AS5ONEBTS-02Linear Amplifier Module - kLAM

APPLICANT: Lucent Technologies Inc. -1 - FCC ID: AS5ONEBTS-02 Lucent Technologies Inc. - Proprietary Use pursuant to Company Instructions. 1 subject: Request for Confidentiality for FCC ID: AS5ONEBTS-02 date: March 30, 2002 from: Rudolf J. Pillmeier 67 Whippany Road Telephone: 973 386 3837 E-Mail [email protected] Sid Sanders – President Timco Engineering Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 Re: Request for Confidentiality for FCC ID: AS5ONEBTS-02 Dear Mr. Sanders On behalf of the Lucent Technologies Network Wireless System Business Unit, I hereby request that the following exhibits included in the Product Certification application for FCC ID: AS5ONEBTS-02 be maintained as confidential information and not be made available for public inspection at any time. Exhibit 4Section 2.1033(c) (8) Active Circuit Devices Drive Levels Exhibit 5Section 2.1033(c) (10) Complete Circuit Diagrams (Schematics) Exhibit 6Section 2.1033(c) (3) Instruction Book Exhibit 7Section 2.1033(c) (9) Tune-Up procedure Exhibit 8Section 2.1033(c) (10) Circuitry for determining frequency Exhibit 9Section 2.1033(c) (11) Circuitry for Suppression of Spurious These exhibits contain Lucent Technologies proprietary information considered to be trade secrets and the property of Lucent Technologies, pursuant to the provisions of Section 0.457(d) of the Commission’s Rules. These exhibits also contain design information that is highly propriety to Lucent Technologies contracted manufacturer /supplier. Exhibits 6,7,8 and 9 are virtually identical to the Exhibits granted as confidential by the FCC in filings for several Lucent Technologies filings including AS5CMP-34, 36 and 26. The information presented in Exhibit 7 and 8 details competitive advantage information. The material in Exhibit 6 is available only to Lucent employees and customers who have signed non-disclosure agreements. The document details product design, methodologies and system architecture details which are sensitive proprietary information. Thank you for your consideration in this matter. Sincerely, R.J.Pillmeier Technical Manager EMC Conformance Test Group, Whippany

APPLICANT: Lucent Technologies Inc. -19 - FCC ID: AS5ONEBTS-02 Lucent Technologies Inc. - Proprietary Use pursuant to Company Instructions. 19 Exhibit 19 SECTION 2.1033 (c) (11) Photographs (8"xlO") of the equipment of sufficient clarity to reveal equipment construction and layout, including meters, if any, and labels for controls and meters and sufficient views of the internal construction to define component placement and chassis assembly. Insofar as these requirements are met by photographs or drawings contained in the instruction manuals supplied with the type acceptance request, additional photographs are necessary only to complete the required showing. RESPONSE: The following photographs show the construction and layout of the PCS Outdoor Flexent OneBTS Modular Cell 3.0 followed by photographs of the kLAM / FCC ID: AS5ONEBTS-02. APPLICANT: Lucent Technologies Inc. -20 - FCC ID: AS5ONEBTS-02 Lucent Technologies Inc. - Proprietary Use pursuant to Company Instructions. 20 Exhibit 19: PCS Outdoor Flexent OneBTS Modular Cell 3.0 -- Front APPLICANT: Lucent Technologies Inc. -21 - FCC ID: AS5ONEBTS-02 Lucent Technologies Inc. - Proprietary Use pursuant to Company Instructions. 21 Exhibit 19: PCS Outdoor Flexent OneBTS Modular Cell 3.0 -- Rear APPLICANT: Lucent Technologies Inc. -22 - FCC ID: AS5ONEBTS-02 Lucent Technologies Inc. - Proprietary Use pursuant to Company Instructions. 22 Exhibit 19: PCS Outdoor Flexent OneBTS Modular Cell 3.0 – Front Door Open

