ASU-SHC2000Smart Host Controller

Box Contents (1) Savant® Smart Host with Control (SHC-2000-00) (1) 5V DC 3A Power Supply with 4 Quick Change AC Adapters (025-XXXX-xx) (2) M3x6 mm Flathead Philips Screw Black (039-00101-xx) (1) Wall Mount Bracket (074-0585-xx) (1) Host Mount Bracket (074-0584-xx) (2) 6-pin Screw Down Plug-in Connector Black (028-0664-xx) (2) 3-pin Screw Down Plug-in Connector Black (028-0665-xx) (1) Quick Reference Guide (this document) Specifications EnvironmentalEnvironmental Temperature32° to 104° F (0° to 40° C) Humidity 10% to 90% Relative Humidity (non- condensing) Cooling10 CFM Maximum BTU51.15 BTU/hr Dimensions and WeightDimensions and Weight Height1.58 in (4 cm) Width7.86 in (19.9 cm) Depth7.65 in (19.4 cm) Weight Net: 1.3 lb (0.58 kg) Shipping: 2.1 lb (0.95 kg) Rack Space1U PowerPower Input Power 5V DC 3A Maximum Power15 watts StandardsStandards Wireless Wi-Fi® (802.11 b/g/n dual band 2.4 GHz and 5.0 GHz) ComplianceCompliance Safety and Emissions FCC Part 15 | CE Mark | C-Tick | UL | ICES-003 | Wi-Fi Alliance RoHSCompliant Minimum Supported ReleaseMinimum Supported Release Savant OSda Vinci 7.2 Chassis Installation The Smart Host can be installed on a solid, flat, level surface such as a table, cabinet or shelf, or wall mounted using the included bracket. The location should be dry, well ventilated, and out of direct sunlight. Rack Installation The optional RCK-3000-xx provides a ventilated shelf for mounting up to 2 Smart Hosts. Wall Bracket Installation A wall bracket is included that can be used to mount the Smart Host to a wall or back of a cabinet. This bracket consists of two pieces, one for the host and one for the wall. 1.Attach the host bracket to the rear of the host using the included M3x6 mm Flathead Philips Screws. 2.Attach the wall bracket to the wall. Screws to attach are not included. 3.Position the host over the wall bracket and gently slide into place. See Wall Bracket Diagram on pg 2. Rear Panel Reset (hole) Press and hold for 5 seconds while powered On to clear Wi-Fi or wired Ethernet settings. Status LED will blink rapidly when reset is complete. Note: This will reset the network settings back to factory defaults. Any static IP Addresses or Wi-Fi settings will be lost. Power Input 5V DC 3A - Connect to included power supply. Status LED Off: Disconnected from power supply. Amber: Controller is booting/rebooting and is disconnected from the network. Amber Blinking: Smart Host is not connected to a wired Ethernet network and has not joined a Wi-Fi network. Green: Connected to wired Ethernet or Wi-Fi Network. Digital Audio Output TOSLink (Optical) digital audio output. Connect to digital optical audio input on switcher for using the Audio Interrupt Service (AIS). Ethernet 8-pin RJ-45 female. 10/100/1000 Base-T auto-negotiating port. Connection to this port will disable Wi-Fi settings. RS-232 8-pin RJ-45 female. Used to transmit and receive serial binary data to and from serial controllable devices. Ports 1-2 RS-232 - CTS/RTS handshaking. CTS/RTS Handshaking availability based on component profile. See RS-232 Wiring for pinouts. IR 6-pin Screw Down Plug-in Connector. Used to send IR signals to control devices with an IR input or IR receiver via an IR flasher (5V tolerant only). See IR Wiring for important precautions regarding IR functionality before making any connections. Relay 3-pin Screw Down Plug-in Connector. See Relay Wiring for pinouts. Normally Open (NO) Normally Closed (NC) to control devices requiring basic on/off operation. DC Voltage Max: 30V DC 1A. GPIO 3-pin Screw Down Plug-in Connector. See GPIO Wiring for pinouts. GPIO Input: When configured as an input, the processor will look for a low (<0.8V DC) or a high (>2.4V DC ) state. Minimum 0V DC / Maximum 12V DC GPIO Output: When configured as an output, the port provides a binary output of 0-12V DC 150mA max. SHC-2000-00 | 009-1326-00 | 150327SHC-2000-00 | 009-1326-00 | 15032745 Perseverance Way, Hyannis, MA 02601 Copyright © 2015 Savant Systems, LLC1of2savant.com | 508.683.2500 Savant® Smart Host with Control Quick Reference Guide For Product Info Wall Bracket Diagram Wiring and Connections RS-232 Wiring Note: CTS/RTS handshaking is supported for flow control based on the profile used in the configuration. RJ-45 to DB9 Adapters Refer to the RS-232 Conversion to DB9 and RS-422/485 Pinout Application Note located on the Savant Community for more information on RJ-45 to DB9 adapters offered by Savant. Note: The SHC-2000 does not support RS-422/485. IR Wiring IR connections are made using 6-pin Screw Down Plug-in Connectors supplied with the Smart Host. The wire slips into the hole and locks with a screw located at the top of the connector. Note: While not shown in the diagram above, IR connections 4 to 6 follow the same wiring as 1 to 3. Note: While not shown in the diagram above, IR connections 4 to 6 follow the same wiring as 1 to 3. IMPORTANT! IR Wiring Precautions • Ensure that all IR emitters are within 15 feet (4.6 meters) from the controllers location. • Use of 3rd party flashing IR emitters with Talk Back is not recommended. These types of emitters can draw voltage away from the IR signal that can degrade IR performance. GPIO Wiring General Purpose Input/Outputs (GPIO) are binary I/O ports used on Savant controllers to trigger an action within the system. Events can control a device, such as turning on an amplifier (output) or detecting a state change for a device (input) to perform a workflow. Pin 2 is used for input or output depending on configuration. GPIO Pull Down Resistor (PD) Usage GPIO pins are configured as inputs and are pulled high to 12V while the host is booting up. To make the GPIO signal low during a host reboot and/or a power cycle, attach the GPIO 1 pin to the PD pin. The PD pin is a 1K ohm pull down resistor (to signal ground) which keeps the GPIO output below 0.8V during processor boot times. Relay Wiring Relay ports are used when a device is controlled via a normally open (NO) or normally…

