2AUTE-IQ41) Thermal Transfer Barcode Printer 2) Barcode Printer

快速安装指南 iQ4 开箱清单 安装碳带 打印机电源线 注意：箱内实际内容以出货清单为准。 注意：接口因客户的选择而异，上图所示接口仅供参考。 前视后视 内视 安装指南 侧盖组 菜单 校准 暂停 走纸 以太网口 控制面板 控制面板 串行接口 1. 将打印机水平正面放置桌面，从打印机右侧下方向 上掀起侧盖。 1. 将纸卷挡板放下，将介质对准介质供应架放入，然后将纸卷挡板抬起。4. 当使用缝标、黑标和圆孔标签时，需手动滑动介质侦测 器以查找标签的侦测位置。 5. 介质安装完成后，将打印头向下压，使 碳带与介质紧密贴合即安装完成。 1. 将电源线一端插入插座。 2. 将电源线的另一端插入打印机电源接口。 2. 将纸卷挡板往里推直到卡紧纸卷。拉出部分纸卷 从外侧介质导板和介质侦测器下方穿过，再拉至出 纸口。 3. 依据纸张宽度向内推动夹纸支架可以固定纸张两侧。 3. 拉出部分碳带穿过外侧介质导板和介质侦测器的 上方，即打印机芯的下方。 说明：介质安装路径详情可参考机身侧盖丝印图或 介质安装指示标签上的说明。 2. 将碳带装入碳带供应轴，再逆时针旋紧碳带供应 轴螺母以固定碳带。 4. 将碳带经打印机芯从下往上拉，穿过碳带回收轴 下方，再从下往上拉。 将碳带前缘放在碳带回收轮 上，再绕2~3圈，转动碳带回收轮，使碳带回卷平整。 显示屏 USB B 型口 打印机芯组 介质侦测器侦测调节杆 手动滑动侦测器调节杆 USB Host 电源开关 出纸口 USB Host 侧盖开启口 顺时针 打印机芯 碳带回收轴 逆时针 夹纸支架外侧介质导板 介质侦测器 碳带 菜单键 待机状态下 , 长按进入显示屏的菜单操作功能 校准键 待机状态下或报错灯红色慢闪 , 长按启动标签学习功能 走纸键 操作详情请参考“iQ4 用户手册” 暂停键 打印中：短按暂停 , 长按请除当下打印任务 打印暂停中：短按继续打印 , 长按清除当下打印任务 电源接口 USB 数据线 ① 碳带供应轴 ② 碳带回收轴 ③ 打印头组 ④ 打印胶辊 ⑤ 介质侦测器 ⑥ 打印头开启杆 ⑦ 外侧介质导板 ⑧ 护板 ⑨ 打印机芯组 ⑩ 介质供应架 ⑪ 侧盖组 ⑫ 碳带供应轴螺母 制造商：厦门汉印股份有限公司 地址：中国福建省厦门市同安区榕源路 96 号 电话：400-766-7666 网址：http://cn.idprt.com ① ① ① ① ① ⑤ ⑤ ⑤ ⑤ ⑤ ② ② ② ② ② ⑥ ⑥ ⑥ ⑥ ⑥ ③ ③ ③ ③ ③ ④ ④ ④ ④ -1- -4- -2- -5- -3- -6- 部件名称 铅 （Pb） 汞 （Hg） 镉 （Cd） 六价铬 （Cr6+） 多溴联苯 （PBB） 多溴二苯醚 （PBDE） 塑料件OOOOOO 五金件XOOOOO 线材OOOOOO 控制板组件XOOOOO 打印头组件XOOOOO 马达XOOOOO LCD 屏OOOOOO 开关电源板XOOOOO 注：本表依据 S/J 11364 的规定编制。 O: 表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572 标准规定的限值要求以下。 X: 表示该有害物质在该部件某一均质材料中的含量超出 GB/T 26572 标准规定的限量要求，但都符合有害物 质限制要求。 如左图所示的电子信息产品污染控制标志适用于在中华人民共和国境内销售的电子信息 产品， 标志中的数字代表环保使用期限的年数。 ͜ ͜ 外观及组件 连接电源 外观及组件 安装介质安装介质 保修条款 产品中有害物质的名称及含量 一、自出库之日算起，本产品热写头片保修3个月或30KM(以先到为准）， 如热写头出现创伤、刮伤、烧毁、腐蚀等不可抗拒因素不在保修范 围内，其余部件保修 12 个月。 二、存在以下情况之一者，不属于保修范围之内： 1. 未经我公司及授权维修人员许可，擅自对产品进行拆卸，或产品序 列号标贴被撕去及模糊不清，无法辨认； 2. 由于固体颗粒刮伤热敏头片，引起的打印白线，则头片不属于保修 范围； 3. 其他人为引起的故障。 三、保修期内，维修时所更换的产品零配件归我公司所有； 四、用户负责将产品寄送至我公司售后服务部或我公司授权的维修站 点进行保修服务； 五、厦门汉印股份有限公司拥有本保修条款的最终解释权。 制造商：厦门汉印股份有限公司 地址：中国福建省厦门市同安区榕源路 96 号 电话：400-766-7666 网址：http://cn.idprt.com 警告：热零部件！ 触摸该零部件时会烫伤手指，关闭电源等 待半小时才能触摸零部件。 在居住环境中，运行此设备可能会造成无线电干扰。 警告：有尖锐边缘， 不要接触。 警告：运动零部件，身体部位远离动作路径。 警告：产品不适用于儿童使用，禁止儿童接触。 产品保修卡 尊敬的用户： 为了保障您的权益以及为您提供更优质的售后服务，请您在购买产 品时仔细填写并保留此卡，进行保修服务时请与购买发票一同出示！ 用户名称： 联系地址：省市区（县） 联系电话： 产品型号（序列号）: 经销商名称（盖章）： 联系地址： 联系电话： 购买日期：年月 ⑧ ⑪ ⑫ ⑦ ⑨ ⑩ 蝲支 兽⨢ 吥ⲥ 饥紺   电源线 插头因地区而异 工具和驱动配置操作详情请参考《iQ4 用户手册》。 ͜ ④ FCC WARNING： This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment isoperated in a commercial environment. This equipment generates, uses, and canradiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Opetion of this equipment in a residential area is likely to cause harmful interference in whichcase the user will be required to correct the interference at his own expense. To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be installed and operated with minimum distance between 20cm the radiator your body: Use only the supplied antenna. WARNING: This Equipment is not suitable for use in locations where childeren are likely to be present. The product needs to be reliably earthing after being powered on. -4- -5--6- Quick Start Guide iQ4 Packing List Loading the Ribbon PrinterPower Cord Note: The packing materials are based on the order. Note: The interface shown in the figure above is for reference only. Replacement of a battery with an incorrect type that can defeat a safeguard. Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting a battery, can result in an explosion. Leaving a battery in an extremely high temperature surrounding environment can result in an explosion or the leakage of fl ammable liquid or gas. Note: This product is not used for children. Warning This product contains abutton battery. If the button battery is swallowed, it can cause severein- ternal burns in just 2 hours and can lead to death. Keep new and used batteries away from children. If the battery compartment does not close secure- ly, stop using the product and keep it away from children. If you think batteries might have been swal- lowed or placed inside any part of the body, seek immedi- ate medical attention. Do not charge button batteries. Risk of fire or explosion if the battery is replaced by an incorrect type The protective grounding conductor of the product shall be connected to the protective grounding conductor of the installation. Front ViewRear View Inside View Quick Start GuideCD Side CoverEthernet PortControl Panel Control Panel Serial Port 1. Place the printer on the flat table, lift the cover from the bottom-right of printer by hands. 1. Lower the paper roll baffle, align the paper with the media spindle, and then lift the paper roll baffle.4. When using the gap label, black mark label or punch hole label, you can manually adjust the media sensor by the adjusting level to find the gap, black mark or punch hole for the detecting print position. 5. After finishing the label loading, press the print head down to make ribbon and label fit snugly. 1.Connect the power plug to power receptacle. 2.Connect the other end of power cord to the AC power port. 2. Push the paper roll baffle inward until it engag- es the paper roll. Pull a part of ribbon, then pass the ribbon between the print mechanism and the media sensor. 3. Push the paper holder inward to adjust for the label width. 3. Pull a part of ribbon of pass the ribbon between the print mechanism and the media sensor. Note: For details o…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-6-2503C328 Report Version: R00 Page 1 of 4 FCC RF EXPOSURE REPORT FCC ID: 2AUTE-IQ4 Project No. : 2503C328 Equipment : 1) Thermal Transfer Barcode Printer 2) Barcode Printer Brand Name : HPRT, iDPRT Test Model : iQ4 Model Name : iQ4, iQ4 PLUS, Q400, Q410, Q420, Q430, iQ400, iQ410, iQ420, iQ430, TT4210, Neo, QT400, QT410, QT231, QT230, QT430, QT240, QS40, QS410, QS231, QS400, QS240, QE40, QE410, QE231, QE400, QE240 , QN40, QN410, QN231, QN400, QN240, QW40, QW410, QW231, QW400, QW240, TT400, TT410, TT231, TT230, TT430, XQ400, XQ410 , XQ420, XQ430, XQ231, XQ240 Hardware Version : IQ4PLUS-MBA Software Version : iQ4_V1.00.00_BETA31 Applicant : Xiamen Hanin Co., Ltd. Address : Room 305A, Angye Building, Pioneering Park,Torch High-tech Zone,Xiamen,China Manufacturer : Xiamen Hanin Co., Ltd. Address : Room 305A, Angye Building, Pioneering Park,Torch High-tech Zone,Xiamen,China Factory : Xiamen Hanin