AS5BBTRX-22B25 RRH 4X30

APPLICANT: Alcatel-Lucent EXHIBIT 4 FCC ID: AS5BBTRX-22 Page 1 of 1 EXHIBIT 4 Section 2.1033 (c)(3) INSTALLATION AND OPERATING INSTRUCTIONS A copy of the installation and operating instructions to be furnished to the user. A draft copy of the instructions may be submitted if the actual document is not available. The actual document shall be furnished to the FCC when it becomes available. Response A copy of Alcatel-Lucent B25 RRH 4X30 Hardware Installation manual is attached to this exhibit. Title page Alcatel-Lucent B25 RRH4x30 SitePreparationGuidelines 3MN-02023-0001-RJZZA Issue 0.02 | January 2015 Alcatel-Lucent–Proprietary Use pursuant to applicable agreements Use pursuant to applicable agreements D RAFT D RAFT Legal notice Legalnotice Alcatel,Lucent,Alcatel-LucentandtheAlcatel-LucentlogoaretrademarksofAlcatel-Lucent.Allothertrademarksarethepropertyoftheirrespective owners. Theinformationpresentedissubjecttochangewithoutnotice.Alcatel-Lucentassumesnoresponsibilityforinaccuraciescontainedherein. Copyright©2015Alcatel-Lucent.Allrightsreserved. Containsproprietary/tradesecretinformationwhichisthepropertyofAlcatel-Lucentandmustnotbemadeavailableto,orcopiedorusedbyanyoneoutside Alcatel-Lucentwithoutitswrittenauthorization. Nottobeusedordisclosedexceptinaccordancewithapplicableagreements. Notice Everyeffortwasmadetoensurethattheinformationinthisdocumentwascompleteandaccurateatthetimeofprinting.However,informationissubjectto change. Mandatorycustomerinformation ProductconformancestatementscanbefoundinAppendixD,“Productconformancestatements”. Use pursuant to applicable agreements Alcatel-Lucent–Proprietary Use pursuant to applicable agreements D RAFT D RAFT Contents Aboutthisdocument Purpose .............................................................................................................................................................................................ixix Intendedaudience .........................................................................................................................................................................ixix Supportedsystems ........................................................................................................................................................................ixix Safetyinformation ........................................................................................................................................................................ixix Conventionsused ..........................................................................................................................................................................ixix Relatedinformation .....................................................................................................................................................................xixi Documentsupport ......................................................................................................................................................................xiiixiii Technicalsupport .......................................................................................................................................................................xiiixiii Howtoorder ................................................................................................................................................................................xiiixiii Howtocomment ........................................................................................................................................................................xiiixiii 1Safety Overview ......................................................................................................................................................................................1-11-1 Structureofsafetystatements ...............................................................................................................................................1-21-2 Basicsafetyaspects ..................................................................................................................................................................1-41-4 Safety-Generalprecautionsforinstallationprocedures ...........................................................................................1-71-7 Safety-Specifichazards ........................................................................................................................................................1-81-8 Productsafety ..........................................................................................................................................................................1-111-11 2Productoverview Overview ......................................................................................................................................................................................2-12-1 Functionaldescription .............................................................................................................................................................2-22-2 Physicaldescription .................................................................................................................................................................2-42-4 Weightsanddimensions .........................................................................................................................................................2-72-7 .................................................................................................................................................................................................................................... B25 RRH4x30 3MN-02023-0001-RJZZA Issue 0.02 January 2015 Alcatel-Lucent–Proprietary Use pursuant to applicable agreements iii D RAFT D RAFT 3Externalinterfaces Overview ........................................................................................................…

Text truncated - open the document above for the full version.

