2ASIVPGV528WG30Lockly Smart Safe

USER MANUAL SMART SAFE ERP机型：PL45E1UQ-US-SMT00010A-V1 Designed：WalterDate：2023-02-28 描述: 说明书:PL45E1UQ/PGV528W,SMT000,REV.A(UMPGV528W20230228),196×196MM, 封面&底面:128g双粉纸双面过哑油,单黑印刷,内页80g书纸,双面印单黑,20页40面装订本, RoHS2.0,REACH,Prop65,POPs,PAHs ERP P/N： REV：1.1 KYMC R 6 43 0 72 8 14 5 39 TABLE OF CONTENTS Section 1 - Product Highlights Section 2 - Product Overview Section 3 - Installation & Setup 3.1 Optional Installation 3.2 Setting Up the Secure Link Wi-Fi Hub 3.3 Connecting Your Lockly Smart Safe 1.1 Product Features Section 6 - Advanced Features Section 7 - Key Duplication Section 9 - Maintenance and Cleaning 9.1 Cleaning 1 2 3 4 6 7 5 8 10 12 25 28 29 26 27 27 31 32 32 32 33 34 Section 10 - Safety Precautions 10.1 Safety Precautions35 Section 8 - Important Notes 8.1 Important Notes34 2.1 Product Overview - Exterior 2.2 Product Overview - Interior 2.3 Understanding Your Smart Safe 2.4 Rebooting Your Smart Safe 2.5 Low Battery 2.6 Changing The Battery 5.1 Unlocking with Access Codes 5.2 Unlocking with Fingerprint 5.3 Unlocking with App 5.4 Unlocking with QR Code 15 16 17 19 21 23 24 4.5 Pairing to a New Mobile Device 4.6 Adding a Fingerprint 4.7 Fingerprint Scanning Directions 4.8 Fingerprint Scanning Tips & Troubleshoot 4.9 Shine Mode Section 4 - Using Your Smart Safe Section 5- Unlocking 14 15 4.1 Configuring Access 4.2 Adding Access Codes 4.3 Checking/Deleting Access Code 4.4 Entering Programming Mode 5.5 Unlocking with Physical Key 5.6 Safe Mode - Overview 6.1 Offline Access Code™ (OAC) 6.2 Smart-Sync 6.3 Sub-Admin Access 6.4 Two-Factor Authentication 30 5.7 Disabling Safe Mode 7.1 Key Duplication Table of Contents For additional support, visit http://Lockly.com/help or email [email protected] 1.1 Product Features 1SECTION 1.1 Patented Hack-Proof PIN Genie Keypad Digits are randomly displayed on the key pad ensuring access codes to be undetectable to intruders after repeated use. Numbers are randomly distributed across 4 buttons, with 3 numbers in each button. Users can press any button showing their number. Location of the numbers are always different every time someone uses the keypad, making it hard for prying eyes to guess the correct code. Advanced 3D Fingerprint Recognition Biometric Fingerprint Recognition protocol allows up to 99 registered fingerprints to be used and accepts only actual fingerprints - preventing lifted prints from being used. Tamper-proof / Premium Build Made of 2.5mm alloy steel with corrosion resistant coating, magnet resistant, laser-cut 3D keyway and fireproof interior inlays. With included safety metal wires and screws to prevent the Smart Safe from being moved or stolen. Air Transfer compatible Quickly transfer fingerprint and trusted user profiles from your Lockly smart locks to your Smart Safe. Hydraulic Easy-Lift Unlocking Unlocks Safe quietly and syncs with LED lights which allows users to unlock, grab valuables with a single hand. Backup Keys and TYPE-C Socket Lockly Smart Safe can be opened with physical backup keys. There is TYPE-C connection socket that can be the source of continuous power supply or can be used as power backup in case the Safe runs out of battery. Offline Access Code ™ (OAC) The offline access code can allow owners to issue access codes, set the allowed access duration, all without Lockly ever connecting to the internet, so in case of power outage, you can still magically and remotely issue Access Codes without any connection to the web. Live Monitoring Through your smartphone, monitor Smart Safe access from anywhere in the world and Secure control access all permissions. Multiple Access Codes & Monitoring Store up to 37 Access Codes for family, friends and guests, as well as monitor entry and exit records. You can also upgrade up to 100 of users with Lockly\OS. 2.1 Product Overview - Exterior 2 SECTION 2.1 Fingerprint Reboot Button LED Indicator OK Button Keypad Buttons Touchscreen Key Hole Battery Compartment LED Light Type-C USB port SECTION 2.23 2.2 Product Overview - Interior Program Button When the Safe opens, the light automatically turns ON and OFF after 2 minutes. Touch the keypad to turn ON the lights again. 2.3 Understanding Your Smart Safe Understanding some key functions of operating your Smart Safe is important. The following guides will walk you through setting the Safe, adding Access Codes, deleting Access Codes, adding finger- prints,deleting fingerprints and how to configure your OAC (Offline Access Code ™ ). For any questions you can always visit https://Lockly.com/help for assistance. Don’t forget that Lockly works best with our iOS and Android ™ app. Please download the app by visiting the link below. Scan or visit Lockly.com/app 4SECTION 2.3 SECTION 2.45 2.4 Rebooting Your Smart Safe Reboot Button NOTICE Reboot Lockly in case of dead battery or malfunction. No settings will be changed and all Access Codes will still be stored within Lockly. Press and release the reboot button when you want to reboot the Safe. Your Lockly will beep once after reboot. Only reboot when necessary. You will need something small such as a paperclip, to press the reboot button located on the exterior of the safe, left of the fingerprint reader. Insert the paperclip and press down firmly and let go. Your screen should restart and the safe should reboot automatically. 6SECTION 2.5 Type-C 2.5 Low Battery When the battery is in seriously low condition, Lockly will make continuous beeping sounds in addition to the flashing low battery icon on the touch screen. You should replace batteries immediately to avoid your Smart Safe from shutting down. When your Safe low-battery warning alert finally dies, you will have 3 chances to unlock your Safe either by a password, APP or fingerprint. If the unlock was successful, the low-battery warning alert will be on for 1 minute. After which, the Safe will go to dead-battery mode and the screen will display a low-battery icon . Dead Battery ConditionIndicatorSolut ion Low Battery Battery Icon on the display …