Co., Ltd. Address : 96# Rongyuan Road,Tong’an District, 361000 Xiamen,China Date of Receipt : Apr. 01, 2025 Date of Test : Apr. 08, 2025 ~ Aug. 21, 2025 Issued Date : Sep. 01, 2025 Test Sample : Engineering Sample No.: DG2025040127 & DG2025040127-24 Standard(s) : FCC Guidelines for Human Exposure IEEE C95.1 & FCC Part 2.1091 FCC Title 47 Part 2.1091 & KDB 447498 D01 v06 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. (Dongguan) Prepared by : Antony Liang Approved by : Steven Lu No.3, Jinshagang 1st Road, Dalang, Dongguan, Guangdong People’s Republic of China. Te l : + 8 6-769-8318-3000 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-FCCP-6-2503C328 Report Version: R00 Page 2 of 4 REVISION HISTORY Report No. Version Description Issued Date Note BTL-FCCP-6-2503C328 R00 Original Report. Sep. 01, 2025 Valid Report No.: BTL-FCCP-6-2503C328 Report Version: R00 Page 3 of 4 1. MPE CALCULATION METHOD Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna 2. ANTENNA SPECIFICATION For BT(EDR+LE): Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 BW2.4FND35-10B1L400 PCB IPEX-1 3.09 Note: The antenna gain is provided by the manufacturer. For WLAN 2.4G: Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 LGY IQ4 Dipole IPEX 4.81 2 LGY IQ4 Dipole IPEX 3.31 Note: 1) This EUT supports CDD, and all antenna gains are not equal Directional gain = G ANT +Array Gain. For power measurements, Array Gain=0dB (N ANT ≤4), so the Directional gain=4.81. For power spectral density measurements, N ANT =2, N SS = 1. So the Directional gain=G ANT +Array Gain=G ANT +10log(N ANT / N SS )dBi=4.81+10log(2/1)dBi=7.82. 2) The antenna gain is provided by the manufacturer. For WLAN 5GHz: Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 LGY IQ4 Dipole IPEX 9.57 2 LGY IQ4 Dipole IPEX 6.86 Note: 1) This EUT supports CDD, all antenna gains are not equal, Directional gain = G ANT +Array Gain. For power measurements, Array Gain=0dB (N ANT ≤4), so the Directional gain=9.57. For power spectral density measurements, N ANT =2, N SS = 1. So the Directional gain=G ANT +Array Gain=G ANT +10log(N ANT / N SS )dBi=9.57+10log(2/1)dBi=12.58. 2) The antenna gain is provided by the manufacturer. Report No.: BTL-FCCP-6-2503C328 Report Version: R00 Page 4 of 4 3. CALCULATED RESULT For BT EDR: Antenna Gain (dBi) Antenna Gain (numeric) Max. Peak Output Power (dBm) Max. Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 3.09 2.0370 6.10 4.0738 0.00165 1 Pass For BT LE: Antenna Gain (dBi) Antenna Gain (numeric) Max. Peak Output Power (dBm) Max. Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 3.09 2.0370 6.10 4.0738 0.00165 1 Pass For WLAN 2.4GHz: Directional Gain (dBi) Directional Gain (numeric) Max. Average Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 4.81 3.0269 21.75 149.6236 0.09015 1 Pass For WLAN 5GHz: Directional Gain (dBi) Directional Gain (numeric) Max. Average Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 9.57 9.0573 16.72 46.9894 0.08471 1 Pass For the max simultaneous transmission MPE: Ratio To tal Limit of Ratio Test Result BT EDR WLAN 2.4GHz 0.00165 0.09015 0.09180 1 Pass Note: (1) The calculated distance is 20 cm. (2) Ratio=Power Density (S) (mW/cm 2 )/Limit of Power Density (S) (mW/cm 2 ) End of Test Report

Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 31 of 102 11. EUT TEST PHOTO AC Power Line Conducted Emissions Test Photos Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 32 of 102 Radiated Emissions Test Photos 9 kHz to 30 MHz Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 33 of 102 Radiated Emissions Test Photos 30 MHz to 1 GHz Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 34 of 102 Radiated Emissions Test Photos Band edge & Harmonic(1 GHz to 18 GHz) Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 35 of 102 Radiated Emissions Test Photos Harmonic(18 GHz to 26.5 GHz) Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 36 of 102 Conducted Test Photos

Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 97 of 102 Test Mode TX G Mode_Ant. 1 Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 -8.89 6.18 Pass 06 2437 -8.96 6.18 Pass 11 2462 -9.04 6.18 Pass CH01 CH06 CH11 Test Mode TX G Mode_Ant. 2 Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 -9.18 6.18 Pass 06 2437 -9.49 6.18 Pass 11 2462 -9.41 6.18 Pass CH01 CH06 CH11 Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 98 of 102 Test Mode TX G Mode_Total Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 -6.02 6.18 Pass 06 2437 -6.21 6.18 Pass 11 2462 -6.21 6.18 Pass Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 99 of 102 Test Mode TX AX(HE20) Mode_Ant. 1 Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 -13.45 6.18 Pass 06 2437 -14.10 6.18 Pass 11 2462 -13.73 6.18 Pass CH01 CH06 CH11 Test Mode TX AX(HE20) Mode_Ant. 2 Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 -14.59 6.18 Pass 06 2437 -14.85 6.18 Pass 11 2462 -14.59 6.18 Pass CH01 CH06 CH11 Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 100 of 102 Test Mode TX AX(HE20) Mode_Total Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 -10.97 6.18 Pass 06 2437 -11.45 6.18 Pass 11 2462 -11.13 6.18 Pass Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 101 of 102 Test Mode TX AX(HE40) Mode_Ant. 1 Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 03 2422 -16.43 6.18 Pass 06 2437 -16.33 6.18 Pass 09 2452 -17.00 6.18 Pass CH03 CH06 CH09 Test Mode TX AX(HE40) Mode_Ant. 2 Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 03 2422 -16.60 6.18 Pass 06 2437 -16.43 6.18 Pass 09 2452 -16.51 6.18 Pass CH03 CH06 CH09 Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 102 of 102 Test Mode TX AX(HE40) Mode_Total Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 03 2422 -13.50 6.18 Pass 06 2437 -13.37 6.18 Pass 09 2452 -13.73 6.18 Pass End of Test Report

Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 78 of 102 Test Mode TX AX(HE20) Mode Channel Frequency (MHz) 6 dB Bandwidth (MHz) 99 % Occupied Bandwidth (MHz) 6 dB Bandwidth Min. Limit (MHz) Result 01 2412 18.600 18.935 0.5 Pass 06 2437 18.640 18.939 0.5 Pass 11 2462 18.600 18.943 0.5 Pass CH01 CH06 CH11 6 dB Bandwidth 99 % Occupied Bandwidth Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 79 of 102 Test Mode TX AX(HE40) Mode Channel Frequency (MHz) 6 dB Bandwidth (MHz) 99 % Occupied Bandwidth (MHz) 6 dB Bandwidth Min. Limit (MHz) Result 03 2422 38.000 37.975 0.5 Pass 06 2437 38.000 37.973 0.5 Pass 09 2452 37.600 38.043 0.5 Pass CH03 CH06 CH09 6 dB Bandwidth 99 % Occupied Bandwidth Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 80 of 102 FAPPENDIX F - MAXIMUM OUTPUT POWER Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 81 of 102 Test Mode TX B Mode_Ant 1 Channel Frequency (MHz) Output Power (dBm) Duty Factor (dB) Output Power + Duty Factor (dBm) Max. Limit (dBm) Max. Limit (W) Result 01 2412 18.55 0.00 18.55 30.00 1.0000 Pass 06 2437 18.66 0.00 18.66 30.00 1.0000 Pass 11 2462 18.59 0.00 18.59 30.00 1.0000 Pass Test Mode TX B Mode_Ant 2 Channel Frequency (MHz) Output Power (dBm) Duty Factor (dB) Output Power + Duty Factor (dBm) Max. Limit (dBm) Max. Limit (W) Result 01 2412 18.53 0.00 18.53 30.00 1.0000 Pass 06 2437 18.81 0.00 18.81 30.00 1.0000 Pass 11 2462 18.74 0.00 18.74 30.00 1.0000 Pass Test Mode TX B Mode_Total Channel Frequency (MHz) Output Power (dBm) Max. Limit (dBm) Max. Limit (W) Result 01 2412 21.55 30.00 1.0000 Pass 06 2437 21.75 30.00 1.0000 Pass 11 2462 21.68 30.00 1.0000 Pass Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 82 of 102 Test Mode TX G Mode_Ant 1 Channel Frequency (MHz) Output Power (dBm) Duty Factor (dB) Output Power + Duty Factor (dBm) Max. Limit (dBm) Max. Limit (W) Result 01 2412 17.86 0.00 17.86 30.00 1.0000 Pass 06 2437 17.53 0.00 17.53 30.00 1.0000 Pass 11 2462 17.59 0.00 17.59 30.00 1.0000 Pass Test Mode TX G Mode_Ant 2 Channel Frequency (MHz) Output Power (dBm) Duty Factor (dB) Output Power + Duty Factor (dBm) Max. Limit (dBm) Max. Limit (W) Result 01 2412 18.22 0.00 18.22 30.00 1.0000 Pass 06 2437 18.16 0.00 18.16 30.00 1.0000 Pass 11 2462 17.94 0.00 17.94 30.00 1.0000 Pass Te s t M o de TX G Mode_Total Channel Frequency (MHz) Output Power (dBm) Max. Limit (dBm) Max. Limit (W) Result 01 2412 21.05 30.00 1.0000 Pass 06 2437 20.87 30.00 1.0000 Pass 11 2462 20.78 30.00 1.0000 Pass Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 83 of 102 Test Mode TX AX(HE20) Mode_Ant 1 Channel Frequency (MHz) Output Power (dBm) Duty Factor (dB) Output Power + Duty Factor (dBm) Max. Limit (dBm) Max. Limit (W) Result 01 2412 13.12 0.00 13.12 30.00 1.0000 Pass 06 2437 12.86 0.00 12.86 30.00 1.0000 Pass 11 2462 12.72 0.00 12.72 30.00 1.0000 Pass Te st Mode TX AX(HE20) Mode_Ant 2 Channel Frequency (MHz) Output Power (dBm) Duty Factor (dB) Output Power + Duty Factor (dBm) Max. Limit (dBm) Max. Limit (W) Result 01 2412 13.45 0.00 13.45 30.00 1.0000 Pass 06 2437 13.53 0.00 13.53 30.00 1.0000 Pass 11 2462 13.10 0.00 13.10 30.00 1.0000 Pass Test Mode TX AX(HE20) Mode_Total Channel Frequency (MHz) Output Power (dBm) Max. Limit (dBm) Max. Limit (W) Result 01 2412 16.30 30.00 1.0000 Pass 06 2437 16.22 30.00 1.0000 Pass 11 2462 15.92 30.00 1.0000 Pass Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 84 of 102 Test Mode TX AX(HE40) Mode_Ant 1 Channel Frequency (MHz) Output Power (dBm) Duty Factor (dB) Output Power + Duty Factor (dBm) Max. Limit (dBm) Max. Limit (W) Result 03 2422 13.15 