ASU-B3X2L9TQ7WASavant Power Director

HST-DIRECTORC-01 - Quick Reference Guide | 009-2454-0045 Perseverance Way, Hyannis, MA 02601 Copyright © 2025 Savant Systems, Inc | 2512081 of 4Savant.com | 508.683.2500 A Status LEDs - See Status LEDs and Buttons for descriptions. B Buttons - See Status LEDs and Buttons for descriptions. C L/N/G Terminal Provides 120V power to the PBC-P2000 using an AC cord, wired as follows: –L - Brown - Line –N - Blue - Neutral –G - Green/Yellow Stripe - Ground D Ethernet Port –8-Pin RJ-45 Port –10/100/1000 Base-T auto negotiating port with link/ activity LEDs E GPIO Input - When configured as an input, the processor will look for a low (<0.8V DC) or a high (>2.4V DC) state. Minimum 0V DC / Maximum 12V DC. GPIO Output - When configured as an output, the port provides a binary output of 0-12V DC 150mA max. See GPIO Wiring for more information. GPIO Output - When configured as an output, the port will provide a binary output of either 0 or 12V DC (150mA max) F RS-485 - Used to control devices with RS-485 input ports. –B - pin 4 –A - pin 5 –GND - pin 8 Regulatory Safety and Emissions FCC Part 15ICTUV RoHsCompliant FCC ID:ASU-B3X2L9TQ7WA IC:10052A-B3X2L9TQ7WA Contains FCC ID:VPYLB1ZM / 2AJYU-8PYA007 Contains IC:772C-LB1ZM / 23761-8PYA008 Front Panel Box Contents (1) Savant Power Director (HST-DIRECTORC-01) (1) AC power cord (064-0914) (1) 6-pin screw down connector (028-9352) (3) #6 x 3/4 SS pan head screws (039-0329) (1) Product Regulatory Statement (009-1950) Environmental Temperature-22° to 122° F (-30° to 50° C) HumidityUp to 100% Humidity (condensing) Location Indoor and Outdoor. (Designed to meet NEMA 3R) Dimensions and Weights HeightWidthDepthWeight HST-DirectorC 7.48 inch (190 mm) 7.08 inch (180 mm) 2.52 inch (64 mm) 1.5 lbs (.68 kg) Shipping 9.0 inch (22.9 cm) 9.0 inch (22.9 cm) 3.0 inch (76.2 mm) 3.1 lbs (1.41 kg) Minimum Supported Release Software ReleaseSavantOS 11.1 Standards BluetoothBluetooth Low Energy 5.1 (BLE) Wi-Fi2.4/5.0 GHz IEEE 802.11 a/b/g/n/ac EthernetIEEE 802.3ab CellularLTE Cat 4 Additional Information –Director can communicate with up to 20 power/lighting modules. –During installation, limit the distance between the Director and the power/lighting modules to 6 1/2 feet (2 meters) or less. –Wi-Fi or cellular are available when a wired Ethernet connection is not accessible. Specifications Savant® Power Director with LTE (HST-DIRECTORC-01) Quick Reference Guide GPIO G 1 PD G 2 PD Power Status Wi-Fi LTE Reset Pair Local Mode L N G Ethernet RS 485 C D E A B F Power Power Supply 120V AC power cord or hard wired (hot, neutral, and ground direct wire) Maximum Power25 Watts HST-DIRECTORC-01 - Quick Reference Guide | 009-2454-0045 Perseverance Way, Hyannis, MA 02601 Copyright © 2025 Savant Systems, Inc | 2512082 of 4Savant.com | 508.683.2500 Status LEDs and Buttons IMPORTANT! In the descriptions below, Home Network refers to the local Wi-Fi or wired network. Power (LED) Solid Green - Power is applied. Off - No power. Verify the power source is supplying the proper voltage. Status (LED) Amber - The Director is booting/rebooting. Amber Blinking - The Director is installing Firmware Updates, Host Software is downloading/installing, or other controllers are updating. Blue - The Director completed startup but doesn’t have an IP Address. Blue Blinking - The Director is in pairing mode and scanning for Power Modules. Green - Normal operation mode. Red Blinking - The Director is unable to communicate with paired Power Modules or Controllers. Red Blinking (three fast blinks) - The Pair button was pressed, but the system is already configured. See the description in the Pair (Button) fields below. Wi-Fi Status (LED) Blue - Access Point (Local) Mode is enabled. Green - The Director is provisioned, and communicating with Wi-Fi. NOTE: The Savant Power & Light App configures the wireless interface. Red - The Director is provisioned to Wi-Fi but unable to communicate with that network. Red Blinking (three fast blinks) - The Local Mode button button was pressed, but