Text truncated - open the document above for the full version.

PIN Genie Inc, DBA LOCKLY. 2023-04-12 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2ASIVPGV528WG30) The applicant: PIN Genie Inc, DBA LOCKLY. certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Print name: Cindy zhou Title: COO Signature: PIN Genie Inc, DBA LOCKLY. 2023-04-12 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID: 2ASIVPGV528WG30) The applicant: PIN Genie Inc, DBA LOCKLY. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Print name: Cindy zhou Title: COO Signature:

Attestation Statements -US agent 2023-04-12 TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for (FCC ID: 2ASIVPGV528WG30) PIN Genie Inc, DBA LOCKLY., the undersigned, hereby authorize (PIN Genie Inc, DBA LOCKLY.) to act as our designated U.S. agent for service of process, PIN Genie Inc, DBA LOCKLY. accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. (PIN Genie Inc, DBA LOCKLY.) accepts the responsibility to act as designated U.S. agent for service of process, provides an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Information： Company name: PIN Genie Inc, DBA LOCKLY. Address: 676 Transfer Rd., St. Paul, MN 55114 FRN: 0028246908 Contact Name: Cindy zhou Telephone No: 4159109522 Email: [email protected] Signature [name] ： Cindy zhou U.S. Agent Information: Company name: PIN Genie Inc, DBA LOCKLY. Address: 676 Transfer Rd., St. Paul, MN 55114 FRN: 0028246908 Contact Name: Cindy zhou Telephone No: 4159109522 Email: [email protected] Signature [name] ：Cindy zhou