0.00 13.15 30.00 1.0000 Pass 06 2437 12.94 0.00 12.94 30.00 1.0000 Pass 09 2452 12.89 0.00 12.89 30.00 1.0000 Pass Test Mode TX AX(HE40) Mode_Ant 2 Channel Frequency (MHz) Output Power (dBm) Duty Factor (dB) Output Power + Duty Factor (dBm) Max. Limit (dBm) Max. Limit (W) Result 03 2422 13.81 0.00 13.81 30.00 1.0000 Pass 06 2437 13.54 0.00 13.54 30.00 1.0000 Pass 09 2452 13.61 0.00 13.61 30.00 1.0000 Pass Test Mode TX AX(HE40) Mode_Total Channel Frequency (MHz) Output Power (dBm) Max. Limit (dBm) Max. Limit (W) Result 03 2422 16.50 30.00 1.0000 Pass 06 2437 16.26 30.00 1.0000 Pass 09 2452 16.28 30.00 1.0000 Pass Note: Output power = Measure result + Cable loss Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 85 of 102 APPENDIX G - CONDUCTED SPURIOUS EMISSIONS Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 86 of 102 Test Mode TX B Mode_Ant. 1 Reference Level-CH01 Reference Level-CH06 Reference Level-CH11 Bandedge-CH01 Bandedge-CH11 Harmonic-CH01 Harmonic-CH06 Harmonic-CH11 Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 87 of 102 Test Mode TX B Mode_Ant. 2 Reference Level-CH01 Reference Level-CH06 Reference Level-CH11 Bandedge-CH01 Bandedge-CH11 Harmonic-CH01 Harmonic-CH06 Harmonic-CH11 Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 88 of 102 Test Mode TX G Mode_Ant. 1 Reference Level-CH01 Reference Level-CH06 Reference Level-CH11 Bandedge-CH01 Bandedge-CH11 Harmonic-CH01 Harmonic-CH06 Harmonic-CH11 Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 89 of 102 Test Mode TX G Mode_Ant. 2 Reference Level-CH01 Reference Level-CH06 Reference Level-CH11 Bandedge-CH01 Bandedge-CH11 Harmonic-CH01 Harmonic-CH06 Harmonic-CH11 Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 90 of 102 Test Mode TX AX(HE20) Mode_Ant. 1 Reference Level-CH01 Reference Level-CH06 Reference Level-CH11 Bandedge-CH01 Bandedge-CH11 Harmonic-CH01 Harmonic-CH06 Harmonic-CH11 Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 91 of 102 Test Mode TX AX(HE20) Mode_Ant. 2 Reference Level-CH01 Reference Level-CH06 Reference Level-CH11 Bandedge-CH01 Bandedge-CH11 Harmonic-CH01 Harmonic-CH06 Harmonic-CH11 Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 92 of 102 Test Mode TX AX(HE40) Mode_Ant. 1 Reference Level-CH03 Reference Level-CH06 Reference Level-CH09 Bandedge-CH03 Bandedge-CH09 Harmonic-CH03 Harmonic-CH06 Harmoni…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 1 of 102 FCC Radio Test Report FCC ID: 2AUTE-IQ4 This report concerns: Original Grant Project No. : 2503C328 Equipment : 1) Thermal Transfer Barcode Printer 2) Barcode Printer Brand Name : HPRT, iDPRT Model Name : iQ4, iQ4 PLUS, Q400, Q410, Q420, Q430, iQ400, iQ410, iQ420, iQ430, TT4210, Neo, QT400, QT410, QT231, QT230, QT430, QT240, QS40, QS410, QS231, QS400, QS240, QE40, QE410, QE231, QE400, QE240, QN40, QN410, QN231, QN400, QN240, QW40, QW410, QW231, QW400, QW240, TT400, TT410, TT231, TT230, TT430, XQ400, XQ410, XQ420, XQ430, XQ231, XQ240 Applicant : Xiamen Hanin Co., Ltd. Address : Room 305A, Angye Building, Pioneering Park,Torch High-tech Zone,Xiamen,China Manufacturer : Xiamen Hanin Co., Ltd. Address : Room 305A, Angye