the Director is already connected to a Wi-Fi network. Off - The Director is not provisioned to Wi-Fi and Access Point (Local) Mode is Off. LTE Status (LED) Green - The Director is provisioned and communicating with a cellular network. Red - The Director is provisioned to a cellular network, but can’t communicate with that network. Red Blinking (fast blink) - The Reset button was pressed and held for 10 seconds. See the description in the Reset (Button) fields below. Off - Cellular has not been configured and is off. Reset (Button) Press and Release - Reboots the Director, and all settings are left intact. Press and hold (5 secs) - Press and hold for 5 seconds until the Status LED blinks red, then release. The Director reboots and all network settings are cleared. All other settings are preserved. Press and hold (10 secs) - Factory Reset. Press and hold for 10 seconds until the Status and Wi-Fi LEDs blink red, then release. After the reboot, the network settings, configuration, logs, and passwords are cleared. NOTE: The Director will continue to be associated with a Home in the Savant Cloud. A call to Savant Support may be necessary to redeploy to a different Home. Pair (Button) Press and Release - Launches On-Device Pairing. In this mode, the Director locates any power or lighting modules that are also in pairing mode, and connects with them. NOTE: A gear icon displayed on a power or lighting module’s LCD screen indicates the module is in pairing mode. Press and Hold - Press and hold for 5 seconds, then release to clear the configuration running on the Director and then initiate a reboot. Network and password settings are preserved. Local Mode (Button) Press and Release - Press and release to put the Director into Access Point (Local) Mode. Press and release again to take it out of this mode. Local Mode is turned off after 10 hours. –In Local Mode the Director functions as an Access Point and can communicate directly with the Savant Power & L…

Text truncated - open the document above for the full version.

HST-DIRECTOR-01 - Quick Reference Guide | 009-2451-0045 Perseverance Way, Hyannis, MA 02601 Copyright © 2025 Savant Systems, Inc | 2505281 of 4Savant.com | 508.683.2500 Regulatory Safety and Emissions FCC Part 15IC RoHsCompliant FCC ID:ASU-B3X2L9TQ7WA IC:10052A-B3X2L9TQ7WA Contains FCC ID:VPYLB1ZM Contains IC:772C-LB1ZM A Status LEDs - See Status LEDs and Buttons for descriptions. B Buttons - See Status LEDs and Buttons for descriptions. C L/N/G Terminal D Ethernet Port –8-Pin RJ-45 Port –10/100/1000 Base-T auto negotiating port with link/ activity LEDs E GPIO Input - When configured as an input port, the processor looks for one of the following: Low state = <0.8V DC. High state = >2.4V DC. Minimum = 0V DC / Maximum = 12V DC GPIO Output - When configured as an output, the port will provide a binary output of either 0 or 12V DC (150mA max) F RS-485 - Used to control devices with RS-485 input ports. G Knockout Locations Box Contents (1) Savant Power Director (HST-DIRECTOR-01) (1) AC power cord (064-0914) (1) 6-pin screw down connector (028-9352) (3) #6 x 3/4 SS pan head screws (039-0329) (1) Product Regulatory Statement (009-1950) Environmental Temperature-22° to 122° F (-30° to 50° C) HumidityUp to 100% Humidity (condensing) LocationIndoor and Outdoor. (Designed to meet NEMA 3R) Dimensions and Weights HeightWidthDepthWeight HST-Director 7.48 inch (190 mm) 7.08 inch (180 mm) 2.52 inch (64 mm) 1.5 lbs (.68 kg) Shipping 9.0 inch (229 mm) 9.0 inch (229 mm) 3.0 inch (76.2 mm) 3.1 lbs (1.41 kg) Power Power Supply120V AC Maximum Power15 Watts Standards BluetoothBluetooth Low Energy 5.1 (BLE) Wi-Fi2.4/5.0 GHz IEEE 802.11 a/b/g/n/ac EthernetIEEE 802.3af Minimum Supported Release Software ReleaseSavantOS 11.1 Additional Information –The Director can communicate with up to 20 power and lighting modules. –During installation, limit the distance between the Director and the power/lighting modules to 6 1/2 feet (2 meters) or less. –Wi-Fi is available when a wired Ethernet connection is not