- 1 - Alcatel-Lucent USA 600-700 Mountain Ave., Rm 28-114H PO Box 636 Murray Hill, NJ 07974 January 19, 2015 Timco Engineering Inc. Telecommunication Certification Bodies 849 NW State Road 45 Newberry, Florida 32669 Subject: Request for Confidentiality for FCC ID: AS5BBTRX-22 Dear Examiner: Pursuant to Sections 0.457 & 0.459 of the Commission’s Rules, we request that the following exhibits, included in the certification application for the FCC ID: AS5BBTRX-22, be maintained as confidential information and not be made available for public inspection at any time. 1. 2. Exhibit 4 Exhibit 6 Installation and Operating Instructions - Short-Term Confidential for 180 days Circuit Schematic Diagrams 3. Exhibit 7 Description of Circuitry and Devices for Determining and Stabilizing Frequency and for Limiting Modulation and Power and Description of the Digital Modulation System These exhibits contain critical design information and are highly proprietary that cannot be made available for public inspection. This information is proprietary both to Alcatel-Lucent and to Alcatel-Lucent’s contracted design manufacturers. The proprietary information contained in these exhibits is considered to be trade secrets and the property of Alcatel-Lucent and its contracted design manufacturers, pursuant to the provisions of Section 0.457(d) of the Commission’s Rules and Section 552 (b) (4) of the Freedom of Information Act. Thank you for your consideration in this matter. Sincerely, R.J. Pillmeier Technical Manager FCC Compliance Test Group

APPLICANT: Alcatel-Lucent, USA FCCID: AS5BBTRX-22 Page 1 of 6 EXHIBIT 9a Section 2.1033 (c) (12) PHOTOGRAPHS OF THE EQUIPMENT Photographs (8 x 10) of the equipment of sufficient clarity to reveal equipment construction and layout, including meters, if any, and labels for controls and meters and sufficient views of the internal construction to define component placement and chassis assembly. Insofar as these requirements are met by photographs or drawings contained in instruction manuals supplied with the certification request, additional photographs are necessary only to complete the required showing. Response The following pages contain the required external photographs of the AS5BBTRX-22, B25 RRH 4X30, subject of this application. Seven External photos in total were submitted, which include: 1) External Front View of the RRH with Solar shield 2) External Front View of the RRH without Solar shield 3) External Rear View of the RRH without Solar shield 4) External Top View of the RRH 5) External Bottom View of the RRH 6) External Right Side View of the RRH 7) External Left Side View of the RRH APPLICANT: Alcatel-Lucent, USA FCCID: AS5BBTRX-22 Page 2 of 6 External Front View of the RRH with Solar shield External Front View of the RRH without Solar shield APPLICANT: Alcatel-Lucent, USA FCCID: AS5BBTRX-22 Page 3 of 6 External Rear View of the RRH without Solar shield APPLICANT: Alcatel-Lucent, USA FCCID: AS5BBTRX-22 Page 4 of 6 External Top View of the RRH External Bottom View of the RRH APPLICANT: Alcatel-Lucent, USA FCCID: AS5BBTRX-22 Page 5 of 6 External Right Side View of the RRH APPLICANT: Alcatel-Lucent, USA FCCID: AS5BBTRX-22 Page 6 of 6 External Left Side View of the RRH