Text truncated - open the document above for the full version.

Savant Systems LLC 75 Perseverance Way Hyannis Massachusetts 02635 United States Date: April 22, 2015 Declaration We, Savant Systems LLC, declare that the device, FCC ID: ASU-SHC2000, Model Name: SHC-2000, does not support any non-US channels in all the operational mode(s). All non-US frequencies, US 2.4G channel 12-13 and Country code selection are disabled through proprietary software and are not user changeable. Should you have any question or comment regarding this matter, please do not hesitate to contact me. Sincerely yours,

Savant Systems LLC 75 Perseverance Way Hyannis Massachusetts 02635 United States Date: April 22, 2015 Federal Communications Commission 7435 Oakland Mills Road - Gate A Columbia, Maryland 21046 SUBJECT: FCC Application for FCC ID: ASU-SHC2000 To Whom It May Concern, We, Savant Systems LLC, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite filing. Sincerely yours,

Savant Systems LLC 75 Perseverance Way Hyannis Massachusetts 02635 United States Date: April 22, 2015 Declaration To whom it may concern, SHC-2000 is a WLAN/Bluetooth combination antenna with FCC ID: ASU-SHC2000. This WLAN/Bluetooth co-existence mechanism is to ensure that the WLAN and Bluetooth transmitters would not simultaneously operate. Therefore, WLAN and Bluetooth antenna in FCC ID: ASU-SHC2000 should not be considered to be able to transmit simultaneously. Though the users can use WLAN and Bluetooth simultaneously, but the real situation is that WLAN and Bluetooth are used by time sharing and no overlap transmission. Should you have any question, please have my best attention. Sincerely yours,

Savant Systems LLC 75 Perseverance Way Hyannis Massachusetts 02635 United States Date: April 22, 2015 Federal Communications Commission 7435 Oakland Mills Road - Gate A Columbia, Maryland 21046 Subject: Request for Confidentiality FCC ID: ASU-SHC2000 T o Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission’s rules (47CFR§§0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely.
Schematic Diagram
Block Diagram
Parts List
Operational Description Software Operational Description Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’ s policy, in order to comply with the marketing regulations in 47 CFT §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days after the Grant Date of Equipment Authorizations.  External Photos  Internal Photos  Test Setup Photos  Users Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards,

Report No.: 150318C29 1 of 9 CONSTRUCTION PHOTOS OF EUT Report No.: 150318C29 2 of 9 Report No.: 150318C29 3 of 9 Report No.: 150318C29 4 of 9

Background: Pantone PMSBlack 1 Printing color of system label All Content Legend : Pantone PMS 877C 2 TEXT FONT - GOTHAM BOOK 3 Quanta Inc. Kuei Shan,Taiwan. Author: Tiger Liu REV.DATE Scale: 1:1 File / Project Name: H6A / Smart Host Despription H6A - System Regulatory Label 2015.04.07. X07-00 RoHS Compliant S/N: XXXXXXXXXXXX M/N: SHC-2000 Designed by Savant, USA Assembled in China INDOOR USE ONLY FCC ID: ASU-SHC2000 IC : 10052A-SHC2000 INPUT 5V 3A Z1328 UID:XXXXXXXXXXXXXXXX Barcode Tag (48 x 3mm) 1 2 31.26mm 87.26mm Barcode Tag (48mm x 3mm, white background with black text) Note: Stick barcode tag above the system label.