accessible. Specifications Savant® Power Director (HST-DIRECTOR-01) Quick Reference Guide GPIO G 1 PD G 2 PD Power Status Wi-Fi Reset Pair Local Mode L N G Ethernet RS 485 Front Panel C D E A B F GG G G HST-DIRECTOR-01 - Quick Reference Guide | 009-2451-0045 Perseverance Way, Hyannis, MA 02601 Copyright © 2025 Savant Systems, Inc | 2505282 of 4Savant.com | 508.683.2500 Status LEDs and Buttons Power (LED) Solid Green - Power is applied. Off - No power. Verify the power source is supplying the proper voltage. Status (LED) Amber - The Director is booting/rebooting. Amber Blinking - The Director is installing Firmware Updates, Host Software is downloading/installing, or other controllers are updating. Blue - The Director completed startup but doesn’t have an IP Address. Blue Blinking - The Director is in pairing mode and scanning for Power Modules. Green - Normal operation mode. Red Blinking - The Director is unable to communicate with paired Power Modules or Controllers. Red Blinking (fast blink) - The Director is unable to communicate with paired Power Modules or Controllers. Red Blinking (three fast blinks) - The Pair button was pressed, but the system is already configured. See the description in the Pair (Button) fields below. Wi-Fi Status (LED) Blue - Access Point (Local) Mode is enabled. Green - The Director is provisioned, and communicating with Wi-Fi. NOTE: The Savant Power & Light App configures the wireless interface. Red - The Director is provisioned to Wi-Fi but unable to communicate with that network. Red Blinking (fast blink) - The Reset button was pressed and held for 10 seconds. See the description in the Reset (Button) fields below. Red Blinking (three fast blinks) - The Local Mode button was pressed, but the Director is already connected to a Wi-Fi network. Off - The Director is not provisioned to Wi-Fi and Access Point (Local) Mode is Off. Reset (Button) Press and Release - Reboots the Director, and all settings are left intact. Press and hold (5 secs) - Press and hold for 5 seconds until the Status LED blinks red, then release. The Director reboots, all the network settings are cleared, and the Director returns to provisioning mode. Network and password settings are preserved. Press and hold (10 secs) - Factory Reset. Press and hold for 10 seconds until the Status and Wi-Fi LEDs blink red, then release. After the reboot, the network settings, configuration, logs, and passwords are cleared. NOTE: The Director will continue to be associated with a Home in the Savant Cloud. A call to Savant Support may be necessary to redeploy to a different Home. Pair (Button) Press and Release - Launches On-Device Pairing. In this mode, the Director locates any power or lighting modules that are also in pairing mode, and connects with them. Press and Hold - Press and hold for 5 seconds, then release to clear the configuration running on the Director and then initiate a reboot. Network and password settings are preserved. NOTE: A gear icon displayed on a power or lighting module’s LCD screen indicates the module is in pairing mode. Local Mode (Button) Press and Release - Press and release to put the Director into Access Point (Local) Mode. Press and release again to take it out of this mode. Local Mode times out after 30 minutes of no activity. –In Local Mode the Director functions as an Access Point and can communicate directly with the Savant Power & Light App over Wi-Fi. –Local Mode is disabled when the Director is provisioned to Wi-Fi. IMPORTANT! In the descriptions below, Home Network refers to the local Wi-Fi or wired network. HST-DIRECTOR-01 - Quick Reference Guide | 009-2451-0045 Perseverance Way, Hyannis, MA 02601 Copyright © 2025 Savant Systems, Inc | 2505283 of 4Savant.com | 508.683.2500 GPIO Wiring General Purpose Inputs/Outputs (GPIO) are binary I/O ports used on the Savant Director and monitors the state of whether a home is using On-Grid or Generator power. A signal of less than 0.8V DC indicates a low s…

Text truncated - open the document above for the full version.

