MWC415 User Manual Miliwave 1 / 7 MWC415 User Manual 60GHz RF/BB Module with USB3.0 interface Rev. 1.0 2020-06-17 MWC415 User Manual Miliwave 2 / 7 Revision History Date Written by Rev. Description 20.006.17 Ken. Jung 1.0 MWC415 User manual .1.0 Release Address: 423 R&DB Center, 105 YoungTong-Gu, SuWon-Si, GyeongGi-Do, 16229 Korea http://www.miliwave.co.kr/ Tel. 070-8825-0630 Fax. Email: [email protected] Copyright © Miliwave Inc. 2020. All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Miliwave Co., Ltd. All specification supplied herein are subject to change without notice at any time. MWC415 User Manual Miliwave 3 / 7 1.Introduction 1.1 Overview Miliwave’s MWC415 module operates in the 60GHz unlicensed frequency band, IEEE802.11ad compliant, and is designed for only using for Smart Factory IoT Applications(ex. AMR(Autonounous Moving Robot, Machine Vision Camera) with , Point to Multi-Pont (PTMP) or Point to Point (PTP) bridge wireless communication, primarily for Line-of Sight (LOS) operation. The MWC415 module connects to a Linux based Host Communication Processor board via an available USB 3.0 port . All required drivers and firmware is pre-installed on the MWC415 module as a self-contained device . However, the MWC415 module would not be operational unless it is connected to the Linux- based Host Communication Processor board for PTP or PTMP bridge wireless communication. For more information, please contact your Miliwave ([email protected]) < Figure 1. MWC415 Use Case for Smart Factory(ex. AMR, Machine Vision Camera)> MWC415 User Manual Miliwave 4 / 7 1.2 Abbreviations and Acronym Definitions 1.3 MWC415 Module Description The Miliwave's MWC415 module in conjunction with the Host Communication Processor board can function as a PTP or PTMP wireless bridge communication . Main chracteristics of the MWC415 module include: - Adaptive Modulation and Link Adaptation: Up to 16QAM and MCS1-12 support - Integrated Phased Array Planar Antena: EIRP 16dBm, 120 degree beam sweep range - Advanced Security: AES-128 - Compact Form Factor: 37 x14 x 72mm Acronym Definition GbpsGiga bits per second GHzGiga Hertz IEEEInstitute of Electrical and Electronics Engineers LEDLight Emitting Diode LoSline-of-sight MbpsMega bits per second MCSModulation and Coding Scheme MHzMega Hertz PTMPPoint-to-multipoint Communication QAMQuadrature amplitude modulation <Figure 2. MWC415> MWC415 User Manual Miliwave 5 / 7 - Connectivity: USB 3.0 type A, 60GHz wireless 2. Technical Specifications - Aggregate capacity: 1.0Gbps uni-directional, 2.0 Gbps bi-directional - Latency : less than 1 millisecond round-trip - Security: AES-128 - I/O interface: USB 3.0(Type Micro-A) - Other Interface: LEDs indicators for connection status 3.0 Radio Specifications - Modulation : Single Carrier(SC) - Time Division Duplex - Frequencies: 59.40 ~ 61.56GHz(Ch.2) - Channel Bandwidth: 2.16 GHz - Antenna: Double Side Dipoles(DSD) 2 or 4 elements Phased Arrays to Scan over 240 degrees in azimuth - EIRP: 16 dBm 4.0 Mechanical, Power and Environmental Specification - Dimension(L x W x H): 37 x 14 x 72mm - Weight: 27g - Power Consumption: 4W(Max) - Operating Temperature: -40ºC ~ +85ºC - Humidity: 5%~95% MWC415 User Manual Miliwave 6 / 7 5.0 Module Throughput - MCS Index : 0~12, - Modulation: BPSK, QPSK, 16QAM - Data Rate : Max PHY rate 4620 Mbit/s 6.0 Installation The MWC415 could only be installed with Host Communication Processor board at the factory level. There is no user serviceable parts in the MWC415 module 7.0 FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. The antenna(s) must be installed such that a minimum separation distance of at least 20 cm is maintained between the radiator (antenna) and all persons at all times. MWC415 User Manual Miliwave 7 / 7 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help.