PIN Genie Inc, DBA LOCKLY. Agent Authorization Letter 2023-04-12 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (The Hong Kong Standards and Testing Centre Limited) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Print name: Cindy zhou Title: COO Signature:

PIN Genie Inc, DBA LOCKLY. Long Term Confidentiality Request Letter Date: 2023-04-12 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: CONFIDENTIALITY REQUEST FOR EUT NAME: Lockly Smart Safe MODEL: PGV528W FCC ID: 2ASIVPGV528WG30 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (block diagram/schematics /operational description ) required to be submitted with this application be permanently withheld from public review. The above documents are company proprietary information that could never get into the possession of your competition. Please contact me if there is any information you may need. Sincerely, Print name: Cindy zhou Title: COO Signature:

1 External Photo FCC ID: 2ASIVPGV528WG30 IC: 25517-PGV528WG30 View of The Product View of The Product 2 View of The Product View of The Product 3 View of The Product View of The Product 4 View of The Product View of The Product 5 View of The Adapter

ERP机型：PL45E1UQ-US-SMT00010A-V1 Designed：WalterDate：2023-03-02 描述: FCC ID IC号标贴: PL45E1UQ/PGV528W，SMT000,REV.A ,70×40mm， #50合成纸背3M 9448胶,黑底灰字印刷,表面覆哑膜，“FCC ID:2ASIVPGV528WG30”， IC: 25517-PGV528WG30”， RoHS2.0,REACH,Prop65，POPs，PAHs ERP P/N： REV：0.4 Do not remove ! Model: PGV528W Name : Lockly Smart Safe HVINPGV528WG30 FCC ID2ASIVPGV528WG30 IC ID25517-PGV528WG30 This device complies with Part 15 of the FCC Rules. Opera�on is subject to the following two condi�ons: (1) This device may not cau se harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired opera�on. Label location

1 Internal Photo FCC ID: 2ASIVPGV528WG30 IC: 25517-PGV528WG30 Inside View of The Product Inside View of The Product 2 Inside View of The Product View of battery（AA x4） 3 Inner Circuit Top View Inner Circuit Top View 4 Inner Circuit Bottom View Inner Circuit Top View 5 Inner Circuit Bottom View Inner Circuit Top View 6 Inner Circuit Top View Inner Circuit Bottom View 7 View of BT antenna

RF Exposure Test Requirement: FCC 47CFR 15.247(i) FCC ID: 2ASIVPGV528WG30 Test Date: 2023-04-18 Mode of Operation: BT Tx mode Requirements: In 15.247(i), an equipment shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the limits in §§ 1.1310 and 2.1093 of this chapter. Applications to the Commission for construction permits, licenses to transmit or renewals thereof, equipment authorizations or modifications in existing facilities must contain a statement confirming compliance with the limits unless the facility, operation, or transmitter is categorically excluded, as discussed below. Technical information showing the basis for this statement must be submitted to the Commission upon request. According to KDB447498 D04 General RF Exposure Guidance v01, Appendix B B.2 Blanket 1 mW Blanket Exemption The 1 mW Blanket Exemption of § 1.1307(b)(3)(i)(A) applies for single fixed, mobile, and portable RF sources with available maximum time-averaged power of no more than 1mW, regardless of separation distance. Result: Pass The Maximum ERP = 0.151mW (at frequency = 2.480GHz) < 1mW

