APPLICANT: Lucent Technologies, Inc.FCC ID: AS5ONEBTS-05 67 Whippany Road Subject:REQUEST FOR CONFIDENTIALITYWhippany, NJ 07981 for FCC ID: AS5ONEBTS-05, Covering a Broadband PCS Transceiver System for OperationRudolf J. Pillmeier with a 5 MHz UMTS/W-CDMA Carrier.Telephone: 973-386-3837 Facsimile: 973-386-3116 E-Mail: [email protected] August 7, 2003 Timco Engineering, Inc. 849 N. W. State Road 45 P. O. Box 370 Newberry, Florida 32669 Dear Sid Sanders: On behalf of Lucent Technologies, I hereby request that the following exhibits, included in this Application for Certification, under FCC ID: AS5ONEBTS-05, covering the Lucent Flexent® UMTS OneBTS™ Macrocell W1900M, Model SD-2R521-01, wireless base station transceiver system be maintained as confidential information and not be made available for public inspection at any time. Exhibit 5:Internal Photographs Exhibit 7:Operational Description (Theory of Operation, Functional Description) Exhibit 8:Block Diagrams Exhibit 9:Schematic Diagrams Exhibit 11:UMTS Flexent® OneBTS™ Macrocell +24V Indoor Operation, Administration and Maintenance Exhibit 13:Parts List, if Applicable These exhibits contain Lucent Technologies proprietary information that is considered to be trade secrets, with possible patents pending, and the property of Lucent Technologies, pursuant to the provisions of Part 0.457(d) of the Commission’s Rules. These exhibits also contain design information that is highly proprietary to Lucent’s contracted manufacturer/supplier. Exhibits 5,7, 8, 9, and 13 are highly proprietary and contain critical design information that can not be made available for public inspection. This information is proprietary both to Lucent Technologies and to Lucent’s contracted manufacturer/supplier. It is critical that all internal photographs (Exhibit 5) be held confidential because they reveal component ID numbers, component values and operating frequencies that are proprietary to the design of the circuit pack. When the equipment cabinet is installed on a customer’s site, the only access is a single door on the cabinet front, which is kept locked at all times. Access to the installation site is limited and restricted, and is kept locked and secured by our customer. 2 The UMTS Flexent® OneBTS™ Macrocell +24V Indoor Operation, Administration and Maintenance document, included in Exhibit 11, is not furnished to the user, except under very exceptional and very limited circumstances. This manual contains highly proprietary circuit, equipment and architecture descriptions that must not be made available for public inspection. The cover/title page is explicitly labeled “Unpublished and Not for Publication”. Thank you for your consideration in this matter. Sincerely, Rudolf J. Pillmeier Technical Manager FCC/EMC Compliance Test Group Whippany, NJ

1 1 APPLICANT: LUCENT TECHNOLOGIESFCC ID: AS5ONEBTS-05 EXHIBIT 4: EXTERNAL PHOTOGRAPHS Lucent UMTS Flexent® OneBTS™ W1900M (SD-2R521-01) Wireless Base Station, incorporating the PCS UMTS-CDMA Radio (UCR1900), BNJ27B; the P2PAM power amplifier; and the 20 MHz wideband, low loss, A/D Dual Duplex (DDpx) bandpass filters. View: UMTS Equipment Frame Front View 2 2 APPLICANT: LUCENT TECHNOLOGIESFCC ID: AS5ONEBTS-05 EXHIBIT 4: EXTERNAL PHOTOGRAPHS Lucent UMTS Flexent® OneBTS™ W1900M (SD-2R521-01) Wireless Base Station, incorporating the PCS UMTS-CDMA Radio (UCR1900), BNJ27B; the P2PAM power amplifier; and the 20 MHz wideband, low loss, A/D Dual Duplex (DDpx) bandpass filters. View: UMTS Equipment Frame Front View, Showing the PCS UMTS-CDMA Radio (UCR1900), BNJ27B, Shelf Close-up. 3 3 APPLICANT: LUCENT TECHNOLOGIESFCC ID: AS5ONEBTS-05 EXHIBIT 4: EXTERNAL PHOTOGRAPHS Lucent UMTS Flexent® OneBTS™ W1900M (SD-2R521-01) Wireless Base Station, incorporating the PCS UMTS-CDMA Radio (UCR1900), BNJ27B; the P2PAM power amplifier; and the 20 MHz wideband, low loss, A/D Dual Duplex (DDpx) bandpass filters. View: UMTS Equipment Frame Front View, Showing the P2PAM Power Amplifier Shelf Close-up. 4 4 APPLICANT: LUCENT TECHNOLOGIESFCC ID: AS5ONEBTS-05 EXHIBIT 4: EXTERNAL PHOTOGRAPHS Lucent UMTS Flexent® OneBTS™ W1900M (SD-2R521-01) Wireless Base Station, incorporating the PCS UMTS-CDMA Radio (UCR1900), BNJ27B; the P2PAM power amplifier; and the 20 MHz wideband, low loss, A/D Dual Duplex (DDpx) bandpass filters. View: UMTS Equipment Frame Front View, Showing the 20 MHz Wideband, Low Loss, A/D Dual Duplex (DDpx) Filter Shelf Close-up.