APPLICANT: Lucent Technologies Inc. -19 - FCC ID: AS5ONEBTS-02 Lucent Technologies Inc. - Proprietary Use pursuant to Company Instructions. 19 Exhibit 18 SECTION 2.1033 (c) (11) A photograph or drawing of the equipment identification plate or label showing the information to be placed thereon. RESPONSE: The equipment identification label information for the kLAM / FCC ID: AS5ONEBTS-02 and placement thereof is attached below. Flexent Power Amplifier 848861084 FCC ID : AS5ONEBTS-02 PART NO : KS24638-L1 Flexent Power Amplifier 848861084 FCC ID : AS5ONEBTS-02 PART NO : KS24638-L1 1.1 1 Title: Designer: Drawn: Checked: Approved: Job No.: PM-0302-113 Date: Date: Date: Comcode: Issue#: Client: Finish: Material: Date: Work#: 848861084 Logo is 10 pt. 1.00 1.5 pt. Rule Text is 9 pt Frutiger Roman .06 Radius Typical Text is 8 pt Helvetica Med. Text is 7 pt Helvetica Med. 2.00 SPEC DRAWING IS FOR REFERENCE ONLY: DO NOT USE FOR REPRODUCTION ORIGINAL ART: USE FOR REPRODUCTION Flexent Modcell/Dave Philips 3/27/02 3/27/02 861084 FCC Label sj sj - updated to 1.1 by DP/Lucent SJ Regular White smudgeproof Kimdura with permanent p.s. adhesive Graphics print Black Serigraph Inc., 3801 E. Decorah Road West Bend, Wisconsin 53095 ■ ■ Graphic Services, Product Marking Group ■ 732 702 2325 ■ 3/27/02 861084 FCC Label Flexent Modcell Comcode No.: 848861084 Issue No.: 1.1 Applicant: Lucent TechnologiesFCC ID: AS5ONEBTS-02 Lucent Technologies Inc / Celiant Corporation - Proprietary Use pursuant to Company Instructions Exhibit 18: kLAM –FCC ID: AS5ONEBTS-02 – FCC ID Label Location - Enclosure - Top FCC ID Label Location for kLAM FCC ID: AS5ONEBTS-02

Applicant: Lucent TechnologiesFCC ID: AS5ONEBTS-02 Lucent Technologies Inc / Celiant Corporation - Proprietary Use pursuant to Company Instructions Exhibit 19 continued Internal and external Photographs of the Lucent Technologies Inc. Linear Amplifier Module Model k (kLAM) FCC ID: AS5ONEBTS-02 Applicant: Lucent TechnologiesFCC ID: AS5ONEBTS-02 Lucent Technologies Inc / Celiant Corporation - Proprietary Use pursuant to Company Instructions Exhibit 19 continued KLAM FCCID: AS5ONEBTS-02 – Module Enclosure - Front Applicant: Lucent TechnologiesFCC ID: AS5ONEBTS-02 Lucent Technologies Inc / Celiant Corporation - Proprietary Use pursuant to Company Instructions Exhibit 19 continued kLAM –FCC ID: AS5ONEBTS-02 Module Enclosure – Bottom – Outside Applicant: Lucent TechnologiesFCC ID: AS5ONEBTS-02 Lucent Technologies Inc / Celiant Corporation - Proprietary Use pursuant to Company Instructions Exhibit 19 continued kLAM –FCC ID: AS5ONEBTS-02 – Module Enclosure – Top – Outside Applicant: Lucent TechnologiesFCC ID: AS5ONEBTS-02 Lucent Technologies Inc / Celiant Corporation - Proprietary Use pursuant to Company Instructions Exhibit 19 continued kLAM –FCC ID: AS5ONEBTS-02 – Module Enclosure – Side A Applicant: Lucent TechnologiesFCC ID: AS5ONEBTS-02 Lucent Technologies Inc / Celiant Corporation - Proprietary Use pursuant to Company Instructions Exhibit 19 continued kLAM –FCC ID: AS5ONEBTS-02 – Module Enclosure – Side B Applicant: Lucent TechnologiesFCC ID: AS5ONEBTS-02 Lucent Technologies Inc / Celiant Corporation - Proprietary Use pursuant to Company Instructions Exhibit 19 continued KLAM-FCC ID: AS5ONEBTS-02 – PCB Boards – Component Side Applicant: Lucent TechnologiesFCC ID: AS5ONEBTS-02 Lucent Technologies Inc / Celiant Corporation - Proprietary Use pursuant to Company Instructions Exhibit 19 continued KLAM-FCC ID: AS5ONEBTS-02 – PCB Boards – Back Side Applicant: Lucent TechnologiesFCC ID: AS5ONEBTS-02 Lucent Technologies Inc / Celiant Corporation - Proprietary Use pursuant to Company Instructions Exhibit 19 continued KLAM-FCC ID: AS5ONEBTS-02 – Digital PCB Board – Back Side

APPLICANT: Lucent Technologies Inc. -15 - FCC ID: AS5ONEBTS-02 Lucent Technologies Inc. - Proprietary Use pursuant to Company Instructions. 15 Exhibit 11 SECTION 2.1033(c)(14) The data required by Section 2.1046 through 2.1057, inclusive, measured in accordance with the procedures set out in Section 2.1041. RESPONSE: The lowest clock frequency in the PCS Outdoor Flexent OneBTS Modular Cell 3.0 is the 10 MHz rubidium reference oscillator. Conducted spurious measurements were performed over the range of 10 kHz to 20GHz which is above the tenth harmonic of the transmit frequency range. The following pages include the data required for the Type Acceptance authorization of the kLAM / FCC ID: AS5ONEBTS-02, measured in accordance with the procedures set out in Section 2.1041 of the Rules. Each required measurement and its corresponding exhibit number are: Exhibit 12Section 2.1046Measurement of Radio Frequency Power Output Exhibit 13Section 2.1047Measurement of Modulation Characteristics Exhibit 14Section 2.1049Measurement of Occupied Bandwidth Exhibit 15Section 2.1051Measurement of Spurious Emissions at Antenna Exhibit 16Section 2.1053Field Strength of Spurious Radiation Exhibit 17Section 2.1055Measurement of Frequency Stability APPLICANT: Lucent Technologies Inc. -16 - FCC ID: AS5ONEBTS-02 Lucent Technologies Inc. - Proprietary Use pursuant to Company Instructions. 16 Exhibit 12 SECTION 2.1046 MEASUREMENT OF RADIO FREQUENCY POWER OUTPUT The test arrangements used to measure the radio frequency power output of the kLAM/ AS5ONEBTS-02 Linear Amplifier Module, Model k/ Multi Carrier Amplifier is on the following page. Measurements were made respectively at each frequency where Occupied Bandwidth measurements were performed. The use of the kLAM is for one to three CDMA carriers. This requires that the J4 power level be calibrated for the specific channel of use. The test configuration, Figure 12a, allowed the measurement of output power for each channel investigated for Occupied Bandwidth. These included the upper and lower Block edges and at the center channel for each Block. The kLAM system has a maximum power output at the antenna terminals of 20.0 Watts (43.01 dBm) +2 / - 4 dB, it also has a minimum power output at the antenna terminals of 0.010 Watts (10.01 dBm +2 / -4 dB, across the PCS downlink Band (1930.00-1990.00 MHz). The signal applied to the kLAM is defined in Table 12.1. The power was reset to a minimum of 20.0 Watts at each measurement frequency to verify the spectral performance at that power level at each specific frequency of interest. The attenuation range was also verified. The specific