Savant Product Regulatory Statement | 009-1950-03 250424 | © 2025 Savant Systems, Inc. 45 Perseverance Way, Hyannis, MA 02601 Savant.com | 508.683.2500 1 of 2 Important Safety Information - Read First! Before installing, configuring, or operating any equipment, all relevant technical documentation must be read, understood, and followed. Savant technical documentation may contain important product-specific installation, mounting, and safety instructions, and can be accessed through the Savant Store. Scan the QR code or visit the URL below, enter the relevant product name or SKU in the Search Savant prompt, and select the product purchased to find documents, specifications and more. https://store.savant.com/DefaultStore/ccrz__HomePage Product Information and Regulatory Statement Safety Statements All safety instructions below must be read, understood, and carefully followed under all applicable circumstances when working with any Savant equipment. 1. Follow all input power ratings marked on product near power input! 2. If fuse replacement is required, replacement fuse should match fuse rating marked on the product. 3. Do not use equipment near water. 4. Clean only with dry cloth. 5. Do not block any ventilation openings or install near any heat sources such as heat registers, stoves, radiators, amplifiers, etc. 6. Refer all servicing to qualified service personnel. Servicing is required when any part of the apparatus has been damaged in any way, or fails to operate normally for any reason. 7. Use only attachments/accessories specified by the manufacturer, following all relevant safety precautions for any such attachments/accessories. 8. For applicable equipment, use the included power cord with the grounding prong intact to insure proper grounding of the device. 9. If the provided plug does not fit the desired outlet, contact a licensed electrician to replace the obsolete outlet. 10. Protect any power cord from being walked on, pinched, strained, or otherwise potentially damaged, especially at the outlet or device connections. 11. Disconnect any outlet powered apparatus from its power source during lightning storms or when unused for long periods of time. 12. To completely disconnect equipment from AC mains power, disconnect the power supply cord plug from the AC receptacle on the device. 13. For any hardwired or fixed in-wall apparatus, carefully follow all wiring diagrams and instructions. All electrical wiring and servicing should be performed by a properly licensed electrician. Déclarations de Sécurité Toutes les instructions de sécurité ci-dessous doivent être lues, comprises et soigneusement suivies dans toutes les circonstances applicables lorsque vous travaillez avec un équipement Savant. 1. Suivez toutes les puissances nominales indiquées sur le produit près de la puissance absorbée! 2. Si le remplacement du fusible est nécessaire, le fusible de remplacement doit correspondre à la valeur nominale du fusible indiquée sur le produit. 3. N’utilisez pas d’équipement près de l’eau. 4. Nettoyer uniquement avec un chiffon sec. 5. Ne bloquez pas les ouvertures de ventilation et n’installez pas à proximité de sources de chaleur telles que les registres de chaleur, les cuisinières, les radiateurs, les amplificateurs, etc. 6. Confiez toutes les réparations à un technicien qualifié. Un entretien est requis lorsqu’une partie de l’appareil a été endommagée de quelque manière que ce soit ou ne fonctionne pas normalement pour une raison quelconque. 7. Utilisez uniquement les attachements / accessoires spécifiés par le fabricant, en suivant toutes les précautions de sécurité applicables à ces attachements / accessoires. 8. Pour l’équipement applicable, utilisez le cordon d’alimentation inclus avec la broche de mise à la terre intacte pour assurer une mise à la terre correcte de l’appareil. 9. Si la fiche fournie ne correspond pas à la prise souhaitée, contactez un électricien agréé pour remplacer la prise obsolète. 10. Protégez tout cordon d’alimentation contre les piétinements, les pincements, les tensions ou autres dommages potentiels, en particulier au niveau de la prise ou des connexions de l’appareil. 11. Débranchez tout appareil alimenté par une prise de courant de sa source d’alimentation pendant les orages ou lorsqu’il n’est pas utilisé pendant de longues périodes. 12. Pour déconnecter complètement l’équipement du secteur, débranchez la fiche du cordon d’alimentation de la prise secteur de l’appareil. 13. Pour tout appareil encastré ou câblé, suivez attentivement tous les schémas de câblage et les instructions. Tout le câblage électrique et l’entretien doivent être effectués par un électricien dûment agréé. IMPORTANT NOTES: • For product mounting, installation, safety instructions, technical specifications, and more, refer to the product Quick Reference Guide, available via the link or QR code noted above. • For regulatory and compliance information, see reverse of this sheet and/or product packaging. Savant Product Regulatory Statement | 009-1950-03 250424 | © 2025 Savant Systems, Inc. 45 Perseverance Way, Hyannis, MA 02601 Savant.com | 508.683.2500 2 of 2 FCC Regulations This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for CLASS B digital devices, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. If this equipment does cause harmful interference to radio or television reception, …

Text truncated - open the document above for the full version.

