2AEBL-M251022CRDisplay module with IC card reader

Date (March 12, 2015) TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Dear Sir or Madam, We, ABB Genway Xiamen Electrical Equipment Co.,Ltd, Room 501-1,No.12-14,3rd Chuang Xin Road,Torch High Technology Development Zone, Xiamen S.E.Z, ,Fujian Province, P.R.China hereby authorize TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch 5F, Communication Building, 163 Pingyun Rd, Huangpu West Ave. Guangzhou 510656 P. R. China Storm Shu Phone: +86 20 3815 3462 e-mail: [email protected] to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that neither we nor any party to this application are subject to denial of U.S Federal benefits, which include FCC benefits, pursuant to section 5301 of Anti-Drug Abuse Act of 1988, U.S.C 862 because of conviction for possession or distribution of controlled substance. This authorization is application to product: Product name: Display module with IC card reader Model name: M251022CR FCC ID: 2AEBL-M251022CR This authorization expires one year from the current date. Yours sincerely, Signature: Signed by (printed name): ShanshanWang Email: [email protected] Date: March 12, 2015

Date: March 12, 2015 TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Confidentiality Request Product name: Display module with IC card reader Model name: M251022CR FCC ID: 2AEBL-M251022CR Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, ABB Genway Xiamen Electrical Equipment Co.,Ltd, Room 501-1,No.12-14,3rd Chuang Xin Road,Torch High Technology Development Zone, Xiamen S.E.Z, ,Fujian Province, P.R.China hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics PCB layout Parts List Block Diagrams The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Signature: Signed by (printed name): ShanshanWang Email: [email protected] Date: March 12, 2015

Date (March 12, 2015) TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Dear Sir or Madam, We, ABB Genway Xiamen Electrical Equipment Co.,Ltd, Room 501-1,No.12-14,3rd Chuang Xin Road,Torch High Technology Development Zone, Xiamen S.E.Z, ,Fujian Province, P.R.China hereby authorize TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch 5F, Communication Building, 163 Pingyun Rd, Huangpu West Ave. Guangzhou 510656 P. R. China Storm Shu Phone: +86 20 3815 3462 e-mail: [email protected] to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that neither we nor any party to this application are subject to denial of U.S Federal benefits, which include FCC benefits, pursuant to section 5301 of Anti-Drug Abuse Act of 1988, U.S.C 862 because of conviction for possession or distribution of controlled substance. This authorization is application to product: Product name: Display module with IC card reader Model name: M251022CR FCC ID: 2AEBL-M251022CR This authorization expires one year from the current date. Yours sincerely, Signature: Signed by (printed name): ShanshanWang Email: [email protected] Date: March 12, 2015

Date: March 12, 2015 TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Confidentiality Request Product name: Display module with IC card reader Model name: M251022CR FCC ID: 2AEBL-M251022CR Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, ABB Genway Xiamen Electrical Equipment Co.,Ltd, Room 501-1,No.12-14,3rd Chuang Xin Road,Torch High Technology Development Zone, Xiamen S.E.Z, ,Fujian Province, P.R.China hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics PCB layout Parts List Block Diagrams The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Signature: Signed by (printed name): ShanshanWang Email: [email protected] Date: March 12, 2015

Report Number: 64.790.15.00707.01 Page B1 of B6 TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch 5F,Communication Building,163 Pingyun Rd, Huangpu Ave. West Guangzhou, P.R.China TEL: +86 20 3832 0668 FAX: +86 20 3832 0478 External photos Front View Back view Report Number: 64.790.15.00707.01 Page B2 of B6 TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch 5F,Communication Building,163 Pingyun Rd, Huangpu Ave. West Guangzhou, P.R.China TEL: +86 20 3832 0668 FAX: +86 20 3832 0478 Side vie w Report Number: 64.790.15.00707.01 Page B3 of B6 TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch 5F,Communication Building,163 Pingyun Rd, Huangpu Ave. West Guangzhou, P.R.China TEL: +86 20 3832 0668 FAX: +86 20 3832 0478