APPLICANT: Alcatel-Lucent, USA EXHIBIT 8 FCCID: AS5BBTRX-22 Page 1 of 1 EXHIBIT 8 Section 2.1033 (c) (11) FCC IDENTIFICATION LABEL COMCODE: 3JR53413AAAA ISSUE#: 2 WORK#: 5 MAR-TEK INDUSTRIES: ISO 9001:2008 REGISTERED 0.00 40.00 0.00 112.00 12pt Frutiger Roman, 6.5pt Helvetica Bold & 8 & 6pt Helvetica Med Condensed ORIGINAL ARTWORK USE FOR REPRODUCTION COMPOSITE SPEC DRAWING FOR REFERENCE ONLY (DO NOT USE FOR REPRODUCTION) Title: 3JR53413AAAA 9745 RRH 1900 OUTDOOR BP LABEL Designer: CB Drawn: SRJ Checked: Date: 01-26-2015 Date: 01-26-2015 Date: Approved: Date: Client: Alcatel-Lucent - Carl Bellinghausen Material Specifications: Font Info: Comcode No.: 3JR53413AAAA Artmaster Issue#: 2w5 10 mil velvet/matte polycarbonate 8B35V (VTM-2) or equivalent with 3M 467 permanent adhesive Subsurface print Black and Cool Gray 1 OS20000 Drawing Issue#: Mar-Tek Industries • 3545-G South Platte River Drive • Englewood, CO 80110 • tele: 973-293-0165 • fax: 973-293-0164 • email: [email protected] Certifications: ALL INFORMATION CONTAINED IN THIS DOCUMENT IS THE PROPERTY OF ALCATEL-LUCENT All units are in millimeters • Tolerance is: 2 places .25mm • Symbology agrees with: ISO 1101 and ISO 1302 Labels are RoHS compliant and conform to Alcatel-Lucent banned substance and environmental hazardous substance requirements in QPS 20.248 & IAA 00266 0035 ASZZA. Artmaster Must Be Obtained From: Label shall meet UL and CSA requirements where applicable. Vendor must be UL and/or CSA approved. Documentation verifying the vendorʼs certifications for the material shall be provided by the vendor with each package/container. AM ISSUE DESCRIPTIONDATEDRAWN 1w1Initial Release.09-05-2014S. JENSEN 1w2Changed system name, removed China RoHS, changed amps, added manufacturing location 10-13-2014S. JENSEN 1w3Changed current rating from 13A to 14A, added FCC ID number11-13-2014S. JENSEN 1w4Changed current rating from 14A to 17A11-14-2014S. JENSEN 2w5Updated FCC ID number from AS5BBTX-22 to AS5BBTRX-2201-26-2015S. JENSEN ® Power DC Input: -48V 17A SELV Source Type 4 Enclosure For Operating Temperature Ratings Reference The Site Preparation Document Manufactured in Mexico by Alcatel-Lucent3JR53413AAAA B25 RRH 4x30 apply MRI / CLEI label here This device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. FCC ID: ® Power DC Input: -48V 17A SELV Source Type 4 Enclosure For Operating Temperature Ratings Reference The Site Preparation Document Manufactured in Mexico by Alcatel-Lucent3JR53413AAAA B25 RRH 4x30 apply MRI / CLEI label here This device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. FCC ID: AS5BBTRX-22 AS5BBTRX-22 R 1.50 TYP

APPLICANT: Alcatel-Lucent, USA FCCID: AS5BBTRX-22 Page 1 of 5 EXHIBIT 9 Section 2.1033 (c) (12) PHOTOGRAPHS OF THE EQUIPMENT Photographs (8 x 10) of the equipment of sufficient clarity to reveal equipment construction and layout, including meters, if any, and labels for controls and meters and sufficient views of the internal construction to define component placement and chassis assembly. Insofar as these requirements are met by photographs or drawings contained in instruction manuals supplied with the certification request, additional photographs are necessary only to complete the required showing.. Response The RF path of the B25 RRH 4X30 wireless base station is comprised of three critical RF active components: Power amplifier (PA) board, the Control Unit (CU) board and the RF Filter. The following pages contain the required photographs of the AS5BBTRX-22 RRH, subject of this application, showing the internal views of the RRH critical RF components. 4 Internal photos are submitted, which include: 1) Top View of PA Board with Shield Removed 2) Top View of CU Board with Shield Removed 3) Bottom View of PA Board 4) Bottom View of CU Board APPLICANT: Alcatel-Lucent, USA FCCID: AS5BBTRX-22 Page 2 of 5 Top View of PABoard with Shield Removed APPLICANT: Alcatel-Lucent, USA FCCID: AS5BBTRX-22 Page 3 of 5 Top View of CU Board with Shield Removed APPLICANT: Alcatel-Lucent, USA FCCID: AS5BBTRX-22 Page 4 of 5 Bottom View of PA Board APPLICANT: Alcatel-Lucent, USA FCCID: AS5BBTRX-22 Page 5 of 5 Bottom View of CU Board