5945 Cabot Parkway Suite 100 Alpharetta, GA 30005 USA Certification Exhibit FCC ID: ASU-B3X2L9TQ7WA FCC Rule Part: 47 CFR Part 2.1091 Project Number: 721004402 Manufacturer: Savant Systems Inc Model Name / Number: HST-DIRECTORC-01 Variant Model Name / Number: HST-DIRECTOR-01 RF Exposure Model Name / Number: HST-DIRECTORC-01 Variant Model Name / number” HST-DIRECTOR-01 FCC ID: ASU-B3X2L9TQ7WA Report: AT721004402.2C0 Page 2 General Information: Applicant: Savant Systems Inc Device Category: Mobile Environment: General Population/Uncontrolled Exposure Purpose: The purpose of this document is the RF exposure evaluation of the HST-DIRECTORC-01 model in accordance with FCC 47 CFR Part 2.1091. Description: The Savant HST-DIRECTORC-01 Power Director is a central energy management controller designed for integration within Savant smart home systems. It facilitates real-time monitoring and control of connected power modules, supporting up to 20 modules via Bluetooth Low Energy (BLE) communication in addition to external cellular communications. HST-DIRECTORC-01 model contains Nordic BLE radio co-located with pre-approved Murata BLE/BT Classic/2.4 &5 GHz Wi-Fi radio module (FCC ID: VPYLB1ZM /IC ID: 772C-LB1ZM) and pre-approved Cellular radio module (FCC ID: 2AJYU-8PYA007 / IC ID: 23761-8PYA008). HST-DIRECTOR-01 variant model is depopulated version of the HST-DIRECTORC-01 which contains Nordic BLE radio co-located with pre-approved Murata BLE/BT Classic/2.4 &5 GHz Wi-Fi radio module (FCC ID: VPYLB1ZM /IC ID: 772C-LB1ZM). The simultaneous transmission evaluation is documented in a separate document. Technical Information (BLE) – “Radio 1”: Frequency Range (MHz): 2402 - 2480 Antenna Type: Flexible Printed Circuit (FPC) Antenna Gains: 2 dBi Maximum Transmitter Conducted Power: 2.8dBm, 1.91mW Maximum System EIRP: 4.8dBm, 3.02mW Exposure Conditions: 20 centimeters Model Name / Number: HST-DIRECTORC-01 Variant Model Name / number: HST-DIRECTOR-01 FCC ID: ASU-B3X2L9TQ7WA Report: AT721004402.2C0 Page 3 RF Exposure Calculation Table 1: Device Characteristics (BLE) Table 2: 47 CFR 1.1307(b)(3)(i)(c) MPE-Based Exemption ERP (W) – (BLE) Technical Parameters Radio 1 λ / 2π (m) 0.020 R≥ λ / 2π YES Maximum (Source-Based) Time-Averaged ERP (W) 0.0018 ERP Threshold (W) 0.7680 Exemption YES Contribution Ratio (ERP / ERP th ) 0.002 Conclusion Exemption from Routine Environmental Evaluation applies. Technical Parameters Radio 1 Frequency (GHz) 2.402 Frequency (MHz) 2402 Separation Distance (cm) 20.00 Separation Distance (m) 0.2000 Antenna Gain (dBi) 2.00 ERP Easily Determined YES 1-g body or 10-g extremity Body Conducted Power (dBm) 2.80 Conducted Power (mW) 1.91 Duty Factor (Source-Based) % 100.0 Maximum (Source-Based) Time-Averaged Conducted Power (mW) 1.91 Maximum (Source-Based) Time-Averaged ERP (mW) 1.84 Maximum (Source-Based) Time-Averaged EIRP (mW) 3.02 Maximum Output (mW) 1.91

5945 Cabot Parkway Suite 100 Alpharetta, GA 30005 USA Certification Exhibit FCC ID: ASU- B3X2L9TQ7WA IC: 10052A- B3X2L9TQ7WA FCC Rule Part: 15.247 ISED Canada Radio Standards Specification: RSS-247 Project Number: 721004402 Manufacturer: SAVANT Systems, Inc. Model Name / Number: HST-DIRECTORC-01 Variant Model Name / Number: HST-DIRECTOR-01 Test Setup Photos 5945 Cabot Parkway Suite 100 Alpharetta, GA 30005 USA Figure:1 – Test Set up – Front View of the EUT - Radiated Emissions <30 MHz Figure:2 – Test Set up – Rear View of the EUT- Radiated Emissions <30 MHz 5945 Cabot Parkway Suite 100 Alpharetta, GA 30005 USA Figure:3 – Test Set up – Front View of the EUT- Radiated Emissions <1 GHz Figure:4 – Test Set up – Rear View of the EUT - Radiated Emissions <1 GHz 5945 Cabot Parkway Suite 100 Alpharetta, GA 30005 USA Figure:5– Test Set up – Front View of the EUT - Radiated Emissions <10 GHz Figure:6– Test Set up – Rear View of the EUT - Radiated Emissions <10 GHz 5945 Cabot Parkway Suite 100 Alpharetta, GA 30005 USA Figure:7– Test Set up – Front View of the EUT - Radiated Emissions <18 GHz Figure:8– Test Set up – Front View of the EUT - Radiated Emissions <18 GHz 5945 Cabot Parkway Suite 100 Alpharetta, GA 30005 USA Figure:9– Test Set up – Front View of the EUT - Radiated Emissions <26.5 GHz Figure:10– Test Set up – Front View of the EUT - Radiated Emissions <26.5 GHz 5945 Cabot Parkway Suite 100 Alpharetta, GA 30005 USA Figure:11 – Test Set up – Antenna Port measurements Figure:12 – Test Set up – AC Power Line Conducted Emissions 5945 Cabot Parkway Suite 100 Alpharetta, GA 30005 USA Figure:13 – Test Set up – AC Power Line Conducted Emissions