Frequencies and channels and set power level was documented on each "Occupied Bandwidth" sheet. TypeNumber of Channels Fraction of Power (Linear) Fraction of Power (dB) Comments Pilot10.2000-7.0Walsh 0 Sync10.0471-13.3 Walsh 32, always 1/8 rate Paging10.1882-7.3 Walsh 1, full rate only Traffic6 0.09412 each -10.3 each Variable Walsh Assignments, full rate only TABLE 12.1 Base Station Test Model, Nominal APPLICANT: Lucent Technologies Inc. -17 - FCC ID: AS5ONEBTS-02 Lucent Technologies Inc. - Proprietary Use pursuant to Company Instructions. 17 Exhibit 12 RF Power Test Configuration Figure 12A/14A/15A Test Configuration For RF Power, Occupied Bandwidth and Conducted Spurious Rohde & Schwartz ESMI, FSEM or ESI Receiver/ Spectrum Analyzer Typically -30 dB from J4 Connection Power Sensor All paths Calibrated to J4 Connection 48.6 dBm Power Meter HP-772D Directional Coupler Incident Reflected PCS Modular Cell kLAM Test Figure WSM 3/29/02 Transmit Filter kLAM AS5ONEBTS-02 Output Output 3:1 Combiner kLAM AS5ONEBTS-02 kLAM AS5ONEBTS-02 Output Input Input Reference Frequency Timing Unit (TFU, Rb-Osc & Osc) CBR AS5CMP-26 Output CBR AS5CMP-26 CBR AS5CMP-26 1:3 Splitter 3:1 Combiner 1 SECTOR SHOWN Input Output Port J4 Lucent FLEXENT  OneBTS PCS CDMA 3.0 MODULAR CELL GPIB Test Controller ROHDE & SCHWARZSpectrum Analyzer FSEM 30 Carrier Reject High Pass or Low Pass Filter For Conducted Spurious Measurements below 1.8 GHz and above 2.5 GHz Lucent Agilent E4406A Code Domain Analyzer APPLICANT: Lucent Technologies Inc. -18 - FCC ID: AS5ONEBTS-02 Lucent Technologies Inc. - Proprietary Use pursuant to Company Instructions. 18 Exhibit 12 continued Measurement Equipment used in Figure 12 For Measurement of RF Power EquipmentDescription Product Frame:PCS Outdoor Flexent OneBTS Modular Cell 3.0 with 9 CBR’s and 9 kLAMs CBR:CDMA Baseband Radio (FCC ID: AS5CMP-26) kLAM:Linear Amplifier Module, Model k (FCC ID: AS5ONEBTS-02) Transmit Filter:PCS Band Transmit Filter appropriate for the investigated Block Directional Coupler:HP 778D and 772D Dual Directional Coupler Power Meter:Agilent E4419B Power Meter with EPC-E18A Power Sensor or HP Model 437 Power Meter with HP-8481A Power Sensor Test Cables:W.L. Gore; Low loss test cables custom mfg. for Lucent FCC Laboratory Plotter:HP Model 7470A Plotter Printer:HP Model 4500DN Printer Attenuator, VariableHP 8494B and 8495B DC-18 GHz digital attenuators Attenuator, FixedWeinschel Corp DC-18 GHz, various values Band Pass Filters:Trialithic, Various 10 MHz-20 GHz, Custom manufactured for Lucent FCC Laboratory Spectrum Analyzer: Rohde & Schwarz ESMI EMI Test Receiver or Rohde & Schwarz FSEM Spectrum Analyzer Code Domain AnalyzerH-P and Agilent E4406A VSA Series Transmitter Tester Computer Controller:EG Technology, Custom Mfg for FCC Laboratory, Intel Pentium III & IV, 550 and 1600 MHz controllers with TILE  software APPLICANT: Lucent Technologies Inc. -19 - FCC ID: AS5ONEBTS-02 Lucent Technologies Inc. - Proprietary Use pursuant to Company Instructions. 19 Exhibit 12continued RESULTS: The kLAM/ AS5ONEBTS-02 was configured in the test setup shown in Figure 12A. For each of the PCS channels tested the kLAM/ AS5ONEBTS-02 delivered a minimum of 20.0 Watts +2/-0 dB when measured at the J4 output connection. This data is recorded on the Occupied Bandwidth Data Sheets for “Left edge” and “…