规格承认书 深圳市金利源兴电子有限公司 Shen zhen Golden-Resource Electronic Co.,Ltd. 客户盛世科技 日期2023/02/28 Date 编号23022801 File No 版本1.0 Revision 规格承认书 SPECIFICATION FOR APPROVAL 客户盛世科技 CUSTOMER: 客户料号PGV528 CUSTOMER NO: 品名BT Antenna PART NAME: 供方料号YJW01.029.112.301A SUPPLIER NO: 送样日期Date: 送样数量Q"TY: PCS 客户确认CUSTOMER APPROVED BY APPROVALCHIEFSUPERVISOR 供方确认SUPPLIER SIGNATURE APPROVALCHECKDESIGN add：深圳市龙华新区梅龙路南贤商业广场B座17A-03ATel:0755-83524561 APPROVALCHECKDESIGN ChenGuoqiangXieLiChenXingcheng YJ-RD-F04-A 承认书项目表 NO . 内容 （Contents） 页数 （Number of Page） 页码 （Page Code） 1 承认书封面 （Spec Cover） 11 2 承认书项目表（Spec Item ） 12 3 工程成品图 （Drawing） 13 4 天线规格（Antenna Specification） 14 5 S参数测试 （S Parameter ） 15 6 无源测试（Passive Test） 26~76 无源测试（Passive Test ） 26 7 7 方向图（Radiation Pattern） 38 ~ 10 8 天线装配图（Antenna Profile） 211 ~ 12 材质 明 9 材质证明（Material Certificate ） 3613 ~ 48 10 RoHS报告（RoHS Test Report ） **** 11N/AN/AN/A add：深圳市龙华新区梅龙路南贤商业广场B座17A-03ATel:0755-83524561 12--- 13--- 天线规格 Antenna Specification Electrical Propertiesp Frequency2.4-2.5GHz Impedance50 Ohm Nominal VSWR20MaxV.S.W.R2.0 Max Gain0.9 dBi RadiationOmni-directional PolarizationLinearPolarizationLinear Physical Properties Connector 1代IPEX Cable TypeO.D.1.13mm Cable Length50mm Cable ColorBlack add：深圳市龙华新区梅龙路南贤商业广场B座17A-03ATel:0755-83524561 Cable ColorBlack Operating Temp.-40 ~ +85 ̊C Storage Temp.