TÜV SÜD America 5945 Cabot Parkway, Suite 100 Alpharetta, GA 30005 Phone: 678-341-5900 www.tuv-sud-america.com TÜV SÜD SIGNATURE NAME JOB TITLE RESPONSIBLE FOR ISSUE DATE Thierry Jean-Charles Senior Engineer TUV SUD America Inc. Authorized Signatory 4/22/2026 Signatures in this approval box have checked this document in line with the requirements of TÜV SÜD America, Inc. document control rules. FCC Accreditation Designation Number US1233 FCC Test Site Registration Number 967699 Innovation, Science, and Economic Development Canada Lab Code 23932 EXECUTIVE SUMMARY A sample of this product was tested and found to be compliant with the standards listed above. A2LA Cert. No. 2955.09 DISCLAIMER AND COPYRIGHT This non-binding report has been prepared by TÜV SÜD America with all reasonable skill and care. The document is confidential to the potential Client and TÜV SÜD America. No part of this document may be reproduced without the prior written approval of TÜV SÜD America. © TÜV SÜD. ACCREDITATION Our A2LA Accreditation does not cover opinions and interpretations and any expressed are outside the scope of our A2LA Accreditation. Report on the Testing of the Savant Systems Inc Model Name / Number: HST-DIRECTORC-01 Variant Model Name / Number: HST-DIRECTOR-01 In accordance with: FCC 47 CFR part 15.247 ISED RSS-247 Issue 4, July 2025 Prepared for: Savant Systems, Inc 45 Perseverance Way Hyannis, MA 02601-1812 COMMERCIAL-IN-CONFIDENCE Document Number: AT721004402.1C0 Document Number: AT721007920.1C0 COMMERCIAL-IN-CONFIDENCE Page 2 of 54 Contents Report Summary .........................................................................................................................3 Report Modification Record ...........................................................................................................3 Introduction ....................................................................................................................................3 Brief Summary of Results .............................................................................................................5 Product Information .......................................................................................................................6 Deviations from the Standard ........................................................................................................9 EUT Modification Record ..............................................................................................................9 Test Location .............................................................................................................................. 10 Test Details ............................................................................................................................... 11 Antenna Requirement ................................................................................................................ 11 Power Line Conducted Emissions ............................................................................................. 12 Fundamental Emission Output Power ........................................................................................ 15 6dB / 99% Bandwidth ................................................................................................................. 20 Maximum Power Spectral Density in the Fundamental Emission ............................................. 