Miliwave Co., Ltd. 423, 105, Gwanggyo-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, South Korea Date: Jun 15, 2020 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA Letter of Authorization We, the undersigned, hereby authorize Guenki Son of DT&C Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCC ID: 2AVCWMWC415 including signing of all documents relating to these matters. Any and all acts carried out by Guenki Son of DT&C Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Miliwave Co., Ltd. “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Sean Rha VP of Business Development

Miliwave Co., Ltd. 423, 105, Gwanggyo-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, South Korea Date: June.15 . 2020 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA RE: Request of Confidentiality for FCC ID: 2AVCWMWC415 To Whom It may Concern: Pursuant to Sections 0.457 and 0.459 of the Commission`s Rules(CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Miliwave Co., Ltd. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give Miliwave Co., Ltd. temporary confidentiality of commercially sensitive information prior to product release. The requested permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT & SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Schematics 3 Part Lists 4 Operation Description 5 NA SHORT-TERM 6 Internal Photos 7 External Photos 8 Test-Setup Photos 9 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be public before the date of the Grant for this application. Sincerely, Sean Rha VP of Business Development

FCC ID : 2AVCWMWC415 Copyright Ⓒ 2020, DT&C Co., Ltd. View 1 FCC ID : 2AVCWMWC415 Copyright Ⓒ 2020, DT&C Co., Ltd. View 2 FCC ID : 2AVCWMWC415 Copyright Ⓒ 2020, DT&C Co., Ltd. View 3

FCC ID : 2AVCWMWC415 Copyright Ⓒ 2020, DT&C Co., Ltd. View 1 FCC ID : 2AVCWMWC415 Copyright Ⓒ 2020, DT&C Co., Ltd. View 2 FCC ID : 2AVCWMWC415 Copyright Ⓒ 2020, DT&C Co., Ltd. View 3 FCC ID : 2AVCWMWC415 Copyright Ⓒ 2020, DT&C Co., Ltd. View 4 <Antenna>

FCC ID: RF function or Mode Max. tune-up EIRP (dBm) Note1 Max. tune-up EIRP (mW) Maximum power density (mW/cm 2 ) Requriment (mW/cm 2 ) 802.11ad60480~6048022.00158.48940.03161.000 ~ ~ ~ ~ ~ ~ ~ ~ ▪ S =- Note = / ( 4 X 20 2 X π ) = mW/cm 2 Electric Field strength (V/m) Magnetic field strength (A/m) Power Density (mW/cm 2 ) Averageing time (minutes) 0.3~1.346141.63*10030 1.34~30824/f2.19 / f *180 / f 2 30 30~30027.50.0730.230 300~1,500f / 150030 1,500~100,0001.030 Conclusion : The exposure condition of this device is compliant with FCC EIRP / ( 4 R 2 π ) 158.4894 S= Maximum power density(mW/cm 2 ) 0.0316 EIRP= Equivalent Isotropic Radiated Power(mW) f = frequency in MHz * = Plane-wave equivalent power density ▪ Limits for General Population/Uncontrolled Exposure Frequency range (MHz) R= Distance to the center of the radiation of the antenna(20cm) 2AVCWMWC415 Frequency range (MHz) The EUT will only be used with a separation of 20 centimeters or greater between the antenna and the body of the user. The MPE sample calculation for this exposure is shown below. Note1: Please refer to the Operational Description for Max tune-up EIRP. MPE Calculation