-40~ +85 ̊C AntennaPerformance Test Agilent Antenna Performance Te s t Agilent E5071B SS Parameter Test // BT Antenna add：深圳市龙华新区梅龙路南贤商业广场B座17A-03ATel:0755-83524561 AntennaPassive TestAntenna Passive Te s t Z YY X X Z Y add：深圳市龙华新区梅龙路南贤商业广场B座17A-03ATel:0755-83524561 Passive Test For BT Antenna FreqEffiEffiGain (MHz)(%)(dB)(dBi) 2400 41.1 -3.9 -0.6 2410 42.4 -3.7 -0.2 2420 43.6 -3.6 0.0 2430 43.6 -3.6 0.0 2440 44.3 -3.5 0.2 2450 47.8 -3.2 0.4 2460 48.9 -3.1 0.5 2470 50.8 -2.9 0.6 2480 50.7 -3.0 0.6 add：深圳市龙华新区梅龙路南贤商业广场B座17A-03ATel:0755-83524561 2490 50.2 -3.0 0.8 2500 49.2 -3.1 0.9 Radiation Pattern For BT Antenna add：深圳市龙华新区梅龙路南贤商业广场B座17A-03ATel:0755-83524561 Radiation Pattern For BTAntenna add：深圳市龙华新区梅龙路南贤商业广场B座17A-03ATel:0755-83524561 Radiation Pattern For BTAntenna add：深圳市龙华新区梅龙路南贤商业广场B座17A-03ATel:0755-83524561 BT Antenna add：深圳市龙华新区梅龙路南贤商业广场B座17A-03ATel:0755-83524561 BT ANT add：深圳市龙华新区梅龙路南贤商业广场B座17A-03ATel:0755-83524561 ， 安 全 資 料 表 版權2021-01-10 PSM-800FSDM-A/SMH-800 1 ，一、化學品與廠商資料 化學品名稱：液態熱固軟板油墨 PSM-800FSDM-A/SMH-800 其他名稱： 建議用途及限制使用：柔性电路板(PI/Cu) ,手機天線板 製造者、輸入者或供應者名稱、地址及電話：製造者：優立實業股份有限公司 住址：桃園市觀音區經建四路22號 電話：886-3-4836651 緊急聯絡電話/傳真電話：電話：886-3-4836651、傳真：886-3-4837487 二、危害辨識資料 化學品危害分類： 健康及環境危害：急毒性物質（吞食）第 4 級、腐蝕／刺激皮膚物質第2級、嚴重損傷／刺激眼睛物質第2A級、皮膚 過敏物質第1級、致癌物質第2級、水環境之危害物質（急毒性）第2級。 標示內容： 象 徵 符 號： 警 示 語：警告 危害警告訊息： 吞食有害 造成皮膚刺激 造成嚴重眼睛刺激 可能造成皮膚過敏 懷疑致癌 對水生生物有毒 危害防範措施： 置容器於通風良好的地方 遠離高温 使用時勿吃、喝 衣服一經污染，立即脫掉 戴眼罩／護面罩 若與眼睛接觸，立刻以大量的水洗滌後洽詢醫療 戴上合適的手套 勿吸入氣體/煙氣/蒸氣/霧氣 使用前取得說明 置放於上鎖處 在瞭解所有安全防範措施之前切勿處置 避免釋放至環境中 其他危害：－ 三、成份辨識資料 混合物： 中英文名稱：液態熱固軟板油墨PSM-800FSDM-A/SMH-800 化學性質： 危害成分之中英文名稱 化學文摘社登記號碼（CAS No.） 