1 APPLICANT: LUCENT TECHNOLOGIESFCC ID: AS5ONEBTS-05 EXHIBIT 2: FCC ID LABEL SAMPLE AND LOCATION INFORMATION SECTION 2.1033(c) (11) also SECTION 2.925 (a) (1) A photograph or drawing of the equipment identification plate or label showing the information to be placed thereon. The FCC ID label representing the Flexent® UMTS OneBTS™ Macrocell W1900M (SD-2R521-01), wireless base station PCS UMTS-CDMA Transceiver System will be displayed on the Broadband PCS UMTS-CDMA Radio (UCR1900), BNJ27B, and shall be in accordance with the following drawing as shown: Approximate Label Placement PCS UMTS-CDMA Radio (UCR1900), BNJ27B A preliminary label drawing is displayed on the following page. Lucent Technologies PCS UMTS-CDMA Transceiver System FCC ID: AS5ONEBTS-05

APPLICANT: LUCENT TECHNOLOGIESFCC ID: AS5ONEBTS-05 EXHIBIT 12: TUNING PROCEDURE Section 2.1033 (c)(9): Tune-up procedure over the power range, or at specific operating power levels. Response: The Lucent UMTS Flexent® OneBTS™ W1900M (SD-2R521-01) Wireless Base Station incorporates the PCS UMTS-CDMA Radio (UCR1900), BNJ27B; the P2PAM power amplifier; and the 20 MHz wideband, low loss, A/D Dual Duplex (DDpx) bandpass filters, which comprise the UMTS1900 Transceiver System that is the subject of this application for certification does not have and does not require any tuning procedure outside of the standard manufacturing test, evaluation and adjustment processes. There is no user tune-up procedure

1 1 APPLICANT: LUCENT TECHNOLOGIESFCC ID: AS5ONEBTS-05 EXHIBIT 10: TEST REPORT The test report attached to this exhibit demonstrates that the Lucent Technologies’ Broadband PCS UMTS- CDMA Transceiver System, which is designed to operate in the Lucent UMTS Flexent® OneBTS™ W1900M (SD-2R521-01) Wireless Base Station, is in full compliance with all requirements of the Rules of the Commission as specified in the Code of Federal Regulations (CFR), Title 47 – Telecommunication; Part 24, Subpart E – Broadband PCS; Section 24.238 - Emission Limits; effective October 1, 2002. All testing was performed in accordance with CFR 47, Part 2, Subpart J – Equipment Authorization Procedures; effective October 1, 2002. It also demonstrates compliance with the spurious emissions limitations specified in ETSI TS 125 141 V4.1.0 (2001-06): Universal Mobile Telecommunications System (UMTS); Base Station Conformance Testing (FDD), (3GPP TS 25.141, Version 4.1.0, Release 4), which is the standard used as a guideline in the design of the UCR1900 transceiver. The objective of this application is to obtain FCC authorization as a new filing, under FCC ID: AS5ONEBTS-05, for operation in the Universal Mobile Telecommunications System (UMTS) with a single 5 MHz carrier (5M0F9W) set to a maximum power level at the antenna terminal of 40 Watts (3-second)., over the frequency spectrum 1930-1950 MHz. The UMTS1900 Transceiver System consists of the principle RF components: (1) Rubidium Reference Oscillator Module (OMR) 15 MHz, (2) UMTS-CDMA Radio (UCR1900), Model BNJ27B, which was previously authorized by the Federal Communications Commission under FCC ID: AS5ONEBTS-04, (3) P2PAM power amplifier, (4) 20 MHz wide Dual Duplex (DDpx), low loss, transmit filter covering the PCS A & D-Block spectrum 1930-1950 MHz, and (5) the Test and Diagnostic Unit (TDU) used to monitor the output of the P2PAMs and feed it back to the UCR for processing and distortion cancellation. These components are considered as a system due to (1) the DDpx filters providing RF feedback to the transceiver in the form of Closed Loop Gain Control (CLGC) to provide constant power over temperature, and (2) Lucent’s proprietary Digital Pre Distortion (DPD) technology which enables software to communicate