28 Band-Edge Compliance of RF Conducted Emissions ............................................................... 33 RF Conducted Spurious Emissions ........................................................................................... 36 Radiated Spurious Emissions into Restricted Frequency Bands ............................................... 39 Test Equipment Used ................................................................................................................. 50 Diagram of Test Set-ups .......................................................................................................... 51 Accreditation, Disclaimers and Copyright............................................................................. 54 Document Number: AT721007920.1C0 COMMERCIAL-IN-CONFIDENCE Page 3 of 54 Report Summary Report Modification Record Alterations and additions to this report will be issued to the holders of each copy in the form of a complete document. Table 1.1-1 – Modification Record Issue Description of Change Date of Issue 0 First Issue 4/22/2026 Introduction The purpose of this report is to demonstrate compliance with Part 15 Subpart C of the FCC’s Code of Federal Regulations Section 15.247 and Innovation Science and Economic Development Canada’s Radio Standards Specification RSS-247 for the tests documented herein. Applicant Lori Pass Manufacturer Savant Systems Inc Applicant’s Email Address [email protected] Model Name Savant Cellular Power Director Model Number HST-DIRECTORC-01 Variant Model Name Savant Power Director Variant Model Number HST-DIRECTOR-01 Serial Number NA FCC ID ASU-B3X2L9TQ7WA ISED Certification Number 10052A-B3X2L9TQ7WA Hardware Version(s) 068-0967-20 Software Version(s) N/A Number of Samples Tested 1 Test Specification/Issue/Date US Code of Federal Regulation (CFR): Title 47, Part 15, Subpart C: Radio Frequency Devices, Intentional Radiators, 2026 ISED Canada Radio Standards Specification: RSS-247 – Digital Transmission Systems (DTSs), Frequency Hopping Systems (FHSs) and License-Exempt Local Area Network (LE-LAN) Devices, Issue 4, July 2025. Order Number 721004402 Date of Receipt of EUT 2/27/2025 Start of Test 2/27/2025 Document Number: AT721007920.1C0 COMMERCIAL-IN-CONFIDENCE Page 4 of 54 Finish of Test 3/27/2025 Related Document(s) ANSI C63.10-2020: American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Device. FCC OET KDB 558074 D01 15.247 Meas Guidance v05r02: Guidance for Compliance Measurements on Digital Transmission System…

Text truncated - open the document above for the full version.

Rev: 2.0 December 4, 2018 Page | 1 WPANT10118 Dual-band Wi-Fi MIMO Antenna WPANT10118-S1A 125 mm long, 1.13 mm micro co-ax cable with IPX MHF connector Note: Different cable and connector style requests can be accommodated. Application Flexible plug and play antenna for wireless devices operating at 2.4 GHz and 5 GHz Wi-Fi / WLAN frequencies. This antenna works very well on any non-metallic surface. We can assist your engineers to optimize mounting positions for these antennas in your specific application and can further assist to troubleshoot system integration issues such as TRP/TIS and FCC requirements. We specialize in developing customized Antenna solutions. Please contact [email protected] with your specific application requirements. Electrical Properties Operating Frequency 2.4 – 2.5 GHz 4.9 – 5.9 GHz Approximate Antenna Impedance [] 50Ω 50Ω VSWR (Typical)* < 2:1 < 2:1 Peak Gain [dBi] (Typical)* 1-2 dBi 2-3 dBi Efficiency [%] (Typical)* 70 % 70 % Polarization Linear Linear Pattern Omni-directional Omni-directional *Note: These performance metrics will vary depending on the position of the antenna within a given wireless device, and the antenna integration optimization. Mechanical / Environmental Properties Antenna Dimensions 3.228’’ x 0.638’’ x 0.041’’ (82mm x 16.5mm x 1.05mm) Antenna Color Black Operating / Storage Temperature -40 o C to +90 o C Environmental Meets standards for UL 94V-0 Hazardou…

Text truncated - open the document above for the full version.