濃度或濃度範圍(成分百分比) 環氧丙烯酸酯寡聚物Epoxy acrylate oligmer 28064-14-4 50 % 二氧化矽Fused silica 7631-86-9 13 % 芳香族溶劑Aromatic solvent 64742-94-5 4 % ， 安 全 資 料 表 版權2021-01-10 PSM-800FSDM-A/SMH-800 2 二丙二醇甲基醚Methyl dipropylene glycol 34590-94-8 4% 碳黑Carbon black 1333-86-4 3.5 % 硫酸鋇BaSO4 13462-86-7 24 % 光敏劑及其它Photoinitiator and the others 5495-84-1 1.5 % 四、急救措施 不同暴露途徑之急救方法： 吸 入：1.施救前先做好自身的防護措施。 2.移走污染源或將患者移至新鮮空氣處。 3.若有病人呼吸停止，立即由受過訓的人施以人工呼吸，若心跳停止，施行心肺復甦術，當患者吸入和吞下 毒性物質時，別直接使用口對口人工呼吸，應使用單向給氣式之口袋型面罩和其他醫療器材來執行人工呼 吸。 4.保持患者安靜及維持正常體溫。6.儘速就醫治療。 皮膚接觸：儘快以緩和流動的水沖洗受污染區域至少20 分鐘，沖水前，脫掉污染的衣物、鞋子、皮飾品。 眼睛接觸：立即將眼皮撐開用緩和流動的水沖洗受污眼睛至少20 分鐘，並立即就醫。 食 入：1.若患者即將喪失意識，或已喪失意識或痙攣，不可餵食任何東西。 2.不可催吐，並給予240-300ml 的水。 3.如果自發性嘔吐，讓其漱口，並反覆給水。 最重要症狀及危害效應：－ 對急救人員之防護：－ 對醫師之提示：－ 五、滅火措施 適用滅火劑：化學乾粉、酒精泡沫、二氧化碳、噴水，大火：噴水、水霧、泡沫水霧。 滅火時可能遭遇之特殊危害： 1.其蒸氣及熱分解物易燃及有毒。 2.其蒸氣較空氣重，能傳播至遠處之火源處，發生回火。 3.蒸氣與大氣結合可能會發生爆炸。 4.當此物質在室內、室外或下水道有蒸氣爆炸危險。 特殊滅火程序： 1.在安全距離的地方滅火，保持在上風位置。 2.可用水冷卻容器，分散蒸氣沖洗外洩並稀釋外洩物，保護搶救人員。 3.用水噴灑露在火焰中的容器四週，使容器冷卻，直到火勢被撲滅為止。離開容器的本端以維安全。 4.撲滅或移開所有引燃源。 消防人員之特殊防護裝備：消防人員必須配戴空氣呼吸器、消防衣及防護手套。 六、洩漏處理方法 個人應注意事項： 1.限制人員進入，直至外溢區完全清理乾淨為止。 2.由受過訓之人員負責清理之工作。 3.穿戴適當的個人防護裝備。 環境注意事項： 1.移去引火源。 2.保持洩漏區通風。 3.處在上風處，避免進入低處。 4.在不危及人員安全情況下，搬移或隔離易燃和可燃物。 5.隔離污染源至少100 至200 公尺。 清理方法： 1.不可碰觸外洩物。 ， 安 全 資 料 表 版權2021-01-10 PSM-800FSDM-A/SMH-800 3 2.避免外洩物進入下水道或密閉的空間內。 3.在安全許可的情形下，設法阻止或減少溢漏。 4.用不會和外洩物反應的泥土、沙或相似穩定且不可燃的物質圍堵外洩物。 5.少量溢漏時，用不會和外洩物反應之吸收劑吸收。已污染的吸收劑和外洩物具有同樣的 6.危害性，須置於加蓋並標示的適當容器裡。用水沖洗溢漏區域。 7.大量溢漏時：連絡消防、緊急處理單位及供應商以尋求協助。 七、安全處置與儲存方法 處置： 1.貯存於陰涼乾燥涼好通風的地方，並避免陽光直射、熱及引火源。 2.遠離不容物如強氧化物、強酸、水。 3.使用接地、與無火花之電器儀器、通風系統。 4.小量時貯存於冰箱，並使用防爆炸冰箱。 5.設外洩警報系統。 