Report Number: 64.7 90.15.00707.01 Page B4 of B6 TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch 5F,Communication Building,163 Pingyun Rd, Huangpu Ave. West Guangzhou, P.R.China TEL: +86 20 3832 0668 FAX: +86 20 3832 0478 Internal photos Report Number: 64.7 90.15.00707.01 Page B5 of B6 TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch 5F,Communication Building,163 Pingyun Rd, Huangpu Ave. West Guangzhou, P.R.China TEL: +86 20 3832 0668 FAX: +86 20 3832 0478 Report Number: 64.7 90.15.00707.01 Page B6 of B6 TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch 5F,Communication Building,163 Pingyun Rd, Huangpu Ave. West Guangzhou, P.R.China TEL: +86 20 3832 0668 FAX: +86 20 3832 0478 Antenna photo

Report Number: 64.7 90.15.00707.01 Page B4 of B6 TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch 5F,Communication Building,163 Pingyun Rd, Huangpu Ave. West Guangzhou, P.R.China TEL: +86 20 3832 0668 FAX: +86 20 3832 0478 Internal photos Report Number: 64.7 90.15.00707.01 Page B5 of B6 TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch 5F,Communication Building,163 Pingyun Rd, Huangpu Ave. West Guangzhou, P.R.China TEL: +86 20 3832 0668 FAX: +86 20 3832 0478 Report Number: 64.7 90.15.00707.01 Page B6 of B6 TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch 5F,Communication Building,163 Pingyun Rd, Huangpu Ave. West Guangzhou, P.R.China TEL: +86 20 3832 0668 FAX: +86 20 3832 0478 Antenna photo

© ABB Group Operation Description The display & IC card reader module always works with other modules in the outdoor station. The module uses the STM32F051R8T6 as the microcontroller. The module gets the power supply from other module and can transfer the power supply to another module through interface1 and interface2. The module can also communicate with other modules through interface1 and interface2. The module can display information via the LCM, and support RFID proximity reader for IC card by using the MFRC522 chip. The module has a Wiegand output interface to connect to the rest of an electronic entry system. The module has a SPI flash to store the word library, card numbers and name list. The module has a USB interface to connect to the personal computer for professional to configurate. The module also has a software update interface and a reset button. Power supply of the product is DC 5V. The modulation type is ASK and carrier frequency is 13.56MHz using PCB layout loop antenna.

© ABB Group Operation Description The display & IC card reader module always works with other modules in the outdoor station. The module uses the STM32F051R8T6 as the microcontroller. The module gets the power supply from other module and can transfer the power supply to another module through interface1 and interface2. The module can also communicate with other modules through interface1 and interface2. The module can display information via the LCM, and support RFID proximity reader for IC card by using the MFRC522 chip. The module has a Wiegand output interface to connect to the rest of an electronic entry system. The module has a SPI flash to store the word library, card numbers and name list. The module has a USB interface to connect to the personal computer for professional to configurate. The module also has a software update interface and a reset button. Power supply of the product is DC 5V. The modulation type is ASK and carrier frequency is 13.56MHz using PCB layout loop antenna.

Report Number: 64.790.15.00707.01-RF Exposure Page 1 of 2 TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch 5F,Communication Building,163 Pingyun Rd, Huangpu Ave. West Guangzhou, P.R.China TEL: +86 20 3832 0668 FAX: +86 20 3832 0478 R F E x p o s u r e C o m p l i a n c e R e p o r t Model : M251022CR FCC ID : 2AEBL-M251022CR Product Type : Display module with IC card reader Applicant : ABB Genway Xiamen Electrical Equipment Co.,Ltd Address : Room 501-1,No.12-14,3rd Chuang Xin Road,Torch High Technology Development Zone,Xiamen S.E.Z,Fujian Province,P.R.China Production Facility : ABB Genway Xiamen Electrical Equipment Co.,Ltd Address : NO.7 Fangshan South Road,Torch High Technology Development Zone (Xiang An) Industrial Zone,Xiamen S.E.Z,Fujian Province,P.R.China Test Result :  COMPLIED Total pages including Appendices : 2 The test result only corresponds to the tested sample. It is not permitted to copy this report, in part or in full, without the permission of the test laboratory. Prepared by Approved by Storm Shu Tony Liu Report Number: 64.790.15.00707.01-RF Exposure Page 2 of 2 TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch 5F,Communication Building,163 Pingyun Rd, Huangpu Ave. West Guangzhou, P.R.China TEL: +86 20 3832 0668 FAX: +86 20 3832 0478 RF Exposure Compliance Requirement SAR exclusion justification in accordance to KDB 447498 D01 Section 4.3.1: EIRP power = 0.0005mW [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 [(0.0005, mW)/(5, mm)] · [√0.01356(GHz)] ≤ 3.0 0.000012 ≤ 3.0 Therefore the device meets the FCC SAR exemption requirements