APPLICANT: Alcatel-Lucent FCC ID: AS5BBTRX-22 EXHIBIT 5 Section 2.1033 (c)(8) DC VOLTAGES AND CURRENTS The dc voltage applied to and dc currents into the several elements of the final radio frequency amplifying device for normal operation over the power range. Response The B25 RRH 4X30 nominally uses the following maximum voltage and minimum currents. The nominal input of the B25 RRH 4X30 is -48VDC. The +28V is achieved using DC to DC converter. Stage Voltage Current Final Stage 28V 4.6A Section 2.1033 (c)(9) TUNE-UP PROCEDURE Turn-up procedure over the power range, or at specific operating power levels. Response The Alcatel-Lucent B25 RRH 4X30, subject of this application, cannot be “tuned-up” by the user. There are no user tune-up features. All tuning is performed by the manufacturer during, and as part of, the manufacturing process. The B25 RRH 4x30 units are tested and verified with 60W (47.8dBm) power at EAC1 & 2 with +/- 0.3dB tolerance in the factory. Section 2.1033 (c)(10) CIRCUITRY AND DEVICES FOR SUPPRESSION OF SPURIOUS RADIATION A description of all circuitry and devices provided for suppression of spurious radiation. Response The B25 RRH 4X30, subject of this application, was designed in adherence to the proper Electromagnetic Compatibility (EMC) guidelines extending from the combination of ALU proprietary Enhanced Digital Pre- Distortion (EDPD) firmware-SW algorithm and Filter module used to suppress spurious emissions.

APPLICANT: Alcatel-Lucent. FCC ID: AS5BBTRX-22 EXHIBIT 3 MANUFACTURERS ─ IDENTIFIER SECTION 2.1033 (c) 1 and 2 APPLICANT: Alcatel-Lucent. FCC ID: AS5BBTRX-22 MANUFACTURERS IDENTIFIER SECTION 2.1033(c) 1 The full name and mailing address of the manufacturer and the applicant of the device for certification: RESPONSE: APPLICATION: Alcatel-Lucent 600-700 Mountain Avenue Murray Hill, NJ 07974 Attention: Rudolf J Pillmeier SECTION 2.1033(c) 2 FCC Identifier: RESPONSE: The Alcatel-Lucent B25 RRH 4X30 operated under Part 24 and OET Rules 662911 D01 and D02 of the FCC Rules. FCC Identifier: AS5 FCC ID: AS5BBTRX-22 APPLICANT: Alcatel-Lucent. FCC ID: AS5BBTRX-22 EMISSIONS, FREQUENCY RANGE, POWER LEVEL SECTION 2.1033 (c) (4), (5), (6) and (7) APPLICANT: Alcatel-Lucent. FCC ID: AS5BBTRX-22 EMISSIONS, FREQUENCY RANGE, POWER LEVEL SECTION 2.1033(c) (4) Type or types of emission: RESPONSE: The “B25 RRH 4X30” is capable of amplifying transmission involving the following types of emissions: Measured Emission type: BW (MHz) Emissions Designation 5 4M50F9W 10 8M95F9W 15 13M42F9W . SECTION 2.1033(c) (5) Frequency Range RESPONSE: PCS Band PCS Blocks Tx Frequency (MHz) Rx Frequency (MHz) Bandwidth (MHz) A - G 1930 - 1995 1850 - 1915 65 SECTION 2.1033(c) (6) Range of operating power values or specific operating power levels, and description of any means provided for variation of operating power. RESPONSE: The “B25 RRH 4X30”, is capable of operating from 0.002 to 60 watts/port, 2x60 MIMO mode or 0.002 to 30 watts/port, 4x30 MIMO mode. The nominal transmit output power for each Tx path shall be translation settable over a range of 16 dB. For 2T case, that is from 60 W down to 1.5 W. For 4T case, that is from 30 W down to 0.75W. Tx output power is controlled by digital step attenuator via software. The gain of the tx path is adjusted by a FPGA to account for gain variations in the Tx chain over the operating temperatures and frequency ranges. Moreover, the FPGC provides fine output power control with a high resolution. The Tx chain parameters are carefully characterized during manufacturing process and provide high accuracy of setting the tx power and maintaining it over operating frequency and temperature ranges. APPLICANT: Alcatel-Lucent. FCC ID: AS5BBTRX-22 SECTION 2.1033(c) (7) Maximum power rating as defined in the applicable part(s) of the rules. RESPONSE: The maximum average power output of the “B25 RRH 4X30 EAC port is 2x60 watts (2x60 MIMO) mode or 4x30 watts (4x30 MIMO). The radio transmitter is operated under 47 CFR 24 and OET Rules 662911 D01 and D02. There were 4 External antenna port (EAC) ports and ports 3 and 4 were dedicated for 4x30W configuration.