6.須貯存區與工作區隔離，並限制人員出入貯存區，並貼示警告標語。 7.避免碰撞，並就近設滅火系統。 8.不可單獨工作，另一人需隨時待命救援。 9.在工作區使用許可裝運燃燒性液體的容器，並且所有桶槽、轉裝容器都要接地，且須接觸到裸金屬。 10.使用最小可能的量，並在指定區內，使用適合的通風系統。 11.標示容器，當不使用時要緊蓋。 儲存： 1.貯存於陰涼乾燥涼好通風的地方，並避免陽光直射、熱及引火源。 2.小量時貯存於冰箱，並使用防爆炸冰箱。 3.須貯存區與工作區隔離，並限制人員出入貯存區，並貼示警告標語。 4.標示容器，當不使用時要緊蓋。 八、暴露預防措施 工程控制： 1.單獨使用步產生火花、接地的通風系統。 2.排氣口直接通到室外、並採取保護的重要措施。 3.大量使用此物質時，可能需要局部排氣裝置和製程密閉。 4.供給充分新鮮空氣以補充排氣系統抽出的空氣。 控制參數：－ 八小時日時量平均容許濃度/短時間時量平均容許濃度/最高容許濃度：－ 生物指標：－ 個人防護設備： ̇呼吸防護：1.含有機蒸汽過濾毒罐之化學品過濾毒呼吸防護具或自攜式呼吸防護具。 2.定流量式供氣式呼吸防護具，動力型含有機蒸氣濾罐空氣淨化呼吸防護具，含有機蒸氣濾毒罐的面罩， 全面型自攜式呼吸防護具，全面型供氣式呼吸防護具，全面型含有機蒸汽濾毒罐之化學品濾毒呼吸防護具。 3.正壓全面型攜式呼吸防護具或含輔助型正壓自攜式呼吸防護具之正壓全面型供氣式呼吸防護具。 4.有機蒸氣濾毒罐的面罩，逃生型自攜式呼吸防護具。 ̇手部防護：丁基橡膠最佳，氯聚乙烯，聚乙烯酸，氟化彈性體、丁基橡膠∕氯丁橡膠，鐵氟龍，氯丁橡膠∕天然橡膠銀罩， 氟化彈性體∕氯丁基橡膠亦佳的防滲手套。 ̇眼睛防護：1.防濺化學安全眼鏡。 2.全面罩。 3.勿戴隱形眼鏡。 ̇皮膚及身體防護：1.工作鞋及連身工作服。 2.工作區要有淋浴/沖洗設備。 衛生措施： 1.工作後儘速脫掉污染之衣物，洗淨後才可再穿戴。 ， 安 全 資 料 表 版權2021-01-10 PSM-800FSDM-A/SMH-800 4 2.工作場所嚴禁抽煙或飲食。 3.處理此物後，須徹底洗手。 4.維持作業場所清潔。 九、物理及化學性質 外觀(物質狀態、顏色等)：黑色膏狀流體 氣味：臭味 嗅覺閾值：－ 熔點：-25°C pH值：－ 沸點/沸點範圍： 218-219°C 易燃性(固體、氣體)：－ 閃火點：＞75°C 分解溫度：－ 測試方法：（ ）開杯（ V ）閉杯 自燃溫度：不自燃 爆炸界限：－ 蒸氣壓：－ 蒸氣密度：6.07 密度：1.24~1.26（水=1） 溶解度：微溶於水 辛醇/水分配係數(log Kow)：－ 揮發速率：－ 十、安定性及反應性 安定性：密封乾燥容器下安定。 特殊狀況下可能之危害反應：－ 應避免之狀況： 洩漏、火焰和其他引火源。 應避免之物質：酸、氧化劑 危害分解物：一氧化碳 十一、毒性資料 暴露途徑：皮膚、吸入、眼睛、食入 症狀：刺激感、困倦、暈眩、疲倦、頭痛、反胃、呼吸困難及痙攣 急毒性： 吸入：1.蒸氣會刺激鼻、咽喉及肺。 皮膚：1.純液體或濃溶液會造成嚴重刺激及灼傷感。 2.蒸氣對皮膚會造成刺激。 3.經由皮膚接觸，液體會被吸收達中毒量。 眼睛：1.蒸氣會刺激眼睛及催淚。 2.液體會造成嚴重眼睛灼傷。 食入：1.會對口及消化道造成明顯的局部刺激。 慢毒性或長期毒性：－ 十二、生態資料 生態毒性：－ 持久性與降解性：避免進入水源入口及水路中，對水中生物具傷害性。 生物蓄積性：－ 土壤中之流動性：－ 其他不良效應： － 十三…