between the transceiver, power amplifier and the transmit filter to achieve this goal. As a Transceiver System, all conducted RF characteristics and emissions measurements were performed at the transmit antenna terminal , using a production equipment frame. All testing was performed in the Lucent Technologies, Whippany, NJ, compliance laboratory by F. E. Chetwynd and M. P. Farina during the period July 18 to August 4, 2003; in adherence to a test plan generated by M. P. Farina, in accordance with Lucent’s ISO/TL9000 Registration. All measurement instrumentation utilized were also calibrated in compliance with Lucent’s ISO/TL9000 Registration. The Whippany 3 & 10 Meter Open Area Test Site (OATS) is authorized by the Federal Communications Commission (FCC) under Registration Number: 90770, in compliance with the the requirements of Section 2.948 of the Rules of the Commission. Frequency stability measurements were performed by V. Van and S. Stephens, at Lucent Technologies, Swindon, United Kingdom, under the direction of M. P. Farina, and in adherence to the previously cited ISO/TL9000 test plan. This test program was conducted during the interval February 19 to March 10, 2003. 2 2 APPLICANT: LUCENT TECHNOLOGIESFCC ID: AS5ONEBTS-05 67 Whippany Road Whippany, NJ 07981 Subject: Application for Certification under FCC ID: AS5ONEBTS-05, Covering a Broadband PC SMichael P. Farina Transceiver System for Operation with aJW10D0000 5 MHz UMTS/W-CDMA Carrier.Telephone: 973-386-4344 [email protected] August 4, 2003 TEST REPORT SYNOPSIS: The exhibits presented in this test report demonstrate that the Lucent Technologies’ Broadband PCS UMTS-CDMA Transceiver System, which is designed to operate in the Lucent UMTS Flexent® OneBTS™ W1900M (SD-2R521-01) Wireless Base Station, is in full compliance with all requirements of the Rules of the Commission as specified in the Code of Federal Regulations (CFR), Title 47 – Telecommunication; Part 24, Subpart E – Broadband PCS; Section 24.238 - Emission Limits; effective October 1, 2002. All testing was performed in accordance with CFR 47, Part 2, Subpart J – Equipment Authorization Procedures; effective October 1, 2002. It also demonstrates compliance with the spurious emissions limitations specified in ETSI TS 125 141 V4.1.0 (2001-06): Universal Mobile Telecommunications System (UMTS); Base Station Conformance Testing (FDD), (3GPP TS 25.141, Version 4.1.0, Release 4). This standard was the guideline used in the design of the UCR1900 transceiver. The objective of this application is to obtain FCC authorization as a new filing, under FCC ID: AS5ONEBTS-05, for operation in the Universal Mobile Telecommunications System (UMTS) with a single 5 MHz carrier (5M0F9W) set to a maximum power level at the antenna terminal of 40 Watts (3- second)., over the frequency spectrum 1930-1950 MHz. The UMTS1900 Transceiver System consists of the principle RF components: (1) Rubidium Reference Oscillator Module (OMR) 15 MHz, (2) UMTS-CDMA Radio (UCR1900), Model BNJ27B, which was previously authorized by the Federal Communications Commission under FCC ID: AS5ONEBTS-04, (3) P2PAM power amplifier, (4) 20 MHz wide Dual Duplex (DDpx), low loss, transmit filter covering the PCS A & D-Block spectrum 1930-1950 MHz, and (5) the Test and Diagnostic Unit (TDU) used to monitor the output of the P2PAMs and feed it back to the UCR for processing and distortion cancellation. These components are considered as a system due to (1) the DDpx filters providing RF feedback to the transceiver in the form of Closed Loop Gain Control (CLGC) to provide constant power over temperature, and (2) Lucent’s proprietary Digital Pre Distortion (DPD) technology which enables software to com…
