ZYAXTWONDERMini Android PC

XTREAMER LIMITED Nov 27, 2014 Federal Communications Commission Authorization and Evaluation Division FCC ID：ZYAXTWONDER Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information applied this application as outlined below: 1. Block Diagram CONF APPENDIX ZYAXTWONDER_Block Diagram.pdf 2. Circuit Diagram CONF APPENDIX ZYAXTWONDER _Schematics.pdf 3. Operational Description CONF APPENDIX ZYAXTWONDER_Operational description.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Signature Name/Title: Roger Wang/Product Manager Applicant: XTREAMER LIMITED Address: Flat A, 15/F Hiller Commercial Building 65-67 Bonham Strand East, Sheung Wan, HongKong, China Tel: 008675529958815 Fax: 008675529958823 Email: [email protected]

XTREAMER LIMITED Ad Hoc Mode Declaration Date: Dec 15, 2014 We, the undersigned company Company Name: XTREAMER LIMITED Address: Flat A,15/F Hiller Commercial Building 65-67 Bonham Strand East,Sheung Wan, HongKong Declare that: Product description: Xtreamer Mini Android PC Model name: Xtreamer Wonder Brand: Xtreamer FCC ID: ZYAXTWONDER 1. Only channels 1~11 will be used in USA. Country code selection is disabled. 2. This product will be used for indoor operations. If you have any questions regarding the authorization, please do not hesitate to contact us, thank you~ Sincerely, Signature: Name/Title: Roger Wang/Product Manager Applicant: XTREAMER LIMITED Address: Flat A, 15/F Hiller Commercial Building 65-67 Bonham Strand East, Sheung Wan, HongKong Tel: 008675529958815 Fax: 008675529958823 Email: [email protected]

External Photo

Internal Photos BT/WIFI Antenna

Report No.: SET2014-13498 P Page 1 of 72 RF TEST REPORT Report No.: SET2014-13498 Product Name: Xtreamer Mini Android PC FCC ID: ZYAXTWONDER Model No. : Xtreamer Wonder Applicant: XTREAMER LIMITED Address： Flat A, 15F Hiller Commercial Building 65-67 Bonham Strand East, Sheung Wan, Hongkong Issued by: CCIC-SET Lab Location: Electronic Testing Building, Shahe Road, Xili, Nanshan District, Shenzhen, 518055, P. R. China Tel: 86 755 26627338 Fax: 86 755 26627238 This test report consists of 72 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CCIC-SET. The test results in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. Any objections must be raised to CCIC-SET within 20 days since the date when the report is received. It will not be taken into consideration beyond this limit. Report No.: SET2014-13498 Page 2 of 72 Test Report Product Name ....................... : Xtreamer Mini Android PC Brand Name .......................... : Xtreamer Applicant ............................... : XTREAMER LIMITED Applicant Address ................ : Flat A, 15F Hiller Commercial Building 65-67 Bonham Strand East, Sheung Wan, Hongkong Manufacturer......................... : XTREAMER LIMITED Manufacturer Address ......... : Flat A, 15F Hiller Commercial Building 65-67 Bonham Strand East, Sheung Wan, Hongkong Test Standards ...................... : 47 CFR Part 15 Subpart C 2013：Radio Frequency Devices ANSI C63.10:2009：American National Standard for Testing Unlicensed Wireless Devices DA 00-705: Filing and Measurement Guidelines for Frequency Hopping Spread Spectrum Systems Test Result ............................ : PASS Tested by ............................. : 2014.12.05 Haigang He，Test Engineer Reviewed by......................: 2014.12.05 Lu Lei, Senior Egineer Approved by ......................... : 2014.12.05 Wu Li’an，Manager Report No.: SET2014-13498 Page 3 of 72 TABLE OF CONTENTS 1. GENERAL INFORMATION .................................................................................................... 4 1.1. EUT Description ....................................................................................................................... 4 1.2. Test Standards and Results ........................................................................................................ 5 1.3. Facilities and Accreditations ..................................................................................................... 6 2. 47 CFR PART 15C REQUIREMENTS .................................................................................... 7 2.1. Antenna requirement ................................................................................................................. 7 2.2. Number of Hopping Frequency ................................................................................................ 8 2.3. Peak Output Power.................................................................................................................. 11 2.4. 20dB Bandwidth ..................................................................................................................... 18 2.5. Carried Frequency Separation ................................................................................................. 25 2.6. Time of Occupancy (Dwell time) ........................................................................................... 28 2.7. Conducted Spurious Emissions ............................................................................................... 35 2.8. Band Edge ............................................................................................................................... 47 2.9. Conducted Emission ............................................................................................................... 58 2.10. Radiated Emission................................................................................................................... 62 Change History Issue Date Reason for change 1.0 2014.12.05 First edition Report No.: SET2014-13498 Page 4 of 72 1. General Information 1.1. EUT Description EUT Type ............................. : Xtreamer Mini Android PC Serial No. .............................. : FCC ID. ................................ : XH3EB00001GI ZYAXTWONDER Hardware Version ................. : RM-MPEG-114AG Ver1.0- 1 Software Version .................. : 4.11.2 Frequency Range .................. : The frequency range used is 2402MHz - 2480MHz (79 channels, at intervals of 1MHz); The frequency block is 2400MHz to 2483.5MHz. Modulation Type .................. : Bluetooth: FHSS (GFSK(1Mbps), π/4-DQPSK(EDR 2Mbps), 8-DPSK(EDR 3Mbps)) Antenna Type ........................ : Internal Antenna Antenna Gain ........................ : 2 dBi Note 1: The EUT is a Xtreamer Mini Android PC, it contains Bluetooth Module operating at 2.4GHz ISM band; the frequencies allocated for the Bluetooth Module is F(MHz)=2402+1*n (0<=n<=78). The lowest, middle, highest channel numbers of the Bluetooth Module used and tested in this report are separately 0 (2402MHz), 39 (2441MHz) and 78 (2480MHz). Note 2: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. Note 3: a. When power on, the EUT will scan the whole frequency until a Connection command from the other BT devices. b. When receiving the signal from the other BT devices, The EUT transmit are sponse signal. c. The other devices receive the response signal and recognize it, then send a connection command to establish the connection. d. After the connection establish successfully, the data transmission is beginning. At the same time, the both devices wil…

Text truncated - open the document above for the full version.

Radiated Emission Test setup photos Below 1G 1G~18G Conducted Emission Test setup photo Conducted Test setup photo