Text truncated - open the document above for the full version.

Test Report Date : 2023-04-18 Page 1 of 40 No. : HMD23040001 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc.group This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. Applicant : PIN Genie Inc, DBA LOCKLY. 676 Transfer Rd., St. Paul, MN 55114 Supplier / Manufacturer : Smart Electronic Industrial (Dongguan) Co., Ltd Qing Long Road, Long Jian Tian Village, Huang Jiang Town, Dong Guan, Guang Dong, China Description of Sample(s) : Submitted sample(s) said to be Product: Lockly Smart Safe Brand Name: LOCKLY Model No.: PGV528W FCC ID: 2ASIVPGV528WG30 Date Samples Received : 2023-04-04 Date Tested : 2023-04-04 to 2023-04-11 Investigation Requested : Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15 and ANSI C63.10:2013 for FCC Certification. Conclusions : The submitted product COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Remarks : Bluetooth DTS (GFSK) _______________________________ Dr.CHAN Kwok Hung, Brian Authorized Signatory Test Report Date : 2023-04-18 Page 2 of 40 No. : HMD23040001 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc.group This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. CONTENT: Cover Page 1 of 40 Content Page 2 of 40 1.0 General Details 1.1 Test Laboratory Page 3 of 40 1.2 Equipment Under Test [EUT] Page 3 of 40 Description of EUT operation 1.3 Date of Order Page 3 of 40 1.4 Submitted Sample(s) Page 3 of 40 1.5 Test Duration Page 3 of 40 1.6 Country of Origin Page 3 of 40 1.7 RF Module Details Page 4 of 40 1.8 Antenna Details Page 4 of 40 1.9 Channel List Page 4 of 40 2.0 Technical Details 2.1 Investigations Requested Page 5 of 40 2.2 Test Standards and Results Summary Page 6 of 40 3.0 Test Results 3.1 Emission Page 7-35 of 40 Appendix A List of Measurement Equipment Page 36 of 40 Appendix B Photograph(s) of Product Page 37-40 of 40 Test Report Date : 2023-04-18 Page 3 of 40 No. : HMD23040001 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc.group This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. 1.0 General Details 1.1 Test Laboratory The Hong Kong Standards and Testing Centre Ltd. EMC Laboratory 10 Dai Wang Street, Taipo Industrial Estate, New Territories, Hong Kong Telephone: 852 2666 1888 Fax: 852 2664 4353 1.2 Equipment Under Test [EUT] Description of Sample(s) Product: Lockly Smart Safe Manufacturer: Smart Electronic Industrial (Dongguan) Co., Ltd Qing Long Road, Long Jian Tian Village, Huang Jiang Town, Dong Guan, Guang Dong, China Brand Name: LOCKLY Model Number: PGV528W . Rating: 6Vd.c.(“AA” battery x4) 5Vd.c. by adapter The AC/DC adapter was provided by the applicant with following details: Brand name: LOCKLY; Model no.: 617058 Input: 100-240Va.c. 50-60Hz 0.15A , Output:5Vd.c. 1A 1.2.1 Description of EUT Operation The Equipment Under Test (EUT) is a Lockly Smart Safe. The transmission signal is digital modulated with channel frequency range 2402-2480MHz. The R.F. signal was modulated by IC; the type of modulation used was digital transmission Modulation. 1.3 Date of Order 2023-04-03 1.4 Submitted Sample(s): 1 Sample 1.5 Test Duration 2023-04-04 to 2023-04-11 1.6 Country of Origin China Test Report Date : 2023-04-18 Page 4 of 40 No. : HMD23040001 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc.group This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited. For Conditions of Issuance of this test report, please refer to “Conditions of Issuance of Test Reports” section or Website. 1.7 RF Module Details Module Model Number: N/A Module FCC ID: N/A Module Transmission Type: Bluetooth 5.0 BLE Modulation: GFSK Data Rates: 1Mbps Frequency Range: 2400-2483.5MHz Carrier Frequencies: 2402MHz – 2480MHz Module Specification (specification provided by manufacturer) 1.8 Antenna Details Antenna Type: FPC antenna Antenna Gain: 0.9dBi 1.9 Channel List Channel Frequency (MHz) Channel Frequency (MHz) 0 2402 20 2442 1 2404 21 2444 2 2406 22 2446 3 2408 23 2448 4 2410 24 2450 5 2412 25 2452 6 2414 26 2454 7 2416 27 2456 8 2418 28 2458 9 2420 29 2460 10 2422 30 2462 11 2424 31 2464 12 2426 32 2466 13 2428 33 2468 14 2430 34 2470 15 2432 35 2472 16 2434 36 2474 17 2436 37 2476 18 2438 38 2478 19 2440 39 2480 Test Report Date : 2023-04-18 Page 5 of 40 No. : HMD23040001 The Hong Kong Standards and Testing Centre Limited 10 Dai Wang Street, Taipo Industrial Estate, Tai Po, N.T., Hong Kong Tel: +852 2666 1888 Fax: +852 2664 4353 Email: [email protected] Website: www.stc.group This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Limited…

Text truncated - open the document above for the full version.

1 Test Photo FCC ID: 2ASIVPGV528WG30 IC: 25517-PGV528WG30 Measurement of Radiated Emission Test Set Up Measurement of Radiated Emission Test Set Up 2 Measurement of Radiated Emission Test Set Up Measurement of Conducted Emission Test Set Up