Report Number: 64.790.15.00707.01 Page 1 of 21 TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch 5F,Communication Building,163 Pingyun Rd, Huangpu Ave. West Guangzhou, P.R.China TEL: +86 20 3832 0668 FAX: +86 20 3832 0478 FCC - TEST REPORT Report Number : 64.790.15.00707.01 Date of Issue: 2015-03-24 Model : M251022CR Product Type : Display module with IC card reader Applicant : ABB Genway Xiamen Electrical Equipment Co.,Ltd Address : Room 501-1,No.12-14,3rd Chuang Xin Road,Torch High Technology Development Zone,Xiamen S.E.Z,Fujian Province,P.R.China Production Facility : ABB Genway Xiamen Electrical Equipment Co.,Ltd Address : NO.7 Fangshan South Road,Torch High Technology Development Zone (Xiang An) Industrial Zone,Xiamen S.E.Z,Fujian Province,P.R.China Test Result :  Positive  Negative Total pages including Appendices : 29 TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch is a subcontractor to TÜV SÜD Product Service GmbH according to the principles outlined in ISO 17025. TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch reports apply only to the specific samples tested under stated test conditions. Construction of the actual test samples has been documented. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. The manufacturer/importer is responsible to the Competent Authorities in Europe for any modifications made to the production units which result in non-compliance to the relevant regulations. TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval Report Number: 64.790.15.00707.01 Page 2 of 21 TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch 5F,Communication Building,163 Pingyun Rd, Huangpu Ave. West Guangzhou, P.R.China TEL: +86 20 3832 0668 FAX: +86 20 3832 0478 1 Table of Contents 1 Table of Contents .............................................................................................................................. 2 2 Details about the Test Laboratory ...................................................................................................... 3 3 Description of the Equipment Under Test .......................................................................................... 4 4 Summary of Test Standards .............................................................................................................. 5 5 Summary of Test Results .................................................................................................................. 5 6 General Remarks .............................................................................................................................. 6 7 Test Setups ....................................................................................................................................... 7 8 Test Methodology .............................................................................................................................. 8 8.1 Conducted Emission ................................................................................................................... 8 8.2 Radiated Emission ...................................................................................................................... 8 8.3 Field Strength Calculation ........................................................................................................... 8 9 Systems test configuration ................................................................................................................ 9 10 Technical Requirement.................................................................................................................... 10 10.1 Conducted Emission Measurement .......................................................................................... 10 10.2 Filed Strength Measurement ..................................................................................................... 15 10.3 Frequency Stability ................................................................................................................... 18 10.4 Occupied Bandwidth ................................................................................................................. 19 11 Test Equipment List ......................................................................................................................... 21 12 System Measurement Uncertainty ................................................................................................... 21 13 Appendix A – Setup Photos ....................................................................................................... A1-A2 14 Appendix B – EUT Photos ......................................................................................................... B1-B6 Report Number: 64.790.15.00707.01 Page 3 of 21 TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch 5F,Communication Building,163 Pingyun Rd, Huangpu Ave. West Guangzhou, P.R.China TEL: +86 20 3832 0668 FAX: +86 20 3832 0478 2 Details about the Test Laboratory Details about the Test Laboratory Test Site 1 Company name: TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, Shenzhen City, 518052, P. R. China FCC Registration Number: 502708 IC Registration Number: 10320A Telephone: 86 755 8828 6998 Fax: 86 755 8828 5299 Test Site 2 Company name: Gua…

Text truncated - open the document above for the full version.

Report Number: 64.790.15.00707.01 Page A1 of A2 TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch 5F,Communication Building,163 Pingyun Rd, Huangpu Ave. West Guangzhou, P.R.China TEL: +86 20 3832 0668 FAX: +86 20 3832 0478 Setup photo of radiated emission (9KHz-30MHz) Setup photo of radiated emission (30MHz-1GHz) Report Number: 64.790.15.00707.01 Page A2 of A2 TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch 5F,Communication Building,163 Pingyun Rd, Huangpu Ave. West Guangzhou, P.R.China TEL: +86 20 3832 0668 FAX: +86 20 3832 0478 Setup photo of conducted emission (150KHz-30MHz)