Report No.: 150318C29 5 of 9 Report No.: 150318C29 6 of 9 Report No.: 150318C29 7 of 9 Report No.: 150318C29 8 of 9 Report No.: 150318C29 9 of 9

FCC MPE Evaluation Report Report Format Version 5.0.0 Page No. : 1 of 7 Report No. : SA150318C29 Issued Date : Apr. 15, 2015 FCC MPE Evaluation Report Report No. : SA150318C29 Applicant : Savant Systems LLC Address : 75 Perseverance Way Hyannis, MA 02635 USA Product : Smart Host Controller FCC ID : ASU-SHC2000 Brand : Savant Model No. : SHC-2000 Standards : FCC Part 2 (Section 2.1091) KDB 447498 D01 Sample Received Date : Mar. 18, 2015 Date of Evaluation : Apr. 10, 2015 CERTIFICATION: The above equipment have been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch – Lin Kou Laboratories, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s SAR characteristics under the conditions specified in this report. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. Prepared By : Gina Liu / Specialist Approved By : Gordon Lin / Assistant Manager This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. FCC MPE Evaluation Report Report Format Version 5.0.0 Page No. : 2 of 7 Report No. : SA150318C29 Issued Date : Apr. 15, 2015 Table of Contents Release Control Record ............................................................................................................................................................... 3 1. Description of Equipment Under Test ................................................................................................................................. 4 2. MPE (Maximum Permissible Exposure) Assessment ......................................................................................................... 5 2.1 Introduction .................................................................................................................................................................. 5 2.2 RF Radiation Exposure Limits ...................................................................................................................................... 5 2.3 MPE Assessment Method ............................................................................................................................................ 6 2.4 MPE Calculation for Standalone Operations ................................................................................................................ 6 3. Information on the Testing Laboratories ............................................................................................................................. 7 FCC MPE Evaluation Report Report Format Version 5.0.0 Page No. : 3 of 7 Report No. : SA150318C29 Issued Date : Apr. 15, 2015 Release Control Record Report No. Reason for Change Date Issued SA150318C29 Initial release Apr. 15, 2015 FCC MPE Evaluation Report Report Format Version 5.0.0 Page No. : 4 of 7 Report No. : SA150318C29 Issued Date : Apr. 15, 2015 1.Description of Equipment Under Test EUT Type Smart Host Controller FCC ID ASU-SHC2000 Brand Name Savant Model Name SHC-2000 Tx Frequency Bands (Unit: MHz) WLAN : 2412 ~ 2462, 5180 ~ 5240, 5745 ~ 5825 Bluetooth : 2402 ~ 2480 Uplink Modulations 802.11b : DSSS 802.11a/g/n : OFDM Bluetooth : GFSK Antenna Type PIFA Antenna EUT Stage Production Unit Note: 1.The above EUT information is declared by manufacturer and for more detailed features description please refers to the manufacturer's specifications or User's Manual. List of Accessory: AC Adapter 1 Brand Name ASIAN POWER DEVICES INC. Model Name WA-15I05RUGKN-AAAA Power Rating I/P:100-240Vac, 50-60Hz, 0.5A; O/P: 5Vdc, 3A AC Adapter 2 Brand Name ASIAN POWER DEVICES INC. Model Name WA-15I05RUKGN-HAAA Power Rating I/P:100-240Vac, 50-60Hz, 0.5A; O/P: 5Vdc, 3A WLAN Chip Brand Name Qualcomm Atheros Model Name QCA6234X FCC MPE Evaluation Report Report Format Version 5.0.0 Page No. : 5 of 7 Report No. : SA150318C29 Issued Date : Apr. 15, 2015 2. MPE (Maximum Permissible Exposure) Assessment 2.1 Introduction According to 47 CFR §2.1091, a mobile device is defined as a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 cm is normally maintained between the transmitting antenna and the body of the user or nearby persons. In this context, the term “fixed location” means that the device is physically secured at one location and is not able to be easily moved to another location. Transmitting devices designed to be used by consumers or workers that can be easily re-located, such as wireless dev…
