Prodigy 4K Xtreamer Prodigy 4K Xtreamer Prodigy 4K Xtreamer Prodigy 4K Chipset: Processor: Mstar9180 (w/Dolby+DTS) ARM Cortex-A9 Quad-Core/1.5GHZ GPU: Quad Core Mali-450 Memory: FLASH: 8GB eMMC, SDRAM: 2GB DDR3, HDD: 3.5" slot up-to 4TB OS & UI: Android 4.4 OS with special Xtreamer Launcher & UI with OTA upgrading Multilingual support: English, Russian, French, German, Spanish, Hebrew, Arabic, Chinese, Korean, Dutch, Portuguese, Polish & many more as supported in Android 4.4 Size: Weight: 1.1kg, Size: 238 x 207 x 64mm Wireless Connectivity: 802.11 b/g/n Wi-Fi, AirPlay, Miracast and DLNA support Video Output: HDMI™ 1.4, 4K*2K H.265/H.264, 3D supporting Audio Output: HDMI™ 1.4, SPDIF optical Power: DC 12V, 2A adapter included (CE, FCC, CCC certied) Supported Video Format: H.264, H.265, MPG/MPEG/MP4, TS, M2ts, AVI, BD-ISO, 3D-MVC, FLV, F4V, MKV, Xvid, DAT, VOB, AVS, 3GP, WebM, TP, TRP, MOV ..etc Sound: Supported Audio Format: MP3/WAV/APE/OGG/FLAC/AAC...etc Dolby&DTS hardware decoding and 7.1ch passthrough Supported Photo Format: HD JPEG/BMP/GIF/PNG/TIFF Peripheral Interface: USB3.0 host X 1, USB2.0 host X 2, USB3.0 slave X 1, Multi Card Slot X 1, HDMI out X 1, Optical X 1, HDMI in X 1, Giga Ethernet LAN (10/100/100M/1000M RJ45) X 1, DC-in X 12.4G wi 802.11. b/g/n System optimization: Airplay & DLNA by Airpin, XBMC Plugins & Repo Innovative New functions: Can Support H.265 HEVC, Hardware Decoding Requirements: Gmail account, Minimum WiFi or LAN may be required to activate Xtreamer Prodigy 4k features/updates with online services. Package Content: Xtreamer Prodigy 4K (WiFi 802.11n Antenna built-in), HDMI 1.4 Cable, 12V 2A Power Adapter IR remote control, Quick start guide. This device and its antenna must not be located or operating in conjunction with any other antenna and transmitter. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modications to this equipment. Such modications could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help Changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. When using the device, ensure that the antenna of the device is as least 20 cm away from all persons. Xtreamer Prodigy 4K Prodigy 4K Prodigy 4K Xtreamer Prodigy 4K Xtreamer Prodigy 4K Prodigy 4K Xtreamer Prodigy 4K Xtreamer Prodigy 4K Xtreamer Prodigy 4K Xtreamer Prodigy 4K Why Pay More? Xtreamer Prodigy 4K Xtreamer Prodigy 4K supports wired and wireless network allowing you to stream multimedia files locally or enjoy a vast variety of online content. Connect USB cable to an external USB storage device of your choice. Prodigy 4K การเชื่อตอสาย Optical คุณสามารถสนุกสนานกับเสียง 5.1 ผานแอมปรีฟายเวอรหรือรีซีฟเวอร โดยการเชื่อมตอกับพอรต Optical ตามที่แสดงในรูปดานบน การเชื่อตอสาย HDMI ตอสาย HDMI เขากับพอรตหลังเครื่อง ปลายอีกดานของสายตอเขากับพอรต HDMI หลังทีวีหรือจอภาพ การเชื่อตอเน็ตเวิรค Xtreamer Prodigy 4K รองรับการเชื่อมตอเน็ตเวิรคทั้งแบบมีสายและไรสาย ทําใหคุณสามารถสตรีมมัลติมีเดียไฟลที่ถูกจัดเก็ บอยูบนวงเน็ตเวิรคเดียวกันหรือคอนเทนตออนไลนตางๆได การเชื่อตออุปกรณจัดเก็บขอมูลภายนอก คุณสามารถใชสายยูเอสบีเชื่อมตออุปกรณจัดเก็บขอมูลภายนอกตางๆกับเครื่องได Xtreamer Prodigy 4K Network Connection HDMI OUT SATELLITE TUNER  CABLE SET-TOP BOX Power AV LAN SD/MMC Power USB2.0 host Optical HDMI WiFi 802.11n Antenna built-in HDD tray IR receiver HDMI in USB slave USB3.0 host Requirements Return Left, Right Up, Down Power Home OK Vol up/down Page up/down Menu HDMI in Learning keys Resolution Google Play Store www.xtreamer.net/Prodigy-4k Learn more at: מגיעה כשהיא מכילה את חנות האפליקציות של גוגל מותקנת מראש. לתשומת ליבך יתכנו Prodigy 4kה- ישומים שנכתבו עבור מכשירי סלולר והם אינם מוצגים באופן המותאם לטלויזיה שברשותך. חנות האפליקציות של גוגל Xtreamer Prodigy 4k is fully compatible with Google Play Store apps. Please note that not all the applications might be suitable for high-definition TV screens. Google Play Store Den Xtreamer Prodigy 4k is 100% compatible mit Google Play Store apps. Achtung bitte: nicht alle verfügbare apps sind ge-eignet für wiedergabe auf HD Fernseher ! Google Play Store De Xtreamer Prodigy 4k is volledig compatible met de Google Play Store apps. Gelieve er rekening mee te houden dat niet alle apps geschikt zijn voor HD tv-schermen ! Google Play Store Xtreamer Prodigy 4k es totalmente compatible con las aplicaciones de Google Play Store. Por favor, ten en cuenta que no todas las aplicaciones pueden ser adecuadas para …

Text truncated - open the document above for the full version.