APPLICANT: Alcatel-Lucent FCC ID: AS5BBTRX-22 TABLE OF CONTENTS Exhibit 1 731 Form Exhibit 2 Section 2.911 (d) Attestation Statement Exhibit 3 Section 2.1033 (c) (1, 2, 4-7) Manufacturer, Applicant, Identifier, Emission Types, Frequency Range, Operating Power Range and Adjustment and Maximum Power Rating Exhibit 4 Section 2.1033 (c) (3) Installation and Operating Instructions -> Confidential Exhibit 5 Section 2.1033 (c) (8, 9, 10) DC Voltages and Currents; Tune-up Procedure; Circuitry and Devices for Suppression of Spurious Radiation Exhibit 6 Section 2.1033 (c) (10) Circuit Schematic Diagrams -> Confidential Exhibit 7 Section 2.1033 (c) (10, 13) Description of Circuitry and Devices for Determining and Stabilizing Frequency and for Limiting Modulation and Power and Description of the Digital Modulation System -> Confidential Exhibit 8 Section 2.1033 (c) (11) Equipment Identification Label Exhibit 9 Section 2.1033 (c) (12) Internal Photographs of the Equipment Exhibit 9a Section 2.1033 (c) (12) External Photographs of the Equipment Exhibit 10 Setup Photos Exhibit 11 TEST REPORT Sub-exhibit 11.1 Section 2.1033 (c) (14) Required Measurement Data Sub-exhibit 11.2 Section 2.1046, 24.232(d) Measurements Required: RF Power Output Peak-to-Average ratio (PAR) Sub-exhibit 11.3 Section 2.1047 Measurements of Modulation Characteristics Sub-exhibit 11.4 Section 2.1049, 24.238( b) Measurements Required: (a) Emissions Bandwidth (b) Occupied Bandwidth and Out-of- Band Emissions Sub-exhibit 11.5 Section 2.1051, 24.238(a) Measurements Required: Spurious Emissions at Antenna Terminal Sub-exhibit 11.6 Section 2.1053, 24.238 Measurements Required: Field Strength of Spurious Radiation Sub-exhibit 11.7 Section 2.1055, 24.235 Measurement of Frequency Stability Sub-exhibit 11.8 Section 2.947 (d) Test Instruments Used for Test – See Test Report Page 1 of 1

APPLICANT: Alcatel-Lucent FCC ID: AS5BBTRX-22 EXHIBIT 10 PHOTOGRAPH(S) OF EUT ARRANGEMENT DURING OCCUPIED BANDWIDTH/SPURIOUS EMISSIONS TESTING APPLICANT: Alcatel-Lucent FCC ID: AS5BBTRX-22 EXHIBIT 10 PHOTOGRAPH(S) OF EUT ARRANGEMENT DURING RADIATED SPURIOUS EMISSIONS TESTING APPLICANT: Alcatel-Lucent FCC ID: AS5BBTRX-22 EXHIBIT 10 PHOTOGRAPH(S) OF EUT ARRANGEMENT DURING SPURIOUS RADIATED EMISSIONS TESTING PLICANT: Alcatel-Lucent FCC ID: AS5BBTRX-22 EXHIBIT 10 PHOTOGRAPH(S) OF EUT ARRANGEMENT DURING SPURIOUS RADIATED EMISSIONS TESTING