Building, Pioneering Park,Torch High-tech Zone,Xiamen,China Factory : Xiamen Hanin Co., Ltd. Address : 96# Rongyuan Road,Tong’an District, 361000 Xiamen,China Date of Receipt : Apr. 01, 2025 Date of Test : Apr. 08, 2025 ~ Aug. 21, 2025 Issued Date : Sep. 01, 2025 Test Sample : Engineering Sample No.: DG2025040127 & DG2025080621 for AC power line conducted emissions and radiated, DG2025040127 for power, DG2025040127-24 for others. Standard(s) : FCC CFR Title 47, Part 15, Subpart C The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. (Dongguan) Prepared by : Antony Liang Approved by : Steven Lu No.3, Jinshagang 1st Road, Dalang, Dongguan, Guangdong People’s Republic of China. Te l : + 8 6-769-8318-3000 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 2 of 102 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL assumes no responsibility for the data provided by the customer, any statements, inferences or generalizations drawn by the customer or others from the reports issued by BTL. The report must not be used by the client to claim product certification, approval, or endorsement by A2LA or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025: 2017 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 3 of 102 Table of Contents Page REVISION HISTORY 6 1 . APPLICABLE STANDARDS 7 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 2.3 TEST ENVIRONMENT CONDITIONS 9 3 . GENERAL INFORMATION 10 3.1 GENERAL DESCRIPTION OF EUT 10 3.2 DESCRIPTION OF TEST MODES 12 3.3 PARAMETERS OF TEST SOFTWARE 13 3.4 DUTY CYCLE 14 3.5 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 16 3.6 SUPPORT UNITS 16 3.7 CUSTOMER INFORMATION DESCRIPTION 16 4 . AC POWER LINE CONDUCTED EMISSIONS 17 4.1 LIMIT 17 4.2 TEST PROCEDURE 17 4.3 DEVIATION FROM TEST STANDARD 17 4.4 TEST SETUP 18 4.5 EUT OPERATION CONDITIONS 18 4.6 TEST RESULTS 18 5 . RADIATED EMISSIONS 19 5.1 LIMIT 19 5.2 TEST PROCEDURE 20 5.3 DEVIATION FROM TEST STANDARD 21 5.4 TEST SETUP 21 5.5 EUT OPERATION CONDITIONS 23 5.6 TEST RESULTS - 9 KHZ TO 30 MHZ 23 5.7 TEST RESULTS - 30 MHZ TO 1000 MHZ 23 5.8 TEST RESULTS - ABOVE 1000 MHZ 23 6 . BANDWIDTH 24 6.1 LIMIT 24 Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 4 of 102 Table of Contents Page 6.2 TEST PROCEDURE 24 6.3 DEVIATION FROM STANDARD 24 6.4 TEST SETUP 24 6.5 EUT OPERATION CONDITIONS 24 6.6 TEST RESULTS 24 7 . MAXIMUM OUTPUT POWER 25 7.1 LIMIT 25 7.2 TEST PROCEDURE 25 7.3 DEVIATION FROM STANDARD 25 7.4 TEST SETUP 25 7.5 EUT OPERATION CONDITIONS 25 7.6 TEST RESULTS 25 8 . CONDUCTED SPURIOUS EMISSIONS 26 8.1 LIMIT 26 8.2 TEST PROCEDURE 26 8.3 DEVIATION FROM STANDARD 27 8.4 TEST SETUP 27 8.5 EUT OPERATION CONDITIONS 27 8.6 TEST RESULTS 27 9 . POWER SPECTRAL DENSITY 28 9.1 LIMIT 28 9.2 TEST PROCEDURE 28 9.3 DEVIATION FROM STANDARD 28 9.4 TEST SETUP 28 9.5 EUT OPERATION CONDITIONS 28 9.6 TEST RESULTS 28 10 . MEASUREMENT INSTRUMENTS LIST 29 11 . EUT TEST PHOTO 31 APPENDIX A - AC POWER LINE CONDUCTED EMISSIONS 37 APPENDIX B - RADIATED EMISSION - 9 KHZ TO 30 MHZ 40 APPENDIX C - RADIATED EMISSION - 30 MHZ TO 1000 MHZ 45 APPENDIX D - RADIATED EMISSION- ABOVE 1000 MHZ 48 Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 5 of 102 Table of Contents Page APPENDIX E - BANDWIDTH 75 FAPPENDIX F - MAXIMUM OUTPUT POWER 80 APPENDIX G - CONDUCTED SPURIOUS EMISSIONS 85 APPENDIX H - POWER SPECTRAL DENSITY 94 Report No.: BTL-FCCP-3-2503C328 Report Version: R00 Page 6 of 102 REVISION HISTORY Report No. Version Description Issued Date N…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-2-2503C328 Report Version: R00 Page 1 of 59 FCC Radio Test Report FCC ID: 2AUTE-IQ4 This report concerns: Original Grant Project No. : 2503C328 Equipment : 1) Thermal Transfer Barcode Printer 2) Barcode Printer Brand Name : HPRT, iDPRT Model Name : iQ4, iQ4 PLUS, Q400, Q410, Q420, Q430, iQ400, iQ410, iQ420, iQ430, TT4210, Neo, QT400, QT410, QT231, QT230, QT430, QT240, QS40, QS410, QS231, QS400, QS240, QE40, QE410, QE231, QE400, QE240, QN40, QN410, QN231, QN400, QN240, QW40, QW410, QW231, QW400, QW240, TT400, TT410, TT231, TT230, TT430, XQ400, XQ410, XQ420, XQ430, XQ231, XQ240 Applicant : Xiamen Hanin Co., Ltd. Address : Room 305A, Angye Building, Pioneering Park,Torch High-tech Zone,Xiamen,China Manufacturer : Xiamen Hanin Co., Ltd. Address : Room 305A, Angye Building, Pioneering Park,Torch High-tech Zone,Xiamen,China Factory : Xiamen Hanin Co., Ltd. Address : 96# Rongyuan Road,Tong’an District, 361000 Xiamen,China Date of Receipt : Apr. 01, 2025 Date of Test : Apr. 08, 2025 ~ Aug. 21, 2025 Issued Date : Sep. 01, 2025 Test Sample : Engineering Sample No.: DG2025040127 & DG2025080621 for AC power line conducted emissions and radiated, DG2025040127-24 for others. Standard(s) : FCC CFR Title 47, Part 15, Subpart C The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. (Dongguan) Prepared by : Antony Liang Approved by : Steven Lu No.3, Jinshagang 1st Road, Dalang, Dongguan, Guangdong People’s Republic of China. Te l : + 8 6-769-8318-3000 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-FCCP-2-2503C328 Report Version: R00 Page 2 of 59 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL assumes no responsibility for the data provided by the customer, any statements, inferences or generalizations drawn by the customer or others from the reports issued by BTL. The report must not be used by the client to claim product certification, approval, or endorsement by A2LA or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025: 2017 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-2-2503C328 Report Version: R00 Page 3 of 59 Table of Contents Page REVISION HISTORY 6 1 . APPLICABLE STANDARDS 7 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 2.3 TEST ENVIRONMENT CONDITIONS 9 3 . GENERAL INFORMATION 10 3.1 GENERAL DESCRIPTION OF EUT 10 3.2 DESCRIPTION OF TEST MODES 11 3.3 PARAMETERS OF TEST SOFTWARE 11 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.5 SUPPORT UNITS 12 3.6 CUSTOMER INFORMATION DESCRIPTION 12 4 . AC POWER LINE CONDUCTED EMISSIONS 13 4.1 LIMIT 13 4.2 TEST PROCEDURE 13 4.3 DEVIATION FROM TEST STANDARD 13 4.4 TEST SETUP 14 4.5 EUT OPERATING CONDITIONS 14 4.6 TEST RESULTS 14 5 . RADIATED EMISSIONS 15 5.1…

Text truncated - open the document above for the full version.