Report No.: DRTFCC2006-0171 FCC ID: 2AVCWMWC415 TRF-RF-245(00)200113 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 2 / 27 Test Report Version Test Report No. Date Description Revised by Reviewed by DRTFCC2006-0171 Jun. 15, 2020 Initial issue JungWoo Kim Geunki Son Report No.: DRTFCC2006-0171 FCC ID: 2AVCWMWC415 TRF-RF-245(00)200113 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 3 / 27 Table of Contents 1. EUT DESCRIPTION ................................................................................... 4 2. INFORMATION ABOUT TESTING ............................................................. 5 2.1 Transmitting configuration of EUT .................................................................................... 5 2.2 Auxiliary equipment ............................................................................................................ 5 2.3 Tested environment ............................................................................................................ 6 2.4 EMI suppression Device(s) / Modifications ....................................................................... 6 2.5 Measurement Uncertainty .................................................................................................. 6 3 SUMMARY OF TEST RESULTS ................................................................. 7 4. TEST METHODOLOGY ............................................................................. 8 4.1 EUT configuration ............................................................................................................... 8 4.2 EUT exercise ....................................................................................................................... 8 4.3 General test procedures ..................................................................................................... 8 4.4 Description of test modes .................................................................................................. 8 5. INSTRUMENT CALIBRATION ................................................................... 9 6. FACILITIES AND ACCREDITATIONS........................................................ 9 6.1 Facilities .............................................................................................................................. 9 6.2 Equipment ........................................................................................................................... 9 7. ANTENNA REQUIREMENTS .................................................................... 9 8 TEST RESULTS ........................................................................................ 10 8.1 20dB Bandwidth ................................................................................................................ 10 8.2 Equivalent Isotropic Radiated Power .............................................................................. 12 8.3 Radiated spurious emissions .......................................................................................... 14 8.4 Frequency stability ........................................................................................................... 21 8.5 AC line conducted emissions .......................................................................................... 23 9 LIST OF TEST EQUIPMENT .................................................................... 26 APPENDIX I ................................................................................................. 27 Report No.: DRTFCC2006-0171 FCC ID: 2AVCWMWC415 TRF-RF-245(00)200113 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 4 / 27 1. EUT DESCRIPTION FCC Equipment Class DXX – Part 15 Low Power communication Device Transmitter Product IEEE802.11ad 60GHz Model Name MWC415 Add Model Name - Power Supply DC 5 V Frequency Range 802.11ad: 60.48 GHz Max. RF Output Power (EIRP) 802.11ad : 20.46 dBm Modulation Type Spread spectrum, PHY modulation Data Rate MCS 0 ~ 12 (up to 4620 Mbps) Antenna Specification Antenna type: Broad band array Antenna gain(Max): 8.5 dBi Report No.: DRTFCC2006-0171 FCC ID: 2AVCWMWC415 TRF-RF-245(00)200113 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 5 / 27 2. INFORMATION ABOUT TESTING 2.1 Transmitting configuration of EUT Test Mode Worst case data rate Test Frequency(GHz) 802.11ad MCS 1 (385 Mbps) 60.48 GHz (ch.2) - - Note 1: The worst case data is determined as above test mode according to the power measurements. Operation test setup for EUT - Software: Tera term 2.2 Auxiliary equipment Equipment Model No. Serial No. Manufacturer Note - - - - - - - - - - Report No.: DRTFCC2006-0171 FCC ID: 2AVCWMWC415 TRF-RF-245(00)200113 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 6 / 27 2.3 Tested environment Temperature : 20 o C ~ 25 o C Relative humidity content : 37 % ~ 43 % Details of power supply : DC 5.0 V 2.4 EMI suppression Device(s) / Modifications EMI suppression device(s) added and/or modifications made during testing → None 2.5 Measurement Uncertainty The measurement uncertainties shown below were calculated in accordance with requirements of ANSI C 63.4- 2014 and ANSI C 63.10-2013. All measurement uncertainty values are shown with a coverage factor of k = 2 to indicate a 95 % level of confidence. Test items Measurement uncertainty AC conducted emission 2.4 dB (The confidence level is about 95 %, k = 2) Radiated spurious emission (1 GHz Below) 4.9 dB (The confidence level is about 95 %, k = 2) Radiated spurious emission (1 GHz ~ 18 GHz) 5.1 dB (The confidence level is about 95 %, k = 2) Radiated spurious emission (18 GHz Above) 5.3 dB (The confidence level is about 95 %, k = 2) Report No.: DRTFCC2006-0171 FCC ID: 2AVCWMWC415 TRF-RF-245(00)200113 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 7 / 27 3 SUMMARY OF TEST RESULTS FCC Part Section(s) …