Rev 11/20/07 XTREAMER LIMITED Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: ZYAPRODIGY4K. Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram ZYAPRODIGY4K _Block Diagram.pdf Circuit Diagram ZYAPRODIGY4K _Schematics.pdf Operational Description ZYAPRODIGY4K _Operational description.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Roger Wang

XTREAMER LIMITED Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 19, Mar, 2015 SUBJECT: FCC Application for ZYAPRODIGY4K To Whom It May Concern: We, the undersigned, hereby authorize Mr. Zhang Shuangwen from CCIC-SET to at XTREAMER LIMITED on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by CCIC-SET on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Roger Wang

External Photo

Size:50mm*25mm

Internal Photos WIFI Antenna

Report No.: SET2015-03041 CCIC-SET/T（00） Page 1 of 69 RF TEST REPORT Report No.: SET2015-03041 Product Name: Xtreamer Mini Android PC FCC ID: ZYAPRODIGY4K Model No. : Xtreamer Prodigy 4k Applicant: Address: XTREAMER LIMITED Flat A,15/F Hiller Commercial Building 65-67 Bonham Strand East, Sheung Wan, HongKong Issued by: CCIC-SET Lab Location: Electronic Testing Building, Shahe Road, Xili, Nanshan District, Shenzhen, 518055, P. R. China Tel: 86 755 26627338 Fax: 86 755 26627238 This test report consists of 69 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CCIC-SET. The test results in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. Any objections must be raised to CCIC-SET within 20 days since the date when the report is received. It will not be taken into consideration beyond this limit. Report No.: SET2015-03041 CCIC-SET/T（00） Page 2 of 69 Test Report Product Name ...................... : Xtreamer Mini Android PC Model No. .........................: Xtreamer Prodigy 4k Brand Name ......................... : Xtreamer Trade Name .......................... : Xtreamer Applicant .............................. : XTREAMER LIMITED Applicant Address ............... : Flat A,15/F Hiller Commercial Building 65-67 Bonham Strand East, Sheung Wan, HongKong Manufacturer ........................ : XTREAMER LIMITED Manufacturer Address ........ : Flat A,15/F Hiller Commercial Building 65-67 Bonham Strand East, Sheung Wan, HongKong Test Standards ..................... : 47 CFR Part 15 Subpart C：Radio Frequency Devices ANSI C63.10:2009：American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 DTS Meas Guidance v03r02 Test Result ........................... : PASS Tested by ............................ : 2015.03.12 Haigang He, Test Engineer Reviewed by ......................... : 2015.03.12 Zhu Qi, Senior Egineer Approved by ........................ : 2015.03.12 Wu Li’an, Manager Report No.: SET2015-03041 CCIC-SET/T（00） Page 3 of 69 TABLE OF CONTENTS GENERAL INFORMATION ............................................................................................................... 5 1.1 EUT Description ......................................................................................................................... 5 1.2 Test Standards and Results ........................................................................................................ 6 1.3 Facilities and Accreditations ...................................................................................................... 7 1.3.1 Facilities .................................................................................................................................... 7 1.3.2 Test Environment Conditions .................................................................................................... 7 2. 47 CFR PART 15C REQUIREMENTS .................................................................................... 8 2.1 Antenna requirement ................................................................................................................. 8 2.1.1 Applicable Standard .................................................................................................................. 8 2.1.2 Antenna Information ................................................................................................................. 8 2.1.3 Result: comply .......................................................................................................................... 8 2.2 Peak Output Power .................................................................................................................... 9 2.2.1 Requirement .............................................................................................................................. 9 2.2.2 Test Description ........................................................................................................................ 9 2.2.3 Test Result ................................................................................................................................. 9 2.3 Bandwidth ................................................................................................................................. 11 2.3.1 Requirement ............................................................................................................................ 11 2.3.2 Test Description ...................................................................................................................... 11 2.3.3 Test Result ............................................................................................................................... 11 2.4 Conducted Spurious Emissions ............................................................................................... 20 2.4.1 Requirement ............................................................................................................................ 20 2.4.2 Test Description ...................................................................................................................... 20 2.4.3 Test Result ............................................................................................................................... 20 2.5 Power spectral density (PSD) .................................................................................................. 35 2.5.1 Requirement ............................................................................................................................ 35 2.5.2 Test Description ...................................................................................................................... 35 2.5.…

Text truncated - open the document above for the full version.

Radiated Emission Test setup photos Below 1G 1G~18G Conducted Emission Test setup photo Conducted Test setup photo

Radiated Emission Test setup photos Below 1G 1G~6G Conducted Emission Test setup photo
